JL679A#ABA HPE Aruba 16-Port 12G CL4 139W 2SFP+ Managed Switches.
- — Free Ground Shipping
- — Min. 6-month Replacement Warranty
- — Genuine/Authentic Products
- — Easy Return and Exchange
- — Different Payment Methods
- — Best Price
- — We Guarantee Price Matching
- — Tax-Exempt Facilities
- — 24/7 Live Chat, Phone Support
- — Visa, MasterCard, Discover, and Amex
- — JCB, Diners Club, UnionPay
- — PayPal, ACH/Wire Transfer
- — Apple Pay, Amazon Pay, Google Pay
- — Buy Now, Pay Later - Affirm, Afterpay
- — GOV/EDU/Institutions PO's Accepted
- — Invoices
- — Deliver Anywhere
- — Express Delivery in the USA and Worldwide
- — Ship to -APO -FPO
- — For USA - Free Ground Shipping
- — Worldwide - from $30
Same product also available in:
SKU/MPN | Warranty | Price | Condition | You save |
---|---|---|---|---|
JL679A#ABA | Six-Month (180 Days) | $696.00 | Factory-Sealed New in Original Box (FSB) | You save: $377.25 (35%) |
JL679A#ABA | Six-Month (180 Days) | $599.00 | New (Box Not Sealed) | You save: $444.55 (43%) |
Product Specifications
Device Characteristics
- Type: Managed Switch
- Port Configuration: 16 Ports, Stackable
- Mounting: Rack-mountable (1U)
Technical Overview
- Network Subtype: 10 Gigabit Ethernet
- Port Types:
- 12 x 10/100/1000 (PoE+)
- 2 x 1G/10G SFP+
- 2 x 1000Base-T
- Power Over Ethernet: PoE+
- Power Budget: 139 Watts
Performance Metrics
- Switching Capacity: 68 Gbps
- Throughput: 45.1 Mpps
- Latency:
- 1 Gbps: 2.3 µs
- 10 Gbps: 2.6 µs
Capacity Specifications
- Switched Virtual Interfaces (SVIs): 16
- ARP Entries: 1,024
- IPv4 Routes (Unicast): 512
- IPv6 Routes (Unicast): 512
- IGMP Groups: 512
- MLD Groups: 512
- ACL Entries:
- IPv4 (Ingress): 256
- IPv6 (Ingress): 128
- MAC (Ingress): 256
MAC Address Table
- Size: 8,192 Entries
Protocols and Encryption
- Supported Routing Protocols: IGMPv2, IGMPv3
- Encryption Method: SSL
- Authentication Methods:
- Secure Shell (SSH)
- RADIUS
- TACACS+
- Secure Shell V.2 (SSH2)
Advanced Features
- Flow Control
- BootP and ARP Support
- VLAN and DiffServ Support
- IPv6 and SNTP Support
- Multiple Spanning Tree Protocol (MSTP)
- Trivial File Transfer Protocol (TFTP)
- Fanless Operation
- LACP Support
- LLDP and LLDP-MED Support
- Port-Based Access Control
- DHCP Client
- Energy Efficient Ethernet
- Management Information Base (MIB)
- Network Access Control (NAC)
- Neighbor Discovery Protocol (NDP)
- SNMP Support
- Internet Control Message Protocol (ICMP)
- Rapid Spanning Tree Reconfiguration (RSTP)
- IPv6 Addressing
Compliance Standards
- IEEE 802.3
- IEEE 802.1D
- IEEE 802.1Q
- IEEE 802.3ab
- IEEE 802.1P
- IEEE 802.3X
- IEEE 802.3AD (LACP)
- IEEE 802.1W
- IEEE 802.1S
- IEEE 802.3AT
- IEEE 802.3AZ
Hardware Configuration
- Processor: 1 x ARM A9 at 1.016 GHz
- Memory: 4 GB DDR3 SDRAM
- Flash Storage: 16 GB
Connectivity Options
- 12 x 10/100/1000 Base-T RJ-45 Ports
- 2 x 1/10 Gbit LAN SFP+ Ports
- 1 x USB-C Console Port
- 1 x USB Type A Port
- 2 x Gigabit LAN Ports
Power Specifications
- Power Supply: Internal Power Supply
- Total Power Provided: 165 Watts at 0.9 A
- Voltage Requirement: AC 230 V (50/60 Hz)
- Operational Power Consumption: 16 Watts
Ports
The HPE Aruba 6100 Managed Network Switches come equipped with 16 ports, making them an ideal choice for businesses and organizations that require a high level of connectivity. These switches offer a versatile and reliable solution for connecting multiple devices to a network, ensuring smooth and efficient communication.
