HPE JL680A#ABA Aruba Instant On 1930 8 Ports Managed Switch 8 GB 2 SFP 11 Watt Managed L3 Switch

JL680A#ABA
Hover on image to enlarge

Brief Overview of JL680A#ABA

Aruba Instant On 1930 8 Ports Managed Switch HPE JL680A#ABA 8 GB 2 SFP 11 Watt Managed L3 Switch. Factory-Sealed New in Original Box (FSB)

with 3-Year Replacement Warranty
QR Code of HPE JL680A#ABA Aruba Instant On 1930 8 Ports Managed Switch 8 GB 2 SFP 11 Watt Managed L3 Switch
$232.20
$155.00
You save: $77.20 (33%)
Ask a question
Price in points: 155 points
+
Quote
Additional 7% discount at checkout
SKU/MPNJL680A#ABAAvailability✅ In StockProcessing TimeUsually ships same day ManufacturerHPE Manufacturer Warranty3 Years Warranty from Original Brand Product/Item ConditionFactory-Sealed New in Original Box (FSB) ServerOrbit Replacement WarrantySix-Month (180 Days)
Our Advantages
  • Free Ground Shipping
  • — Min. 6-month Replacement Warranty
  • — Genuine/Authentic Products
  • — Easy Return and Exchange
  • — Different Payment Methods
  • — Best Price
  • — We Guarantee Price Matching
  • — Tax-Exempt Facilities
  • — 24/7 Live Chat, Phone Support
Payment Options
  • — Visa, MasterCard, Discover, and Amex
  • — JCB, Diners Club, UnionPay
  • — PayPal, ACH/Wire Transfer
  • — Apple Pay, Amazon Pay, Google Pay
  • — Buy Now, Pay Later - Affirm, Afterpay
  • — GOV/EDU/Institutions PO's Accepted
  • — Invoices
Delivery
  • — Deliver Anywhere
  • — Express Delivery in the USA and Worldwide
  • — Ship to -APO -FPO
  • For USA - Free Ground Shipping
  • — Worldwide - from $30
Description

Product Specifications

Overview of HPE JL680A#ABA

The HPE JL680A#ABA Aruba Instant On 1930 8G 2SFP Switch is designed for efficient networking. With a total of 10 ports, this managed device is suitable for rack mounting in a 1U enclosure.

Manufacturer and Model Information

  • Brand: HPE
  • Model Number: JL680A#ABA
  • Device Type: Managed Switch

Key Features

Port Configuration

This switch is equipped with a diverse set of ports:

  • 8 x 10/100/1000 Mbps Ethernet ports
  • 2 x Gigabit SFP slots for fiber connections

Performance Metrics

  • Switching Capacity: 20 Gbps
  • Throughput: 14.88 Mpps
  • Latency:
    • 5.2 μs (100 Mbps)
    • 3 μs (1 Gbps)

Capacity and Functionality

  • Link Aggregation: 8 ports
  • Static IPv4 Routes: 32
  • Supported VLANs: 256
  • Access Control Entries (ACEs) per ACL: 480
  • Packet Buffer Size: 1.5 MB
  • MAC Address Table Size: 8000 entries
  • Jumbo Frame Support: 9216 bytes

Networking Protocols

Routing and Management

  • Routing Protocol: Static IP Routing
  • Remote Management Protocols: SNMP v1, RMON, SNMP v3, SNMP v2c, HTTP, HTTPS, TFTP, RADIUS

Security Features

  • Encryption: SSL
  • Authentication: RADIUS

Additional Features

  • Flow Control
  • DHCP and ARP Support
  • VLAN Support
  • Auto-Uplink (Auto MDI/MDI-X)
  • IGMP Snooping
  • IPv6 Support
  • Half Duplex and Full Duplex Modes
  • Spanning Tree Protocol (STP) Support
  • Multiple Spanning Tree Protocol (MSTP) Support
  • Access Control List (ACL) Support
  • Quality of Service (QoS)
  • Trusted Platform Module (TPM)
  • LLDP Support
  • Link Aggregation Control Protocol (LACP)
  • Energy Efficient Ethernet
  • Class of Service (CoS)
  • BPDU Filter

