Cisco WS-C4500X-F-16SFP+ 10GE 16-Port Managed Switch IP Base

Overview of Cisco WS-C4500X-F-16SFP+ Managed Switch

Manufacturer & Part Details

• Manufacturer: Cisco
• Part Number: WS-C4500X-F-16SFP+
• Product Line: Catalyst
• Series: 4500-X
• Product Type: Ethernet Switch

Technical Specifications

• Token Ring Support: Not Available
• LRE Ports: Not Supported
• Uplink Ports: None
• Bypass Functionality: Not Included
• Modular Design: No
• Management Port: Available
• USB Port: Available
• Stacking Ports: Not Supported

Performance & Media Handling

• Data Throughput: 800 Gbps
• IPv4 Packet Routing: 250 Mpps
• IPv6 Packet Routing: 125 Mpps

Expansion Capabilities

• Total Expansion Slots: 16
• Slot Type: SFP+
• Shared SFP Slots: No
• Total SFP+ Ports: 16

Network Communication Features

• Layer Support: Layer 3

Memory & Processing Power

• Processor Speed: 1.5 GHz
• RAM Capacity: 4 GB DDR2 SDRAM
• Flash Memory: 2 GB (Max)

Capacity Highlights

• IPv4 Forwarding Entries: 64,000
• IPv6 Forwarding Entries: 32,000
• Netflow Entries: 128,000
• Virtual Interfaces (VLANs): 4,094
• IGMP Groups: 32,000
• IPv4 Multicast Entries: 24,000
• IPv6 Multicast Entries: 12,000
• ARP Entries: 47,000
• Spanning Tree Protocol Instances: 10,000
• QoS Queues: 64
• ACL Entries: 131,072

Advanced Features

• Layer 2 Switching: Supported
• VLAN Support: Yes
• Access Control Lists (ACL): Available
• Quality of Service (QoS): Integrated
• Front-to-back airflow: Yes
• Redundant Hot-Swappable Fans: Yes

Standards & Protocols Compliance

• Compliant Standards:
• IEEE 802.3, 802.1D, 802.1Q, 802.1P
• IEEE 802.3ad (LACP), 802.1W, 802.1X
• IEEE 802.3ae, 802.1S

Expansion & Connectivity Options

• Ethernet Ports: 16 x 10Gb / 1Gb SFP/SFP+
• Management Ports: 1 x RJ-45 (10Base-T/100Base-TX/1000Base-T)
• USB Ports: 1 x USB Type A
• Console Ports: 1 x RJ-45
• SD Memory Card Slot: 1 (free)
• Expansion Slot: 1 (free)

Power & Energy Specifications

• Power Supply: Internal, Hot-Pluggable
• Power Redundancy: Optional, 1+1 Configuration
• Max Power Supply: 2 units (optional)
• Operational Power Consumption: 330 Watts

Ports

The Cisco WS-C4500X-F-16SFP+ Managed Switch is equipped with 16 SFP+ ports, making it a powerful and versatile networking solution for businesses of all sizes. These ports offer numerous benefits and play a crucial role in ensuring seamless connectivity and efficient data transfer.

Increased Connectivity

With 16 SFP+ ports, this managed switch provides ample connectivity options for various devices and network components. Whether you need to connect servers, storage systems, or other network switches, the abundance of ports ensures that you have enough flexibility to meet your specific requirements. This increased connectivity allows for easy expansion and scalability of your network infrastructure as your business grows.

Enhanced Performance

The 16 SFP+ ports on the Cisco WS-C4500X-F-16SFP+ Managed Switch support 10 Gigabit Ethernet, enabling lightning-fast data transfer speeds. This high-performance connectivity is essential for bandwidth-intensive applications such as video streaming, large file transfers, and data backup. By leveraging the speed capabilities of these ports, you can significantly improve network performance and ensure the smooth operation of your critical business processes.

Aggregation and Link Redundancy

The abundance of SFP+ ports allows for effective aggregation and link redundancy strategies. You can use these ports to create link aggregation groups (LAGs) or EtherChannels, which combine multiple physical connections into a single logical link. This not only increases overall bandwidth but also provides redundancy in case of link failures. In the event of a link failure, traffic can automatically be rerouted through alternate links, ensuring uninterrupted network connectivity.

Improved Network Resilience

With 16 SFP+ ports, the Cisco WS-C4500X-F-16SFP+ Managed Switch offers improved network resilience. By utilizing redundant links and LAGs, you can create a highly resilient network infrastructure that minimizes downtime and ensures continuous operation. This feature is particularly valuable for businesses that rely heavily on their network for critical operations and cannot afford any disruptions.

Flexible Network Design

The versatility of the 16 SFP+ ports allows for flexible network design options. You can connect different types of devices, such as servers, storage systems, and network switches, using a combination of copper and fiber connections. This flexibility empowers you to design a network that suits your specific needs, taking into consideration factors such as distance limitations and bandwidth requirements.

Future-Proofing

Investing in a switch with 16 SFP+ ports ensures future-proofing your network infrastructure. As technology advances and demands for higher bandwidth increase, having sufficient connectivity options becomes paramount. With 16 ports, you have the flexibility to adapt to future network requirements without the need for additional hardware investments. This scalability not only saves costs but also ensures that your network can support emerging technologies and applications.

Speed

The Cisco WS-C4500X-F-16SFP+ Managed Switch offers 10 Gigabit Ethernet speed capabilities, providing users with a high-performance networking solution. The speed feature is essential for businesses that require fast and reliable data transfer, enabling them to meet their demanding connectivity needs effectively.

