Cisco CS-KITPLUS-K9 Quad Camera Video Conferencing Kit

Features

Includes four cameras for high-quality video conferencing

The Cisco CS-KITPLUS-K9 Quad Camera Video Conferencing Kit is designed to provide users with a high-quality video conferencing experience. With this kit, you will receive four cameras that can be strategically placed in your conference room to capture multiple angles. This allows participants to have a more immersive and engaging video conference, as they can see different perspectives of the room.

Overview of the Cisco CS-KITPLUS-K9

Manufacturer and Model Information

• Manufacturer: Cisco
• Part Number: CS-KITPLUS-K9
• Product Category: Telephony Conferencing Kit

Technical Specifications

VoIP and Networking Protocols

• VoIP Protocols: H.323
• Voice Codecs Supported: G.711, G.722, G.729, G.722.1, AAC-LD, Opus
• Video Codecs: H.264
• Network Protocols: HTTP, DNS, HTTPS, NTP
• IP Address Assignment: DHCP

Quality of Service and Security

• Quality of Service (QoS): IEEE 802.1Q (VLAN), Differentiated Services (DiffServ), IEEE 802.1p
• Security Standards: IEEE 802.1X, H.235 v3

Digital Signaling and Data Compression

• Digital Signaling Protocols: H.323, SIP, H.460.18, H.460.19, BFCP
• Data Compression Protocol: H.264

Video, Audio, and Connectivity Features

Video Specifications

• Type: Digital color video camera (external)
• Interface: HDMI
• Resolution: 3840 x 2160, 1080p
• Supported Display Graphics: 3840×2160
• Video Standard: HDMI (High-Definition Multimedia Interface)

Audio Specifications

• Audio Input: Integrated microphones (6)
• Audio Output: Speaker(s)
• Frequency Response: 70 – 20,000 Hz

Networking and Connectivity

• Connectivity Options: Wireless, Wired
• Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b/g/n/ac, Bluetooth 4.0 LE
• Network/Transport Protocols: NTP, DHCP, DNS
• Additional Features: DiffServ support, Wall mountable, QoS, SSH support, Audio Return Channel (ARC), 4K resolution support, Security lock slot (cable lock sold separately), Automatic Gain Control (AGC), 802.1x authentication, URI Dialing, Administrator’s password
• Compliant Standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x

Expansion and Connectivity Ports

• Video Inputs: 2 x HDMI (19-pin Type A), 1 x HDMI (19-pin Type A)
• Video Outputs: 2 x HDMI (19-pin Type A)
• Audio Outputs: 1 x Mini-phone stereo (3.5 mm), 1 x RCA
• Audio Inputs: 3 x Mini-phone (3.5 mm)
• Network Connections: 3 x RJ-45
• USB Ports: 1 x USB 2.0

Audio Quality and Additional Features

Audio Capabilities

• High-Quality Audio: 20 kHz
• Subwoofer Line Out: For Quad Camera
• Inductive Loop Prepared: Line out
• Automatic Gain Control (AGC): Yes
• Automatic Noise Reduction: Yes
• Active Lip Synchronization: Yes

Power and Miscellaneous Information

Power Requirements

• Power Device: External power supply
• Voltage Required: AC 120/230 V (50/60 Hz)
• Power Consumption (Operational): 70 Watts

Included Accessories and Compliance

• Cables Included: 1 x Network cable (8 meters)
• Mounting Kit: Included
• Compliance Standards: AES, RoHS, WEEE, CEC, Directive 2002/96/EC, Directive 2011/65/EU, FCC CFR47 Part 15 B Class A, Directive 2014/35/EU, Directive 2014/30/EU, Directive 2014/53/EU

Having four cameras also ensures that every participant is visible during the conference. No one will be left out of the conversation or have their presence minimized. This feature is especially important for larger conference rooms or meetings with a significant number of participants.

By including four cameras, this kit eliminates the need for additional equipment or complicated setups. You can easily achieve a professional-looking video conference without the hassle of dealing with multiple devices. This not only saves time but also reduces the risk of technical difficulties during important meetings.

Designed for professional video conferencing setups

The Cisco CS-KITPLUS-K9 Quad Camera Video Conferencing Kit is specifically designed for professional video conferencing setups. Whether you have a small huddle room or a large conference room, this kit provides the necessary components to create a seamless and efficient video conferencing experience.

The cameras included in the kit are carefully engineered to capture high-quality video footage. They are equipped with advanced features such as autofocus and image stabilization, ensuring that the video remains clear and sharp throughout the conference. This attention to detail is crucial, as it allows participants to focus on the content of the meeting rather than being distracted by technical issues.

In addition, the cameras can be easily integrated with existing Cisco video conferencing systems. This compatibility ensures that you can seamlessly incorporate the Quad Camera Video Conferencing Kit into your current setup without any compatibility issues or complicated configurations.

