HPE JL324A Aruba 2930M Smart Rate PoE+ 1-Slot Network Switches.

Product Overview

Key Specifications

• Manufacturer: HPE
• Model Number: JL324A
• Product Type: Managed L3 Switch

Technical Information

• Port Count: 24 Ports
• Rack Compatibility: Rack-mountable 1U
• Ethernet Subtype: 5 Gigabit Ethernet
• Power Over Ethernet: PoE+
• PoE Budget: 860 W

Performance Metrics

• Latency:
  • 1 Gbps: 3.1 µs
  • 2.5 Gbps: 6.5 µs
  • 5 Gbps: 4.2 µs
  • 10 Gbps: 3.4 µs
• Throughput: 112 Mpps
• Stacking Bandwidth: 100 Gbps
• Switching Capacity: 320 Gbps

Routing Capabilities

• IPv4 Routing Table Entries: 2000
• IPv6 Routing Table Entries: 1000
• OSPF Routes: 200
• RIP Routes: 10,000
• Static Routes: 256

Additional Features

• MAC Address Table: 32,768 entries
• Jumbo Frame Support: 9220 Bytes
• Supported Protocols:
  • OSPF, RIP, IGMPv2, IGMPv3
  • Static IP Routing (IPv4 & IPv6)
  • ECMP, MLD, CIDR
• Remote Management Protocols:
  • SNMP (v1, v2, v2c, v3), Telnet, SSH, RMON
  • HTTP, CLI, XRMON

Security Features

• Encryption: MD5, SSL, TLS
• Authentication Methods:
  • RADIUS, PAP, CHAP, TACACS+
  • SSH v2, EAP

Compliant Standards

• IEEE 802.1D, 802.1Q, 802.3AB, 802.3AF, 802.3X, 802.3AD (LACP)
• IEEE 802.1P, 802.1W, 802.1X, 802.1S, 802.1V
• IEEE 802.1AB (LLDP), 802.3AT, 802.3AZ, 802.1AX, 802.3BZ

Hardware Specifications

• Processor: 1 x ARM Cortex-A9 at 1.016 GHz
• RAM: 1 GB DDR3 SDRAM
• Flash Memory: 4 GB

Connectivity Options

• Interfaces:
  • 24 x 1/2.5/5GBASE-T PoE+
  • 1 x Serial (Console)
  • 1 x USB Type B
  • 1 x 1000BASE-T Management
• Expansion Slots:
  • 1 Stacking Module Slot (1 free)
  • 1 Expansion Slot (1 free)

Power Specifications

• Power Device: Internal Power Supply (not installed)
• Maximum Supported Quantity: 2
• Required Voltage: AC 120/230 V (50/60 Hz)

Power

The HPE Aruba 2930M Network Switch is equipped with an impressive Power over Ethernet (PoE+) capability of 840W. This remarkable feature offers numerous benefits and plays a crucial role in ensuring a seamless network experience for users.

High Power Efficiency

With PoE+ 840W, the HPE Aruba 2930M Network Switch enables efficient power delivery to connected devices. This high power efficiency ensures that each device receives the required power without any wastage, resulting in optimized energy usage and reduced electricity bills.

Flexibility in Network Design

The substantial power capacity of PoE+ 840W allows for flexible network design and deployment. It provides the ability to connect numerous high-power consuming devices, such as wireless access points, IP cameras, and VoIP phones, without the need for additional power sources or messy cables. This flexibility simplifies network installation and reduces overall infrastructure costs.

Powering Remote Devices

One of the significant advantages of PoE+ 840W is its capability to power remote devices. By utilizing the existing Ethernet infrastructure, the HPE Aruba 2930M Network Switch can power devices located in remote areas where traditional power outlets may not be easily accessible. This feature is particularly beneficial in scenarios such as outdoor installations or remote offices, eliminating the need for expensive electrical work and ensuring uninterrupted connectivity.

Enhanced Network Reliability

The PoE+ 840W feature of the HPE Aruba 2930M Network Switch enhances network reliability by providing a centralized power source. In the event of a power outage, the switch can automatically switch to an auxiliary power source, such as an uninterruptible power supply (UPS). This redundancy ensures that critical network devices, such as security cameras or access points, stay operational, minimizing downtime and maintaining a secure network environment.

Improved Device Management

Managing powered devices becomes more efficient with PoE+ 840W. The switch provides advanced management capabilities, allowing administrators to monitor power consumption, troubleshoot issues remotely, and prioritize power allocation to specific devices. This level of control simplifies network maintenance, enhances security, and optimizes device performance.

Slots

The HPE Aruba 2930M Network Switch boasts a single slot design, offering users exceptional flexibility and scalability for their network infrastructure.

Expansion Possibilities

The single slot feature of the HPE Aruba 2930M Network Switch allows for easy expansion as businesses grow. Users can add additional modules or cards to the switch to accommodate increased network demands without the need to invest in a completely new switch. This scalability ensures future-proofing of the network infrastructure and minimizes costs associated with network upgrades.

Module Compatibility

The single slot design is compatible with a wide range of modules and cards available for the HPE Aruba 2930M Network Switch. Whether it's adding more ports for increased connectivity or incorporating specialized modules for specific network requirements, users have the flexibility to customize their switch based on their unique needs. This compatibility simplifies the integration of new technologies and provides a scalable solution for evolving business needs.

Space-Saving Design

The single slot design of the HPE Aruba 2930M Network Switch ensures a compact form factor, making it ideal for environments with limited space. Users can optimize their network infrastructure even in cramped server rooms or crowded network cabinets, without sacrificing performance or functionality. This space-saving feature allows for efficient utilization of available resources and facilitates better organization and cable management.

Part Number

The HPE Aruba 2930M Network Switch is identified by the part number JL324A, which holds significance in terms of product identification and compatibility.

Product Identification

The part number JL324A is unique to the HPE Aruba 2930M Network Switch and serves as a specific identifier for this particular model. It ensures accurate identification, eliminates confusion, and facilitates easy procurement or replacement of the switch when required. Users can confidently refer to the part number when communicating with suppliers or seeking technical support, ensuring seamless compatibility and streamlined operations.

Compatibility Assurance

The part number JL324A plays a vital role in ensuring compatibility with other HPE Aruba products and accessories. It guarantees that users can seamlessly integrate the HPE Aruba 2930M Network Switch into their existing network infrastructure without any compatibility issues. This assurance simplifies the deployment process, reduces potential conflicts, and ensures optimal performance and functionality across the entire network ecosystem.

Product Documentation

The part number JL324A is referenced extensively in product documentation such as user manuals, datasheets, and technical specifications. This documentation provides detailed information about the switch's features, capabilities, and configuration options. Users can easily locate the relevant documentation using the part number, enabling them to make informed decisions, troubleshoot issues, and maximize the utilization of the HPE Aruba 2930M Network Switch.
