HPE ML110 Gen11 Server P55535-001 3408U 1P 32G 8Sff 800W

Part Number: P55535-001

The HPE ML110 Server Gen11 Server is an exceptional piece of hardware designed to meet the demanding needs of businesses and organizations. One of the standout features of this server is its part number, P55535-001. In this section, we will explore the benefits and importance of this specific part number for users.

General Overview of Server Gen11

• Manufacturer: Hewlett Packard Enterprise
• Part Number: P55535-001
• Form Factor: Tower - 4.5 U
• Scalability: 1-way
• Hot-swap Bays: 8
• Product Name: HPE Proliant ML110 Gen11

Processor & Chipset Details

• Processor: Intel Xeon Bronze 3408u
• Clock Speed: 1.8 GHz
• Max Turbo Frequency: 1.9 GHz
• Cores: 8-core
• Installed Processors: 1
• Maximum Processors: 1
• Chipset Model: C741
• CPU Socket: FCLGA4677 Socket
• Upgradability: Yes

Processor Features

• Intel Quick Assist Technology (QAT)
• Intel Hyper-Threading Technology
• Intel Turbo Boost Technology 2.0

Cache Memory

• Type: Smart Cache
• Installed Size: 22.5 MB
• Cache per Processor: 22.5 MB

Memory Specifications

• Memory Type: HPE DDR5 Smart Memory, Registered (RDIMM)
• Installed Size: 32 GB / Up to 1 TB
• Technology: Advanced ECC
• Effective Speed: 4000 MHz
• Rated Speed: 4800 MHz
• DIMM Rank: Dual Rank (2R)
• Form Factor: DIMM 288-pin
• Configuration: 1 x 32 GB
• Slots: 16 (Total) / 15 (Empty)

Features

• Registered Memory
• Online Spare Memory
• Dual Rank
• Mixing of Different Types of Memory Modules Not Supported
• 16 DIMM Slots Per Processor
• 8 Channels Per Processor
• 2 DIMMs Per Channel

Storage Information

• HDD/SSD: None Included as Standard
• Optical Drive: Available as an Option (DVD-ROM or DVD-RW)

Storage Controller

• Name: Embedded 8 SATA Ports Controller with Intel VROC Software RAID
• Controller Interface Type: SATA 6Gb/s
• Controller Model: Intel VROC
• Channel Quantity: 8
• RAID Supported: Yes
• RAID Levels: RAID 0, RAID 1, RAID 5, RAID 10

Graphics and Display

• Video Interfaces: VGA
• Video Memory: 16 MB
• Supported Video Mode: Up to 1920 x 1200 @ 60Hz (32 Bpp)

Network and Communication

• Name: Embedded 2-Port 1GbE BCM5720 Networking Ports
• Ethernet Ports: 2 x Gigabit Ethernet
• Ethernet Controller: Broadcom BCM5720
• Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
• Remote Management Protocols: SNMP 3, IPMI 2.0, SMASH CLP
• Remote Management Controller: Integrated Lights-Out 5
• Features: Wake On LAN (WOL), PXE Support

Expansion and Connectivity

• External Bays: 1 x External 5.25 (Free)
• Hot-swap Bays: 8 x 2.5 SFF (All Free)
• PCIe Slots: 2 x PCIe 5.0 x16 (Free), 1 x PCIe 5.0 x16 / OCP 3.0 (x16 Mode) (Free)

Interfaces

• 1 x VGA
• 2 x LAN (Gigabit Ethernet)
• 1 x HPE iLO - RJ-45 (Rear)
• 3 x USB 3.0 (1 Front, 2 Rear)
• 1 x HPE iLO - Type A (Front)

Miscellaneous

• Included Accessories: HPE Standard Heatsink, 2 Non-hot Plug Standard Fans
• Compliance Standards: WEEE, PCIe 5, ASHRAE Class A3, ACPI 6.4

Power Specifications

• Device Type: Power Supply - Hot-plug
• Power Redundancy: Optional
• Redundancy Scheme: 1+1 (with Optional Power Supply)
• Installed Quantity: 1 (1x Platinum)
• Maximum Supported Quantity: 2
• Nominal Voltage: AC 120/230 V (50/60 Hz)
• Power Provided: 800 Watts
• Efficiency: Platinum 94%
• 80 Plus Certification: 80 Plus Platinum

Dimensions and Weight

• Width: 7.68 in
• Depth: 23.1 in
• Height: 18.19 in
• Weight: 44.31 lbs

Enhanced Compatibility and Support

The part number P55535-001 signifies a specific configuration of the HPE ML110 Server Gen11 Server. This configuration has been meticulously designed and tested to ensure maximum compatibility and support for various software applications and operating systems. By using this particular part number, users can be confident that their server has undergone rigorous testing to ensure seamless integration with their existing infrastructure.

