Cisco WS-G5484 Multi-mode Fiber SW Transceiver Module

WS-G5484
Hover on image to enlarge

Brief Overview of WS-G5484

Multi-mode Fiber Short Wave Transceiver Module Cisco WS-G5484. New (System) Pull with a 6-Month Replacement Warranty
QR Code of Cisco WS-G5484 Multi-mode Fiber SW Transceiver Module
$56.70
$36.00
You save: $20.70 (37%)
Ask a question
+
Quote
Additional 7% discount at checkout
SKU/MPNWS-G5484Availability✅ In StockProcessing TimeUsually ships same day ManufacturerCisco Product/Item ConditionNew (System) Pull ServerOrbit Replacement WarrantySix-Month (180 Days)
Our Advantages
  • Free Ground Shipping
  • — Min. 6-month Replacement Warranty
  • — Genuine/Authentic Products
  • — Easy Return and Exchange
  • — Different Payment Methods
  • — Best Price
  • — We Guarantee Price Matching
  • — Tax-Exempt Facilities
  • — 24/7 Live Chat, Phone Support
Payment Options
  • — Visa, MasterCard, Discover, and Amex
  • — JCB, Diners Club, UnionPay
  • — PayPal, ACH/Wire Transfer
  • — Apple Pay, Amazon Pay, Google Pay
  • — Buy Now, Pay Later - Affirm, Afterpay
  • — GOV/EDU/Institutions PO's Accepted
  • — Invoices
Delivery
  • — Deliver Anywhere
  • — Express Delivery in the USA and Worldwide
  • — Ship to -APO -FPO
  • For USA - Free Ground Shipping
  • — Worldwide - from $30

Same product also available in:

Description

Cisco WS-G5484 Multi-mode Fiber Short Wave Transceiver Module

Overview

The Cisco WS-G5484 Multi-mode Fiber Short Wave Transceiver Module is a high-performance network interface module designed for use in Cisco switches and routers. It provides a reliable and cost-effective solution for short-range fiber optic connections, making it ideal for data centers, campuses, and other high-bandwidth environments.

The Cisco WS-G5484 Transceiver Module

The Cisco WS-G5484 is a high-performance transceiver module designed for reliable data networking and optical communication. Below are the detailed specifications and features of this module:

Manufacturer and Model

  • Manufacturer: Cisco
  • Model Number: WS-G5484
  • Product Type: Transceiver Module

Technical Specifications

Ethernet and Media Type

  • Ethernet Technology: GBIC-SFP Gigabit Ethernet
  • Supported Media Type: Optical Fiber
  • Fiber Optic Cable Standards: 62.5 µm, 50 µm
  • Supported Fiber Mode: Multi-mode
  • Network Technology: 1000Base-SX

Performance Metrics

  • Maximum Transfer Distance: 550 Meters
  • Data Transfer Rate: 1 Gbps
  • Standards Compliance: IEEE 802.3z
  • Maximum Data Transfer Rate: 1 Gbit/s
  • Application: Data Networking, Optical Networks

Miscellaneous Details

Channel Insertion Loss

  • Transmitter Output Power (Minimum/Maximum): 0/-9.5 dBm
  • Receiver Maximum Input Power: 0 dBm
  • Receiver Sensitivity: -17 dBm
  • 50 Micron MMF Loss: 3.4 dB
  • 62.5 Micron MMF Loss: 3.2 dB
  • Laser Class: Class 1 Laser at 850 nm for 1000BASE-SX (short-wavelength) applications

Compatibility

The Cisco WS-G5484 Transceiver Module is designed to be compatible with the following Cisco Catalyst series:

  • Catalyst 4000 Series
  • Catalyst 5000 Series
  • Catalyst 6000 Series

Key Features

1. Advanced Optics

The WS-G5484 module utilizes advanced optics technology to deliver excellent performance and reliability. It supports multi-mode fiber connections and operates at a wavelength of 850 nm, allowing for data transmission at speeds of up to 1 Gbps.

2. Hot-Swappable Design

With its hot-swappable design, the WS-G5484 module can be easily inserted or removed from compatible Cisco devices without the need for system downtime. This feature ensures minimal disruption to network operations and simplifies maintenance tasks.

3. Compatibility

This transceiver module is compatible with various Cisco switches and routers, including the Catalyst 3550 Series, Catalyst 3750 Series, and Catalyst 4500 Series. It seamlessly integrates with existing network infrastructures, offering a flexible solution for network expansion or upgrades.

4. Extended Reach

Designed for short-range applications, the WS-G5484 module supports link distances of up to 550 meters over multi-mode fiber optic cables. This extended reach capability enables connectivity across large premises without the need for additional equipment or complex installations.

Benefits

1. Cost-Effective Solution

By leveraging multi-mode fiber technology, the WS-G5484 module offers a cost-effective solution for high-speed data transmission within short distances. It eliminates the need for expensive long-range fiber optic cables, making it an economical choice for network deployments.

2. Reliable Performance

With its advanced optics and compatibility with Cisco devices, this transceiver module ensures reliable performance in even the most demanding network environments. It delivers low latency and high data integrity, minimizing the risk of data loss or network interruptions.

3. Easy Installation and Maintenance

The hot-swappable design of the WS-G5484 module simplifies installation and maintenance processes. It can be effortlessly plugged into or removed from compatible Cisco switches and routers, allowing for quick and hassle-free upgrades or replacements.

4. Scalability

The WS-G5484 module's compatibility with a wide range of Cisco devices makes it highly scalable. As network requirements evolve, additional modules can be easily deployed to accommodate increased bandwidth demands or expand network coverage.

5. Future-Proof Solution

With support for data transmission speeds of up to 1 Gbps, the WS-G5484 module offers a future-proof solution that can handle the growing demands of modern networks. It ensures compatibility with emerging technologies and provides a reliable foundation for future network upgrades.

Applications

1. Data Centers

The WS-G5484 module is well-suited for data center environments where high-speed connectivity is crucial. It enables efficient data transmission between servers, switches, and storage systems, ensuring smooth operation of critical applications and services.

2. Campus Networks

In campus networks, the WS-G5484 module facilitates fast and reliable communication between different buildings or departments. Its extended reach capability allows for seamless connectivity across large campuses, enabling efficient collaboration and information exchange.

3. High-Bandwidth Environments

With its support for multi-mode fiber and high-speed data transmission, the WS-G5484 module is an excellent choice for high-bandwidth environments. It can handle the increased network traffic generated by video streaming, cloud computing, and other data-intensive applications.

Conclusion

The Cisco WS-G5484 Multi-mode Fiber Short Wave Transceiver Module offers a reliable, cost-effective, and high-performance solution for short-range fiber optic connections. With its advanced optics, hot-swappable design, and compatibility with Cisco devices, this module ensures seamless network connectivity and enables efficient data transmission in various environments. Whether in data centers, campuses, or high-bandwidth environments, the WS-G5484 module delivers reliable performance and scalability for both current and future network needs.
