HPE DL380 G10 2U Rack Server P24850-B21 Xeon Gold 6250 3.9GHz 32GB RAM

Processor: Intel Xeon Gold 6250 3.9GHz

Unleash Unmatched Performance

The HPE Proliant DL380 G10 2U Rack Server is equipped with the powerful Intel Xeon Gold 6250 3.9GHz processor, delivering exceptional performance and cutting-edge capabilities. With its high clock speed and advanced architecture, this processor ensures that your server can handle even the most demanding workloads with ease.

Server Overview

• Type: Rack-mountable Server
• Form Factor: 2U Rackmount
• Built-in Devices: LED Panel
• Scalability: 2-Way
• Hot-Swap Bays: 8
• Localization: Global

Processor and Chipset

CPU Specifications

• Processor: Intel Xeon Gold 6250
• Clock Speed: 3.9 GHz with Max Turbo Speed of 4.5 GHz
• Cores: 8 Cores
• Socket Type: FCLGA3647
• Maximum CPUs: 2
• Upgrade Potential: Upgradable

Chipset Features

• Chipset Type: Intel C621
• Main Features: Hyper-Threading Technology, Intel Turbo Boost Technology 2

Cache Memory

• Installed Size: 35.75 MB L3 Cache
• Cache Per Processor: 35.75 MB

RAM Specifications

Installed Memory

• Size: 32 GB, expandable up to 1.5 TB
• Technology: DDR4 SDRAM with Advanced ECC
• Memory Speed: 2933 MHz
• Form Factor: DIMM 288-pin
• Total Slots: 24 (23 available)

Supported RAM Configurations

• Load-Reduced ECC: Up to 3 TB
• Registered ECC: Up to 1.5 TB
• Non-Volatile ECC: 192 GB
• HPE Persistent Memory: Up to 6 TB Optane DC Persistent

Storage and Connectivity

Hard Drive

• Type: No HDD

Storage Controller

• Type: SATA
• Controller Interface: SATA 6 Gb/s
• Controller Name: HPE Smart Array S100i SR Software
• Channel Quantity: 14

Optical Storage

• Type: No Optical Drive

Card Reader

• Type: Card Reader
• Supported Flash Memory Cards: microSD

Networking and Expansion

Networking

• Ethernet Ports: 4 x Gigabit Ethernet
• Ethernet Controller: HPE 331i
• Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
• Remote Management Controller: Integrated Lights-Out 5
• Additional Features: Wake On LAN (WoL), ACPI Support, PXE Support

Expansion and Connectivity

• Bays: 8 Hot-Swap 2.5" SFF
• Internal Slots: 1 x MicroSD Card, 1 x PCIe 3.0 x8 (Full-Length, Full-Height), 1 x PCIe 3.0 x16 (Full-Length, Full-Height), 1 x PCIe 3.0 x8 (Half-Length, Full-Height), 1 x FlexibleLOM
• Interfaces: 1 x HPE iLO - Type A (Front), 5 x USB 3.0 (Front, Rear, Internal), 1 x HPE iLO - RJ-45 (Rear), 4 x LAN (Gigabit Ethernet) - RJ-45 (Rear), 1 x VGA (Rear)

Power and Physical Characteristics

Power Supply

• Type: Hot-Plug Power Supply
• Redundancy: Optional, 1+1 with Optional Power Supply
• Installed Quantity: 1
• Maximum Supported Quantity: 2
• Nominal Voltage: AC 120/230 V (50/60 Hz)
• Power Provided: 800 Watts

Dimensions and Weight

• Width: 17.5 inches
• Depth: 26.7 inches
• Height: 3.4 inches
• Weight: 32.85 lbs

Compliance and Standards

• Compliant Standards: AES, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.1

Enhanced Multitasking and Efficiency

Thanks to its 18 cores and 36 threads, the Intel Xeon Gold 6250 processor enables efficient multitasking, allowing you to run multiple applications simultaneously without any lag or performance degradation. This means you can maximize your productivity and get more work done in less time.

Improved Virtualization Performance

Virtualization has become an essential technology for businesses of all sizes, allowing them to consolidate their hardware resources and run multiple virtual machines on a single physical server. The Intel Xeon Gold 6250 processor is optimized for virtualization, providing enhanced performance and scalability for virtualized environments. This means you can run more virtual machines on your server, increasing resource utilization and reducing costs.

Advanced Security Features

Data security is a top priority for any business, and the Intel Xeon Gold 6250 processor includes advanced security features to protect your valuable data. It supports Intel Software Guard Extensions (SGX), which provides hardware-based security for applications and data, protecting them from unauthorized access or tampering. Additionally, it includes Intel Trusted Execution Technology (TXT), which helps ensure the integrity of your server's firmware and operating system.

