HPE DL380p Gen8 Xeon 6C 2.1GHz 16GB DDR3 8Sff SSD Server - 734790-S01

Processor

The HPE DL380p Gen8 Server is equipped with a powerful Xeon 6 Core 2.1GHz processor, delivering exceptional performance and reliability. The processor is the heart of any server, responsible for executing all the computing tasks and ensuring smooth operation. With the Xeon 6 Core 2.1GHz processor, users can expect lightning-fast processing speed and efficient multitasking capabilities

Manufacturer Details

• Manufacturer: Hewlett Packard Enterprise (HPE)
• Manufacturer Part Number: 734790-S01
• Product Name: ProLiant DL380p Gen8 2U Rack Server

Processor and Chipset Specifications

Processor Type

• Type: Intel Xeon E5-2620 V2
• Clock Speed: 2.1 GHz
• Socket: LGA2011
• Core Count: Hexa-core (6-core)
• 64-Bit Computing: Supported

Chipset Details

• Chipset Model: Intel C600
• Max Supported Processors: 2
• Upgradability: Yes

Cache Memory

• Cache Type: L3 Cache
• Installed Size: 15 MB
• Cache Per Processor: 15 MB

Memory Specifications

Installed Memory

• Size: 16 GB
• Maximum Capacity: 768 GB
• Technology: DDR3 SDRAM
• Memory Speed: 1600 MHz
• Compliance: PC3-10600
• Form Factor: DIMM 240-pin
• Total Slots: 24
• Features: Registered, Dual Rank, Quad Channel Architecture, HP Smart Memory

Supported RAM Configurations

• PC3-12800: Up to 384 GB - Registered
• PC3-10600: Up to 768 GB
• PC3-10600: Up to 128 GB - Unbuffered - Advanced ECC

Storage Details

Hard Drive Options

• Standard Configuration: No Hard Drive Included
• Internal Storage Bays: 8 SFF SAS/SATA HDD Bays
• Optical Drive Bay: Optional Slim Optical Bay (SATA DVD-RW/ROM)

Storage Controllers

• Controller Type: RAID - Plug-in Card - PCI Express 3.0 x8
• Controller Interface: SATA 6Gb/s / SAS 6Gb/s
• Controller Name: Smart Array P420i with 512MB FBWC
• RAID Levels: RAID 0, RAID 1, RAID 5, RAID 10, RAID 50
• Buffer Size: 512 MB

Display and Graphics

• Graphics Type: Integrated
• Graphics Controller: Matrox G200

Networking and Communication

Network Interfaces

• Networking Type: Plug-in Card
• Interface Type: PCIe x4
• Ethernet Ports: 4 x Gigabit Ethernet
• Ethernet Controller: HP 331FLR
• Protocols Supported: Ethernet, Fast Ethernet, Gigabit Ethernet
• Remote Management: Integrated Lights-Out 4 (iLO 4)
• Additional Features: Wake On LAN (WoL), PXE Support
• Standards Compliance: IEEE 802.3, IEEE 802.3u, IEEE 802.1q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3ad (LACP)

Expansion and Connectivity

Expansion Bays

• Front Accessible Bays: 1 x 5.25in Slim Line (free)
• Hot-Swap Bays: 8 x 2.5in SFF (all available)

Expansion Slots

• Memory Slots: 24 DIMM 240-pin (23 free)
• Processor Slots: 2 (1 free)
• PCI Express x16 Slots: 2 (both free)
• PCI Express x8 Slots: 3 (all free)
• PCI Express x8 (X4 Mode) Slot: 1 (available)
• FlexibleLOM Slot: 1 (free)

Interfaces and Ports

• Serial Port: 1 x RS-232 9-pin D-sub
• Display Ports: 2 x VGA 15-pin HD D-sub (1 front, 1 rear)
• USB Ports: 7 x USB 2.0 (2 front, 4 rear, 1 internal)
• Network Ports: 4 x Ethernet RJ-45
• Management Port: HP iLO RJ-45

Power Specifications

• Power Supply Type: Hot Plug
• Redundancy: 1+1
• Installed Power Supply: 460 Watts
• Max Supported Power Supplies: 2
• Voltage Required: AC 120/220 V
• 80 Plus Certification: 80 Plus Platinum

Dimensions and Weight

• Width: 17.5 inches
• Depth: 27.5 inches
• Height: 3.4 inches
• Weight: 41 lbs

Enhanced Performance

The Xeon 6 Core 2.1GHz processor offers enhanced performance compared to its predecessors, allowing users to handle demanding workloads with ease. Whether you are running resource-intensive applications, virtualization environments, or database servers, this processor can handle it all. Its high clock speed and multiple cores ensure that each task is processed quickly and efficiently.

Multitasking Made Easy

With six cores, the Xeon 6 Core 2.1GHz processor enables seamless multitasking. Users can run multiple applications simultaneously without experiencing any lag or slowdowns. This feature is particularly beneficial for businesses that rely on their servers to handle a wide range of tasks simultaneously, improving overall productivity and efficiency.