Streamlined Troubleshooting

In the event of any issues or technical difficulties, having a specific part number like P55535-001 can significantly streamline the troubleshooting process. Technical support teams can quickly identify the exact configuration of the server and provide targeted assistance, minimizing downtime and maximizing productivity.

Efficient Upgrades and Expansion

When it comes to expanding or upgrading your server, having a specific part number like P55535-001 can be immensely helpful. It ensures that you can easily identify compatible components and accessories that will seamlessly integrate with your existing setup. This eliminates the guesswork and minimizes the risk of compatibility issues, saving both time and money.

Easy Documentation

Another advantage of having a unique part number like P55535-001 is the ease of documentation. Whether you need to keep track of your server's specifications for internal purposes or share them with external stakeholders, having a distinct identifier simplifies the process. You can easily refer to the part number in manuals, invoices, or any other documentation related to your server, ensuring clarity and consistency.

Summary:

In summary, the part number P55535-001 of the HPE ML110 Server Gen11 Server offers enhanced compatibility and support, streamlined troubleshooting, efficient upgrades and expansion, and easy documentation. By choosing this specific configuration, users can enjoy a hassle-free experience and maximize the performance of their server.

Processor: 3408U

The processor is the heart of any server, and the HPE ML110 Server Gen11 Server is equipped with a powerful 3408U processor. In this section, we will delve into the benefits and importance of this specific processor for users.

Exceptional Performance

The 3408U processor delivers exceptional performance, making it ideal for resource-intensive tasks and demanding workloads. With its high clock speed and multiple cores, it can handle complex calculations, data processing, virtualization, and much more with ease. This ensures that your server operates at optimal levels, providing fast and responsive performance for your business-critical applications.

Improved Energy Efficiency

Energy efficiency is a crucial consideration in today's environmentally conscious world. The 3408U processor is designed to be highly power-efficient, allowing you to reduce your carbon footprint and lower your energy costs. By utilizing advanced power management technologies, it intelligently adjusts power consumption based on workload demands, optimizing efficiency without compromising performance.

Enhanced Scalability

The 3408U processor offers enhanced scalability options, allowing you to easily scale up your server's processing power as your business grows. Whether you need to add more virtual machines or handle increased user traffic, this processor can accommodate your expanding needs. Its scalability ensures that your server remains future-proofed and can adapt to evolving requirements without significant hardware upgrades.

Reliable Security Features

Security is a top priority for any server, and the 3408U processor incorporates robust security features to protect your data and infrastructure. It includes advanced encryption technologies, secure boot capabilities, and hardware-based security enhancements to safeguard against unauthorized access and data breaches. With the 3408U processor, you can have peace of mind knowing that your server is fortified against potential threats.

Summary:

To summarize, the 3408U processor in the HPE ML110 Server Gen11 Server offers exceptional performance, improved energy efficiency, enhanced scalability, and reliable security features. It empowers users to handle demanding workloads, reduce energy costs, future-proof their server, and ensure the integrity of their data.

Memory: 32G

When it comes to server performance, having an ample amount of memory is crucial. The HPE ML110 Server Gen11 Server boasts an impressive 32G of memory. In this section, we will explore the benefits and importance of this significant memory capacity for users.

Efficient Multitasking

With 32G of memory, the ML110 Server Gen11 can effortlessly handle multiple tasks simultaneously. This is particularly important for businesses and organizations that rely on their servers to run multiple applications or virtual machines concurrently. The generous amount of memory ensures smooth multitasking without any noticeable slowdowns or performance bottlenecks.

Improved System Responsiveness

Insufficient memory can result in sluggish system responsiveness, leading to frustrated users and decreased productivity. The 32G of memory in the ML110 Server Gen11 ensures optimal system responsiveness even under heavy loads. Users can expect swift responses from their applications and a seamless user experience, enabling them to work efficiently without unnecessary delays.

Enhanced Virtualization Capabilities

Virtualization has become a standard practice for many businesses as it allows them to consolidate multiple servers onto a single physical machine. The ML110 Server Gen11's 32G of memory provides ample resources for virtualization, allowing you to create and manage multiple virtual machines without compromising performance. This enables businesses to optimize their infrastructure, reduce hardware costs, and simplify IT management.

