HPE DL380 Gen10 Server Xeon 2.2GHz DDR4 SDRAM P39380-B21

P39380-B21
Hover on image to enlarge

Brief Overview of P39380-B21

HPE Proliant DL380 Server Gen10 Xeon 2.2GHz DDR4 SDRAM P39380-B21. New Cto With Standard Mfg Warranty
QR Code of HPE DL380 Gen10 Server Xeon 2.2GHz DDR4 SDRAM P39380-B21
$5,231.25
$3,360.00
You save: $1,871.25 (36%)
Ask a question
+
Quote
Additional 7% discount at checkout
SKU/MPNP39380-B21Availability✅ In StockProcessing TimeUsually ships same day ManufacturerHPE Manufacturer WarrantyFull Warranty from Original Brand Product/Item ConditionFactory-Sealed New in Original Box (FSB) ServerOrbit Replacement WarrantySix-Month (180 Days)
Our Advantages
  • Free Ground Shipping
  • — Min. 6-month Replacement Warranty
  • — Genuine/Authentic Products
  • — Easy Return and Exchange
  • — Different Payment Methods
  • — Best Price
  • — We Guarantee Price Matching
  • — Tax-Exempt Facilities
  • — 24/7 Live Chat, Phone Support
Payment Options
  • — Visa, MasterCard, Discover, and Amex
  • — JCB, Diners Club, UnionPay
  • — PayPal, ACH/Wire Transfer
  • — Apple Pay, Amazon Pay, Google Pay
  • — Buy Now, Pay Later - Affirm, Afterpay
  • — GOV/EDU/Institutions PO's Accepted
  • — Invoices
Delivery
  • — Deliver Anywhere
  • — Express Delivery in the USA and Worldwide
  • — Ship to -APO -FPO
  • For USA - Free Ground Shipping
  • — Worldwide - from $30
Description

Processor

One of the standout features of the HPE Proliant DL380 Server Gen10 is its powerful processor. Equipped with an Intel Xeon 2.2GHz processor, this server delivers exceptional performance and reliability for a wide range of applications.

Main Information of P39380-B21

  • Manufacturer: Hewlett Packard Enterprise
  • Part Number (SKU): P39380-B21
  • Scalability: Supports up to 2-way server configuration
  • Height: 2U rack unit
  • Product Name: ProLiant DL380 Gen10 - Rack Mountable Server (SMB Networking Choice)

Processor & Chipset

  • CPU: 2nd Gen Intel Xeon Gold 5220 / 2.2 GHz
  • Max Turbo Speed: 3.9 GHz
  • Number of Cores: 18 cores
  • CPU Installed: 1, Max Supported: 2
  • Upgradability: Processor upgradable
  • Advanced Features: Hyper-Threading, Intel Turbo Boost Technology 2.0
  • CPU Socket: FCLGA3647
  • Chipset: Intel C621

Cache Memory

  • Installed Size: 24.75 MB L3 Cache
  • Per Processor Cache: 24.75 MB

Memory (RAM)

  • Installed Size: 32 GB DDR4 SDRAM with Advanced ECC
  • Max Supported Memory: 1.5 TB (Registered ECC) / 3 TB (Load-Reduced ECC)
  • Effective Speed: 2666 MHz, Rated Speed: 2933 MHz
  • Form Factor: 288-pin DIMM
  • Total Slots: 24, with 23 slots free in single CPU setup
  • Additional Features: HPE SmartMemory, Dual Rank, Registered ECC

Storage

Hard Drive
  • Type: No HDD included
Storage Controller
  • Type: 1x RAID
  • Interface: SATA 6Gb/s, SAS 12Gb/s
  • Controller: HPE Smart Array P408i-a
  • RAID Levels Supported: 0, 1, 5, 6, 10, 50, 60, 1 ADM, 10 ADM
  • Buffer Size: 2 GB

Optical & Card Reader

  • Optical Drive: Not included
  • Card Reader: MicroSD supported

Graphics Controller

  • Video Memory: 16 MB
  • Video Interface: VGA

Network & Communication

  • Ethernet Ports: 2 x 10/25 Gigabit Ethernet (SFP28)
  • Controller: Broadcom BCM57414
  • Protocols Supported: 10GbE, 25GbE
  • Management: Integrated Lights-Out 5 (iLO 5), PXE Support, Wake-on-LAN

Expansion & Connectivity

  • Expansion Bays: 8x 2.5" SFF Hot-Swap (all available)
  • Expansion Slots:
    • 1x MicroSD (internal)
    • 1x PCIe 3.0 x8 Full-Length, Full-Height
    • 1x PCIe 3.0 x16 Full-Length, Full-Height
    • 1x PCIe 3.0 x8 Half-Length, Full-Height
    • 1x FlexibleLOM Slot
  • Interfaces:
    • 3x USB 3.0 (1 Front, 2 Rear)
    • 1x VGA
    • 2x LAN (10GbE)
    • 1x HPE iLO
    • 1x HPE iLO Service Port

