57-1000485-01 Brocade 32Gbps SFP+ Transceiver Module

Product Overview: Brocade 57-1000485-01 32Gbps Transceiver

The Brocade 57-1000485-01 is a high-performance Fibre Channel transceiver designed for modern storage networking environments requiring ultra-fast and reliable data transmission. Built to support next-generation SAN (Storage Area Network) infrastructures, this optical module delivers enhanced speed, stability, and efficiency for enterprise-level connectivity.

Engineered as a compact SFP+ optical transceiver module, it ensures seamless integration into compatible Brocade networking equipment while providing scalable bandwidth for demanding data center applications.

Manufacturer & Product Identification

• Manufacturer: Brocade
• Part Number: 57-1000485-01
• Device Category: Fibre Channel Transceiver Module

Product Classification

• Optical networking transceiver
• Enterprise SAN connectivity component
• High-speed fiber communication module

Technical Specification

Data Rate Support

• Auto-sensing 8Gbps Fibre Channel
• Supports 16Gbps Fibre Channel networks
• Advanced compatibility with 32Gbps high-speed SAN systems

Form Factor Design

• SFP+ (Small Form-Factor Pluggable Plus)
• Also referenced in SFP28-compatible environments
• Hot-swappable design for easy installation and maintenance

Operating Wavelength

• 850 nm optimized laser transmission
• Designed for multi-mode optical fiber communication

Fiber Compatibility

• Multi-mode Fiber (MMF) support
• Optimized for OM3, OM4, and OM5 fiber cabling

Connector Type

• Duplex LC optical interface
• Secure and low-loss fiber connection
• Industry-standard compatibility for SAN deployments

Transmission Distance

• Up to 100 meters on OM4 fiber
• Extended reach on OM5 optimized cabling
• Ideal for short-range data center interconnects

Key Features of Brocade 57-1000485-01 Transceiver

High-Speed Data Transmission

• Supports ultra-fast 32Gbps Fibre Channel performance
• Backward compatible with 16Gbps and 8Gbps systems

Enterprise-Grade Reliability

• Stable optical performance for mission-critical workloads
• Designed for continuous 24/7 operation in data centers

Energy-Efficient Operation

• Low power consumption for reduced operational costs
• Optimized thermal performance for dense environments

Easy Deployment

• Plug-and-play installation
• Hot-swappable module for minimal downtime

Compatibility and Use Cases

Supported Network Environments

• Storage Area Networks (SAN)
• Enterprise data centers
• Cloud infrastructure networking
• High-performance computing clusters

Device Compatibility

• Brocade Fibre Channel switches
• Compatible SAN switching platforms
• Enterprise-grade fiber networking equipment

Applications and Industry Usage

Where It Is Commonly Used

• Large-scale enterprise storage systems
• Virtualized server environments
• Data replication and backup systems
• High-speed database access infrastructure

Performance-Critical Environments

• Financial data processing systems
• Cloud computing centers
• Telecommunication backbone networks

Advantages of Using This Fibre Channel Transceiver

Operational Benefits

• Improved network throughput and reduced latency
• Enhanced scalability for expanding data centers
• Stable and interference-free optical communication

Cost and Efficiency Benefits

• Reduced maintenance requirements
• Long operational lifecycle
• Optimized infrastructure investment

Advantages of Brocade 57-1000485-01

• Trusted enterprise networking brand
• Proven compatibility with Fibre Channel ecosystems
• High-speed optical performance with dependable stability

Key Highlights

• 32Gbps maximum Fibre Channel speed support
• 850nm multi-mode optical transmission
• Duplex LC connector interface
• Up to 100m transmission distance over OM4 fiber

Brocade 57-1000485-01 32Gbps Fibre Channel Transceiver

High-Speed Optical Connectivity in Modern Storage Area Networks

The Brocade 57-1000485-01 32Gbps Fibre Channel Single-Mode Fiber SFP+ Transceiver Module is designed to support next-generation storage area network (SAN) infrastructures where high throughput, low latency, and long-distance optical communication are essential. As enterprise data continues to grow exponentially, the need for efficient and scalable interconnect solutions becomes critical. This 32Gbps Fibre Channel SFP+ module plays a central role in enabling seamless communication between storage arrays, switches, directors, and servers in enterprise-class data centers.

