Cisco SG350-28MP-K9 Managed Switch (28-Ports)

SG350-28MP-K9
Hover on image to enlarge

Brief Overview of SG350-28MP-K9

Cisco SG350-28MP-K9 28-Ports Managed Switch. Factory-Sealed New in Original Box (FSB) with 6-Month Replacement Warranty
QR Code of Cisco SG350-28MP-K9 Managed Switch (28-Ports)
$1,080.00
$705.67
You save: $374.33 (35%)
Ask a question
+
Quote
Additional 7% discount at checkout
SKU/MPNSG350-28MP-K9Availability✅ In StockProcessing TimeUsually ships same day ManufacturerCisco Product/Item ConditionFactory-Sealed New Retail in Original Box (FSB) ServerOrbit Replacement WarrantySix-Month (180 Days)
Our Advantages
  • Free Ground Shipping
  • — Min. 6-month Replacement Warranty
  • — Genuine/Authentic Products
  • — Easy Return and Exchange
  • — Different Payment Methods
  • — Best Price
  • — We Guarantee Price Matching
  • — Tax-Exempt Facilities
  • — 24/7 Live Chat, Phone Support
Payment Options
  • — Visa, MasterCard, Discover, and Amex
  • — JCB, Diners Club, UnionPay
  • — PayPal, ACH/Wire Transfer
  • — Apple Pay, Amazon Pay, Google Pay
  • — Buy Now, Pay Later - Affirm, Afterpay
  • — GOV/EDU/Institutions PO's Accepted
  • — Invoices
Delivery
  • — Deliver Anywhere
  • — Express Delivery in the USA and Worldwide
  • — Ship to -APO -FPO
  • For USA - Free Ground Shipping
  • — Worldwide - from $30

Same product also available in:

Description

Overview of Cisco SG350-28MP-K9

Manufacturer and Model Details

  • Manufacturer: Cisco
  • Model Number/SKU: SG350-28MP-K9
  • Product Series: 350P
  • Product Type:  Ethernet Switch

Interface and Port Specifications

Network Ports

  • Total Network Ports: 26
  • Uplink Port: Yes
  • Modular: Yes
  • Stack Port: No

Port and Expansion Slot Details

  • Gigabit Ethernet Network Ports: 26
  • Gigabit Ethernet Expansion Slots: 4

Performance Specifications

Supported Media Types

  • Twisted Pair
  • Optical Fiber

Network Technology

  • Ethernet Technology: Gigabit Ethernet
  • Network Technologies Supported: 1000Base-X, 10/100/1000Base-TX

Switching Capacity and VLANs

  • Switching Capacity: 56 Gbps
  • Forwarding Performance: 38.69 Mpps (64-byte packet size)
  • Active VLAN Capacity: 4096

Expansion and Connectivity

Expansion Slots

  • Total Expansion Slots: 4
  • Expansion Slot Type: SFP
  • Shared SFP Slot: Yes
  • Number of SFP Slots: 4

Network and Communication Features

Layer Support

  • Layer 3

Management and Protocols

Manageability

  • Manageable: Yes

Routing Protocols

  • Static IPv4 Routing
  • CIDR

Remote Management Options

  • SNMP v1, v2c, v3
  • RMON v1, v2, v3, v9
  • Telnet
  • HTTP, HTTPS
  • TFTP
  • SSH
  • CLI

Advanced Features

  • Unicast Storm Control
  • Firmware Upgradable
  • Spanning Tree Protocol (STP) Support
  • Rapid Spanning Tree Protocol (RSTP) Support
  • Trivial File Transfer Protocol (TFTP) Support
  • Access Control List (ACL) Support
  • Quality of Service (QoS)
  • Jumbo Frames Support
  • MLD Snooping
  • 12MB Packet Buffer

Compliance and Standards

  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3z
  • IEEE 802.1D
  • IEEE 802.1Q
  • IEEE 802.3ab
  • IEEE 802.1p
  • IEEE 802.3x
  • IEEE 802.3ad (LACP)
  • IEEE 802.1w
  • IEEE 802.1x
  • IEEE 802.1s
  • IEEE 802.3az

Memory Specifications

Flash Memory

  • Flash Memory: 256 MB

Power Requirements

Power Source and Device

  • Power Source: Power Supply
  • Redundant Power Supply Supported: No
  • Power Device: Internal Power Supply
  • Voltage Required: AC 120/230 V (50/60 Hz)

Physical and Environmental Specifications

Dimensions and MTBF

  • Height (Rack Units): 1
  • MTBF: 213,373 hours

Temperature and Humidity

  • Minimum Operating Temperature: 32 °F
  • Maximum Operating Temperature: 104 °F
  • Operating Humidity Range: 10 – 90% (non-condensing)
  • Minimum Storage Temperature: -4 °F
  • Maximum Storage Temperature: 158 °F
  • Storage Humidity Range: 10 – 90% (non-condensing)

Miscellaneous Details

  • Authentication Methods: RADIUS, Secure Shell (SSH), TACACS+
  • Color Category: Black
  • Compliant Standards: CSA 22.2, FCC Part 15 A, UL 60950
  • Encryption Algorithm: SSL

SG350-28MP-K9

Ports

The Cisco SG350-28MP-K9 Managed Switch is equipped with a total of 28 ports, making it an ideal choice for small to medium-sized businesses. With this impressive number of ports, users can connect multiple devices to the switch simultaneously, ensuring efficient and seamless network connectivity.

