HPE P41523-001 960GB SSD SATA 6Gbps Read Intensive

Capacity - 960GB

The Benefits of a 960GB Capacity

When it comes to solid-state drives (SSDs), capacity plays a crucial role in determining the overall performance and functionality of the device. With a generous capacity of 960GB, the HPE P41523-001 Solid State Drive provides users with ample storage space for their data and applications.

HPE P41523-001 Solid State Drive Overview

Product Details

• Brand: HPE
• Part Number: P41523-001
• Alternative Part Number: P40498-B21
• Spare Part Number: P41523-001

General Specifications

Drive Characteristics

• Type: Hot-Swap Solid State Drive
• Capacity: 960 GB
• Form Factor: 2.5-inch SFF
• Interface: SATA 6Gbps
• NAND Flash Memory: Triple-Level Cell (TLC)
• Plug Type: Hot Pluggable
• Carrier Type: Basic Carrier (BC)
• Workload Type: Read Intensive
• Included With: HPE Basic Carrier (BC)
• Firmware: Digitally Signed Firmware (DS)
• Platform Support: HPE ProLiant Rack
• Height: 7.00 mm

Performance Metrics

Write Endurance and Speed

• 30-Day Writes (TB): 1400
• Endurance (DWPD): 0.80
• Drive Transfer Rate: 6 Gbps (external)
• Max Sequential Read Throughput: 515 MiB/s
• Max Sequential Write Throughput: 480 MiB/s

Latency and IOPS

• Random Read Average Latency (4KiB, Q1): 125 µs
• Random Write Average Latency (4KiB, Q1): 60 µs
• Random Read IOPS (4KiB, Q=16): 58,500
• Random Write IOPS (4KiB, Q=16): 29,000
• Max Random Read IOPS (4KiB): 58,500@Q32
• Max Random Write IOPS (4KiB): 29,000@Q4

Expansion & Connectivity

Interfaces and Bays

• Interfaces: 1 x SATA 6 Gb/s
• Compatible Bay: 2.5" SFF

Power Consumption

Power Usage Details

• Idle Time: 1.35 Watts
• Random Read: 3.02 Watts
• Random Write: 3.02 Watts
• Sequential Read: 3.05 Watts
• Sequential Write: 3.37 Watts
• Random Read/Write: 3.02 Watts
• Max Power Consumption: 3.37 Watts

Dimensions & Weight

Physical Measurements

• Height: 5.75 inches (14.61 cm)
• Width: 8.63 inches (21.92 cm)
• Depth: 9.00 inches (22.86 cm)
• Weight: 1.10 lbs (0.50 kg)

Compatibility

Supported Systems

This drive is designed to be compatible with a range of HPE ProLiant and SimpliVity models:

• HPE ProLiant DL Series (e.g., DL20 Gen10 Plus, DL360 Gen10 Plus)
• HPE ProLiant ML Series (e.g., ML30 Gen10 Plus)
• HPE SimpliVity 325 Gen10 Plus V2 Node

1. Ample Storage Space

With 960GB of storage capacity, users can store a vast amount of data, including documents, photos, videos, and software applications. This large storage space ensures that users will not run out of storage quickly and can keep all their important files in one place.

2. Enhanced Performance

A higher capacity SSD allows for better performance due to improved read and write speeds. With 960GB of storage, the HPE P41523-001 Solid State Drive can handle more data simultaneously, resulting in faster access times and reduced latency. This is especially beneficial for users who work with large files or run resource-intensive applications.

3. Future-Proofing

As technology continues to advance at a rapid pace, file sizes are also increasing. Having a 960GB capacity ensures that users will have enough space to accommodate larger files and applications in the future. This future-proofing aspect makes the HPE P41523-001 Solid State Drive a smart investment for individuals and businesses alike.

The Importance of a 960GB Capacity

The importance of a 960GB capacity cannot be overstated, especially in today's data-driven world. Whether you are a professional photographer, video editor, or simply a casual user who wants to store your files securely, having a high-capacity SSD like the HPE P41523-001 is crucial.

1. Professional Use

For professionals who rely on their storage devices to handle large files, such as photographers and videographers, a 960GB capacity is essential. High-resolution photos and 4K videos can quickly consume storage space, and having ample capacity ensures that professionals can store and access their work without any limitations.

2. Gaming Enthusiasts

Gaming enthusiasts also benefit greatly from a 960GB capacity SSD. Modern games often require large amounts of storage space, and having a high-capacity drive allows gamers to install multiple games simultaneously without worrying about running out of space. Additionally, faster read and write speeds provided by the HPE P41523-001 enhance the gaming experience by reducing loading times.

