Cisco Catalyst WS-C3850-24U-L 24 Port Rack-mountable Switch

Overview of Cisco WS-C3850-24U-L Switch

Manufacturer Details

• Brand: Cisco
• Model Number: WS-C3850-24U-L
• Product Category: Network Switch

Device Specifications

• Type: Managed Switch with 24 Ports
• Mounting Options: Desktop or Rack-mountable (1U)
• Port Type: Gigabit Ethernet
• Port Count: 24 x 10/100/1000 (UPOE)

Power and Performance

• Power Over Ethernet (POE): UPOE
• POE Budget: 800W
• Switching Capacity: 92 Gbps
• Stacking Bandwidth: 480 Gbps

Capacity and Table Sizes

• IPv4 Routes: 24,000
• Netflow Entries: 24,000
• Switched Virtual Interfaces (SVIs): 1,000
• MAC Address Table Size: 32,000 Entries
• Jumbo Frame Support: 9,198 Bytes

Management and Protocols

• Remote Management: SNMP 1, RMON 1 & 2, Telnet, SNMP 2c & 3, SSH, CLI
• Protocol Support: Auto-negotiation, ARP, Trunking, VLAN, Auto-uplink (Auto MDI/MDI-X)

Advanced Features

• IGMP Snooping
• Syslog Support
• IPv6 Support
• Rapid Spanning Tree Protocol (RSTP)
• Multiple Spanning Tree Protocol (MSTP)
• DHCP Snooping
• Dynamic Trunking Protocol (DTP)
• Port Aggregation Protocol (Pagp)
• Trivial File Transfer Protocol (TFTP)
• Access Control Lists (ACL)
• Quality of Service (QoS)
• RADIUS Support
• Virtual Route Forwarding-Lite (VRF-Lite)
• MLD Snooping
• Dynamic ARP Inspection (DAI)
• STP Root Guard
• Uni-directional Link Detection (UDLD)
• Rapid Per-VLAN Spanning Tree Plus (PVRST+)
• IPv4 Support
• Shaped Round Robin (SRR)
• Link Aggregation Control Protocol (LACP)
• Remote Switch Port Analyzer (RSPAN)
• Layer 3 Load Balancing
• Energy Efficient Ethernet
• Universal Power Over Ethernet (UPOE)
• Cisco StackWise-480 Technology
• Cisco StackPower Technology
• Flexible NetFlow (FnF)

Standards Compliance

• IEEE 802.3
• IEEE 802.3u
• IEEE 802.3z
• IEEE 802.1D
• IEEE 802.1Q
• IEEE 802.3ab
• IEEE 802.1p
• IEEE 802.3af
• IEEE 802.3x
• IEEE 802.3ad (LACP)
• IEEE 802.1w
• IEEE 802.1x
• IEEE 802.1s
• IEEE 802.3at

Power Specifications

• Input Voltage: AC 120/230V (50/60 Hz)
• Redundant Power: Optional

Port Count

Introduction to Port Count

The Cisco WS-C3850-24U-L Rack-mountable Switch is equipped with a remarkable 24 ports, making it an ideal choice for businesses and organizations that require a high-density network infrastructure. The port count refers to the total number of physical ports available on the switch, which enables the connection of various network devices, such as computers, servers, printers, and IP phones. This feature provides users with the flexibility and scalability required to meet the growing demands of their network.

Benefits of 24 Port Count

1. Increased Connectivity

With 24 ports, this Cisco switch offers a significant increase in connectivity options compared to switches with fewer ports. This allows businesses to connect a greater number of devices directly to the switch without the need for additional networking equipment. The increased connectivity eliminates the need for additional switches or hubs, simplifying the overall network infrastructure and reducing costs.

2. Scalability

The 24-port count of the Cisco WS-C3850-24U-L Rack-mountable Switch ensures scalability and future-proofing for businesses. As companies expand and add more devices to their network, having ample ports allows them to easily accommodate new connections without the need for costly upgrades or investments in additional networking equipment. This scalability ensures that businesses can seamlessly grow their network infrastructure as needed.

3. Improved Network Performance

Having multiple ports on a switch enables efficient data transfer between devices connected to the network. The 24-port count of this Cisco switch ensures that bandwidth is evenly distributed across devices, preventing congestion and optimizing network performance. Users can experience faster data transfer rates and reduced latency, resulting in improved productivity and enhanced user experience.

4. Enhanced Flexibility

The Cisco WS-C3850-24U-L Rack-mountable Switch's 24 port count offers users the flexibility to connect a wide range of network devices simultaneously. This switch is suitable for small to medium-sized businesses, where a variety of devices are used, such as computers, printers, IP phones, and wireless access points. The increased port count allows for seamless integration of these devices, enabling efficient communication and collaboration within the network.

Importance of 24 Port Count

1. Accommodating Growth

As businesses grow and evolve, their network requirements also increase. The 24-port count of the Cisco WS-C3850-24U-L Rack-mountable Switch ensures that businesses have the necessary capacity to accommodate new devices and users on their network. This prevents bottlenecking and performance issues that can arise when a network lacks sufficient ports for expansion.

2. Cost-effective Solution

Investing in a switch with a higher port count, such as the Cisco WS-C3850-24U-L, initially may seem like an additional expense. However, it is a cost-effective solution in the long run. By having 24 ports available, businesses can avoid purchasing multiple switches or additional networking equipment to meet their connectivity needs. This reduces upfront costs and simplifies network management.

3. Streamlined Network Infrastructure

A switch with 24 ports allows for a streamlined network infrastructure by eliminating the need for additional devices like switches or hubs. With fewer devices to manage and maintain, network administrators can save time and effort in troubleshooting and maintenance tasks. Additionally, a simplified infrastructure reduces complexity and potential points of failure, resulting in a more reliable network.

4. Future-proofing

Investing in a switch with a higher port count is a forward-thinking decision that future-proofs the network infrastructure. As technology continues to advance, the demand for network connectivity will only increase. By choosing a switch with 24 ports, businesses are prepared to meet the future needs of their growing network without the need for immediate upgrades or replacements.

Conclusion

The 24-port count feature of the Cisco WS-C3850-24U-L Rack-mountable Switch is essential for businesses and organizations that require a reliable, scalable, and high-performance network infrastructure. With increased connectivity options, improved network performance, and enhanced flexibility, this switch enables businesses to meet their current needs while accommodating future growth. Furthermore, the cost-effectiveness and streamlined nature of a higher port count ensure that businesses can efficiently manage their network without compromising on performance or scalability.