Increased Connectivity
With 16 ports, the HPE Aruba 6100 Managed Network Switches allow users to connect a large number of devices simultaneously. This is particularly beneficial for businesses with multiple departments or offices that require extensive connectivity. Whether it's connecting computers, printers, servers, or other network devices, the ample number of ports ensures that all devices can be linked without any limitations.
Flexibility in Network Design
The 16 ports on these switches offer flexibility in network design. Users can create separate VLANs (Virtual Local Area Networks) to segregate traffic and improve network performance. This feature allows businesses to optimize their network infrastructure by separating different types of traffic and controlling access to specific resources.
Scalability
The HPE Aruba 6100 Managed Network Switches' 16 ports provide scalability for growing businesses. As the organization expands, additional devices can easily be connected without the need for external switches or complex network reconfigurations. This scalability ensures that the network can accommodate future growth and adapt to changing business requirements.
Reduced Equipment Costs
By offering 16 ports in a single switch, the HPE Aruba 6100 Managed Network Switches eliminate the need for multiple switches and reduce equipment costs. Businesses can save on purchasing additional networking hardware while still enjoying the benefits of a robust and scalable network infrastructure.
Improved Performance
The 16 ports on these switches contribute to improved network performance. With more ports available, data traffic is distributed evenly, preventing congestion and bottlenecks. This ensures that all connected devices receive the necessary bandwidth, resulting in faster and more reliable communication.
Speed
The HPE Aruba 6100 Managed Network Switches offer a speed of 12G, making them an excellent choice for businesses that require high-speed connectivity. This feature enables fast data transfer and ensures a seamless user experience.
Efficient Data Transfer
The 12G speed of the HPE Aruba 6100 Managed Network Switches allows for efficient data transfer between connected devices. Whether it's transferring large files, streaming multimedia content, or running bandwidth-intensive applications, the high speed ensures quick and reliable data transmission.
Improved Productivity
The fast data transfer speed provided by these switches directly contributes to improved productivity. Employees can access and share files more quickly, resulting in faster collaboration and decision-making. This increased efficiency translates into time savings and enhanced overall productivity for businesses.
Enhanced User Experience
The 12G speed of these switches guarantees an enhanced user experience. Users can enjoy lag-free video conferencing, seamless online gaming, and smooth multimedia streaming. This feature is particularly important in industries where real-time communication and multimedia content play a crucial role in daily operations.
Support for Bandwidth-Intensive Applications
The HPE Aruba 6100 Managed Network Switches' 12G speed supports bandwidth-intensive applications such as video editing, graphic design, and virtualization. These switches ensure that the network can handle the high data demands of these applications without compromising performance or causing latency issues.
Future-Proofing
The 12G speed offered by these switches future-proofs the network infrastructure. As technology continues to advance, the need for higher speeds will become more prevalent. By investing in switches with a faster speed like the HPE Aruba 6100 Managed Network Switches, businesses can ensure that their network is capable of handling future requirements without the need for immediate upgrades.
Power
The HPE Aruba 6100 Managed Network Switches provide a power capacity of 139W, making them a reliable choice for businesses that require a high-power network infrastructure. This feature ensures that all connected devices receive the necessary power supply for uninterrupted operation.
Powering Multiple Devices
With a power capacity of 139W, these switches can efficiently power multiple devices simultaneously. This is particularly beneficial for businesses with a large number of network devices that require power, such as IP phones, wireless access points, and security cameras. The switches' high-power capacity eliminates the need for additional power sources or adapters, simplifying the network setup and reducing clutter.
Power Over Ethernet (PoE) Support
The HPE Aruba 6100 Managed Network Switches offer Power over Ethernet (PoE) support, allowing them to deliver both data and power over a single Ethernet cable. This feature eliminates the need for separate power cables and adapters for each device, reducing installation and maintenance costs. PoE support also enables greater flexibility in device placement since devices can be installed in locations without direct access to power outlets.
Improved Energy Efficiency
The HPE Aruba 6100 Managed Network Switches are designed with energy efficiency in mind. With advanced power management features such as intelligent power allocation and port sleep mode, these switches optimize power usage and reduce energy consumption. This not only lowers electricity costs but also contributes to a greener and more sustainable network infrastructure.
Reliable Power Backup
The 139W power capacity of these switches ensures a reliable power backup for critical network devices. In the event of a power outage, the switches can continue to provide power, keeping essential devices operational. This feature is particularly important for businesses that rely on uninterrupted network connectivity, such as healthcare facilities or financial institutions.
Remote Power Cycling
The HPE Aruba 6100 Managed Network Switches' power capacity allows for remote power cycling of connected devices. This feature enables IT administrators to restart devices without physically accessing them, saving time and effort. Remote power cycling is especially useful for troubleshooting network issues or performing routine maintenance tasks.