Improved Power Efficiency

The Intel Xeon Gold 6250 processor is built on a 14nm manufacturing process, which enables higher performance while consuming less power. This means your server can deliver exceptional performance while minimizing energy consumption and reducing your operating costs. With its power-efficient design, this processor is also environmentally friendly, helping you to reduce your carbon footprint.

Future-Proof Your Infrastructure

Investing in a server with the Intel Xeon Gold 6250 processor ensures that you have a future-proof infrastructure that can handle the evolving needs of your business. Its advanced features and capabilities make it well-suited for emerging technologies such as artificial intelligence, machine learning, and big data analytics. By choosing this server, you can stay ahead of the curve and take advantage of the latest technological advancements.

RAM: 32GB

Seamless Performance and Responsiveness

The HPE Proliant DL380 G10 2U Rack Server comes with 32GB of RAM, providing ample memory for smooth and responsive performance. Whether you're running resource-intensive applications or handling large datasets, this generous amount of RAM ensures that your server can handle the workload without any slowdowns or bottlenecks.

Efficient Virtualization

Virtualization relies heavily on memory resources, and having sufficient RAM is crucial for running multiple virtual machines efficiently. With 32GB of RAM, you can allocate enough memory to each virtual machine, ensuring optimal performance and responsiveness. This allows you to maximize the utilization of your server's resources and run more virtual machines simultaneously.

Improved Data Processing and Analysis

Large datasets require significant memory resources for processing and analysis. The 32GB of RAM in this server enables faster data processing, reducing the time required for complex calculations and analysis tasks. This can be particularly beneficial for businesses that deal with big data analytics or scientific simulations, allowing you to derive insights and make informed decisions more quickly.

Enhanced Application Performance

With ample RAM, your server can store frequently accessed data in memory, reducing the need for frequent disk access. This results in faster application performance, as data retrieval times are significantly reduced. Whether you're running a database server, a web server, or any other application that relies on fast data access, the 32GB of RAM ensures smooth and responsive performance.

Future Scalability

The 32GB of RAM in the HPE Proliant DL380 G10 2U Rack Server provides a solid foundation for your current needs while allowing room for future expansion. If your business grows or your workload demands increase, you can easily upgrade the server's memory to meet the new requirements. This scalability ensures that your infrastructure can adapt to changing needs without the need for a complete hardware overhaul.

Reliable Memory Performance

HPE is known for its commitment to quality and reliability, and the RAM included in this server is no exception. With HPE-branded memory modules, you can trust that your server will deliver consistent performance and reliability. This peace of mind is crucial for businesses that rely on their servers for critical operations.

Product Code: P24850-B21

Easy Identification and Inventory Management

The HPE Proliant DL380 G10 2U Rack Server has a unique product code, P24850-B21, which makes it easy to identify and manage in your inventory. This product code allows you to quickly locate the server when needed, ensuring efficient asset tracking and management. Whether you have a small server room or a large data center, having a clear and distinct product code simplifies your operations.

Compatibility and Support

With a specific product code, HPE can provide accurate and tailored support for your server. If you encounter any issues or need assistance, you can easily reference the product code when contacting HPE's support team. This ensures that you receive the appropriate support and troubleshooting guidance, minimizing downtime and maximizing productivity.

Ordering and Procurement

The product code is essential for ordering additional servers or components. By using the P24850-B21 product code, you can ensure that you receive the exact server model and configuration you need. This eliminates any confusion or potential errors during the ordering process, speeding up procurement and ensuring that you have the right equipment to meet your business requirements.

Warranty and Service Coverage

HPE provides comprehensive warranty and service coverage for their servers, and having a specific product code helps streamline the warranty process. When registering your server for warranty, you can easily provide the product code to ensure accurate registration and coverage. In case of any hardware issues covered by the warranty, HPE can quickly identify your server model and provide timely repair or replacement services.

Consistency in Documentation and Updates

The product code is used across various documentation and software updates related to the HPE Proliant DL380 G10 2U Rack Server. This ensures consistency in information and compatibility with specific server models. When accessing technical documentation or downloading software updates, referencing the product code guarantees that you have the correct resources for your server configuration.

Efficient Lifecycle Management

Throughout the lifecycle of your server, from deployment to retirement, having a clear product code simplifies management tasks. It allows you to track hardware changes, software updates, and other relevant information specific to your server model. This streamlined lifecycle management ensures that you can optimize your server's performance and make informed decisions regarding upgrades or replacements.
