P09718-H21 HPE 960GB SATA 3.5 Inch Mixed Use SSD

HPE P09718-H21 960GB SATA 6Gbps SCC Mixed SSD

The HPE P09718-H21 is a high-performance 960GB solid state drive designed for mixed-use workloads. Built with Multi-Level Cell (MLC) NAND technology and a 3.5-inch form factor, this drive ensures reliability, speed, and compatibility with HPE ProLiant servers.

Key Features and Specifications

• Manufacturer: HPE
• Part Number: P09718-H21
• Device Type: Hot-Swap Solid State Drive
• Capacity: 960 GB
• NAND Flash: Multi-Level Cell (MLC)
• Form Factor: 3.5 inch Large Form Factor (LFF)
• Interface: SATA 6Gb/s
• Plug Type: Hot Plug
• Carrier: Smart Carrier Converter (SCC)
• Workload: Mixed Use
• Firmware: Digitally Signed
• Bundled: HPE Smart Carrier Converter

Performance Specifications

• 30-Day Writes: 6000 GB
• Drive Writes Per Day (DWPD): 3.5
• External Transfer Rate: 6 Gb/sec
• Internal Data Rate: 535 MBps (Read) / 495 MBps (Write)
• Random Read IOPS (4KiB, Q=16): 70,000
• Max Random Read IOPS (4KiB): 80,000@Q32
• Random Write IOPS (4KiB, Q=16): 31,000
• Max Random Write IOPS (4KiB): 31,000@Q4

Power Consumption

• Idle: 1.12 W
• Random Read/Write: 2.57 W
• Sequential Read: 1.86 W
• Sequential Write: 2.18 W
• Maximum Power Required: 2.18 W

Physical Dimensions and Weight

• Height: 5.74 inches
• Width: 10.00 inches
• Depth: 8.63 inches
• Weight: 3.00 lbs

Interface and Connectivity

• Interface: 1 x SATA 6Gb/s
• Compatible Bay: 3.5-inch LFF

Compatibility with HPE ProLiant Servers

The HPE P09718-H21 SSD is compatible with a wide range of HPE ProLiant DL Series servers, ensuring seamless integration and high performance for enterprise workloads.

Supported HPE ProLiant DL360 Models

• DL360 Gen10 (3.5 inch) – Base, Entry, High Performance, Low, Performance, SMB, Solution
• DL360 Gen9 (3.5 inch) – Base, CMS, Entry, Performance, Special Server

Supported HPE ProLiant DL380 Models

• DL380 Gen10 (3.5 inch) – Base, Entry, Entry SMB, Cohesity DataPlatform, High Performance, Performance, SMB, Solution
• DL380 Gen9 (3.5 inch) – Base, Entry, High Performance, Performance, Scale-up SAP HANA, Special

Supported HPE ProLiant DL385 Models

• DL385 Gen10 (3.5 inch) – Base, Entry, High-Performance, Performance, Solution

Advantages of the HPE P09718-H21 Mixed Use SSD

• High-speed SATA 6Gbps interface for fast data transfers
• Robust MLC NAND technology for endurance and reliability
• Digitally signed firmware ensures secure operation
• Smart Carrier Converter (SCC) simplifies installation and hot-swap support
• Optimized for mixed-use workloads, supporting both read-intensive and write-intensive applications
• Wide compatibility across multiple HPE ProLiant server generations

Ideal Use Cases

• Enterprise storage solutions requiring high reliability
• Database applications with frequent read/write cycles
• Virtualized environments with mixed workloads
• Data centers aiming for energy-efficient high-performance SSDs
• Backup and disaster recovery systems needing fast access

HPE P09718-H21 960GB SATA 6GBPS SSD

Reliable Storage Solution for Mixed Workloads

The HPE P09718-H21 960GB SATA 6GBPS 3.5 Inch SCC Mixed Use Solid State Drive is engineered for enterprise environments where reliability, endurance, and performance are critical. This solid-state drive leverages HPE's advanced storage technology to deliver optimal performance across a wide range of workloads, including read-intensive and mixed-use scenarios. Designed for compatibility with HPE ProLiant servers and storage systems, this SSD ensures seamless integration into existing infrastructure, providing high availability and operational efficiency.

High-Capacity SATA SSD Design

With a capacity of 960GB, the HPE P09718-H21 offers a substantial storage solution capable of handling demanding applications and large datasets. The 3.5-inch form factor allows for easy installation in standard server bays, while the SATA 6GBPS interface ensures fast data transfer rates. This drive is optimized for mixed-use environments, offering a balanced combination of read and write performance, which makes it suitable for database applications, virtualization, and heavy transactional workloads.

Advanced Solid State Drive Features

This SSD incorporates HPE's Smart Array technology and SmartSSD features, including power loss protection, wear-leveling algorithms, and advanced error correction. These innovations extend the drive’s lifespan, ensure data integrity, and minimize downtime. The SCC (Self-Certified Controller) architecture enhances drive reliability and reduces latency, delivering consistent performance for mission-critical applications. Enterprise users can trust the HPE P09718-H21 to maintain high throughput and low latency under continuous operational load.

