02326-001 AXIS P3265-v High-performance Fixed Dome Camera.

AXIS P3265-V Fixed Dome Camera Overview

The AXIS 02326-001 P3265-V is a professional fixed dome network camera engineered for intelligent surveillance. Built by AXIS, this model combines advanced imaging, deep learning capabilities, and enterprise-grade reliability to support demanding security environments.

Manufacturer & Product Identity

• Brand: AXIS Communications
• Model Series: AXIS P3265-V
• Part Number / SKU: 02326-001
• Product Category: High-performance fixed dome camera

Advanced Imaging & Sensor Technology

Image Sensor Specifications

• RGB CMOS sensor for accurate color reproduction
• 1/2.8-inch sensor size optimized for low-light performance
• 2-megapixel effective resolution delivering sharp Full HD visuals

Lens & Optical Flexibility

• Varifocal lens with focal length ranging from 3.4 mm to 8.9 mm
• Wide horizontal field of view adjustable from 100° to 36°
• Vertical viewing angle spanning 53° to 20° for scene coverage control

Video Performance & Encoding Formats

High-Frame-Rate Capture

• Supports up to 50/60 frames per second for smooth motion rendering
• Native 60 Hz refresh rate enhances real-time monitoring

Supported Video Codecs

• H.265 for efficient bandwidth usage
• H.264 ensuring broad system compatibility
• Motion JPEG for frame-by-frame image access

Maximum Video Resolution

• Full HD recording at 1920 × 1080 pixels

Deep Learning Processing & System Resources

Integrated DLPU Capabilities

The built-in Deep Learning Processing Unit enables advanced analytics at the edge, improving object classification and event detection without overloading network infrastructure.

• 1 GB system RAM for stable multitasking
• 8 GB onboard flash memory for applications and buffering

Network Connectivity & Power Options

Wired Network Interface

• RJ-45 Ethernet connectivity
• 10Base-T / 100Base-TX network support
• Power over Ethernet (PoE) for simplified installation

Interfaces, Audio & I/O Integration

Input / Output Connections

• 4-pin 2.5 mm terminal block
• One supervised digital input
• One digital output with 12 V DC, up to 25 mA load

Audio Capabilities

• Dedicated 4-pin audio terminal block
• Audio input and output support
• Compatibility with external microphones

Deployment & Application Use Cases

Designed for Professional Surveillance

• Ideal for commercial buildings and corporate offices
• Suitable for retail, banking, and industrial monitoring
• Optimized for environments requiring intelligent video analytics

Advanced Fixed Dome Network Cameras for Intelligent Indoor Surveillance

The AXIS 02326-001 P3265-v high-performance fixed dome camera belongs to a professional category of indoor network surveillance solutions engineered for environments where image accuracy, reliability, and intelligent analytics are critical. This category focuses on discreet yet powerful dome cameras that integrate advanced imaging technologies with deep learning processing capabilities. Designed for enterprise, commercial, and institutional deployments, fixed dome cameras like this model are optimized for continuous operation, consistent video quality, and dependable performance under challenging lighting and environmental conditions.

Within this category, emphasis is placed on combining robust hardware design with sophisticated software intelligence. These cameras are not only responsible for capturing video but also for interpreting scenes, detecting objects, and enabling proactive security operations. The AXIS P3265-v represents a class of cameras that merge forensic-level image quality with on-device analytics, reducing reliance on external processing and improving response times across surveillance systems.

Deep Learning Processing Unit (DLPU) for On-Device Intelligence

A defining characteristic of this category is the integration of a deep learning processing unit directly within the camera. The DLPU allows advanced analytics to run at the edge, enabling faster decision-making and more scalable system architectures. Instead of sending raw video streams to centralized servers for analysis, cameras process data locally, significantly reducing bandwidth usage and system latency.

The AXIS 02326-001 P3265-v leverages this on-device intelligence to support advanced analytics applications such as AXIS Object Analytics. This capability enables accurate detection and classification of humans and vehicles in real time, even in complex indoor scenes. Cameras in this category are designed to evolve over time, supporting future analytics applications and firmware enhancements without requiring hardware replacement.

Edge-Based Analytics and Operational Efficiency

By performing analytics at the camera level, fixed dome cameras with DLPU enhance overall system efficiency. Security teams can deploy large camera networks without overwhelming network infrastructure or central servers. This approach is particularly valuable in enterprise campuses, retail chains, transportation hubs, and healthcare facilities where scalability and reliability are paramount.

