Cisco Catalyst Switch WS-C2960L-24TS-LL 24 Ports SFP Layer 4

Ports

The Cisco WS-C2960L-24TS-LL Switch is equipped with 24 ports, making it an ideal choice for small to medium-sized businesses that require a reliable and scalable network solution. These ports provide the necessary connectivity for various devices, such as computers, printers, IP phones, and access points.

Overview of the Cisco WS-C2960L-24TS-LL Switch

Product Details

The Cisco WS-C2960L-24TS-LL is a robust Ethernet switch designed for high-performance networking needs. It belongs to Cisco's Catalyst 2960-L series, offering exceptional functionality and reliability.

Key Specifications

• Manufacturer: Cisco
• Model Number: WS-C2960L-24TS-LL
• Product Line: Catalyst
• Series: 2960-L
• Type: Ethernet Switch

Network Interfaces and Ports

Total Ports and Slots

• Network Ports: 24 Gigabit Ethernet ports
• Uplink Ports: 4 x 10 Gigabit Ethernet uplinks
• Expansion Slots: 4 SFP slots

Port Configuration

This model includes:

• 24 Gigabit Ethernet network ports
• 4 x 10 Gigabit Ethernet uplinks
• 4 SFP slots for additional connectivity options

Performance and Capabilities

Switching and Forwarding

• Switching Bandwidth: 56 Gbps
• Forwarding Bandwidth: 28 Gbps

VLAN and MAC Address Support

• MAC Addresses: Up to 8000
• Supported VLANs: 4094
• Active VLANs: 64

Management and Protocols

Management Features

• Manageable: Yes
• Routing Protocol: IGMP
• Remote Management: SNMP 3, CLI

Hardware and Power Specifications

Processor and Memory

• Processor Type: ARM7
• Clock Speed: 800 MHz
• Installed RAM: 512 MB

Power Requirements

• Power Source: Power Supply
• Redundant Power Supply: Not Supported
• Voltage Required: AC 120/230 V (50 – 60 Hz)

Standards and Compliance

• IEEE 802.3
• IEEE 802.3u
• IEEE 802.3z
• IEEE 802.1D
• IEEE 802.1p
• IEEE 802.3x
• IEEE 802.3ad (LACP)
• IEEE 802.1x
• IEEE 802.3ah
• IEEE 802.3az

Increased Connectivity

With 24 ports, this switch offers users the ability to connect multiple devices to their network without the need for additional equipment. This feature is particularly beneficial for growing businesses that require more connectivity options as they expand. It eliminates the need to invest in additional switches or hubs, saving both time and money.

Flexibility

The 24 ports on the Cisco WS-C2960L-24TS-LL Switch can be used for a variety of purposes, providing users with the flexibility to configure their network as per their specific requirements. Whether it's creating separate VLANs for different departments or setting up dedicated connections for critical devices, the ample number of ports ensures that there are enough options available to meet the needs of any network setup.

Improved Performance

Having 24 ports allows for better network performance and reduces bottlenecks. With more ports available, each device can have its dedicated connection, ensuring faster data transfer speeds and minimizing network congestion. This is especially important in environments where high-bandwidth applications are used or where large amounts of data need to be transferred quickly.

Interface

The Cisco WS-C2960L-24TS-LL Switch features SFP (Small Form-Factor Pluggable) interfaces, which offer users a range of benefits and importance when it comes to networking and connectivity options.

Flexibility in Connectivity

The SFP interfaces on this switch provide users with the flexibility to connect to various types of network media, such as fiber optic cables or copper Ethernet cables. This versatility allows businesses to choose the most suitable and cost-effective medium for their specific needs. Whether it's connecting to remote locations or establishing long-distance connections, the SFP interfaces enable seamless integration into existing network infrastructures.

Scalability

The SFP interfaces also offer scalability options for businesses that anticipate future growth or expansion. These interfaces can support higher data transfer rates, allowing for more bandwidth-intensive applications and accommodating increasing network demands. This scalability ensures that the Cisco WS-C2960L-24TS-LL Switch can adapt to evolving business requirements without the need for a complete infrastructure overhaul.

Interoperability

One of the key advantages of SFP interfaces is their interoperability with a wide range of networking equipment. This means that users can easily integrate the Cisco WS-C2960L-24TS-LL Switch into their existing network infrastructure without compatibility issues. The ability to work with different manufacturers' devices ensures seamless connectivity and simplifies the process of expanding or upgrading the network.

Layer

The Cisco WS-C2960L-24TS-LL Switch operates at Layer 4 of the OSI (Open Systems Interconnection) model, providing users with a range of benefits and importance in terms of network functionality and security.

Enhanced Network Control

Operating at Layer 4 allows for granular control over network traffic and enables features such as access control lists (ACLs) and quality of service (QoS). ACLs allow administrators to define rules and policies for controlling traffic flow, ensuring that only authorized users or devices can access specific resources. QoS, on the other hand, prioritizes certain types of traffic, ensuring that critical applications or services receive the necessary bandwidth and performance.

Improved Network Security

Layer 4 switches offer enhanced security features compared to lower layer switches. With the ability to inspect traffic at the transport layer, Layer 4 switches can identify and mitigate potential threats, such as DDoS attacks or unauthorized access attempts. This added layer of security helps protect the network infrastructure and sensitive data from malicious activities, providing peace of mind to businesses.

Optimized Performance

Layer 4 switches optimize network performance by intelligently routing traffic based on specific criteria, such as source IP, destination IP, or port numbers. This allows for load balancing and efficient utilization of network resources, ensuring that critical applications or services receive optimal performance. By effectively managing network traffic, Layer 4 switches can minimize bottlenecks and reduce latency, resulting in a smoother and more responsive network experience for users.

In conclusion, the Cisco WS-C2960L-24TS-LL Switch offers numerous benefits and importance through its 24 ports, SFP interfaces, and Layer 4 functionality. The ample ports provide increased connectivity, flexibility, and improved performance for growing businesses. The SFP interfaces offer flexibility in connectivity options, scalability, and interoperability with other networking equipment. Operating at Layer 4 enables enhanced network control, improved security measures, and optimized performance. Overall, this switch is a reliable and feature-rich solution for businesses seeking a scalable and efficient network infrastructure.
