HPE JL681A 2SFP 124W Switch 8 Ports Managed Rack Mountable

JL681A
Hover on image to enlarge

Brief Overview of JL681A

HPE 2SFP 124W Switch 8 Ports Managed Rack Mountable JL681A. Factory-Sealed New in Original Box (FSB) 3 Years HPE Warranty
QR Code of HPE JL681A 2SFP 124W Switch 8 Ports Managed Rack Mountable
$328.73
$244.00
You save: $84.73 (26%)
Ask a question
+
Quote
Additional 7% discount at checkout
SKU/MPNJL681AAvailability✅ In StockProcessing TimeUsually ships same day ManufacturerHPE Manufacturer Warranty3 Years from the Original Brand Product/Item ConditionFactory-Sealed New in Original Box (FSB) ServerOrbit Replacement WarrantySix-Month (180 Days)
Our Advantages
  • Free Ground Shipping
  • — Min. 6-month Replacement Warranty
  • — Genuine/Authentic Products
  • — Easy Return and Exchange
  • — Different Payment Methods
  • — Best Price
  • — We Guarantee Price Matching
  • — Tax-Exempt Facilities
  • — 24/7 Live Chat, Phone Support
Payment Options
  • — Visa, MasterCard, Discover, and Amex
  • — JCB, Diners Club, UnionPay
  • — PayPal, ACH/Wire Transfer
  • — Apple Pay, Amazon Pay, Google Pay
  • — Buy Now, Pay Later - Affirm, Afterpay
  • — GOV/EDU/Institutions PO's Accepted
  • — Invoices
Delivery
  • — Deliver Anywhere
  • — Express Delivery in the USA and Worldwide
  • — Ship to -APO -FPO
  • For USA - Free Ground Shipping
  • — Worldwide - from $30
Description

Product Details of HPE JL681A Aruba Switch

General Information

  • Brand: HPE
  • Model Number: JL681A
  • Device Type: Managed Switch with Layer 2+ Features
  • Form Factor: 1U Rack-Mountable
  • Subtype: Gigabit Ethernet
  • Ports:
    • 8 x 10/100/1000 (PoE+)
    • 2 x Gigabit SFP

Power and Performance Specifications

  • Power over Ethernet (PoE): PoE+ with 124W Budget
  • Switching Capacity: 20 Gbps
  • Throughput: 14.88 Mpps
  • Latency:
    • 5.2 μs at 100 Mbps
    • 3 μs at 1 Gbps
  • MAC Address Table Size: 8,000 Entries
  • Jumbo Frames: Supports up to 9,216 Bytes

Routing and Protocol Support

  • Routing Protocols:
    • Static IPv4 Routing
    • IGMPv2 and IGMP
    • MSTP, RSTP, and STP
  • Remote Management:
    • SNMP Versions 2c and 3
    • HTTP/HTTPS
    • TFTP and SCP

Advanced Features

  • Energy-Efficient Ethernet (IEEE 802.3az)
  • Access Control List (ACL) Support
  • VLAN and QoS Features
  • Flow Control and Port Mirroring
  • Link Aggregation (LACP) and Trunking
  • Support for IPv4 and IPv6

Hardware Specifications

  • Processor: ARM Cortex-A9, 800 MHz
  • RAM: 512 MB
  • Flash Memory: 256 MB
  • Interfaces:
    • 8 x RJ-45 (1000Base-T)
    • 2 x Gigabit LAN SFP
Compliance and Standards
  • IEEE 802.3, 802.3u, 802.3z, and 802.3ab
  • IEEE 802.1D, 802.1Q, 802.1W, and 802.1S
  • Supports LLDP, RSTP, MSTP, and LACP

Power and Voltage

  • Power Device: Internal Power Supply
  • Power Provided: 150.2 Watts
  • Voltage: 120/230 V AC, 50/60 Hz

Ports

The HPE JL681A Managed Switch is equipped with 8 ports, making it an ideal choice for small to medium-sized businesses looking to establish a reliable and efficient network infrastructure. These ports provide connectivity for various devices, allowing for seamless communication and data transfer within the network.

Increased Connectivity

With 8 ports, this managed switch offers an ample number of connections for your networking needs. This allows you to connect multiple devices such as computers, printers, servers, and other network-enabled devices without the need for additional hardware. Whether you are setting up a small office network or expanding an existing one, the 8 ports on this switch ensure that you have sufficient connectivity options.

