Overview of Dell CGT2C Host Bus Adapter
- Brand: Dell
- Part Number: CGT2C
- Product Category: Host Bus Adapter
Technical Specifications
Physical Dimensions
- Compact design with a low-profile PCIe card form factor.
- Dimensions: 167.64mm x 68.91mm (6.60" x 2.71").
Performance and Compatibility
- Generation: Gen 7 technology supporting 64GFC and 32GFC speeds.
- Data Transfer Rates:
- 28.05 Gb/s (3200 MB/s).
- 14.025 Gb/s (1600 MB/s).
- 8.5 Gb/s (800 MB/s).
- Auto-detection ensures optimal performance across supported rates.
Cable and Optical Specifications
- Cable Length Support:
- Up to 100m on OM4 and OM5 multimode fiber at 64GFC/32GFC.
- Up to 70m on OM3 multimode fiber at 64GFC/32GFC.
- 10 km on single-mode fiber at 32GFC/16GFC (requires Emulex-approved longwave transceivers).
- Optics: Short wave lasers with LC-type connectors for reliable connections.
Environmental and Operating Conditions
- Operating Humidity: 5% to 95% non-condensing.
- Operating Temperature: 0°C to 55°C.
- Storage Temperature: -20°C to 85°C (-4°F to 185°F).
Hardware and System Support
- Compatible with Intel x64, Intel x86, and PowerPC architectures.
- Host Bus Type: PCIe Gen4 x8.
- I/O Controller: XE601 for seamless data handling.
Supported Operating Systems
- Microsoft Windows.
- Oracle Linux (including Unbreakable Enterprise Kernel).
- Oracle Solaris.
- Red Hat Enterprise Linux.
- SUSE Linux Enterprise Server.
- VMware vSphere.
- Additional support available via OEMs and partners.
Dell CGT2C 2-Port Host Bus Adapter Overview
The Dell CGT2C 2-Port Host Bus Adapter LPE35002-M2 is a high-performance Emulex 32GB Fibre Channel (FC) PCI-Express Gen4 x8 Full Height (FH) card. This adapter is designed to deliver exceptional throughput, low latency, and robust reliability, making it an essential component for data-intensive environments, enterprise storage solutions, and high-speed data transfer requirements. Its compatibility with the latest PCIe Gen4 interface ensures maximum bandwidth and efficiency.
Key Features
- High-Speed Connectivity: Supports 32GB Fibre Channel for ultra-fast data transfer rates, ideal for storage area networks (SANs).
- Dual Port Design: The two-port configuration enhances fault tolerance and enables load balancing for critical applications.
- PCIe Gen4 Interface: Ensures high bandwidth and future-ready compatibility with cutting-edge server platforms.
- Advanced Emulex Technology: Delivers low latency, high IOPS, and superior reliability for enterprise environments.
- Full-Height Form Factor: Compatible with full-height PCIe slots, offering flexibility in deployment across various server configurations.
Use Cases
This host bus adapter is an optimal choice for enterprises managing extensive databases, virtualization platforms, and high-transaction workloads. Key applications include:
- Data Centers: Enhances storage performance and ensures seamless scalability for large-scale data operations.
- Virtualized Environments: Supports robust connectivity for virtual machines, ensuring low-latency and high-availability solutions.
- Mission-Critical Workloads: Designed for applications demanding uninterrupted access and high-speed data transfers.
Benefits of Using the Dell CGT2C Host Bus Adapter
Enhanced Storage Performance
The Dell CGT2C adapter significantly enhances storage area network (SAN) performance, ensuring faster data access and seamless scalability. This makes it an excellent solution for organizations relying on high-throughput storage systems.
Future-Proof Connectivity
With PCIe Gen4 compatibility, this host bus adapter is designed to meet future performance demands, making it a long-term investment for enterprise IT infrastructure.
Improved Reliability and Availability
Dual ports allow for load balancing and failover capabilities, ensuring uninterrupted connectivity even in the event of a single port failure. Advanced Emulex technology ensures dependable performance under demanding workloads.
Deployment Scenarios
Enterprise-Level SANs
This adapter is ideal for building or upgrading enterprise-level storage area networks, offering high-speed connectivity and efficient data management capabilities.
High-Performance Computing (HPC)
The Dell CGT2C excels in HPC environments, where data-intensive computations demand robust and reliable storage interfaces.
Virtualization and Cloud Applications
Its low-latency and high-bandwidth characteristics make it a perfect fit for virtualization and cloud computing environments, ensuring optimal resource utilization and performance.
Compatibility with Dell Servers
Supported Dell Models
This host bus adapter is compatible with a range of Dell PowerEdge servers, ensuring seamless integration and optimal performance. Commonly supported models include:
- Dell PowerEdge R750
- Dell PowerEdge R650
- Dell PowerEdge R550
Driver Support and Updates
Dell provides comprehensive driver support and regular updates to ensure compatibility with the latest operating systems and applications.
