Cisco C9120AXE-E Catalyst 9120 WiFi 6 AP

Cisco Catalyst C9120AXE-E Wireless Access Point Overview

• Manufacturer: Cisco
• Part Number (SKU): C9120AXE-E
• Product Line: Catalyst
• Product Series: 9120
• Device Type: Wireless Access Point

Advanced Wireless Connectivity

• Wireless Standard: 802.11ax for faster speeds and improved performance
• Bluetooth Standard: Bluetooth 5.0, ideal for IoT devices
• Dual Frequency Bands: 2.4 GHz and 5 GHz for versatile connectivity
• Data Transfer Rate: Up to 5.38 Gbps ensuring rapid data transmission
• MIMO Technology: Delivers multiple data streams simultaneously for improved efficiency
• Beamforming: Enhances wireless coverage by focusing the signal strength

Wi-Fi 6 with Integrated Antenna System

• Flexible radio configuration on either 2.4 GHz or 5 GHz
• 2.4 GHz Antenna: Peak gain of 4 dBi, internal, omnidirectional
• 5 GHz Antenna: Peak gain of 5 dBi, internal, omnidirectional
• Dedicated 5 GHz radio: Additional peak gain of 4 dBi, omnidirectional
• Smart Antenna Connector: Uses DART interface for multi-RF applications
• Compatible with AIR-CAB002-DART-R= 2 ft smart antenna connector (sold separately)

Network Interfaces & Connectivity

• 1x Multigigabit Ethernet (RJ-45) supporting 100, 1000, 2500 speeds
• USB 2.0 interface with 3.75W power (enabled by future updates)
• Management Console Port (RJ-45)

Visual Status Indicators

• Status LED: Indicates boot loader activity, device association, operational status, and error notifications

Power Supply Options and Consumption

• Supports Power over Ethernet (PoE+) 802.3at, Cisco UPOE
• Optional power injector: AIR-PWRINJ6= (sold separately)
• Power draw with PoE+ (802.3at): 25.5W for full-feature mode
• Power draw with PoE (802.3af): 13.4W with limited radio functionality

Power Consumption Breakdown

• PoE+ (802.3at):
  • 2.4 GHz radio: 4x4 MIMO
  • 5 GHz radio: 4x4 MIMO
  • Link Speed: 2.5G
  • USB: Enabled
  • LLDP Power: 25.5W
• PoE (802.3af):
  • 2.4 GHz radio: 2x2 MIMO
  • 5 GHz radio: Disabled
  • Link Speed: 1G
  • USB: Disabled
  • LLDP Power: 13.4W

Environmental Conditions

• Non-operating temperature range: -30ºC to 70ºC (-22ºF to 158ºF)
• Storage altitude limit: 15,000 ft. at 25ºC
• Operating temperature range: -20ºC to 50ºC (-4ºF to 122ºF)
• Operating humidity: 10% to 90%, non-condensing
• Operating altitude limit: 9,843 ft. at 40ºC

Internal Memory Specifications

• System Memory: 2048 MB DRAM
• Flash Memory: 1024 MB

Optional External Antenna Support

• Supports antenna gains up to 6 dB on both 2.4 GHz and 5 GHz bands
• Certified with Self-Identifiable Antennas (SIA) via one RP-TNC port
• Broad selection of Cisco antennas available to optimize deployment

Supported Networking & Management Protocols

• Transport Protocol: IPSec
• Remote Management Protocols: RESTCONF, NETCONF
• Supported Standards: IEEE 802.11ac, 802.11n, 802.11ax, 802.11b, 802.11g, and IPv6
• Bluetooth 5.0 for enhanced IoT connectivity