Improved Energy Efficiency

The Xeon 6 Core 2.1GHz processor is designed to maximize energy efficiency without compromising performance. It incorporates advanced power management technologies that dynamically adjust power consumption based on workload demands. This not only reduces electricity costs but also contributes to a greener and more sustainable IT infrastructure.

Reliability and Scalability

The Xeon 6 Core 2.1GHz processor is built to deliver exceptional reliability and scalability, ensuring that your server can handle future growth and expansion. With its robust architecture and advanced features, this processor provides a solid foundation for your server infrastructure, minimizing downtime and maximizing uptime.

Memory

The HPE DL380p Gen8 Server comes equipped with 16GB DDR3 memory, offering ample capacity for smooth and efficient operation. Memory plays a crucial role in server performance, enabling quick access to data and facilitating seamless multitasking. With 16GB DDR3 memory, users can expect optimal performance and responsiveness from their server.

Improved Performance and Responsiveness

The 16GB DDR3 memory ensures that data can be accessed quickly, resulting in improved overall performance and responsiveness. This is particularly important for applications that rely heavily on data retrieval, such as databases or virtualization environments. Users will experience reduced latency and faster response times, leading to increased productivity.

Seamless Multitasking

The ample capacity of 16GB DDR3 memory allows for seamless multitasking, even when running resource-intensive applications. Users can run multiple virtual machines, perform complex calculations, or handle large datasets without experiencing any slowdowns or performance bottlenecks. This feature enhances productivity and enables businesses to maximize their server resources.

Future-Proofing Your Server

With 16GB DDR3 memory, the HPE DL380p Gen8 Server offers room for future expansion and scalability. As your business grows and demands increase, you can easily upgrade the memory to meet your evolving needs. This future-proofing capability ensures that your server investment remains viable for years to come, saving you time and money in the long run.

Reliability and Data Integrity

Reliability is a critical aspect of any server's memory subsystem. The 16GB DDR3 memory in the HPE DL380p Gen8 Server is designed with error-correcting code (ECC) technology, which detects and corrects memory errors on the fly. This ensures data integrity and minimizes the risk of system crashes or data corruption, providing peace of mind to users.

Storage

The HPE DL380p Gen8 Server features 8SFF SSD storage, offering fast and reliable data storage capabilities. Storage is a crucial component of any server, as it determines the capacity, speed, and reliability of data access. With 8SFF SSD storage, users can expect exceptional performance and enhanced data protection.

High-Speed Data Access

The 8SFF SSD storage provides lightning-fast data access speeds, significantly outperforming traditional hard disk drives (HDDs). This is particularly important for applications that require quick access to large datasets, such as databases or virtualization environments. Users will experience reduced latency and faster data retrieval, resulting in improved overall system performance.

Improved Reliability and Durability

SSDs are known for their superior reliability and durability compared to HDDs. The absence of moving parts in SSDs reduces the risk of mechanical failures, increasing the lifespan of the storage system. Additionally, SSDs are less susceptible to environmental factors such as temperature fluctuations or vibrations, further enhancing their reliability in demanding server environments.

Enhanced Data Protection

8SFF SSD storage provides enhanced data protection features to safeguard critical information. These SSDs typically incorporate advanced error correction algorithms and wear-leveling technologies to ensure data integrity and minimize the risk of data loss. With reliable data protection mechanisms in place, businesses can confidently store and access their valuable data.

Optimized Storage Capacity

The 8SFF SSD storage offers optimized storage capacity within a compact form factor. These small form factor SSDs allow for greater storage density, enabling businesses to maximize their storage capacity within limited server space. This feature is particularly beneficial for organizations with data-intensive applications or limited rack space availability.

Product Code

The HPE DL380p Gen8 Server is identified by the product code 734790-S01. This unique identifier is essential for accurately identifying and procuring the specific server model required. The product code serves as a reference point for support, warranty, and compatibility purposes, ensuring a seamless and efficient user experience.

Quick and Accurate Identification

The product code 734790-S01 allows for quick and accurate identification of the HPE DL380p Gen8 Server model. When ordering or requesting support, users can simply provide the product code to ensure that they receive the correct model with the desired specifications. This eliminates any confusion or potential issues that may arise from miscommunication.

Compatibility Assurance

The product code 734790-S01 ensures compatibility with specific accessories, spare parts, and software updates designed for the HPE DL380p Gen8 Server. It serves as a reference point for vendors and IT professionals when sourcing components or performing maintenance tasks. This compatibility assurance simplifies the procurement process and ensures seamless integration within existing server infrastructures.

Streamlined Warranty Support

The product code enables streamlined warranty support by providing a unique identifier for the HPE DL380p Gen8 Server model. When submitting warranty claims or seeking technical assistance, users can reference the product code to expedite the support process. This ensures prompt resolution of any issues and minimizes downtime, enabling businesses to maintain uninterrupted operations.

Model Differentiation

The HPE DL380p Gen8 Server may have multiple variations or configurations available. The product code 734790-S01 allows users to differentiate between different models and choose the one that best suits their requirements. Whether it's selecting a specific processor, memory capacity, or storage configuration, the product code ensures accurate identification and selection of the desired server model.
