IE-4010-16S12P= Cisco Layer 3 Ethernet Switch - 28 Ports

Cisco IE-4010-16S12P= Managed Industrial Switch Overview

The Cisco IE-4010-16S12P= is a robust 1U rack-mountable switch designed for industrial environments. Part of the Cisco 4010 Series, it provides a reliable, high-performance solution for network management and connectivity.

Key Specifications

• Manufacturer: Cisco
• Model / SKU: IE-4010-16S12P=
• Device Type: Industrial Ethernet Managed Switch
• Ports: 28 total ports
• Form Factor: 1U Rack Mountable / Din Rail Compatible
• Network Speed: Gigabit Ethernet

Port Configuration

• 12 x 10/100/1000 Mbps (PoE+) RJ-45 ports
• 4 x 10/100/1000 Mbps SFP uplink ports
• 12 x 1000BASE-TX SFP ports
• 1 x Console RJ-45 port
• 1 x Mini-USB Type B port

Performance & Capacity

• Forwarding Bandwidth: 28 Gbps
• Switching Bandwidth: 56 Gbps
• MAC Address Table: 16,000 entries
• VLAN Support: Up to 1,000 virtual interfaces
• IGMP Groups: 1,000
• NAT Translations: 128

Routing & Management

• Supports IGMPv2, IGMPv3, and static IPv4 routing
• Remote management via SNMP v1, v2, v3, RMON 2, Telnet, HTTP, SSH, CLI, and SCP

Power & Reliability

• AC 120/230V (50–60Hz) power requirement
• Redundant power supply supported for enhanced uptime

Expansion & Modularity

• 1 expansion slot (1 free)
• Modular design for flexible deployment in industrial networks

Physical Dimensions & Weight

• Dimensions: 17.5" W x 14" D x 1.8" H
• Weight: 12.74 lbs

Cisco IE-4010-16S12P= Managed Switch Overview

The Cisco IE-4010-16S12P= is a high-performance 1U rack-mountable managed switch designed to meet the demanding requirements of modern industrial and enterprise networks. With 28 ports, including 16 SFP and 12 PoE-enabled Ethernet ports, the switch offers unparalleled connectivity options for both standard and power-over-Ethernet devices. Its robust design is optimized for reliable operation in challenging environments, making it a cornerstone solution for industrial automation, manufacturing, and mission-critical network infrastructures.

Advanced Network Management Capabilities

One of the primary strengths of the Cisco IE-4010-16S12P= lies in its comprehensive network management capabilities. It supports advanced Layer 2 and Layer 3 functionalities, including VLAN segmentation, QoS prioritization, link aggregation, and multicast management. These features allow network administrators to optimize traffic flow, reduce latency, and maintain high availability across the network. The switch integrates seamlessly with Cisco’s management ecosystem, providing centralized monitoring, configuration, and troubleshooting tools through Cisco DNA Center and other supported platforms.

Layer 2 and Layer 3 Functionality

The Cisco IE-4010 series supports both Layer 2 switching and basic Layer 3 routing, enabling efficient packet forwarding within local networks and between subnets. VLAN support allows the creation of segmented network environments to isolate traffic, improve security, and enhance performance. Link aggregation ensures redundancy and increased bandwidth for critical connections, reducing the risk of downtime and network congestion. Multicast support enables efficient transmission of video, audio, and other streaming data, making it suitable for industrial control systems and high-bandwidth applications.

PoE Capabilities for Industrial Applications

With 12 PoE-enabled ports, the Cisco IE-4010-16S12P= can deliver both data and electrical power to connected devices such as IP cameras, wireless access points, and industrial sensors. PoE simplifies network deployment by eliminating the need for separate power cabling, reducing installation costs, and providing centralized power management. Each port is capable of delivering up to 30W, allowing for compatibility with a wide range of devices while maintaining network reliability and energy efficiency.

