HPE Proliant DL360 Gen10 P56957-B21 Xeon 3.2GHz Server Silver 4215r

Processor

The HPE Proliant DL360 Server is equipped with an Intel Xeon 8-core Silver 4215r processor, delivering exceptional performance for demanding workloads. With a base clock speed of 2.5GHz and a maximum turbo frequency of 3.2GHz, this processor offers fast and efficient processing power.

General Overview of P56957-B21

The HPE DL360 Gen10 4210R server is a high-performance, 1U rack-mountable server designed for scalability and reliability. It is equipped with a variety of features to support demanding workloads.

Manufacturer Details

• Brand: Hewlett Packard Enterprise
• Part Number: P56957-B21

Form Factor and Scalability

• Server Scalability: 2-way
• Form Factor: Rack-mountable, 1U
• Hot-swap Bays: 8
• Model Name: DL360 Gen10 4210R 1P 32G NC 8SFF BC Server (Pre-configured)

Processor & Chipset

• Processor: Intel Xeon Silver 4215R
• Base Clock Speed: 3.2 GHz
• Max Turbo Frequency: 4 GHz
• Cores: 8-core
• Installed CPUs: 1
• Max CPUs Supported: 2
• CPU Socket Type: FCLGA3647
• Chipset: Intel C621
• Features: Hyper-Threading Technology, Intel Turbo Boost Technology 2

Cache Memory

• Installed L3 Cache Size: 11 MB
• Cache Per Processor: 11 MB

Memory Specifications

• Installed Memory: 32 GB
• Maximum Memory: 1.5 TB
• Memory Technology: DDR4 SDRAM with Advanced ECC
• Effective Memory Speed: 2400 MHz
• Rated Memory Speed: 2933 MHz

Memory Configuration

• Memory Slots: 24 (total) / 23 (empty)
• Supported Memory Types: Load-reduced ECC, Registered ECC, Non-volatile ECC
• Memory Configuration Features: Registered, Online Spare Memory, Dual Rank
• Slots Available: Slots 13-24 are available with a two-processor configuration only

Storage & Storage Controller

• RAID Support: RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60
• Storage Controller: HPE Smart Array MR416i-a
• Controller Interface: SATA 6Gb/s, SAS 12Gb/s, PCIe 4.0 (NVMe)
• Channel Quantity: 16
• Buffer Size: 4 GB

Optical & Card Reader

• Optical Drive: No Optical Drive
• Card Reader: Supports MicroSD cards

Graphics & Network Communicatio

• Video Memory: 16 MB
• Video Interface: VGA

Network Interfaces

• Ethernet Ports: 2 x 10 Gigabit Ethernet
• Ethernet Controller: Broadcom BCM57416
• Remote Management Protocols: SNMP 3, IPMI 2.0, SMASH CLP
• Remote Management Controller: Integrated Lights-Out 5 (iLO 5)
• Compliance Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.1q, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1as, IEEE 802.3az

Expansion & Connectivity

• External Universal Media Bay: 1 (free)
• Hot-swap 2.5" SFF Bays: 8 (all free)
• PCIe Slots:
  • 1 x PCIe 3.0 x16 (three-quarter-length, full-height)
  • 1 x PCIe 3.0 x8 (low-profile)
  • 1 x FlexibleLOM (three-quarter-length, full-height, low-profile)
  • 1 x MicroSD Card (internal)
  • 1 x PCIe x16 (full-height)

Interfaces

• 1 x HPE iLO - Type A (front)
• 1 x HPE iLO - RJ-45 (rear)
• 5 x USB 3.0 (1 front, 2 rear, 2 internal)
• 1 x VGA (rear)
• 4 x Gigabit Ethernet - RJ-45 (rear)

Miscellaneous

• CPU Standard Heatsink
• 5 x Standard Fans
• SFF Easy Install Rails

Compliance Standards

• AES
• FIPS 140-2
• IPv6 Ready
• PCI DSS
• TLS v1.2
• ASHRAE Class A4
• ASHRAE Class A3
• WEEE 2002/95/EC
• ACPI 6.1