Interfaces
The HPE Aruba 6100 Managed Network Switches offer 2 interfaces, providing users with the necessary connectivity options for their network infrastructure. These interfaces ensure seamless integration with other network devices and enable smooth data transfer.
Versatile Connectivity
With 2 interfaces, these switches offer versatile connectivity options. The interfaces can be used to connect to various devices such as routers, servers, or storage systems, ensuring seamless integration within the network infrastructure. The ability to connect different types of devices enhances the flexibility and scalability of the network.
Link Aggregation
The 2 interfaces on these switches support link aggregation, also known as port trunking or bonding. Link aggregation combines multiple physical interfaces into a single logical interface, increasing bandwidth and providing redundancy. This feature improves network performance and ensures uninterrupted connectivity, even in the event of a link failure.
Network Expansion
The interfaces on the HPE Aruba 6100 Managed Network Switches allow for easy network expansion. Additional switches or devices can be connected using these interfaces, extending the network's reach and accommodating growing business needs. The ability to expand the network without disrupting existing operations is crucial for businesses that require scalability.
High-Speed Data Transfer
The 2 interfaces on these switches enable high-speed data transfer between connected devices. Whether it's transferring large files, streaming multimedia content, or running bandwidth-intensive applications, the interfaces ensure quick and reliable data transmission. This high-speed connectivity is essential for businesses that rely on fast and efficient communication.
Improved Network Efficiency
The interfaces provided by the HPE Aruba 6100 Managed Network Switches contribute to improved network efficiency. By connecting devices through interfaces, users can avoid bottlenecks and ensure smooth data flow. This prevents congestion and latency issues, resulting in better overall network performance.
Interface Type
The HPE Aruba 6100 Managed Network Switches feature an SFP+ interface type, offering users advanced connectivity options for their network infrastructure. This interface type ensures high-speed data transfer and compatibility with a wide range of network devices.
Fiber Optic Connectivity
The SFP+ interface type on these switches enables fiber optic connectivity. Fiber optic cables offer several advantages over traditional copper cables, including higher bandwidth, longer transmission distances, and immunity to electromagnetic interference. This makes the SFP+ interface ideal for businesses that require reliable and high-performance networking.
Interoperability
The SFP+ interface type is widely used in the networking industry, ensuring interoperability with various network devices. Users can easily connect the HPE Aruba 6100 Managed Network Switches to devices such as routers, switches, or servers that support SFP+ interfaces. This compatibility allows for seamless integration within existing network infrastructures.
Scalability and Future-Proofing
The SFP+ interface type offers scalability and future-proofing capabilities for businesses. As technology advances, higher-speed interfaces may become necessary to meet growing demands. By using switches with SFP+ interfaces like the HPE Aruba 6100 Managed Network Switches, businesses can easily upgrade their network infrastructure without replacing the entire switch.
Longer Transmission Distances
The SFP+ interface type supports longer transmission distances compared to copper interfaces. This makes it suitable for businesses with large office spaces or multiple locations that require connectivity over extended distances. The ability to transmit data over longer distances without signal degradation ensures reliable communication throughout the network.
High-Speed Data Transfer
The SFP+ interface type enables high-speed data transfer between connected devices. With data rates of up to 10Gbps, these switches ensure fast and efficient communication. This high-speed connectivity is particularly beneficial for bandwidth-intensive applications such as data backups, video streaming, or virtualization.
Part Number
The HPE Aruba 6100 Managed Network Switches have a part number of JL679A#ABA, which is an essential identifier for businesses when purchasing, managing, or troubleshooting network equipment. This part number ensures accurate ordering and compatibility with other network devices.
Accurate Ordering
The part number JL679A#ABA provides businesses with a precise identifier when ordering HPE Aruba 6100 Managed Network Switches. This ensures that the correct model and specifications are obtained, minimizing errors and streamlining the procurement process. Accurate ordering helps businesses avoid delays and ensures that the network infrastructure is equipped with the required equipment.
Compatibility Assurance
The part number JL679A#ABA guarantees compatibility with other HPE Aruba network devices. When expanding or upgrading the network, businesses can confidently select additional switches or related equipment with matching part numbers, ensuring seamless integration within the existing network infrastructure. Compatibility assurance simplifies the deployment process and reduces the risk of compatibility issues.
Efficient Troubleshooting
The unique part number allows for efficient troubleshooting in case of network issues. IT personnel can easily identify the specific switch model using the part number, facilitating targeted diagnostics and support. This expedites the resolution of network problems and reduces downtime, ultimately improving productivity and user satisfaction.
Warranty and Support
The part number JL679A#ABA is associated with specific warranty and support options provided by HPE Aruba. Businesses can verify warranty coverage, access technical support, and obtain software updates or firmware upgrades specific to their switch model using the part number. This ensures that businesses receive the necessary assistance to maintain and optimize their network infrastructure.