Future-Proofed Scalability

As businesses grow and their IT requirements evolve, it is essential to have a server that can scale alongside them. The 32G of memory in the ML110 Server Gen11 provides room for future expansion. Whether you need to add more virtual machines, accommodate increased user traffic, or run memory-intensive applications, this server can adapt to your changing needs without requiring significant hardware upgrades.

Summary:

In summary, the 32G of memory in the HPE ML110 Server Gen11 Server offers efficient multitasking, improved system responsiveness, enhanced virtualization capabilities, and future-proofed scalability. It enables users to seamlessly handle multiple tasks, ensures swift application responses, simplifies virtualization efforts, and accommodates future growth.

Drive Bays: 8Sff

Storage is a critical component of any server, and the HPE ML110 Server Gen11 Server provides ample storage capacity with its 8Sff drive bays. In this section, we will explore the benefits and importance of this specific drive bay configuration for users.

Significant Storage Capacity

The 8Sff drive bays in the ML110 Server Gen11 offer significant storage capacity for businesses and organizations. Each small form factor (SFF) drive bay can accommodate a 2.5-inch hard drive or solid-state drive (SSD), allowing you to store large amounts of data. With eight drive bays available, you have plenty of room to expand your storage capacity as your needs grow.

Flexible Storage Configuration

The 8Sff drive bays provide flexibility in storage configuration, allowing you to customize your server to meet your specific requirements. You can choose to install a combination of hard drives and SSDs to optimize performance and storage capacity. This flexibility enables businesses to create storage solutions tailored to their unique needs, whether it's prioritizing speed, capacity, or a balance of both.

Hot-Swappable Drives

The ML110 Server Gen11's 8Sff drive bays support hot-swappable drives, which means you can replace or add drives without shutting down the server. This feature is invaluable for businesses that require high availability and cannot afford any downtime. With hot-swappable drives, you can perform maintenance or upgrades without interrupting critical operations, ensuring continuous access to your data.

Improved Data Redundancy

Redundancy is essential for data protection and disaster recovery. The 8Sff drive bays allow you to configure RAID arrays, which replicate data across multiple drives for enhanced redundancy. This ensures that if one drive fails, your data remains accessible and intact. By utilizing the 8Sff drive bays and implementing RAID configurations, you can safeguard your data against potential hardware failures.

Summary:

To summarize, the 8Sff drive bays in the HPE ML110 Server Gen11 Server offer significant storage capacity, flexible storage configuration, hot-swappable drives, and improved data redundancy. They provide ample room for data storage and expansion, customization options to meet specific requirements, uninterrupted maintenance capabilities, and enhanced data protection.

Power Supply: 800W

The power supply is a vital component of any server, and the HPE ML110 Server Gen11 Server is equipped with an 800W power supply. In this section, we will explore the benefits and importance of this specific power supply for users.

Reliable Power Delivery

The 800W power supply in the ML110 Server Gen11 ensures reliable and uninterrupted power delivery to your server components. It provides sufficient power to support the processor, memory, drives, and other hardware, ensuring optimal performance without any power-related issues. With a reliable power supply, you can avoid unexpected shutdowns or system instability, minimizing downtime and maximizing productivity.

Energy Efficiency

Energy efficiency is a key consideration for businesses looking to reduce their environmental impact and lower their energy costs. The 800W power supply in the ML110 Server Gen11 is designed to be highly efficient, converting power from the electrical outlet to usable energy with minimal waste. This not only benefits the environment but also contributes to cost savings by reducing electricity consumption.

Scalability and Expansion

The 800W power supply provides ample headroom for scalability and expansion. As your server requirements grow, you may need to add more components or upgrade existing ones. The ML110 Server Gen11's power supply can accommodate these changes, ensuring that you have enough power to support your expanding infrastructure without requiring a complete replacement of the power supply.

Redundancy and Fault Tolerance

Businesses rely on servers for critical operations, making redundancy and fault tolerance essential. The 800W power supply in the ML110 Server Gen11 supports redundant configurations, allowing you to connect multiple power supplies for increased reliability. In the event of a single power supply failure, the redundant configuration ensures that your server continues to operate without interruption, minimizing the risk of downtime.

Summary:

In summary, the 800W power supply in the HPE ML110 Server Gen11 Server offers reliable power delivery, energy efficiency, scalability and expansion capabilities, and redundancy and fault tolerance. It ensures uninterrupted operation, reduces energy consumption, accommodates future growth, and enhances system reliability.