Power Specifications

• Type: Hot-plug Power Supply
• Redundancy: Optional
• Redundancy Scheme: 1+1 (with optional power supply)
• Installed Quantity: 1
• Max Supported Quantity: 2
• Nominal Voltage: AC 120/230 V (50/60 Hz)
• Power Provided: 800 Watts
• 80 Plus Certification: 80 Plus Platinum

Dimensions & Weight

• Width: 17.1 inches
• Depth: 27.8 inches
• Height: 1.7 inches
• Weight: 28.75 lbs

Enhanced Multitasking

The 8-core design of the Intel Xeon Silver 4215r processor allows for efficient multitasking capabilities. It enables users to run multiple applications simultaneously without experiencing any lag or performance issues. This is particularly beneficial for businesses that require their servers to handle heavy workloads and run multiple virtual machines.

Improved Efficiency

The Silver 4215r processor incorporates advanced technologies that optimize power consumption and enhance energy efficiency. This not only reduces operational costs but also contributes to a greener and more sustainable IT infrastructure.

Reliable Performance

Intel processors are known for their reliability and stability, and the Xeon Silver 4215r is no exception. It is designed to deliver consistent performance even under heavy loads, ensuring that critical tasks are completed without any disruptions.

Benefits of the Intel Xeon 8-core Silver 4215r Processor:

- Exceptional performance for demanding workloads
- Efficient multitasking capabilities
- Improved power consumption and energy efficiency
- Reliable and stable performance

CPU Speed

Lightning-Fast Processing

The HPE Proliant DL360 Server features a CPU speed of 3.2GHz, providing lightning-fast processing capabilities. This high clock speed allows for quick execution of tasks, resulting in reduced waiting times and improved overall system responsiveness.

Optimized Workflows

The 3.2GHz CPU speed enables businesses to optimize their workflows and improve productivity. Applications and processes that require fast processing, such as data analysis, virtualization, and database management, can benefit significantly from this increased speed.

Real-Time Responsiveness

In today's fast-paced business environment, real-time responsiveness is crucial. The high CPU speed ensures that users can interact with the server and its applications seamlessly. It reduces latency and enables quick response times, enhancing user experience and productivity.

Efficient Resource Utilization

With a higher CPU speed, tasks can be completed more quickly, allowing for efficient resource utilization. This means that workloads can be processed faster, freeing up server resources for other tasks or users. It maximizes the server's capabilities and ensures optimal performance.

Benefits of a 3.2GHz CPU Speed:

- Lightning-fast processing capabilities
- Optimization of workflows and improved productivity
- Real-time responsiveness for enhanced user experience
- Efficient resource utilization for optimal performance

Generation

Latest Technology

The HPE Proliant DL360 Server belongs to the Gen10 generation, which represents the latest advancements in server technology. Being part of the Gen10 family ensures that users benefit from the most up-to-date features and capabilities.

Enhanced Security

Gen10 servers incorporate advanced security features to protect critical data and applications. These servers have built-in security measures such as firmware protection, secure boot, and encryption capabilities. This ensures that sensitive information remains secure and protected from potential threats.

Improved Performance

Each generation of servers brings performance improvements, and Gen10 is no exception. It offers faster processing speeds, higher memory capacity, and improved storage capabilities. Upgrading to Gen10 allows businesses to leverage the latest technology advancements and benefit from enhanced performance.

Scalability and Future-Proofing

Gen10 servers are designed with scalability in mind. They offer expandable configurations, allowing businesses to easily scale their server infrastructure as their needs grow. Investing in Gen10 ensures future-proofing, as these servers can accommodate future upgrades and technological advancements.

Benefits of the Gen10 Generation:

- Access to the latest advancements in server technology
- Enhanced security features for data protection
- Improved performance with faster processing speeds and higher memory capacity
- Scalability and future-proofing for business growth