Built to support 32G Fibre Channel protocols, this transceiver ensures backward compatibility with 16G and 8G Fibre Channel systems while delivering enhanced performance for modern workloads. It leverages single-mode fiber (SMF) technology to achieve extended transmission distances, making it suitable for campus-level and metropolitan-scale data center deployments. The Brocade 57-1000485-01 is widely used in mission-critical environments where reliability, performance consistency, and optical precision are essential.

Role in Enterprise Storage Networking Environments

In enterprise SAN environments, the Brocade 57-1000485-01 32Gbps Fibre Channel SFP+ transceiver module serves as a fundamental building block for high-performance storage connectivity. It enables servers to communicate with storage arrays through high-speed optical links that minimize latency and maximize bandwidth efficiency. The use of single-mode fiber ensures that signals remain stable across long distances without significant degradation, which is crucial for distributed data centers and disaster recovery sites.

The module is optimized for environments that require predictable performance under heavy I/O workloads, including virtualization platforms, database clusters, cloud infrastructure, and large-scale enterprise applications. Its ability to maintain signal integrity across long fiber runs makes it an ideal choice for organizations that prioritize scalability and operational continuity.

Technical Architecture and Engineering Design

Advanced Optical Engineering for High-Speed Data Transmission

The Brocade 57-1000485-01 SFP+ transceiver is engineered with precision optical components designed to handle 32Gbps Fibre Channel data rates. The module integrates a highly efficient laser transmitter operating at a wavelength optimized for single-mode fiber transmission, typically around the 1310nm range. This allows for long-distance connectivity while maintaining low bit error rates and strong signal integrity.

The receiver component of the module utilizes a high-sensitivity photodiode system capable of detecting weak optical signals over extended distances. This is essential in ensuring that data transmitted across kilometers of fiber arrives intact and ready for processing by storage networking equipment. The balance between transmitter power and receiver sensitivity is carefully calibrated to meet strict Fibre Channel standards.

Transmitter Subsystem Design

The transmitter within the Brocade 57-1000485-01 module is built around a laser diode that is optimized for high-speed modulation. It converts electrical signals into optical pulses with extremely low jitter, ensuring that data integrity is preserved at 32Gbps line rates. The laser driver circuitry is designed to maintain stable output power even under varying temperature conditions, which is essential in dense data center environments where thermal fluctuations are common.

Receiver Subsystem Performance

The receiver side of the transceiver is equally important in ensuring reliable communication. It includes a photodetector that converts incoming light signals into electrical signals, followed by amplification and signal conditioning circuits. These components are designed to reduce noise and improve signal-to-noise ratio, which is crucial for maintaining high-speed data transmission accuracy over long distances of single-mode fiber.

Signal Integrity and Error Reduction Mechanisms

Signal integrity is a critical aspect of the Brocade 57-1000485-01 32Gbps Fibre Channel SFP+ module. The design incorporates advanced equalization techniques and error correction support at the protocol level to minimize data corruption. Fibre Channel systems inherently include mechanisms for detecting and retransmitting corrupted frames, but the optical transceiver itself is optimized to reduce the likelihood of errors occurring in the first place.

The module’s internal circuitry is designed to mitigate issues such as dispersion, attenuation, and reflection that can affect single-mode fiber transmission. By maintaining tight control over optical signal characteristics, the transceiver ensures stable performance even in complex and extended network topologies.

Compatibility and Interoperability in Brocade Ecosystems

Integration with Brocade Fibre Channel Switches and Directors

The Brocade 57-1000485-01 SFP+ transceiver module is engineered for seamless integration within Brocade Fibre Channel switching environments. It is commonly deployed in Brocade SAN switches and directors that support 32G Fibre Channel ports. This ensures optimal compatibility and performance tuning between hardware components.

In Brocade ecosystems, transceivers are validated through rigorous interoperability testing to ensure consistent behavior across firmware versions and hardware platforms. The 57-1000485-01 module benefits from this ecosystem validation, making it a reliable choice for enterprise deployments where stability and vendor compatibility are critical.

Cross-Vendor SAN Interoperability Considerations

Although optimized for Brocade environments, the 32Gbps Fibre Channel SFP+ module is often used in heterogeneous storage networks where equipment from multiple vendors must coexist. In such scenarios, adherence to Fibre Channel standards ensures that the transceiver can interoperate with compliant switches and storage devices from other manufacturers.

