CGS-2520-16S-8PC Cisco Connected Grid Ethernet Switch with 8 Ports

Cisco CGS-2520-16S-8PC Connected Grid Managed Switch Overview

The Cisco CGS-2520-16S-8PC is a robust managed switch designed for high-performance networking environments. Ideal for businesses requiring reliable connectivity, this switch combines versatility with advanced technology.

Manufacturer & Product Details

• Brand: Cisco
• Model / SKU: CGS-2520-16S-8PC
• Product Type: Ethernet Switch
• Switch Category: Managed 8-Port Switch

Key Features of the Cisco CGS-2520-16S-8PC

• Total Network Ports: 10 for seamless device connectivity
• Uplink Ports: Available for network expansion
• USB Port: Included for configuration and updates
• Power over Ethernet (PoE) RJ-45 Ports: 8, supporting connected devices efficiently

Port & Expansion Configuration

• Fast Ethernet Ports: 8
• Gigabit Ethernet Uplink Ports: 2
• Fast Ethernet Expansion Slots: 16
• Gigabit Ethernet Expansion Slots: 2

Performance & Network Technology

• High-Speed Ethernet: Gigabit Ethernet ensures rapid data transfer
• Standard Connections: Fast Ethernet supports everyday networking
• Network Compatibility:
  • 10/100Base-TX for Fast Ethernet connections
  • 10/100/1000Base-T for Gigabit Ethernet connectivity

Memory & Storage Capabilities

• SFP Slots: 16 Small Form-Factor Pluggable slots for flexible fiber optic connections
• Standard Memory: 256 MB DDR2 SDRAM for smooth data handling
• Memory Card Support: Compatible with Secure Digital (SD) cards for additional storage

Cisco CGS-2520-16S-8PC Connected Grid 8 Ports Managed Switch

The Cisco CGS-2520-16S-8PC Connected Grid Switch is a high-performance managed Ethernet switch designed specifically for industrial environments and mission-critical applications. With a focus on reliability, energy efficiency, and robust network performance, this switch provides seamless connectivity for smart grid, utility, and automation networks. Equipped with advanced Layer 2 and Layer 3 capabilities, the CGS-2520 series enables businesses to streamline operations while maintaining high security and operational continuity.

Advanced Network Management Capabilities

The CGS-2520-16S-8PC is engineered for professional-grade network management. It supports comprehensive monitoring, diagnostic, and troubleshooting functions, allowing network administrators to optimize traffic flow and maintain consistent performance across the network. Features such as VLAN segmentation, QoS prioritization, and link aggregation provide granular control over network resources, ensuring critical applications receive the bandwidth and reliability they require. Additionally, the switch supports SNMP and other standard network management protocols, facilitating integration with existing monitoring frameworks.

VLAN and QoS Support

Virtual LAN (VLAN) support enables logical segmentation of networks, improving security and performance by isolating traffic between different network zones. Quality of Service (QoS) prioritizes critical traffic, ensuring low-latency communication for time-sensitive applications. These features are particularly beneficial in industrial automation and smart grid networks, where predictable performance is crucial. The switch’s ability to handle multiple VLANs simultaneously allows organizations to scale networks efficiently without compromising control or security.

Link Aggregation and Redundancy

The Cisco CGS-2520 series supports link aggregation, allowing multiple physical connections to operate as a single logical link. This increases bandwidth and provides redundancy, ensuring uninterrupted connectivity even in the event of a single link failure. Combined with Spanning Tree Protocol (STP) and Rapid STP support, the switch delivers a resilient network topology that minimizes downtime and enhances operational reliability.

High-Performance Connectivity and PoE Support

Featuring 8 Power over Ethernet (PoE) ports, the CGS-2520-16S-8PC supports both data transmission and device powering over a single Ethernet cable. This simplifies network deployment by reducing cabling requirements for devices such as IP cameras, sensors, and industrial controllers. The switch ensures consistent power delivery while maintaining high-speed data transfer, supporting the simultaneous operation of multiple devices without performance degradation.

Industrial-Grade Reliability

Designed for deployment in harsh industrial environments, the Cisco Connected Grid switch is rated for wide temperature ranges, vibration resistance, and electromagnetic interference tolerance. This rugged construction ensures long-term reliability and minimizes maintenance costs. By delivering robust performance under challenging conditions, the CGS-2520 series is ideal for critical infrastructure networks, including power utilities, transportation systems, and manufacturing plants.

Energy Efficiency and Green Networking

The switch incorporates energy-efficient technologies that reduce power consumption without compromising performance. With intelligent power management and adaptive PoE allocation, the CGS-2520-16S-8PC optimizes energy usage based on network demands. This not only lowers operational costs but also contributes to sustainable network practices, supporting organizations in achieving environmental goals.

Security Features and Network Protection

Security is a core aspect of the Cisco CGS-2520 series. The switch supports advanced security protocols, including 802.1X port-based authentication, access control lists (ACLs), and DHCP snooping. These features protect the network from unauthorized access and mitigate potential threats such as spoofing and denial-of-service attacks. The inclusion of IP-MAC-Port binding further ensures that only trusted devices can communicate within the network, enhancing overall cybersecurity resilience.

Integrated Management Tools

For efficient network administration, the CGS-2520-16S-8PC provides an intuitive web-based interface alongside command-line interface (CLI) access. Cisco’s network management tools allow centralized monitoring, configuration, and firmware updates, reducing administrative overhead and ensuring consistent network performance. These integrated management solutions support both small-scale and large-scale deployments, making the switch highly adaptable across diverse operational environments.

Applications in Smart Grid and Industrial Networks

The Cisco Connected Grid switch is specifically tailored for smart grid and industrial automation applications. Its robust connectivity, PoE support, and network management features make it ideal for utilities, water treatment facilities, transportation systems, and manufacturing plants. By enabling reliable data exchange between devices, sensors, and control systems, the CGS-2520 series ensures efficient monitoring, rapid response to operational changes, and optimized network performance.

Scalable Network Deployment

Scalability is a key advantage of the CGS-2520-16S-8PC. The switch can be deployed as a standalone unit or integrated into larger network infrastructures. Its combination of fiber and copper ports facilitates flexible network design, accommodating both long-distance connectivity and high-speed local communication. Organizations can expand their networks incrementally while maintaining consistent performance and security across all nodes.

Seamless Integration with Cisco Ecosystem

Compatibility with other Cisco networking solutions ensures seamless integration and unified management. The switch supports Cisco DNA Center, enabling automated provisioning, policy enforcement, and AI-driven insights. This integration simplifies network operations, enhances visibility, and ensures that critical infrastructure networks remain resilient and responsive to changing demands.