Optimized Performance for Mixed Use

Mixed-use SSDs like the HPE P09718-H21 are specifically designed to handle a combination of read and write operations. Unlike read-intensive or write-intensive drives, this mixed-use SSD provides consistent performance across variable workloads. The drive is capable of sustaining high Input/Output Operations Per Second (IOPS) while maintaining low latency, which is essential for applications requiring rapid data access and processing. It ensures efficient performance in environments with frequent database transactions, virtualization, and content management systems.

Compatibility and Integration

The HPE P09718-H21 is fully compatible with HPE ProLiant servers, HPE storage arrays, and HPE Smart Array controllers. This ensures smooth deployment in enterprise environments without compatibility concerns. Integration is simplified by HPE’s firmware, which allows the drive to automatically optimize performance parameters based on workload characteristics. IT administrators can rely on this SSD for predictable performance and minimal system configuration requirements.

Enterprise-Grade Reliability and Endurance

Reliability is a cornerstone of HPE SSDs, and the P09718-H21 is no exception. This drive undergoes rigorous testing to meet stringent enterprise standards. Features such as power loss protection safeguard against unexpected shutdowns, while advanced wear-leveling and error correction mechanisms protect data over the drive’s operational life. The mixed-use design provides endurance for sustained workloads, making it suitable for both read-heavy and write-intensive applications in enterprise storage environments.

Data Security and Management

The HPE P09718-H21 supports a range of security features, including encryption and secure erase capabilities, to ensure data protection. Administrators can use HPE management tools to monitor drive health, track wear levels, and perform predictive analysis for proactive maintenance. These management features enable enterprises to maintain optimal storage performance while minimizing the risk of data loss or corruption.

Power Efficiency and Thermal Management

This SSD is designed with energy efficiency in mind, consuming minimal power while maintaining high performance. The low power consumption reduces operational costs and thermal output in data centers. Effective thermal management ensures that the drive operates within optimal temperature ranges, maintaining performance and longevity. HPE's engineering ensures that the drive remains stable even under high operational loads, contributing to the overall efficiency of enterprise storage environments.

Scalable Storage for Growing Workloads

The 960GB capacity of the HPE P09718-H21 allows enterprises to scale storage infrastructure without compromising performance. Its mixed-use capability makes it ideal for virtualized environments, high-performance computing applications, and mixed transactional workloads. By leveraging HPE’s storage ecosystem, organizations can expand storage capacity, manage data efficiently, and support growing business demands while maintaining consistent service levels.

Key Benefits of HPE P09718-H21 SSD

The HPE P09718-H21 delivers several critical benefits for enterprise IT environments. High-performance mixed-use design ensures balanced read/write operations, enabling smooth database and virtualization performance. Enterprise-grade reliability and endurance extend operational life, reducing the need for frequent replacements. Advanced data protection and management tools provide security and maintain drive health, while efficient power consumption minimizes energy costs. Compatibility with HPE ProLiant servers ensures seamless integration into existing infrastructures, providing predictable, high-speed storage performance for mission-critical workloads.

Technical Specifications and Performance Metrics

Storage Capacity and Form Factor

With 960GB of storage in a 3.5-inch form factor, the HPE P09718-H21 is optimized for enterprise server bays and storage racks. This form factor provides a balance between high capacity and compatibility with existing hardware setups, allowing IT teams to upgrade storage without major system modifications.

Interface and Data Transfer Rates

The SATA 6GBPS interface delivers high-speed connectivity, ensuring fast data access and efficient storage operations. This interface supports seamless integration with a wide range of HPE storage controllers, offering predictable performance and compatibility across diverse server environments.

Endurance and Reliability Metrics

The drive is designed to handle extensive mixed workloads with high endurance. Features such as power loss protection, advanced wear leveling, and error correction guarantee data integrity, even under intensive operations. These metrics make the HPE P09718-H21 suitable for mission-critical applications where reliability is non-negotiable.

Use Cases and Application Scenarios

Virtualization and Cloud Environments

The HPE P09718-H21 excels in virtualized infrastructures where multiple virtual machines require consistent storage performance. Its mixed-use capabilities ensure that read and write operations remain balanced, preventing bottlenecks and enabling smoother deployment of cloud-based applications.

Database and Transactional Workloads

This SSD is ideal for database environments with frequent read/write transactions. The drive’s high IOPS and low latency enable fast query responses and efficient data handling, ensuring optimal application performance and end-user experience.

Enterprise Storage Arrays

In enterprise storage arrays, the HPE P09718-H21 provides reliable, high-capacity storage for both primary and secondary workloads. Its SCC architecture ensures stable performance and minimizes latency, making it suitable for high-density storage configurations and demanding enterprise applications.