Flexible Network Expansion

The availability of 8 ports provides flexibility when it comes to expanding your network in the future. As your business grows and your networking requirements evolve, having extra ports allows you to easily accommodate new devices or add more connections to support increased data traffic. This scalability ensures that your network can adapt to the changing needs of your organization without requiring costly upgrades or replacements.

Efficient Data Transfer

Each port on the HPE JL681A Managed Switch supports high-speed data transfer rates, enabling quick and efficient communication between connected devices. This is particularly beneficial in environments where large files or data-intensive applications are common. By leveraging the 8 ports on this switch, you can enjoy smooth and uninterrupted data transfer, enhancing productivity and minimizing downtime.

Power

When it comes to network equipment, power is a critical aspect that directly affects performance and reliability. The HPE JL681A Managed Switch boasts a power capacity of 124W, ensuring that it can handle the demands of your network without compromising on stability or functionality.

Sufficient Power Supply

With a power capacity of 124W, this managed switch can provide sufficient power to all connected devices, including Power over Ethernet (PoE) devices. This eliminates the need for separate power adapters for individual devices, simplifying cable management and reducing clutter. Additionally, the switch allocates power intelligently, ensuring that each device receives the necessary power without overloading the system.

Support for Power-hungry Devices

The 124W power capacity of the HPE JL681A Managed Switch allows it to support power-hungry devices such as wireless access points, IP cameras, and VoIP phones. These devices often require PoE capabilities to function properly, and with this switch, you can seamlessly integrate them into your network infrastructure without worrying about inadequate power supply. This feature is especially beneficial in environments where multiple PoE devices need to be deployed.

Enhanced Reliability

Adequate power supply is crucial for maintaining a reliable network. The 124W capacity of this switch ensures that even during peak usage periods or when multiple devices are connected, the switch can deliver consistent power without experiencing performance degradation. This reliability reduces the risk of network downtime and ensures uninterrupted connectivity for your business-critical operations.

Mounting

The HPE JL681A Managed Switch offers the convenience of rack mountable installation, allowing you to optimize space utilization and streamline your network infrastructure setup.

Space Optimization

Rack mountable switches are designed to be installed in standard server racks or cabinets, making efficient use of vertical space. By mounting the switch along with other networking equipment in a rack, you can consolidate your network infrastructure into a compact and organized form factor. This not only saves valuable floor space but also facilitates easier cable management and troubleshooting.

Easier Maintenance

Rack mountable switches offer improved accessibility compared to non-mountable alternatives. With the HPE JL681A Managed Switch, you can conveniently access and manage the switch from the front or rear of the rack, eliminating the need to physically handle or move the switch during maintenance tasks. This saves time and effort, especially in larger network setups where multiple switches are deployed.

Scalability and Future-proofing

Rack mountable switches provide scalability for your network infrastructure. As your organization grows or your networking requirements change, you can easily add or replace switches within the rack without disrupting the existing setup. This future-proofing capability allows you to adapt to evolving technologies and expand your network seamlessly, saving costs associated with extensive rewiring or reconfigurations.

Interfaces

The HPE JL681A Managed Switch features 2 SFP (Small Form-factor Pluggable) interfaces, offering versatile connectivity options for your network.

Flexibility in Network Design

The inclusion of 2 SFP interfaces provides flexibility in designing your network architecture. SFP interfaces are widely used in fiber optic networks and allow for longer distance connections compared to traditional copper-based Ethernet connections. With these interfaces, you can establish connections over longer distances without compromising on speed or reliability.

Interoperability with Fiber Optic Technology

Fiber optic technology is known for its superior speed, bandwidth, and immunity to electromagnetic interference. By incorporating SFP interfaces into the HPE JL681A Managed Switch, you can seamlessly integrate fiber optic connectivity into your network infrastructure. This is particularly advantageous in scenarios where high-speed data transfer or long-distance connections are required, such as in data centers or remote offices.

Redundancy and Failover Protection

SFP interfaces also offer redundancy and failover protection for critical network connections. By utilizing multiple SFP interfaces with redundant fiber optic links, you can create resilient connections that automatically switch to a backup link in the event of a failure. This ensures uninterrupted connectivity and minimizes the impact of network disruptions, enhancing overall network reliability and uptime.

Features
Manufacturer Warranty:
3 Years from the Original Brand
Product/Item Condition:
Factory-Sealed New in Original Box (FSB)
ServerOrbit Replacement Warranty:
Six-Month (180 Days)