Industrial-Grade Reliability and Rugged Design

Engineered for industrial environments, the Cisco IE-4010-16S12P= operates reliably under extreme temperature conditions, vibrations, and electrical interference. Its robust metal chassis and redundant power supply options ensure continuous operation even in harsh environments. The switch meets stringent industrial standards, including IEC certifications for electromagnetic compatibility and environmental tolerance. This rugged design makes it ideal for deployment in manufacturing plants, energy facilities, and transportation networks where consistent uptime is critical.

Security and Network Protection

Security is a core component of the Cisco IE-4010-16S12P= managed switch. It incorporates advanced features such as access control lists (ACLs), port security, DHCP snooping, and dynamic ARP inspection to protect against unauthorized access and network attacks. These measures help safeguard sensitive industrial operations and ensure compliance with corporate and regulatory security policies. Integrated threat detection and mitigation capabilities provide real-time protection against network anomalies, making the switch a reliable choice for secure enterprise and industrial deployments.

Scalability and Future-Proof Networking

The Cisco IE-4010-16S12P= is designed to scale with growing network demands. Its modular port configuration allows easy integration with additional switches, enabling the expansion of network topologies without significant reconfiguration. High bandwidth SFP uplinks support long-distance connections and interconnectivity with other network segments, providing a future-proof solution for evolving industrial and enterprise infrastructures. The switch’s firmware supports ongoing feature upgrades, ensuring compatibility with emerging network technologies and standards.

Energy Efficiency and Operational Cost Reduction

Designed with energy efficiency in mind, the Cisco IE-4010-16S12P= incorporates features such as intelligent power management and low-power Ethernet options. These technologies minimize operational costs while maintaining high performance and reliability. PoE scheduling and port-level power adjustments allow network administrators to optimize energy consumption according to usage patterns. This combination of performance and efficiency makes the IE-4010 series an ideal choice for organizations seeking sustainable network solutions without compromising operational capabilities.

Integration with Cisco Ecosystem

The Cisco IE-4010-16S12P= integrates seamlessly with the broader Cisco ecosystem, offering compatibility with Cisco DNA Center, Cisco Prime Infrastructure, and other management platforms. This integration enables centralized control, streamlined network monitoring, and automated configuration, reducing administrative overhead and improving operational efficiency. The switch supports standard network protocols such as SNMP, RMON, and NetFlow, allowing easy integration with third-party monitoring and analytics tools for enhanced visibility into network performance and security.

Application in Industrial Automation

In industrial automation, reliable connectivity and low-latency communication are critical. The Cisco IE-4010-16S12P= provides deterministic performance and high availability required for real-time control systems, programmable logic controllers (PLCs), and SCADA networks. Its rugged design ensures continuous operation in demanding factory and industrial environments, supporting mission-critical processes without interruption. This makes it a preferred solution for industries such as automotive, energy, and process manufacturing.

Deployment Flexibility and Rack-Mount Design

The 1U rack-mountable form factor of the Cisco IE-4010-16S12P= allows for efficient use of data center and network rack space. Its compact design simplifies deployment in server rooms, network closets, and industrial control cabinets. Easy access to ports and LED indicators enhances troubleshooting and maintenance, while standardized mounting kits ensure compatibility with existing infrastructure. The combination of high port density, PoE support, and modular uplink options provides a flexible networking solution adaptable to diverse deployment scenarios.

Reliability, Redundancy, and High Availability

The Cisco IE-4010 series emphasizes operational reliability and uptime. Redundant power supply options, resilient software architecture, and rapid failover mechanisms ensure continuous network operation even in the event of hardware or link failures. High availability features such as Rapid Spanning Tree Protocol (RSTP) and Multiple Spanning Tree Protocol (MSTP) prevent network loops and minimize downtime. These capabilities make the IE-4010-16S12P= an ideal choice for environments where uninterrupted connectivity is crucial for business continuity and industrial operations.
