740-140352 Juniper Networks 1310nm 10 Gigabit Module

Overview of Juniper Networks 740-140352 Optical Module

The Juniper Networks 740-140352 SFP+ transceiver is a high-performance optical module designed for 10 Gigabit Ethernet connectivity. Supporting long-range transmission over single-mode fiber, it offers advanced monitoring and compliance features, making it ideal for enterprise and data center applications.

General Information

• Manufacturer: Juniper Networks
• Part Number: 740-140352
• Category: Ethernet Optical Transceiver

Technical Specifications

Performance & Speed

• Data Rate: 10 Gigabit Ethernet
• Breakout Capability: Not supported
• Form Factor: SFP+
• Connector Type: Duplex LC
• Monitoring: Digital Optical Monitoring supported
• Standards Compliance: 10GBASE-L

MSA Compliance

• SFF-8431
• SFF-8472
• SFF-8432

Optical Characteristics

• Signaling Rate: 10 Gbps per lane
• Transmitter Fiber: Single-mode Fiber (SMF)
• Transmitter Wavelength Range: 1260 nm – 1355 nm
• Receiver Wavelength Range: 1260 nm – 1355 nm
• Transmitter Output Power: Min –8.2 dBm, Max 0.5 dBm
• Receiver Input Power: Min –14.4 dBm, Max –1.0 dBm
• Receiver Sensitivity (OMA): –14.1 dBm
• Stressed Receiver Sensitivity: –10.3 dBm

Cabling & Fiber

Supported Fiber Types

• Cable Type: SMF (Single-Mode Fiber)
• Core/Cladding: 9/125 µm
• Distance: Up to 10 km

Power & Environmental Specifications

Power Consumption

• Maximum Consumption: 1.0 W

Temperature Range

• Operating: –5° C to 70° C
• Storage: –40° C to 85° C

Physical Dimensions & Weight

• Width: 14 mm
• Height: 12.05 mm
• Length: 57.5 mm
• Weight: 0.15 lb

Juniper Networks 740-140352 LR SMF Ethernet Module

The Juniper Networks 740-140352 LR SMF 1310nm SFP 10 Gigabit Ethernet Module represents a high-performance optical transceiver solution designed for enterprise-grade and service provider networking environments requiring reliable long-reach connectivity. This category of 10G SFP+ optical modules is engineered to support high-speed data transmission across single-mode fiber (SMF) infrastructures, ensuring low latency, high bandwidth efficiency, and stable network performance across metropolitan, campus, and backbone deployments.

As modern networks continue to scale in complexity and throughput demand, optical modules such as the 740-140352 LR SMF 1310nm SFP play a critical role in enabling seamless data flow across distributed systems. The module is optimized for 10 Gigabit Ethernet applications and operates at a wavelength of 1310nm, which is widely recognized for long-range optical communication over single-mode fiber.

High-Speed Data Transmission Framework

The Juniper Networks 740-140352 module belongs to the SFP+ (Small Form-Factor Pluggable Plus) category, which supports enhanced bandwidth capabilities compared to earlier SFP standards. This architecture allows for 10 Gbps full-duplex transmission, making it suitable for data-intensive environments such as cloud computing centers, virtualization clusters, and high-performance enterprise networks.

The module's internal design focuses on signal integrity optimization, incorporating advanced laser transmitter technology and highly sensitive photodiode receivers. These components ensure minimal signal degradation over extended distances when deployed on single-mode fiber infrastructure.

1310nm Wavelength Efficiency

Operating at a wavelength of 1310nm, this optical transceiver is specifically tuned for long-reach applications. The 1310nm spectrum is widely used due to its low dispersion characteristics, allowing optical signals to travel significant distances without substantial loss or distortion.

This wavelength selection ensures stable communication across enterprise backbone links, inter-building connections, and regional data distribution networks where consistent performance is essential.

Single-Mode Fiber (SMF) Compatibility and Network Optimization

Long-Range Optical Connectivity

The 740-140352 LR SMF module is designed exclusively for single-mode fiber environments, which provide superior transmission distance compared to multi-mode fiber systems. SMF technology supports narrow core fiber pathways, enabling light signals to travel with reduced attenuation and minimal modal dispersion.

This makes the module suitable for long-distance networking scenarios, including campus interconnections, metropolitan area networks, and service provider backhaul infrastructure.

