540-BDHI Dell Emulex LPe31000-M6-D 16GB Fibre Channel HBA

Details of Dell 540-BDHI 16GB Single Port HBA

The Dell 540-BDHI Emulex LPe31000-M6-D 16Gb Fibre Channel HBA is a high-performance host bus adapter engineered for enterprise-grade storage networking. With PCI Express 3.0 support and advanced Fibre Channel protocols, this adapter ensures reliable throughput, scalability, and efficiency for modern data centers, virtualization, and cloud infrastructures.

Main Information

• Brand: Dell
• Part Number: 540-BDHI
• Device Type: Network Adapter / Host Bus Adapter

Technical Specifications

• Form Factor: Plug-in Card
• Interface (Bus): PCI Express 3.0 x8
• PCI Specification Revision: PCIe 3.0

Port Configuration

• Ports: Single-port (1 x 16Gb Fibre Channel)
• Cabling Type: Fibre Optic
• Connectivity Technology: Wired
• Data Transfer Rate: 14.025Gbps

Supported Protocols

• 16Gb Fibre Channel

Fibre Channel Standards

• FC-DA, FC-FS, FC-GS-2, FC-GS-3, FC-GS-4
• FC-MI, FC-PH-2, FC-PH-3, FC-PI, FC-Tape
• FCP-2, FCP-3, FCP-4
• FC-PI-2, FC-PI-3, FC-PI-4, FC-PI-5, FC-PI-6
• FC-GS-5, FC-GS-6, FC-FS-3
• FC-HBA, FC-LS-2, FC-DA-2
• SSC-2, SSC-4
• SBC-2, SBC-3
• SPC-3, SPC-4

Advanced Features

• Forward Error Correction (FEC)
• Optimized for Fibre Channel storage networking
• Reliable throughput for enterprise workloads

Compliance Standards

• CSA
• UL
• FCC
• RoHS
• TUV Bauart
• BSMI Class A
• ICES Class A
• VCCI Class A
• MSIP Class A
• China RoHS
• RCM

Operating System Compatibility

• SUSE Linux Enterprise Server
• Microsoft Windows
• Red Hat Enterprise Linux

Environmental Parameters

• Minimum Operating Temperature: 0 °C
• Maximum Operating Temperature: 55 °C
• Humidity Range Operating: 5% - 95% (non-condensing)

Compatibility

Tower Servers

• PowerEdge T630
• PowerEdge T640

Rack Servers

• PowerEdge R440
• PowerEdge R530
• PowerEdge R540
• PowerEdge R630
• PowerEdge R640
• PowerEdge R730 / R730xd
• PowerEdge R740 / R740xd
• PowerEdge R830
• PowerEdge R930
• PowerEdge R940