Easy to set up and use

The Cisco CS-KITPLUS-K9 Quad Camera Video Conferencing Kit is designed to be user-friendly and easy to set up. The kit includes all the necessary components and cables, eliminating the need for additional purchases or searching for compatible accessories.

The cameras can be mounted on walls or placed on stands, depending on your preference and the layout of your conference room. The kit comes with detailed instructions that guide you through the setup process, making it accessible even for users with limited technical knowledge.

Once set up, using the Quad Camera Video Conferencing Kit is straightforward. The cameras can be controlled remotely, allowing you to adjust angles and zoom levels without having to physically interact with them. This feature adds convenience and flexibility to your video conferencing experience.

Compatible with Cisco video conferencing systems

One of the key advantages of the Cisco CS-KITPLUS-K9 Quad Camera Video Conferencing Kit is its compatibility with Cisco video conferencing systems. If you already have a Cisco system in place, integrating this kit will be seamless and hassle-free.

By using the Quad Camera Video Conferencing Kit in conjunction with a Cisco system, you can leverage the full capabilities of both products. This compatibility ensures that you can take advantage of advanced features such as screen sharing, document collaboration, and virtual whiteboarding.

In addition, the compatibility with Cisco systems allows for easy scalability. If your organization expands or your video conferencing needs grow, you can easily add more cameras or upgrade your system without having to replace the entire setup. This flexibility is essential in a rapidly changing business environment.

Benefits

The inclusion of four cameras in the Cisco CS-KITPLUS-K9 Quad Camera Video Conferencing Kit offers several benefits to users:

Enhanced visual experience

With four cameras capturing multiple angles, participants can have a more immersive and engaging video conferencing experience. They can see different perspectives of the room, making it feel as if they are physically present. This enhances communication and collaboration, especially in larger conference rooms.

Increased visibility for all participants

No one will be left out of the conversation or have their presence minimized with the Quad Camera Video Conferencing Kit. The four cameras ensure that every participant is visible during the conference, creating a more inclusive atmosphere. This is particularly important for meetings where everyone's input is valuable.

Professional-looking video conferences

The Cisco CS-KITPLUS-K9 Quad Camera Video Conferencing Kit is designed to create a professional-looking video conference without any additional equipment. The high-quality cameras and easy setup contribute to a polished and sophisticated appearance. This is essential when representing your organization to clients, partners, or remote team members.

Easy integration into existing setups

The compatibility of the Quad Camera Video Conferencing Kit with Cisco video conferencing systems allows for easy integration without any compatibility issues or complicated configurations. This saves time and effort, as you can seamlessly incorporate the kit into your current setup without disruptions.

User-friendly setup and operation

The kit includes all necessary components and detailed instructions for hassle-free setup. The cameras can be easily mounted or placed on stands, and remote control functionality adds convenience during operation. Users with limited technical knowledge can set up and use the kit without difficulty.

Importance

The feature of including four cameras in the Cisco CS-KITPLUS-K9 Quad Camera Video Conferencing Kit is of significant importance to users:

Improved collaboration and communication

By capturing multiple angles, the Quad Camera Video Conferencing Kit enhances collaboration and communication during video conferences. Participants can see facial expressions, body language, and other visual cues that are essential for effective communication. This leads to better understanding and more productive discussions.

Increased engagement and participation

The inclusion of four cameras ensures that every participant is visible during the conference, reducing the chances of anyone feeling left out or ignored. This leads to increased engagement and participation from all attendees, resulting in more diverse perspectives and better decision-making.

Efficient use of conference room space

With the Quad Camera Video Conferencing Kit, you can optimize the use of your conference room space. The four cameras can capture different areas of the room, allowing for a more comprehensive view without the need for additional equipment or rearranging furniture. This is especially important in small or limited-space conference rooms.

Flexibility for different meeting scenarios

The ability to adjust angles and zoom levels remotely provides flexibility for different meeting scenarios. Whether you need a wide-angle view or a close-up of specific participants, the Quad Camera Video Conferencing Kit allows you to adapt to different meeting requirements without physically adjusting the cameras.

Seamless integration and scalability

The compatibility with Cisco video conferencing systems ensures seamless integration with your existing setup. This allows for easy scalability as your organization grows or your video conferencing needs change. You can add more cameras or upgrade your system without disrupting your current configuration.

In conclusion, the Cisco CS-KITPLUS-K9 Quad Camera Video Conferencing Kit's feature of including four cameras offers users numerous benefits and is of significant importance. It enhances the visual experience, increases visibility for all participants, creates professional-looking video conferences, and is easy to set up and use. The compatibility with Cisco video conferencing systems adds further value by enabling seamless integration and scalability. With this kit, users can enjoy an immersive, inclusive, and efficient video conferencing experience that facilitates collaboration and communication.