Compliance Standards

This switch adheres to various IEEE standards, ensuring compatibility and performance:

  • IEEE 802.3, 802.3u, 802.1d, 802.1q, 802.3ab, 802.1p, 802.3af, 802.3x, 802.3ad (LACP), 802.1w, 802.1x, 802.1s, 802.1ab (LLDP), 802.3at, 802.3az

Hardware Specifications

Processor and Memory

  • Processor: 1 x ARM Cortex-A9 at 800 MHz
  • RAM: 512 MB SDRAM
  • Flash Memory: 256 MB

Status Indicators

  • Port Status
  • Power

Power Requirements

Power Supply and Consumption

  • Power Device: External Power Adapter
  • Voltage Requirements: AC 120/230 V (50/60 Hz)
  • Operational Power Consumption: 11 Watts

Ports

The HPE Aruba Instant On 1930 Managed Switch is equipped with 8 ports, making it an ideal choice for small to medium-sized businesses that require a reliable and efficient network solution. These ports allow for seamless connectivity between various devices, including computers, printers, servers, and more.

Increased Connectivity

With 8 ports, the HPE Aruba Instant On 1930 Managed Switch provides users with increased connectivity options. This allows businesses to connect multiple devices simultaneously without the need for additional switches or routers. Whether you need to connect workstations in an office environment or devices in a retail setting, the 8 ports ensure that you have enough connectivity options to meet your needs.

Flexibility

The 8 ports on the HPE Aruba Instant On 1930 Managed Switch offer flexibility in network design. Users have the freedom to connect devices in a variety of configurations, including daisy-chaining, star topology, or a combination of both. This flexibility allows for easy expansion and scalability as your business grows.

Improved Performance

Having 8 ports on the HPE Aruba Instant On 1930 Managed Switch ensures optimal performance for all connected devices. Each port supports high-speed data transfer rates, enabling fast and efficient communication between devices. Whether you are transferring large files or streaming multimedia content, the 8 ports ensure a smooth and uninterrupted experience.

Memory

The HPE Aruba Instant On 1930 Managed Switch features 8 GB of memory, providing users with ample storage capacity for network configurations and settings. This memory capacity is crucial for ensuring smooth operation and efficient performance of the switch.

Configuration Storage

With 8 GB of memory, users can store and save network configurations on the HPE Aruba Instant On 1930 Managed Switch itself. This eliminates the need for external storage devices or cloud-based solutions, simplifying the management process. Storing configurations directly on the switch ensures that settings are easily accessible and can be quickly applied when needed.

Backup and Recovery

The 8 GB of memory also allows for easy backup and recovery of network configurations. Users can create regular backups of the switch's settings, ensuring that in the event of a failure or unexpected reset, configurations can be easily restored. This feature provides peace of mind and minimizes downtime, as network settings can be quickly recovered without the need for manual reconfiguration.

Enhanced Performance

The ample memory capacity of 8 GB ensures that the HPE Aruba Instant On 1930 Managed Switch operates smoothly and efficiently. With this memory capacity, the switch can handle a high volume of data traffic and complex network operations without experiencing performance issues. This is particularly beneficial for businesses with demanding network requirements, such as those handling large data transfers or running resource-intensive applications.

SFP Ports

The HPE Aruba Instant On 1930 Managed Switch is equipped with 2 SFP (Small Form-factor Pluggable) ports. These specialized ports offer users additional connectivity options and flexibility when it comes to network deployment.

Extended Connectivity Range

SFP ports enable long-range connectivity by allowing users to connect fiber optic cables to the HPE Aruba Instant On 1930 Managed Switch. This feature is particularly valuable for businesses that require network connections over long distances, such as those spanning multiple floors or buildings. The 2 SFP ports ensure that you have the necessary connectivity options to extend your network reach without sacrificing performance or reliability.

Flexible Network Design

The SFP ports on the HPE Aruba Instant On 1930 Managed Switch provide flexibility in network design. Users can choose to connect devices using either copper Ethernet cables or fiber optic cables, depending on their specific requirements. This flexibility allows for easy integration with existing infrastructure and enables seamless communication between devices, regardless of their physical location.

