Cisco AIR-WLC2106-K9 Wireless LAN Controller

AIR-WLC2106-K9
Hover on image to enlarge

Brief Overview of AIR-WLC2106-K9

Cisco 2100 Wireless LAN Controller - AIR-WLC2106-K9. Factory-Sealed New in Original Box (FSB)

QR Code of Cisco AIR-WLC2106-K9 Wireless LAN Controller
$950.00
$699.00
You save: $251.00 (26%)
Ask a question
180 days
+
Quote

Additional 7% discount at checkout

SKU/MPNAIR-WLC2106-K9Availability✅ In StockProcessing TimeUsually ships same day ManufacturerCisco Product/Item ConditionFactory-Sealed New in Original Box (FSB) ServerOrbit Replacement WarrantySix-Month (180 Days)
Our Advantages
  • Free Ground Shipping
  • — Min. 6-month Replacement Warranty
  • — Genuine/Authentic Products
  • — Easy Return and Exchange
  • — Different Payment Methods
  • — Best Price
  • — We Guarantee Price Matching
  • — Tax-Exempt Facilities
  • — 24/7 Live Chat, Phone Support
Payment Options
  • — Visa, MasterCard, Discover, and Amex
  • — JCB, Diners Club, UnionPay
  • — PayPal, ACH/Wire Transfer
  • — Apple Pay, Amazon Pay, Google Pay
  • — Buy Now, Pay Later - Affirm, Afterpay
  • — GOV/EDU/Institutions PO's Accepted
  • — Invoices
Delivery
  • — Deliver Anywhere
  • — Express Delivery in the USA and Worldwide
  • — Ship to -APO -FPO
  • For USA - Free Ground Shipping
  • — Worldwide - from $30

Same product also available in:

Description

Overview of AIR-WLC2106-K9 Wireless LAN Controller

  • Brand: Cisco
  • Part Number: AIR-WLC2106-K9
  • Product Series: Aironet
  • Model: 2100 Wireless LAN Controller
  • Type: Wireless LAN Controller

Wireless Standards Supported

  • IEEE 802.11a
  • IEEE 802.11b
  • IEEE 802.11g
  • IEEE 802.11d
  • IEEE 802.11h
  • IEEE 802.11n

Wired and Routing Specifications

  • IEEE 802.3 10BASE-T
  • IEEE 802.3u 100BASE-TX
  • IEEE 802.1Q VLAN Tagging

Data Protocols

  • RFC 768: UDP
  • RFC 791: IP
  • RFC 792: ICMP
  • RFC 793: TCP
  • RFC 826: ARP
  • RFC 1122: Internet Host Requirements
  • RFC 1519: CIDR
  • RFC 1542: BOOTP
  • RFC 2131: DHCP

Security Protocols

Encryption Standards

  • WEP and TKIP-MIC: RC4 40, 104, and 128 bits
  • SSL and TLS: RC4 128-bit, RSA 1024- and 2048-bit
  • AES: CCM, CCMP

Authentication and Authorization

  • IEEE 802.1X
  • RFC 2548: Microsoft Vendor-Specific RADIUS Attributes
  • RFC 2716: PPP EAP-TLS
  • RFC 2865: RADIUS Authentication
  • RFC 2866: RADIUS Accounting
  • RFC 2867: RADIUS Tunnel Accounting
  • RFC 2869: RADIUS Extensions
  • RFC 3576: Dynamic Authorization Extensions to RADIUS
  • RFC 3579: RADIUS Support for EAP
  • RFC 3580: IEEE 802.1X RADIUS Guidelines
  • RFC 3748: Extensible Authentication Protocol
  • Web-based Authentication

Management Features

  • SNMP v1, v2c, v3
  • RFC 854: Telnet
  • RFC 1155: Management Information for TCP/IP-Based Internets
  • RFC 1156: MIB
  • RFC 1157: SNMP
  • RFC 1213: SNMP MIB II
  • RFC 1350: TFTP
  • RFC 1643: Ethernet MIB
  • RFC 2030: SNTP
  • RFC 2616: HTTP
  • RFC 2665: Ethernet-Like Interface types MIB
  • RFC 2674: Managed Objects for Bridges with Traffic Classes, Multicast Filtering, and VLAN Extensions
  • RFC 2819: RMON MIB
  • RFC 2863: Interfaces Group MIB
  • RFC 3164: Syslog
  • RFC 3414: User-Based Security Model for SNMPv3
  • RFC 3418: MIB for SNMP
  • RFC 3636: Managed Objects for IEEE 802.3 MAUs
  • Cisco Private MIBs

Management Interfaces

  • Compatible with Cisco Wireless Control System
  • Web Interface: HTTP/HTTPS for device management
  • Command-Line Interface: Telnet, SSH, Serial Port