3. Business Applications

In the business world, data storage needs are constantly increasing. With the rise of cloud computing and big data analytics, companies require reliable and high-capacity storage solutions to store and process vast amounts of data. The 960GB capacity of the HPE P41523-001 Solid State Drive ensures that businesses can handle their data-intensive applications efficiently.

Interface - SATA 6Gbps

The Benefits of SATA 6Gbps Interface

The HPE P41523-001 Solid State Drive features a SATA 6Gbps interface, which offers several advantages over its predecessors. This high-speed interface enhances the overall performance and reliability of the drive, making it an ideal choice for users who require fast and efficient data transfer.

1. Increased Data Transfer Speeds

The SATA 6Gbps interface provides significantly faster data transfer speeds compared to its predecessors, such as SATA 3Gbps. This improved speed allows users to transfer large files, such as videos or software applications, in a fraction of the time it would take with a slower interface. Faster data transfer speeds also contribute to reduced system boot times and improved overall system responsiveness.

2. Seamless Compatibility

SATA 6Gbps is a widely adopted interface standard, making the HPE P41523-001 SSD compatible with a wide range of devices and systems. Whether you are upgrading an existing computer or building a new one, the SATA 6Gbps interface ensures seamless compatibility with most modern motherboards and storage controllers.

3. Backward Compatibility

Despite being a faster interface, SATA 6Gbps maintains backward compatibility with previous SATA versions, including SATA 3Gbps and SATA 1.5Gbps. This means that the HPE P41523-001 Solid State Drive can be used in systems that only support older SATA interfaces without any issues. Users can easily upgrade their storage without worrying about compatibility constraints.

The Importance of SATA 6Gbps Interface

The importance of the SATA 6Gbps interface lies in its ability to provide users with faster data transfer speeds and seamless compatibility with various systems.

1. Multimedia Professionals

For multimedia professionals who work with large files, such as video editors or graphic designers, the SATA 6Gbps interface is crucial. Its fast data transfer speeds ensure efficient file handling and editing, enabling professionals to complete their tasks more quickly and effectively.

2. Gamers

Gamers also benefit greatly from the SATA 6Gbps interface. With modern games becoming increasingly complex and requiring larger file sizes, faster data transfer speeds are essential. The SATA 6Gbps interface allows gamers to install and load games quickly, reducing waiting times and enhancing the gaming experience.

3. System Builders

For system builders and enthusiasts, the SATA 6Gbps interface is a preferred choice when selecting storage devices. Its widespread compatibility ensures that the HPE P41523-001 SSD can be easily integrated into various system configurations, providing reliable and high-performance storage solutions.

Intended Use - Read Intensive

The Benefits of Reading Intensive Usage

The HPE P41523-001 Solid State Drive is specifically designed for read-intensive workloads, offering several benefits that cater to the needs of users who require fast and reliable read operations.

1. Enhanced Read Performance

Read-intensive SSDs are optimized to deliver superior read performance compared to other types of drives. The HPE P41523-001 SSD excels in handling read operations, making it ideal for tasks that involve accessing large amounts of data quickly. This enhanced read performance translates into faster boot times, shorter application load times, and improved overall system responsiveness.

2. Extended Lifespan

Read-intensive SSDs are designed to withstand heavy read workloads over extended periods. They are built with advanced NAND flash memory that can handle high read volumes without compromising the drive's lifespan. The HPE P41523-001 Solid State Drive ensures longevity, making it a reliable storage solution for users who frequently access their stored data.

3. Cost-Effective Solution

Read-intensive SSDs are generally more cost-effective compared to write-intensive or mixed-use SSDs. They are specifically tailored for workloads that involve a higher ratio of read operations to write operations. For users who prioritize read performance and do not require extensive write capabilities, the HPE P41523-001 SSD offers a cost-effective solution without compromising on speed and reliability.

The Importance of Reading Intensive Usage

Read-intensive SSDs serve a vital role in meeting the demands of users who rely heavily on read operations, offering benefits that cater specifically to their needs.

1. Content Creators

Content creators, such as photographers and videographers, often require fast access to their media files for editing and post-production. The read-intensive nature of the HPE P41523-001 SSD ensures that content creators can efficiently retrieve their files, making the editing process smoother and more efficient.

2. Database Servers

Database servers handle large volumes of read requests from various applications and users. Utilizing a read-intensive SSD like the HPE P41523-001 ensures that database servers can retrieve data quickly, resulting in improved response times and enhanced overall performance.

3. Virtualized Environments

In virtualized environments, where multiple virtual machines rely on shared storage resources, read-intensive SSDs are essential for maintaining optimal performance. By prioritizing read operations, the HPE P41523-001 SSD ensures that virtual machines can access data swiftly, minimizing latency and maximizing efficiency.
