BCM957810A1008G Broadcom 57810S Dual Port 10GbE Ethernet PCIe Adapter

Overview of the Broadcom Dual Ports Adapter

The BCM957810A1008G Broadcom 57810S Dual Port 10GbE Ethernet PCIe Adapter is designed for enterprise environments that require reliable, high-bandwidth network connectivity. Built around the Broadcom 57810S controller, this adapter delivers dual-port 10 Gigabit Ethernet performance while supporting advanced networking technologies required by modern data centers, virtualization infrastructures, cloud deployments, and storage networks.

Specifications of the Adapter

• Manufacturer: Broadcom
• Part Number: BCM957810A1008G
• Product Type: Network Adapter

Technical Specifications

• Controller Chipset: Broadcom NetXtreme II BCM57810S MAC
• Port Count: 2 physical network interfaces
• Bandwidth Capacity: 10 Gbps per port in full-duplex mode
• Aggregate Throughput: 20 Gbps combined multi-port capacity
• Host Interface: PCI Express (PCIe) Gen 2.0 (5.0 GT/s data rate)
• PCIe Slot Requirement: Mechanical and electrical x8 lane width slot configuration
• Cabling Medium (RJ-45 Option): Standard Twisted-Pair Category 6A / Category 7 copper cabling
• Cabling Medium (SFP+ Option): Direct Attach Copper (DAC) twinax or SFP+ Optical Transceivers
• Physical Form Factor: Short, low-profile plug-in PCIe adapter card
• Power Profile Efficiency: Approximately 10W standard drawing footprint during full operations

Advanced Networking Features

• Processor Burden Relief: Complete TCP/IP Hardware Protocol Engine Offload (TOE)
• Network Storage Support: Native internal Hardware iSCSI Host Bus Adapter initialization
• Storage Consolidation: Complete Fibre Channel over Ethernet (FCoE) offload processing
• Traffic Management: Data Center Bridging (DCB) congestion and quality optimization controls
• VLAN Isolation Engine: Hardware-driven IEEE 802.1Q virtual local area network tagging
• Remote Server Startup: Integrated Preboot Execution Environment (PXE 2.0) bootstrap launcher
• San Storage Boot: Remote iSCSI and FCoE direct Storage Area Network boot sequences
• Port Virtual Partitioning: Dynamic network slicing allocations to segment individual port

Compatibility

• Microsoft Server Environment: Fully validated
• Microsoft Client Environment: Driver deployment supported via internal updates on Windows 10 and Windows 11.
• Red Hat Linux Family: Mainline native driver integration within Red Hat Enterprise Linux (RHEL) 5 through 9.
• SUSE Linux Platforms: Fully compatible out of the box with SUSE Linux Enterprise Server (SLES) 10, 11, 12, and 15.
• Debian Ecosystem: Standard driver support for Debian variants including Ubuntu Desktop/Server distributions.
• Proxmox Virtual Environment: Native support inside Proxmox VE via the Linux kernel's standard module framework.
• VMware ESXi 7/8 Exceptions: Dropped heritage legacy drivers; hardware storage offload features (HW iSCSI/FCoE) are unavailable under modern
• Virtual Machine Density: Single-Root I/O Virtualization (SR-IOV) hardware allocation.
• Hyper-V Enhancements: Microsoft Virtual Machine Queue (VMQ) traffic delivery steering.
• VMware NetQueue Engine: Dynamic physical network queue sorting optimization for virtual environments.

Compatible environments commonly include

• Windows Server platforms.
• Linux distributions.
• VMware virtualization environments.
• Hypervisor-based infrastructures.
• Private cloud platforms.
• Enterprise server architectures.
• Data center systems.

The Broadcom 57810S Dual Port 10GbE Ethernet PCIe Adapter

Organizations that demand scalable networking solutions often rely on dual-port 10GbE adapters to improve throughput and reduce latency. The BCM957810A1008G provides a balance of performance, efficiency, and compatibility, making it suitable for servers, blade systems, virtualization clusters, and storage environments that require consistent high-speed data transmission. Featuring a PCI Express interface, the adapter integrates seamlessly into compatible server platforms while supporting multiple operating systems and network architectures. The combination of enterprise-grade reliability and advanced networking capabilities makes the Broadcom 57810S adapter a valuable component for mission-critical applications.

Dual-Port 10 Gigabit Ethernet Architecture

The BCM957810A1008G utilizes a dual-port architecture that enables simultaneous network connections. Each port is capable of delivering up to 10 Gigabits per second, significantly improving bandwidth availability compared with conventional Gigabit Ethernet adapters.

By utilizing two independent 10GbE interfaces, organizations can distribute traffic efficiently and maintain uninterrupted communication even if one connection experiences issues.

Benefits of High-Speed 10GbE Connectivity

Modern applications generate enormous amounts of data, requiring network infrastructure capable of sustaining high throughput. The Broadcom 57810S adapter helps eliminate bandwidth constraints while improving application responsiveness. These capabilities make the adapter suitable for environments where network speed directly impacts productivity and application efficiency.