Interoperability depends on consistent adherence to optical specifications, encoding standards, and signal timing requirements. The Brocade 57-1000485-01 is designed to meet these strict standards, allowing it to function effectively in mixed-vendor SAN architectures while maintaining performance stability.

Performance Characteristics

Bandwidth Efficiency and Data Throughput Optimization

The 32Gbps Fibre Channel standard represents a significant advancement in storage networking performance. The Brocade 57-1000485-01 SFP+ transceiver module enables this high-speed connectivity by supporting full-duplex data transmission at 32 gigabits per second per channel. This level of bandwidth is essential for modern workloads such as high-performance computing, virtualization clusters, and large-scale database operations.

By doubling the throughput of previous 16Gbps generations, this transceiver helps reduce congestion in storage networks and improves application response times. The increased bandwidth also allows for greater consolidation of storage traffic, reducing the number of required interconnects in large-scale deployments.

Encoding and Transmission Efficiency

The 32G Fibre Channel protocol utilizes advanced encoding schemes designed to maximize data efficiency while minimizing overhead. The Brocade 57-1000485-01 transceiver supports these encoding methods, ensuring that raw bandwidth is effectively utilized for actual data transmission rather than protocol overhead. This contributes to improved performance in latency-sensitive applications.

Latency Reduction in Storage Networks

Low latency is a defining characteristic of Fibre Channel technology, and the Brocade 57-1000485-01 SFP+ module plays a critical role in maintaining this performance metric. By ensuring rapid optical signal conversion and minimal processing delay, the module helps maintain near-real-time data transfer between storage and compute resources.

This is particularly important in transactional databases, virtualization environments, and financial systems where even microsecond-level delays can impact application performance. The optimized optical path and high-speed electronics contribute to consistently low latency across the network.

Single-Mode Fiber Technology and Long-Distance Connectivity

Advantages of Single-Mode Fiber in Enterprise Networks

The Brocade 57-1000485-01 transceiver is specifically designed for single-mode fiber (SMF) applications, which provide superior long-distance transmission capabilities compared to multimode fiber. Single-mode fiber allows light to travel in a single propagation path, reducing dispersion and enabling clearer signal transmission over extended distances.

This makes SMF ideal for interconnecting geographically distributed data centers or connecting separate buildings within a campus environment. The use of 1310nm wavelength optical transmission further enhances distance capabilities while maintaining signal clarity.

Long-Distance Data Center Interconnectivity

One of the primary use cases for the Brocade 57-1000485-01 SFP+ module is long-distance data center interconnect (DCI). Enterprises often require reliable high-speed links between primary and secondary data centers for replication, backup, and disaster recovery. The single-mode fiber capability of this transceiver enables such connectivity over kilometers of optical fiber without significant performance degradation.

This long-distance capability ensures business continuity and data redundancy, which are essential components of modern IT infrastructure strategies. The module’s optical stability supports continuous synchronization between storage systems across multiple locations.

Reliability, Diagnostics, and Operational Stability

Built-In Monitoring and Diagnostic Capabilities

The Brocade 57-1000485-01 32Gbps Fibre Channel SFP+ module includes support for digital diagnostics monitoring (DDM), which provides real-time insights into optical performance metrics such as transmit power, receive power, temperature, and voltage. These diagnostics enable proactive maintenance and help prevent potential network failures.

By continuously monitoring operational parameters, network administrators can identify performance degradation before it impacts system availability. This predictive capability is critical in maintaining high levels of uptime in enterprise environments.

Long-Term Operational Stability

The module is designed for long-term reliability in demanding data center conditions. Its robust optical components and carefully engineered circuitry ensure stable performance over extended operational lifecycles. Resistance to environmental fluctuations such as temperature changes and electromagnetic interference further enhances its reliability profile.

Power Efficiency and Thermal Management

Low Power Consumption Design

The Brocade 57-1000485-01 SFP+ transceiver is engineered with energy efficiency in mind, consuming minimal power while delivering high-performance optical transmission. This contributes to reduced operational costs in large-scale deployments where hundreds or thousands of modules may be in use simultaneously.

Thermal Stability in Dense Environments

Thermal management is a critical aspect of high-density fiber optic deployments. The module is designed to operate within standard temperature ranges commonly found in enterprise data centers. Efficient heat dissipation ensures that performance remains stable even under sustained high-throughput conditions.