High-Speed Data Transfer

The SFP ports support high-speed data transfer rates, ensuring fast and efficient communication between devices. This is particularly beneficial for businesses that require quick data transfers, such as those involved in media production, video surveillance, or data centers. The 2 SFP ports ensure that you have the necessary bandwidth to handle large data volumes and maintain optimal network performance.

Power Consumption

The HPE Aruba Instant On 1930 Managed Switch boasts a power consumption of 11 Watts. This low power consumption ensures energy efficiency and cost savings for businesses while still maintaining reliable network performance.

Energy Efficiency

With a power consumption of only 11 Watts, the HPE Aruba Instant On 1930 Managed Switch is designed to be energy-efficient. This not only reduces the environmental impact but also lowers energy costs for businesses. The switch intelligently manages power usage, optimizing energy consumption without sacrificing performance or functionality.

Cost Savings

By consuming less power, the HPE Aruba Instant On 1930 Managed Switch helps businesses save on electricity costs. Over time, these savings can significantly contribute to reducing operational expenses. Additionally, the switch's energy efficiency may also make businesses eligible for certain energy-saving incentives or certifications.

Reliable Performance

Despite its low power consumption, the HPE Aruba Instant On 1930 Managed Switch delivers reliable and consistent network performance. It is designed to handle high data traffic and demanding network operations without compromising on reliability or quality. Users can enjoy uninterrupted connectivity and smooth operation while still benefiting from energy-efficient technology.

Management Type

The HPE Aruba Instant On 1930 Managed Switch is a Managed L3 Switch, providing users with advanced management capabilities and enhanced control over their network infrastructure.

Centralized Management

As a Managed L3 Switch, the HPE Aruba Instant On 1930 allows for centralized management of network devices. This means that users can control and configure multiple switches from a single interface, simplifying network administration. Centralized management streamlines operations, reduces complexity, and enhances efficiency by providing a unified view of the entire network.

Advanced Network Monitoring

Managed L3 Switches offer advanced monitoring and reporting capabilities, allowing users to gain insights into network performance and troubleshoot issues effectively. With the HPE Aruba Instant On 1930 Managed Switch, users can monitor traffic patterns, identify bottlenecks, and proactively address potential problems. This level of visibility ensures optimal network performance and minimizes downtime.

Enhanced Security

Managed L3 Switches provide robust security features to protect the network from unauthorized access and potential threats. The HPE Aruba Instant On 1930 Managed Switch offers features such as access control lists (ACLs), VLANs, and secure authentication protocols. These security measures help safeguard sensitive data, prevent unauthorized access, and ensure compliance with industry regulations.

SKU

The SKU (Stock Keeping Unit) for the HPE Aruba Instant On 1930 Managed Switch is JL680A#ABA. This unique identifier is important for businesses to accurately track inventory and manage their network infrastructure effectively.

Inventory Management

By using the SKU JL680A#ABA, businesses can easily track and manage their HPE Aruba Instant On 1930 Managed Switch within their inventory system. The SKU ensures that the switch is correctly identified and helps streamline inventory management processes, including procurement, tracking, and asset management.

Product Identification

The SKU JL680A#ABA is crucial for accurately identifying the HPE Aruba Instant On 1930 Managed Switch among other similar products. This ensures that businesses can easily differentiate between different models, versions, or configurations of switches. The SKU simplifies the purchasing process and ensures that the correct product is obtained.

Warranty and Support

The SKU JL680A#ABA is also important for warranty and support purposes. By referencing the SKU, businesses can quickly and accurately communicate with HPE or authorized resellers regarding any warranty claims, technical support, or product inquiries. This streamlines the support process and ensures that businesses receive the appropriate assistance in a timely manner.

Features
Manufacturer Warranty:
3 Years Warranty from Original Brand
Product/Item Condition:
Factory-Sealed New in Original Box (FSB)
ServerOrbit Replacement Warranty:
Six-Month (180 Days)