Edge analytics also improve privacy compliance by allowing selective data processing and minimizing unnecessary video transmission. Cameras can be configured to trigger events only when relevant activity is detected, ensuring that surveillance systems remain both effective and responsible.

Forensic WDR for High-Contrast Indoor Scenes

Forensic Wide Dynamic Range is a core imaging feature within this category, addressing one of the most common challenges in indoor surveillance: high-contrast lighting. Environments such as building entrances, lobbies, corridors with windows, and retail spaces often contain bright and dark areas within the same scene. Forensic WDR ensures that details remain visible in both highlights and shadows simultaneously.

The AXIS P3265-v captures multiple exposures and intelligently combines them to produce balanced images with preserved detail. This capability is essential for forensic analysis, where identifying faces, clothing, or objects accurately can make a critical difference in investigations.

Maintaining Image Integrity Across Lighting Variations

Cameras in this category are designed to adapt dynamically to changing light conditions without introducing motion blur or artifacts. Forensic WDR works in harmony with high frame rates to ensure that moving subjects are captured clearly, even when lighting conditions fluctuate rapidly. This is particularly important in indoor environments with automatic lighting systems or large windows.

Lightfinder 2.0 for Superior Low-Light Performance

Lightfinder 2.0 technology defines a premium segment within the fixed dome camera category, focusing on color-accurate imaging in low-light conditions. Unlike traditional low-light solutions that rely heavily on infrared illumination or monochrome imaging, Lightfinder 2.0 preserves natural colors and fine details even when illumination levels drop significantly.

The AXIS 02326-001 P3265-v uses optimized sensors and advanced image processing to deliver usable color video in near-darkness. This capability enhances situational awareness and forensic value, allowing operators to distinguish colors of clothing, signage, or objects without relying solely on supplemental lighting.

Enhanced Visibility Without Compromising Discretion

In indoor environments where visible lighting or IR illumination may be undesirable, Lightfinder 2.0 provides a discreet alternative. Cameras can operate effectively in ambient light conditions, maintaining a low-profile appearance while still delivering high-quality video. This is particularly beneficial in offices, hotels, museums, and healthcare settings where aesthetics and occupant comfort are important considerations.

Discreet Fixed Dome Design for Indoor Installations

The fixed dome form factor is a cornerstone of this camera category, offering a balance between visibility and subtlety. Dome cameras are less obtrusive than traditional box cameras and blend seamlessly into ceilings and architectural designs. The AXIS P3265-v exemplifies this approach with a compact, discreet housing that supports professional surveillance without drawing unnecessary attention.

This category emphasizes vandal resistance and durability alongside aesthetics. Despite their subtle appearance, these cameras are built to withstand physical impact and tampering attempts, ensuring reliable operation in both public and semi-public indoor areas.

IK10 Vandal Resistance and Dust Protection

An IK10-rated housing places the AXIS 02326-001 P3265-v within a robust class of indoor cameras designed for demanding environments. Vandal resistance is essential in areas such as schools, transportation terminals, retail stores, and building entrances where cameras may be exposed to accidental or intentional impact.

Dust-resistant construction further enhances longevity and reduces maintenance requirements. Cameras in this category are engineered for long-term deployment, maintaining consistent performance even in environments with airborne particles or variable indoor conditions.

Varifocal P-Iris Lens with Remote Zoom and Focus

Optical flexibility is a defining feature of high-performance fixed dome cameras. The varifocal 3.4–8.9 mm P-iris lens used in this category allows precise control over field of view and depth of field. Installers can adjust framing remotely, ensuring optimal coverage without the need for physical access after installation.

The P-iris mechanism enhances image sharpness by controlling the iris position with high precision. This results in improved contrast, better depth of field, and consistent image quality across varying lighting conditions.

Precision Framing for Diverse Indoor Use Cases

Remote zoom and focus capabilities enable efficient deployment and ongoing optimization. Security teams can fine-tune camera views as layouts change or surveillance requirements evolve. This flexibility is particularly valuable in dynamic environments such as retail stores, warehouses, and corporate offices where camera positioning may need periodic adjustment.

Multiple, Individually Configurable Video Streams

Cameras in this category are designed to support complex surveillance ecosystems by offering multiple, independently configurable video streams. This allows different stakeholders or systems to access video feeds optimized for their specific needs. High-resolution streams can be used for recording and forensic analysis, while lower-resolution streams support live monitoring or mobile access.

The AXIS P3265-v supports flexible stream configuration, enabling efficient bandwidth management without compromising image quality where it matters most.

Optimized Bandwidth Utilization Across Networks

By tailoring stream parameters such as resolution, frame rate, and compression, organizations can ensure optimal performance across diverse network infrastructures. This is especially important in large-scale deployments where hundreds or thousands of cameras may operate simultaneously.

