Cisco WS-C3850-48T-E Catalyst 3850 Layer 3 48 Ports Switch

Ports

The Cisco Catalyst 3850 Layer 3 Manageable switch comes equipped with a remarkable 48 ports, making it an ideal choice for users who require a high-density switch solution. These ports provide numerous benefits and are of utmost importance for businesses and organizations that demand a robust network infrastructure.

Overview of WS-C3850-48T-E Switch

• Part Number: WS-C3850-48T-E
• Manufacturer: Cisco
• Product Type: Stackable Switch

Device Specifications

• Type: 48-Port Switch, Layer 3, Managed, Stackable
• Mounting Options: Desktop or Rack-Mountable (1U)
• Interface Type: Gigabit Ethernet
• Ports: 48 x 10/100/1000 Mbps

Performance Metrics

• Switching Capacity: 176 Gbps
• Stacking Bandwidth: 480 Gbps

Capacity Details

• IPv4 Routes: Up to 24,000
• NetFlow Entries: 48,000
• Switched Virtual Interfaces (SVIs): 1,000
• MAC Address Table Size: 32,000 Entries
• Jumbo Frame Support: 9,198 bytes

Routing and Management Protocols

• Routing Protocols: BGP-4, IS-IS, RIP-1, RIP-2, EIGRP, PIM-SM, EIGRP for IPv6, OSPFv3, PIM-SSM, RIPng
• Remote Management: SNMP v1, SNMP v2c, SNMP v3, RMON v1, RMON v2, Telnet, SSH, CLI

Advanced Features

• Auto-Negotiation and ARP Support
• Trunking and VLAN Support
• Auto-Uplink (Auto MDI/MDI-X)
• IGMP Snooping and Syslog Support
• IPv6 Support and Rapid Spanning Tree Protocol (RSTP)
• Multiple Spanning Tree Protocol (MSTP)
• DHCP Snooping and Dynamic Trunking Protocol (DTP)
• Port Aggregation Protocol (PAgP)
• Trivial File Transfer Protocol (TFTP)
• Access Control List (ACL) Support
• Quality of Service (QoS)
• RADIUS Support
• Virtual Routing Forwarding Lite (VRF-Lite)
• MLD Snooping and Dynamic ARP Inspection (DAI)
• STP Root Guard and Uni-Directional Link Detection (UDLD)
• Rapid Per-VLAN Spanning Tree Plus (PVRST+)
• IPv4 Support and Shaped Round Robin (SRR)
• Link Aggregation Control Protocol (LACP)
• Remote Switch Port Analyzer (RSPAN)
• Layer 3 Load Balancing
• Energy Efficient Ethernet
• CISCO StackWise-480 Technology
• CISCO StackPower Technology
• Flexible NetFlow (FNF)

Compliance Standards

• IEEE 802.3, IEEE 802.3u, IEEE 802.3z
• IEEE 802.1d, IEEE 802.1q, IEEE 802.3ab
• IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP)
• IEEE 802.1w, IEEE 802.1x, IEEE 802.1s

Power Specifications

• Input Voltage: AC 120/230V (50/60 Hz)
• Power Redundancy: Optional

High Port Density

One of the major advantages of the Cisco Catalyst 3850's 48 ports is its high port density. With this switch, users have access to a significantly larger number of ports compared to other switches in the market. This is particularly beneficial for businesses that have a large number of network devices, such as computers, servers, printers, and IP phones, as it allows them to connect multiple devices simultaneously without the need for additional equipment or expansion modules.

Scalability and Future-Proofing

The high port density of the Cisco Catalyst 3850 ensures that businesses can easily scale their network infrastructure as their needs grow. With 48 ports available, organizations can accommodate additional devices or expand their network without any hassle. This scalability feature not only saves costs in terms of equipment purchases but also provides a future-proof solution that can adapt to changing business requirements.

Improved Network Performance

Having 48 ports on the Cisco Catalyst 3850 significantly enhances network performance. Each port provides dedicated bandwidth to connected devices, ensuring optimal data transfer speeds and minimizing network congestion. This results in improved overall network performance, reduced latency, and seamless communication between devices. Whether it is transferring large data files, streaming high-quality multimedia content, or supporting real-time communication applications, the high port density of this switch ensures smooth and uninterrupted operations.

Flexibility and Versatility

The Cisco Catalyst 3850's 48 ports offer remarkable flexibility and versatility in network deployment. The abundance of ports allows users to connect various devices and create complex network topologies. Whether it's a small office, a medium-sized business, or a large enterprise, the switch's port density enables IT administrators to design and implement networks that meet their specific needs. From segmenting departments into separate VLANs to connecting wireless access points or IP surveillance cameras, the flexibility provided by the 48 ports on this switch caters to a wide range of network requirements.

Aggregation and Uplink Connectivity

The high port density also enables aggregation and uplink connectivity options for businesses that require a higher level of network performance or need to connect to other switches or routers. With 48 ports available, users can easily aggregate multiple lower-speed connections into higher-speed links, increasing the overall throughput of the network. This is particularly crucial for organizations that have high-bandwidth demands or deal with data-intensive applications. Additionally, the multiple ports allow for seamless integration with existing network infrastructure and provide ample connectivity options for future expansion.

Cost-Effective Solution

The Cisco Catalyst 3850's 48 ports offer a cost-effective networking solution. By providing a large number of ports within a single switch, businesses can avoid the need for additional equipment or expansion modules, which would otherwise increase the overall cost of deploying and maintaining the network infrastructure. The high port density not only saves on equipment costs but also reduces power consumption, cabling requirements, and rack space utilization. This makes the Cisco Catalyst 3850 an economical choice for organizations looking to maximize value without compromising on performance.

In conclusion, the Cisco Catalyst 3850 Layer 3 Manageable switch's 48 ports provide numerous benefits for users. The high port density ensures scalability, improved network performance, flexibility, and cost-effectiveness. Whether it's accommodating a large number of devices, creating complex network topologies, or meeting future growth requirements, the 48 ports on this switch deliver the reliability and performance that businesses demand from their network infrastructure.
