Cisco SG500-52MP-K9-NA 52-Ports Ethernet Switch for Small Business

Cisco SG500-52MP-K9-NA 52-Port Managed Switch

Product Information

• Manufacturer: Cisco
• Part Number: SG500-52MP-K9-NA
• Product Line: Smart Plus
• Product Series: 500
• Model: SG500-52P
• Product Type: Layer 3 Managed Switch

Interface and Expansion Details

• Total Network Ports: 52
• Uplink Ports: Yes
• Modular Design: No
• Port Types:
  • 50 x Gigabit Ethernet Ports
  • 2 x Gigabit Ethernet Expansion Slots
• Expansion Slots:
  • 2 x SFP Slots
  • Shared SFP Slot: Yes

Media and Performance Specifications

• Media Type: Twisted Pair
• Ethernet Technology: Gigabit Ethernet
• Network Technology: 10/100/1000Base-T

Networking and Communication

• Layer Supported: 3
• IPv4 Routes: 2048
• IPv6 Routes: 2048
• MAC Address Table Size: 16K Entries
• Jumbo Frame Support: 9216 Bytes
• Maximum Units in Stack: 8
• Routing Protocol: Static IP Routing

Management and Protocols

• Manageable: Yes
• Remote Management Protocols:
  • SNMP 1, 2c, 3
  • RMON 1, 2, 3, 9
  • HTTP, HTTPS, SSH, SSH-2, CLI
• Authentication Methods: RADIUS, TACACS+

Compliant Standards

• IEEE 802.3
• IEEE 802.3u
• IEEE 802.3z
• IEEE 802.1D
• IEEE 802.1Q
• IEEE 802.3ab
• IEEE 802.1p
• IEEE 802.3af
• IEEE 802.3x
• IEEE 802.3ad (LACP)
• IEEE 802.1w
• IEEE 802.1x
• IEEE 802.1s
• IEEE 802.1ab (LLDP)
• IEEE 802.3at
• IEEE 802.3az

Features and Capabilities

• Flow Control
• Layer 2 Switching
• Power over Ethernet (PoE) & PoE+
• VLAN Support
• IGMP Snooping
• DoS Attack Prevention
• Port Mirroring
• Weighted Round Robin (WRR) Queuing
• Broadcast Storm Control
• IPv6 Support
• Multicast Storm Control
• Unicast Storm Control
• Spanning Tree Protocol (STP) Support
• Rapid Spanning Tree Protocol (RSTP) Support
• Multiple Spanning Tree Protocol (MSTP) Support
• DHCP Snooping
• Access Control List (ACL) Support
• Quality of Service (QoS)
• RADIUS Support
• DHCP Server
• MLD Snooping
• Dynamic ARP Inspection (DAI)
• STP Root Guard
• Uni-Directional Link Detection (UDLD)
• LACP Support
• LLDP Support
• DHCP Relay
• Energy Efficient Ethernet
• Dynamic VLAN Support (GVRP)
• Class of Service (CoS)
• Strict Priority (SP)
• Generic Attribute Registration Protocol (GARP)
• 16MB Packet Buffer

Reliability and Power Specifications

• Mean Time Between Failures (MTBF): 186,968 Hours
• Power Source: Power Supply
• Voltage Required: AC 120/230 V (50/60 Hz)

Environmental Parameters

• Operating Temperature Range: 32 °F to 122 °F
• Humidity Range (Operating): 10 – 90% (Non-Condensing)
• Storage Temperature Range: -4 °F to 158 °F
• Humidity Range (Storage): 10 – 90% (Non-Condensing)

Included Accessories

• Power Cord
• Mounting Kit
• Serial Cable
• CD-ROM with User Documentation (PDF)

Ports

The Cisco SG500-52MP-K9-NA Ethernet Switch is equipped with a remarkable 52 ports, making it an ideal choice for businesses that demand high-speed connectivity and extensive network management capabilities. With such a vast number of ports, this switch offers numerous benefits and is well-suited for small to medium-sized enterprises that require seamless communication and efficient data transfer.

Flexible Network Expansion

Having 52 ports provides businesses with the flexibility to expand their network infrastructure as their needs grow. Each port on the Cisco SG500-52MP-K9-NA can be utilized to connect various devices, including computers, servers, printers, IP phones, access points, and more. This allows for easy scalability, ensuring that businesses can effortlessly accommodate new devices or additional users without disrupting the existing network setup.

Enhanced Network Performance

The abundance of ports on this Ethernet switch results in improved network performance. With multiple ports available, the switch can handle heavy data traffic efficiently, preventing congestion and maintaining optimal network speeds. This is especially crucial for businesses that rely heavily on data-intensive applications or multimedia content, as it ensures smooth and uninterrupted operations.

Seamless Network Management

The Cisco SG500-52MP-K9-NA Ethernet Switch offers advanced network management capabilities through its extensive port availability. Each port can be configured individually, allowing IT administrators to control and manage the network effectively. This includes setting up VLANs (Virtual Local Area Networks) to segment the network, implementing quality of service (QoS) to prioritize certain types of traffic, and enabling port security to prevent unauthorized access. With 52 ports at their disposal, administrators have the flexibility to fine-tune the network according to their specific requirements.

Size

Designed specifically for small businesses, the Cisco SG500-52MP-K9-NA Ethernet Switch combines powerful features with a compact form factor. The size of this switch holds immense benefits and importance for users in small business environments, where space constraints and ease of installation are critical considerations.

Space Optimization

The compact size of the SG500-52MP-K9-NA switch allows businesses to optimize their physical space effectively. Small businesses often operate in limited office spaces, where every square inch matters. By choosing a switch with a small form factor, businesses can maximize their available space, allowing for more efficient office layouts and reducing clutter. This not only enhances the aesthetics of the workplace but also improves overall productivity by providing a clean and organized environment.

Easy Installation

The small size of this switch simplifies the installation process, making it a user-friendly option for small businesses. With limited IT resources and expertise, small business owners or administrators may find complex installations challenging. However, the compact design of the SG500-52MP-K9-NA eliminates any potential installation difficulties. It can be conveniently mounted on a rack or placed on a desk without requiring excessive space or additional equipment, ensuring a hassle-free setup process.

Energy Efficiency

In addition to its small size, the Cisco SG500-52MP-K9-NA Ethernet Switch is designed to be energy-efficient. This is particularly important for small businesses aiming to reduce their environmental footprint and lower operational costs. With energy-saving features such as power-saving mode and intelligent power management, this switch optimizes power consumption without compromising performance. By choosing a compact and energy-efficient switch like the SG500-52MP-K9-NA, small businesses can contribute to sustainability efforts while enjoying cost savings in the long run.

In conclusion, the Cisco SG500-52MP-K9-NA Ethernet Switch offers an impressive 52 ports and a compact form factor tailored for small businesses. The extensive port availability allows for flexible network expansion, enhanced network performance, and seamless network management. Simultaneously, the small size of the switch enables space optimization, easy installation, and energy efficiency. For small businesses seeking a reliable and efficient networking solution, the Cisco SG500-52MP-K9-NA Ethernet Switch is an excellent choice that caters to their specific needs.