Rapid Data Transfer

By supporting 10 Gigabit Ethernet, this switch can transfer data at incredibly fast speeds. This high-speed capability is particularly beneficial for businesses that deal with large file transfers or bandwidth-intensive applications. Whether you are transferring multimedia content or processing massive amounts of data, the 10 Gigabit Ethernet speed ensures efficient and timely delivery.

Improved Work Efficiency

The fast data transfer speeds offered by the Cisco WS-C4500X-F-16SFP+ Managed Switch significantly enhance work efficiency. Employees can access and share data quickly, allowing for smoother collaboration and streamlined business processes. This speed advantage also reduces latency, ensuring that time-sensitive applications, such as voice and video conferencing, run smoothly without any interruptions or delays.

Network Performance Optimization

The 10 Gigabit Ethernet speed of this managed switch optimizes overall network performance. It eliminates bottlenecks and congestion by providing ample bandwidth for data-intensive tasks. This ensures that your network operates efficiently and can handle the increasing demands of modern applications and services. With improved network performance, you can deliver a better user experience to your customers and maintain a competitive edge in the market.

Scalability for Growing Networks

As businesses grow and expand, their networking requirements also increase. The 10 Gigabit Ethernet speed of the Cisco WS-C4500X-F-16SFP+ Managed Switch allows for seamless scalability of your network infrastructure. It provides the necessary bandwidth to accommodate additional devices, users, and services without compromising performance. This scalability ensures that your network can keep up with your business's growth and adapt to changing needs.

Support for Virtualization

Virtualization has become a common practice in modern IT environments, allowing businesses to consolidate resources and streamline operations. The 10 Gigabit Ethernet speed of this switch is well-suited for virtualized environments, where data needs to be transferred rapidly between virtual machines and physical servers. It enables efficient communication between virtualized resources and ensures that performance is not hampered by networking limitations.

Future-Proof Investment

Investing in a switch with 10 Gigabit Ethernet speed is a future-proof choice for your networking infrastructure. As technology continues to advance, the demand for higher bandwidth will only increase. By choosing a switch with this speed capability, you ensure that your network can handle future requirements without the need for costly upgrades or replacements. This future-proof investment saves you both time and money, allowing you to focus on other business priorities.

License

The Cisco WS-C4500X-F-16SFP+ Managed Switch comes with the IP Base license, offering a range of benefits and features that are essential for effective network management and security. The license feature plays a crucial role in ensuring the switch's functionality and provides users with the necessary tools to optimize their network infrastructure.

Enhanced Network Visibility

The IP Base license provides advanced network visibility features that enable administrators to monitor and analyze network traffic effectively. It offers tools such as NetFlow, which allows for detailed traffic analysis, helping identify potential bottlenecks, anomalies, or security threats. This enhanced visibility enables proactive troubleshooting, capacity planning, and network optimization, resulting in improved performance and reliability.

Robust Security Features

The IP Base license includes a range of security features that protect your network from unauthorized access and potential threats. These features include access control lists (ACLs), which allow administrators to define and enforce traffic policies, ensuring that only authorized users and devices can access specific resources. Additionally, the license provides support for Virtual LAN (VLAN) segmentation, which enhances network security by isolating different departments or user groups from each other.

Quality of Service (QoS) Control

With the IP Base license, administrators have access to sophisticated QoS controls that prioritize critical traffic and ensure optimal performance for important applications. QoS allows you to allocate bandwidth based on specific requirements, guaranteeing that mission-critical applications receive the necessary resources. This feature is particularly beneficial for businesses that rely on real-time applications such as voice-over IP (VoIP) or video conferencing.

Simplified Network Management

The IP Base license provides a range of management features that simplify network administration tasks. These features include Simple Network Management Protocol (SNMP) support, which allows for centralized monitoring and configuration of network devices. Additionally, the license enables remote management capabilities, facilitating efficient network management, particularly in geographically dispersed environments.

Scalability and Flexibility

The IP Base license offers scalability and flexibility, allowing you to adapt your network to changing needs. It supports features such as Virtual Routing and Forwarding (VRF), which enables the creation of multiple virtual routing instances within a single physical device. This capability is valuable for businesses that require logical separation of their network infrastructure or need to accommodate different routing policies.

Cost-Effective Solution

The IP Base license provides a cost-effective solution for businesses that require essential network management and security features. While offering robust functionality, this license level is more affordable compared to higher-tier licenses. By choosing the IP Base license, you can ensure that your network meets your immediate requirements without exceeding your budget. Additionally, the license's scalability allows for future expansion and upgrades as your business grows.

In conclusion, the Cisco WS-C4500X-F-16SFP+ Managed Switch with its 16 SFP+ ports, 10 Gigabit Ethernet speed, and IP Base license offers a comprehensive networking solution for businesses. The 16 SFP+ ports provide increased connectivity, enhanced performance, aggregation options, and flexibility in network design. The 10 Gigabit Ethernet speed ensures rapid data transfer, improved work efficiency, optimized network performance, scalability for growing networks, and support for virtualization. The IP Base license enhances network visibility, provides robust security features, enables quality of service control, simplifies network management, offers scalability and flexibility, and provides a cost-effective solution. With these features, the Cisco WS-C4500X-F-16SFP+ Managed Switch empowers businesses to build a reliable, high-performance, and secure network infrastructure that can meet their current and future needs.