Power Supply

  • Power Supply Type: Hot-plug
  • Power Redundancy: Optional (1+1 configuration with additional power supply)
  • Installed Power: 800W, Max Supported: 2
  • Voltage Required: AC 120/230 V, 50/60 Hz
  • Certification: 80 PLUS Platinum

Environmental Standards

  • Energy Star Certified: Yes, Version 3.0
  • Operating Temperature: 50°F to 95°F
  • Humidity Range: 8% to 90% (non-condensing)

Dimensions & Weight

  • Width: 17.5 inches
  • Depth: 26.7 inches
  • Height: 3.4 inches
  • Weight: 32.54 lbs

Enhanced Performance

The Xeon 2.2GHz processor is designed to handle demanding workloads and provide high levels of performance. With its advanced architecture and multiple cores, it can efficiently process complex tasks and deliver faster results. This means that businesses can run resource-intensive applications, such as virtualization or database management, without experiencing any slowdowns or performance bottlenecks.

Improved Productivity

By utilizing the power of the Xeon 2.2GHz processor, the HPE Proliant DL380 Gen10 enables businesses to improve their overall productivity. With faster processing speeds, tasks can be completed more quickly, allowing employees to focus on other important activities. Whether it's running multiple virtual machines simultaneously or performing data analysis, this server can handle it all with ease.

Scalability and Future-Proofing

The Xeon 2.2GHz processor also offers scalability, allowing businesses to adapt their server infrastructure as their needs evolve. With support for multiple sockets and high memory capacity, the HPE Proliant DL380 Gen10 can easily accommodate future growth and handle increasing workloads. This ensures that businesses can make the most of their investment by extending the lifespan of their server and avoiding costly upgrades shortly.

Memory

Another key feature of the HPE Proliant DL380 Server Gen10 is its DDR4 SDRAM memory. This advanced memory technology provides numerous benefits for users in terms of performance, reliability, and flexibility.

Enhanced Performance and Speed

DDR4 SDRAM offers significant improvements over its predecessor, DDR3, in terms of speed and bandwidth. With higher clock speeds and increased data transfer rates, this memory technology allows for faster access to data, resulting in improved application performance. Whether it's running memory-intensive applications or handling large datasets, the HPE Proliant DL380 Gen10 with DDR4 SDRAM ensures that businesses can achieve optimal performance and responsiveness.

Reliability and Data Integrity

Memory errors can lead to data corruption and system crashes, causing downtime and potential loss of critical information. DDR4 SDRAM incorporates advanced error correction mechanisms, such as Error Correcting Code (ECC) technology, which detects and corrects memory errors in real time. This ensures the integrity of data stored in memory and enhances the overall reliability of the server. Businesses can have peace of mind knowing that their valuable data is protected and their server is operating at its best.

Flexible Configuration Options

The HPE Proliant DL380 Gen10 offers flexible memory configuration options to meet the specific needs of different applications and workloads. With support for a wide range of memory modules and capacities, businesses can customize their server's memory configuration based on their requirements. This flexibility allows for efficient resource allocation and ensures that the server is optimized for maximum performance.

Part Number

The HPE Proliant DL380 Server Gen10 is identified by its unique part number, P39380-B21. This part number serves as a crucial identifier for users and plays a significant role in various aspects of server management.

Easy Identification

With a specific part number like P39380-B21, users can easily identify the HPE Proliant DL380 Gen10 server among other models or variations within the Proliant series. The part number serves as a clear indicator of the server's specific features, capabilities, and compatibility, allowing users to make informed decisions when selecting or managing their server infrastructure.

Efficient Inventory Management

Part numbers play a vital role in inventory management for businesses. By using a unique part number like P39380-B21, organizations can easily track and manage their server assets. It enables efficient inventory management processes such as stock tracking, asset allocation, and maintenance scheduling. This ensures that businesses have better control over their server infrastructure and can optimize their resources effectively.

Seamless Replacement and Upgrades

In the event of a hardware failure or the need for an upgrade, having the specific part number of the HPE Proliant DL380 Gen10, such as P39380-B21, simplifies the replacement or upgrade process. Users can quickly identify and order the exact replacement part or compatible upgrade components, ensuring compatibility and minimizing downtime. This streamlines the maintenance and support activities, resulting in faster resolution times and improved overall server availability.

In conclusion, the HPE Proliant DL380 Server Gen10 offers impressive features that enhance performance, reliability, and flexibility. The Xeon 2.2GHz processor provides exceptional processing power, allowing businesses to handle demanding workloads with ease. The DDR4 SDRAM memory technology ensures improved performance, data integrity, and scalability. Additionally, the unique part number, P39380-B21, facilitates easy identification, efficient inventory management, and seamless replacement or upgrades. With these features combined, businesses can rely on the HPE Proliant DL380 Gen10 for their critical server needs.