Advanced Video Compression with H.264, H.265, and Zipstream

Efficient video compression is central to this category, as high-resolution and high-frame-rate video can place significant demands on storage and network resources. Support for H.264 and H.265 ensures compatibility with modern video management systems while delivering high compression efficiency.

Axis Zipstream technology further enhances efficiency by dynamically reducing bitrate without sacrificing critical image details. Zipstream analyzes scene content and prioritizes areas of interest, ensuring that essential forensic information is preserved while minimizing storage consumption.

Motion JPEG for Compatibility and Flexibility

In addition to advanced codecs, support for Motion JPEG provides flexibility for integration with legacy systems or specialized applications. This multi-codec approach ensures that cameras in this category can adapt to a wide range of operational requirements and system architectures.

HDTV 1080p Resolution with High Frame Rates

Full HD 1080p resolution is a standard benchmark within this category, delivering detailed imagery suitable for identification and analysis. The AXIS 02326-001 P3265-v supports HDTV 1080p streaming at up to 60 frames per second, enabling smooth capture of fast-moving subjects.

High frame rates are particularly valuable in indoor environments with significant movement, such as transportation facilities, manufacturing floors, and retail spaces. Even when Forensic WDR is enabled, the camera maintains a strong balance between image quality and temporal resolution.

Capturing Motion with Clarity and Accuracy

By combining high resolution with high frame rates, cameras in this category reduce motion blur and improve the clarity of recorded events. This enhances both real-time monitoring and post-event investigation, supporting more confident decision-making.

AXIS Object Analytics for Proactive Surveillance

Object-based analytics represent a major evolution in the fixed dome camera category. Instead of relying solely on motion detection, modern cameras analyze scenes to identify and classify specific objects. The AXIS P3265-v supports AXIS Object Analytics, enabling reliable detection of humans and vehicles while minimizing false alarms.

This capability allows organizations to shift from reactive surveillance to proactive security strategies. Alerts can be configured based on object type, movement patterns, and defined zones, providing actionable intelligence rather than raw video data.

Reducing False Positives and Operator Fatigue

Traditional motion detection often generates false alarms due to lighting changes, shadows, or background movement. Object analytics powered by deep learning significantly reduce these false positives, allowing security teams to focus on meaningful events. This improves operational efficiency and enhances overall system effectiveness.

Video Motion Detection and Tampering Alarm

In addition to advanced object analytics, this category continues to support refined video motion detection for flexible event triggering. Motion detection can be customized to specific areas and sensitivity levels, complementing object-based analytics in complex scenarios.

Tampering alarms provide an additional layer of protection by detecting attempts to obstruct, redirect, or damage the camera. These alarms ensure that surveillance coverage remains intact and that incidents involving camera interference are promptly addressed.

Maintaining System Integrity and Reliability

By combining motion detection with tampering alerts, cameras like the AXIS 02326-001 P3265-v support comprehensive system monitoring. This dual approach ensures both environmental awareness and device-level security, reinforcing trust in the surveillance infrastructure.

Scalable Integration with Professional Surveillance Systems

Fixed dome cameras in this category are designed for seamless integration with professional video management systems and broader security platforms. Open standards and robust APIs enable interoperability with access control systems, alarm management software, and analytics platforms.

This integration capability allows organizations to build unified security ecosystems that scale with operational needs. Cameras become intelligent sensors within a larger framework, contributing data and insights beyond simple video capture.

Applications Across Enterprise and Institutional Environments

The AXIS 02326-001 P3265-v and similar cameras are well-suited for a wide range of indoor applications. Corporate offices benefit from discreet monitoring and advanced analytics that support safety and asset protection. Retail environments leverage high-quality imaging and object detection to reduce shrinkage and improve operational insights.

Healthcare facilities, educational institutions, and transportation hubs rely on the durability, reliability, and intelligence of this category to maintain secure and well-monitored spaces. The combination of image quality, analytics, and robust design ensures adaptability across diverse use cases.

Long-Term Value Through Reliability and Innovation

This category emphasizes long-term investment value through durable construction, regular firmware updates, and ongoing analytics development. Cameras like the AXIS P3265-v are designed to remain relevant as security requirements evolve, supporting new applications and capabilities over their operational lifespan.

By integrating advanced imaging, deep learning analytics, and efficient compression technologies, this class of fixed dome cameras represents a forward-looking approach to indoor surveillance, delivering consistent performance, actionable intelligence, and scalable security solutions.