Increased Connectivity Options

The 28 ports on the Cisco SG350-28MP-K9 Managed Switch offer users a wide range of connectivity options. Whether you need to connect computers, servers, printers, or other network devices, the switch has you covered. This versatility allows for easy expansion and integration of new devices into your network infrastructure without the need for additional switches or equipment.

Improved Network Performance

Having 28 ports available on the switch means that network traffic can be distributed evenly across multiple devices. This helps prevent congestion and bottlenecks, resulting in improved network performance and reduced latency. Users can enjoy faster data transfer speeds and a more reliable network connection, ensuring smooth operations and increased productivity.

Flexibility and Scalability

The Cisco SG350-28MP-K9 Managed Switch's 28 ports provide users with the flexibility to connect their devices according to their specific requirements. Whether you need to connect a large number of devices in a single location or spread them out across different areas, this switch can accommodate your needs. Additionally, the switch supports advanced features such as VLANs (Virtual Local Area Networks), allowing you to segment your network and enhance security and performance.

Simplified Network Management

With 28 ports available, managing your network becomes much simpler. The Cisco SG350-28MP-K9 Managed Switch offers intuitive web-based management tools that allow you to configure and monitor your network easily. You can set up VLANs, prioritize traffic, and troubleshoot any issues that may arise, all from a centralized interface. This streamlined management process saves time and effort, enabling IT administrators to focus on other critical tasks.

Cost-Effective Solution

By having 28 ports on a single switch, businesses can save on costs associated with purchasing and maintaining multiple switches. Instead of investing in several smaller switches, which can quickly become complex and difficult to manage, the Cisco SG350-28MP-K9 Managed Switch provides a cost-effective solution that meets the connectivity needs of your organization.

Future-Proof Investment

The 28 ports offered by the Cisco SG350-28MP-K9 Managed Switch ensure that your network infrastructure is future-proofed. As your business grows and your network requirements increase, you won't need to worry about running out of ports. This switch provides ample capacity for expansion, allowing you to add more devices and users without any hassle or additional costs.

Power-over-Ethernet (PoE)

One of the standout features of the Cisco SG350-28MP-K9 Managed Switch is its Power-over-Ethernet (PoE) capability. This feature enables the switch to power devices directly through the Ethernet cables, eliminating the need for separate power sources. With its support for PoE, this switch offers a range of benefits and convenience for users.

Effortless Device Installation

With PoE support, users can easily install network devices such as IP phones, wireless access points, and security cameras without the need for additional power outlets near each device. This eliminates the hassle of running power cables to each device location and simplifies the installation process. It allows for greater flexibility in device placement and reduces the time and effort required for setup.

Reduced Cable Clutter

By utilizing PoE technology, the Cisco SG350-28MP-K9 Managed Switch eliminates the need for additional power cables, resulting in reduced cable clutter. This not only improves the aesthetics of your network infrastructure but also enhances airflow and reduces the risk of cable tangling or accidental disconnections. A tidy and organized network environment leads to easier maintenance and troubleshooting.

Cost Savings

PoE technology offers significant cost savings by reducing the need for separate power supplies or adapters for each network device. With the Cisco SG350-28MP-K9 Managed Switch's PoE capability, you can power compatible devices directly from the switch, eliminating the need for additional power equipment. This not only reduces upfront costs but also lowers ongoing energy consumption, resulting in long-term savings.

Flexibility and Scalability

The PoE feature on the Cisco SG350-28MP-K9 Managed Switch provides flexibility and scalability for your network infrastructure. You can easily add or relocate devices without the constraints of power outlet availability. This allows for efficient network expansion and simplifies future upgrades or reconfigurations.

Remote Power Management

With the Cisco SG350-28MP-K9 Managed Switch's PoE capability, you can centrally manage and control the power supply to connected devices. This remote power management feature allows you to turn devices on or off, reboot them, or adjust power levels as needed. This level of control enhances network security, saves energy, and enables efficient troubleshooting or maintenance operations.

Enhanced Device Reliability

By utilizing PoE technology, the Cisco SG350-28MP-K9 Managed Switch ensures a reliable power supply to connected devices. In case of a power outage or failure, the switch can provide backup power to critical devices through its built-in uninterruptible power supply (UPS) capabilities. This feature ensures that essential services like IP phones or security systems remain operational even during unexpected power disruptions.

In conclusion, the Cisco SG350-28MP-K9 Managed Switch's 28 ports offer users increased connectivity options, improved network performance, flexibility, simplified network management, and cost savings. Additionally, the Power-over-Ethernet capability of the switch provides effortless device installation, reduced cable clutter, cost savings, flexibility, remote power management, and enhanced device reliability. Whether you need to expand your network or upgrade your existing infrastructure, the Cisco SG350-28MP-K9 Managed Switch with its impressive features is a reliable and future-proof solution for any organization.

Features
Product/Item Condition:
Factory-Sealed New Retail in Original Box (FSB)
ServerOrbit Replacement Warranty:
Six-Month (180 Days)
