HPE Proliant DL360 Gen10 Server P19178-B21 Xeon Gold 5222 32GB RAM

Processor

The HPE Proliant DL360 Server Gen10 Server is equipped with a powerful 1X Xeon Gold 5222/3.8GHz Quad-Core processor. This feature sets the server apart from others in its class and provides numerous benefits and advantages to users.

Product Overview

General Information

• Manufacturer: Hewlett Packard Enterprise
• Part Number: P19178-B21
• Product Name: HPE Proliant DL360 Gen10 Rack-Mountable

Processor and Chipset

• Processor Type: Intel Xeon Gold 5222, 3.8GHz
• Max Turbo Speed: 3.9GHz
• Core Count: Quad-Core
• Installed Quantity: 1
• Max Supported Quantity: 2
• CPU Socket: FCLGA3647
• Chipset: Intel C621
• CPU Upgradability: Yes

Cache Memory

• Cache Type: L3 Cache
• Cache Size per Processor: 16.5MB

RAM Specifications

• Installed RAM: 32GB
• Max RAM Supported: 768GB
• RAM Technology: DDR4 SDRAM
• Form Factor: DIMM 288-pin
• Slots Available: 12 total, 11 empty
• RAM Features: Registered, HPE SmartMemory
• RAM Configuration: 1 x 32GB
• Supported RAM Types: PC4-20800 (Registered, Load-Reduced, Non-Volatile)

Storage and Controllers

• Hard Drive: None included
• Storage Controller Type: RAID
• Controller Interface: SATA 6Gb/s, SAS 12Gb/s
• Controller Name: HPE Smart Array P408i-a
• Channels: 8
• RAID Levels Supported: 0, 1, 5, 6, 10, 50, 60, 1 ADM, 10 ADM
• Buffer Size: 2GB

Card Reader

• Type: Card Reader
• Supported Flash Memory Cards: microSD

Graphics and Video

• Video Memory: 16MB
• Video Interfaces: VGA

Networking

• Ethernet Ports: 2 x 10/25 Gigabit Ethernet SFP28
• Ethernet Controller: HPE 640FLR
• Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet, 25 Gigabit Ethernet
• Remote Management Protocols: SNMP 3, IPMI 2.0, SMASH CLP
• Remote Management Controller: Integrated Lights-Out 5 (iLO 5)
• Features: Wake On LAN (WOL), PXE Support

Expansion and Connectivity

• Bays:
  • 1 x External Universal Media Bay (free)
  • 8 x Hot-Swap 2.5" SFF (free)
• Slots:
  • 1 x PCIe 3.0 x16 (Three-Quarter-Length, Full-Height, free)
  • 1 x PCIe 3.0 x8 (Low-Profile, free)
  • 1 x FlexibleLOM (Three-Quarter-Length, Full-Height, Low-Profile, free)
  • 1 x microSD Card (Internal, free)
  • 1 x PCIe x16 (Full-Height, free)
• Interfaces and Ports:
  • 1 x HPE iLO - Type A (Front)
  • 1 x HPE iLO - RJ-45 (Rear)
  • 5 x USB 3.0 (1 Front, 2 Rear, 2 Internal)
  • 1 x VGA (Rear)
  • 2 x LAN (10/25 Gigabit Ethernet) (SFP28)

Compliance and Standards

• AES
• FIPS 140-2
• IPv6 Ready
• PCI DSS
• TLS v1.2
• ASHRAE Class A4
• ASHRAE Class A3
• WEEE 2002/95/EC
• ACPI 6.1

Power Specifications

• Type: Hot-Plug / Redundant Power Supply
• Power Redundancy: Optional (1+1 with Optional Power Supply)
• Installed Quantity: 1
• Max Supported Quantity: 2
• Nominal Voltage: AC 120/230V (50/60 Hz)
• Power Provided: 800 Watts
• 80 Plus Certification: 80 Plus Platinum

Dimensions and Weight

• Width: 17.1 inches
• Depth: 27.8 inches
• Height: 1.7 inches
• Weight: 28.75 lbs

Enhanced Performance

With its 3.8GHz clock speed, the Xeon Gold 5222 processor delivers outstanding performance for demanding applications and workloads. The quad-core design ensures efficient multi-threaded processing, allowing the server to handle multiple tasks simultaneously without any slowdowns or bottlenecks.

Improved Efficiency

The Xeon Gold 5222 processor is built on Intel's advanced architecture, incorporating features such as Turbo Boost Technology and Hyper-Threading. These technologies optimize the server's performance by dynamically adjusting the clock speed and allocating resources efficiently. As a result, users can experience improved productivity and reduced wait times when running resource-intensive applications.

Seamless Virtualization

Virtualization has become a critical aspect of modern IT infrastructure, enabling businesses to maximize their hardware resources and streamline operations. The Xeon Gold 5222 processor excels in virtualized environments, thanks to its robust architecture and advanced virtualization technologies. Users can create and manage multiple virtual machines effortlessly, ensuring efficient resource utilization and minimizing downtime.

Future-Proofing

Investing in a server with a high-performance processor like the Xeon Gold 5222 ensures future-proofing for your IT infrastructure. As technology advances and new software applications emerge, having a powerful processor becomes increasingly important. The quad-core design and impressive clock speed of the Xeon Gold 5222 ensure that your server will remain capable of handling upcoming workloads efficiently.

Overall, the Xeon Gold 5222/3.8GHz Quad-Core processor of the HPE Proliant DL360 Server Gen10 Server delivers exceptional performance, improved efficiency, seamless virtualization, and future-proofing capabilities. Whether you run resource-intensive applications, require efficient multi-threaded processing, or need a server that can handle virtualization effortlessly, this processor is an ideal choice.

Memory

The HPE Proliant DL360 Server Gen10 Server is equipped with a generous 32GB DDR4 SDRAM memory module. This feature plays a crucial role in the server's overall performance and provides several benefits and advantages to users.

Enhanced Multitasking

With 32GB of DDR4 SDRAM, the server has ample memory capacity to handle multiple tasks simultaneously. This is particularly beneficial for businesses that rely on their servers for running numerous applications and services concurrently. The high memory capacity ensures smooth multitasking and prevents performance degradation when operating in demanding environments.

Improved System Responsiveness

Memory plays a vital role in determining the system's overall responsiveness and speed. With 32GB of DDR4 SDRAM, the HPE Proliant DL360 Server Gen10 Server can store and retrieve data quickly, resulting in faster response times for applications and services. Users will experience reduced lag and improved efficiency when accessing files, databases, or running complex computations.

Scalability and Future Growth

One of the key advantages of the HPE Proliant DL360 Server Gen10 Server's 32GB DDR4 SDRAM is its scalability. As your business grows and demands increase, the server can easily accommodate additional memory modules to meet your evolving needs. This ensures that your IT infrastructure remains adaptable and ready to handle future growth without requiring a complete hardware overhaul.

Reliability and Data Integrity

Memory plays a crucial role in maintaining data integrity and preventing errors or data loss. The HPE Proliant DL360 Server Gen10 Server's 32GB DDR4 SDRAM offers robust error detection and correction capabilities, ensuring data integrity throughout the server's operation. This feature is particularly important for businesses that handle critical data and cannot afford any loss or corruption.

In conclusion, the 32GB DDR4 SDRAM memory module of the HPE Proliant DL360 Server Gen10 Server provides enhanced multitasking capabilities, improved system responsiveness, scalability for future growth, and ensures reliability and data integrity. Whether you need to run multiple applications simultaneously, require a responsive system, plan for future expansion, or prioritize data integrity, this memory feature delivers exceptional performance and value.