Signal Stability and Attenuation Control

One of the primary advantages of single-mode fiber compatibility is its ability to maintain signal clarity over extended distances. The optical design of the Juniper Networks 740-140352 ensures optimized power output and receiver sensitivity, allowing stable data transmission even under varying environmental conditions.

Network administrators benefit from reduced need for signal regeneration or amplification in mid-span deployments, improving cost efficiency and simplifying network design.

Enterprise Networking Applications

Data Center Interconnect Solutions

In modern data centers, high-speed interconnectivity is essential for maintaining synchronized workloads, virtualization traffic flow, and cloud service availability. The Juniper Networks 740-140352 LR module supports data center interconnect (DCI) architectures where 10 Gigabit Ethernet links are required for high-volume data transfer.

Its long-reach capability ensures that geographically separated data centers can operate cohesively, maintaining redundancy and load balancing across distributed systems.

Carrier and Service Provider Networks

Telecommunication carriers rely heavily on robust optical modules to support backbone infrastructure. This 10G SFP+ module is suitable for carrier-grade Ethernet transport, enabling high-capacity data transmission across metropolitan fiber rings and aggregation networks.

The stability and performance characteristics of the module make it an ideal choice for service providers requiring consistent uptime and predictable latency behavior.

Enterprise Campus Connectivity

Large enterprise campuses often require inter-building fiber links capable of handling significant internal traffic loads. The 740-140352 module provides reliable connectivity between core switches, distribution layers, and access nodes, ensuring seamless communication across departments and facilities.

Performance Characteristics and Engineering Design

Low Latency Optical Processing

Latency is a critical performance metric in high-speed networking environments. The Juniper Networks 740-140352 is designed to minimize optical-to-electrical conversion delays, ensuring near real-time data transmission across network segments.

This makes it highly suitable for latency-sensitive applications such as financial trading systems, cloud computing synchronization, and real-time analytics platforms.

Power Efficiency and Thermal Stability

Energy efficiency is an essential factor in modern networking hardware design. The SFP+ module architecture is optimized for low power consumption while maintaining high output performance. This reduces overall operational costs and supports greener data center initiatives.

Thermal stability is maintained through precision-engineered housing that dissipates heat effectively, ensuring consistent performance even in high-density switch environments.

Hot-Swappable Design Benefits

The module supports hot-swappable functionality, allowing network engineers to install or replace units without shutting down the entire system. This feature is critical for maintaining uptime in mission-critical infrastructure environments where downtime can result in significant operational disruption.

Compatibility Across Juniper Networking Platforms

Switch and Router Integration

The 740-140352 LR SMF module is designed for seamless integration with a wide range of Juniper Networks switching and routing platforms that support SFP+ interfaces. This ensures operational consistency across different hardware deployments within an enterprise ecosystem.

The module's standardized form factor ensures plug-and-play functionality, reducing configuration complexity and simplifying deployment processes.

Interoperability in Mixed Network Environments

In heterogeneous networking environments where multiple vendors may be present, optical interoperability becomes crucial. The module supports industry-standard 10G Ethernet protocols, enabling integration into mixed infrastructure setups while maintaining stable connectivity.

Fiber Optic Transmission Principles

Light Signal Propagation in SMF Systems

Single-mode fiber transmission relies on a narrow core diameter that allows light to travel in a single propagation path. This eliminates modal dispersion, which is common in multi-mode fiber systems, thereby ensuring higher signal clarity and longer transmission distances.

The Juniper Networks 740-140352 module leverages this principle to deliver high-quality optical transmission performance over extended network links.

Error Reduction and Signal Integrity

Advanced error correction and signal conditioning techniques are implemented within optical transceiver systems to ensure data integrity. The module maintains low bit error rates (BER), which is essential for maintaining stable communication in high-throughput environments.

Modern Networking Infrastructure

Cloud Computing Environments

Cloud data centers require high-speed interconnectivity between compute, storage, and networking layers. The 10G SFP+ module enables rapid data synchronization and workload distribution across cloud clusters, ensuring scalable performance for virtualized environments.

High-Performance Computing Clusters

Scientific computing and artificial intelligence workloads demand extremely fast data transfer rates between nodes. The Juniper Networks 740-140352 module supports these requirements by providing consistent low-latency connectivity across high-performance computing clusters.

Enterprise Backbone Networks

Enterprise backbone networks rely on stable and scalable optical connections to manage internal data traffic. This module ensures that core network layers remain interconnected with high reliability and minimal downtime risk.