Physical Specifications

  • Dimensions: 1.75 x 7.89 x 6.87 inches (4.45 x 20.04 x 17.45 cm)
  • Weight: 4.0 lbs (including power supply)
  • Operating Temperature: 32 to 104°F (0 to 40°C)
  • Storage Temperature: -13 to 158°F (-25 to 70°C)
  • Operating Humidity: 10 to 95% (non-condensing)
  • Storage Humidity: Up to 95%
  • Power Adapter Input: 100 to 240 VAC; 50/60 Hz
  • Heat Dissipation: 72 BTU/hour

Compliance and Certification

  • CE Mark
  • Safety: UL 60950-1:2003, EN 60950:2000
  • EMI and Susceptibility (Class B): FCC Part 15.107 and 15.109 (U.S.), ICES-003 (Canada), VCCI (Japan), EN 55022, EN 55024 (Europe)

Features

Supports up to 6 access points

The Cisco 2100 Wireless LAN Controller - AIR-WLC2106-K9 is a cutting-edge wireless LAN controller that offers support for up to 6 access points. This feature is crucial for businesses and organizations that require a reliable and efficient wireless network infrastructure. With the ability to connect up to 6 access points, this controller provides expanded coverage and enhanced network performance, ensuring that users can seamlessly access the network from any location within the coverage area.

Improved Network Performance

By supporting up to 6 access points, the Cisco 2100 Wireless LAN Controller enables businesses to optimize their network performance. The increased number of access points ensures that network traffic is distributed evenly, preventing congestion and reducing latency. This means that users can enjoy a faster and more reliable connection, resulting in improved productivity and user satisfaction.

Enhanced Coverage

The ability to support multiple access points allows the Cisco 2100 Wireless LAN Controller to provide extended coverage throughout a facility or campus. This is particularly beneficial for organizations with large buildings or outdoor areas where a single access point may not be sufficient to cover the entire space. By strategically placing multiple access points, businesses can ensure that all areas have a strong and stable wireless signal, allowing users to stay connected wherever they are.

Integrated wireless controller functionality

One of the standout features of the Cisco 2100 Wireless LAN Controller is its integrated wireless controller functionality. This means that the controller not only manages and controls the connected access points but also eliminates the need for a separate dedicated hardware controller. This integration simplifies the network infrastructure and reduces costs for businesses.

Simplified Network Management

With integrated wireless controller functionality, the Cisco 2100 Wireless LAN Controller offers centralized management of the wireless network. This allows IT administrators to easily configure, monitor, and troubleshoot the entire wireless network from a single interface. The centralized management capability saves time and effort, streamlining network operations and reducing the complexity associated with managing multiple access points individually.

Cost-Effective Solution

By eliminating the need for a separate hardware controller, the Cisco 2100 Wireless LAN Controller offers a cost-effective solution for businesses. The integration of controller functionality into the device itself reduces upfront costs and eliminates the need for additional hardware investments. This makes it an ideal choice for small to medium-sized businesses or organizations operating on a tight budget.

Centralized management of wireless network

The Cisco 2100 Wireless LAN Controller enables centralized management of the wireless network, providing businesses with greater control and flexibility over their network operations. This feature offers several benefits that contribute to improved efficiency and performance.

Simplified Network Configuration

Centralized management allows IT administrators to configure the entire wireless network from a single interface. This eliminates the need to manually configure each access point individually, saving time and reducing the chances of configuration errors. With a few clicks, administrators can set up security policies, define SSIDs, and manage user access across all connected access points.

Real-time Monitoring and Troubleshooting

The centralized management capability of the Cisco 2100 Wireless LAN Controller enables real-time monitoring and troubleshooting of the wireless network. IT administrators can easily identify and resolve network issues promptly, ensuring minimal downtime and uninterrupted connectivity for users. Access point performance, client connectivity status, and other vital network statistics can be monitored in real-time, allowing administrators to proactively address any potential problems.

Enhanced Security

Effective security measures are crucial for any wireless network. The Cisco 2100 Wireless LAN Controller provides advanced encryption capabilities to ensure secure connectivity. With support for industry-standard encryption protocols such as WPA2, businesses can protect their network from unauthorized access and data breaches. The centralized management feature allows administrators to enforce security policies uniformly across all access points, ensuring a consistent level of protection throughout the network.

Scalability for Growing Networks

As businesses grow and expand, their network requirements also evolve. The Cisco 2100 Wireless LAN Controller offers a scalable solution for growing networks. With the ability to support up to 6 access points, businesses can easily expand their wireless network infrastructure as needed. This scalability ensures that the controller can accommodate increased user demands and adapt to changing business needs without significant upgrades or replacements.

In conclusion, the Cisco 2100 Wireless LAN Controller - AIR-WLC2106-K9 is a powerful and feature-rich solution for businesses and organizations seeking a reliable and efficient wireless network infrastructure. With its support for up to 6 access points, integrated wireless controller functionality, centralized management capabilities, advanced encryption for secure connectivity, and scalability for growing networks, this controller offers numerous benefits that enhance network performance, simplify management tasks, and provide a cost-effective solution. Whether it's improving network performance, extending coverage, simplifying network management, enhancing security, or accommodating future growth, the Cisco 2100 Wireless LAN Controller is an excellent choice for businesses looking to optimize their wireless network infrastructure.