PCI Express Interface Integration

The BCM957810A1008G Broadcom 57810S adapter utilizes a PCI Express interface to provide high-bandwidth communication between the network controller and the host server. PCIe architecture ensures that data transmission between the server and network adapter remains efficient even under heavy workloads. The combination of PCIe performance and 10GbE capabilities enables the adapter to support demanding workloads without creating performance bottlenecks.

Broadcom 57810S Controller Technology

The Broadcom 57810S network controller is engineered to provide reliable Ethernet performance in enterprise environments. It incorporates advanced processing features that help optimize network traffic and improve overall efficiency.

The controller supports sophisticated packet handling mechanisms that reduce CPU overhead and allow servers to dedicate more resources to application workloads. This contributes to improved system responsiveness and higher efficiency across virtualized and physical infrastructures.

Hardware Offload Capabilities

Hardware acceleration technologies integrated into the Broadcom 57810S controller help optimize network performance and reduce processor utilization. These hardware functions allow the adapter to process networking tasks more efficiently, improving throughput while minimizing CPU consumption.

Virtualization Support and Cloud Infrastructure Compatibility

Virtualization environments place significant demands on network resources. The BCM957810A1008G Broadcom 57810S Dual Port 10GbE Ethernet PCIe Adapter is designed to support these requirements by delivering high-performance connectivity for virtual machines and cloud applications.

As organizations increasingly adopt virtualization technologies, network adapters must provide scalability and traffic isolation capabilities that maintain performance across multiple workloads.

Virtual Machine Performance Optimization

High-density virtualized servers benefit from advanced network features that help distribute traffic efficiently among numerous virtual machines. The adapter helps maintain consistent communication between virtual machines and external resources while supporting demanding enterprise applications.

Cloud Computing Applications

Cloud infrastructures require high-speed connectivity to support dynamic workloads and rapid data exchange. The Broadcom 57810S adapter provides the bandwidth and reliability necessary for private cloud, hybrid cloud, and enterprise cloud deployments.

Storage Networking Capabilities

Storage infrastructures depend heavily on low-latency communication and high throughput. The BCM957810A1008G adapter supports data-intensive storage applications that require efficient network connectivity. Enterprise storage environments often involve continuous transfers of large data sets. The Broadcom 57810S helps ensure that storage traffic flows efficiently while minimizing delays.

Enterprise Server Deployment Scenarios

The BCM957810A1008G Broadcom 57810S Dual Port 10GbE Ethernet PCIe Adapter is suitable for a broad range of enterprise deployments. Its versatility enables integration into numerous server configurations and network architectures.

Database Servers

Database workloads require low-latency communication and rapid data exchange. The Broadcom 57810S adapter supports these requirements by delivering consistent network throughput and reliable connectivity.

Application Servers

Application servers hosting business-critical software benefit from high-speed networking that minimizes delays and improves user experience. Dual-port architecture helps maintain availability and traffic distribution.

Web Hosting Platforms

Web servers and hosting environments often process large volumes of simultaneous requests. High-bandwidth Ethernet connectivity enables efficient handling of these workloads while maintaining responsiveness.

Virtualization Clusters

Clustered environments rely on robust communication between nodes. The BCM957810A1008G facilitates reliable inter-server communication, supporting migration operations and distributed workloads.

High-Performance Computing Environments

Compute-intensive applications generate significant amounts of network traffic. The Broadcom 57810S adapter helps ensure rapid data transfer between systems, contributing to improved processing efficiency.

Network Reliability and Availability Features

Enterprise infrastructures require dependable networking components capable of operating continuously under demanding conditions. The BCM957810A1008G is engineered to provide stable performance and high availability. Dual-port configurations contribute to resilience by enabling redundancy and failover mechanisms that protect against network interruptions.

Operating System and Platform Compatibility

The Broadcom 57810S Dual Port 10GbE Ethernet PCIe Adapter is designed for compatibility with various enterprise operating systems and server environments. Broad support allows organizations to integrate the adapter into existing infrastructures without extensive modifications. This flexibility simplifies deployment and supports diverse IT requirements.

Data Center Networking Applications

Modern data centers depend on efficient communication among servers, storage systems, and network resources. The BCM957810A1008G Broadcom 57810S adapter provides the throughput necessary for demanding workloads and high-density environments.

Scalability for Expanding Networks

As network demands increase, organizations require infrastructure components that can accommodate future growth. The BCM957810A1008G offers scalability that aligns with evolving business requirements. Its dual-port design and high-bandwidth capabilities enable organizations to expand workloads while maintaining network performance. This makes the adapter suitable for businesses planning long-term infrastructure growth and modernization.

The Broadcom 57810S controller architecture delivers a combination of performance, reliability, compatibility, and efficiency that supports a wide range of enterprise networking applications. From virtualization clusters and cloud infrastructures to storage systems and high-performance servers, the BCM957810A1008G Broadcom 57810S Dual Port 10GbE Ethernet PCIe Adapter remains an effective solution for organizations requiring dependable 10 Gigabit Ethernet connectivity.
