HPE Proliant DL360 Xeon 8 Core 3.2GHz DDR4 Server P40638-B21

Processor

The HPE Proliant DL360 Server is equipped with a powerful Xeon 8 Core 3.2GHz processor, providing exceptional performance and reliability for users. This feature is a key component of the server, offering numerous benefits that make it an ideal choice for businesses of all sizes.

General Specifications of Server Xeon

Discover the Hewlett Packard Enterprise Proliant DL360 Gen10, a highly scalable and reliable rack-mountable server designed for superior performance.

Product Details

• Manufacturer: Hewlett Packard Enterprise
• Part Number: P40638-B21
• Server Scalability: 2-way
• Height (Rack Units): 1U
• Product Name: Proliant DL360 Gen10 - Rack Mountable Server (Networking Choice Model)

Processor & Chipset

• Processor: 2nd Gen Intel Xeon Silver 4215R, 3.2 GHz
• Max Turbo Speed: 4 GHz
• Core Count: 8-core
• Processor Quantity: 1 (Max: 2)
• CPU Socket: FCLGA3647 Socket
• Chipset: Intel C621

Processor Features

• Hyper-Threading Technology
• Intel Turbo Boost Technology 2

Cache Memory

• Installed Cache Size: 11 MB L3 Cache
• Cache Per Processor: 11 MB

RAM Specifications

• Installed Size: 32 GB (Max: 1.5 TB)
• Memory Type: DDR4 SDRAM - Advanced ECC
• Effective Memory Speed: 2400 MHz
• Rated Memory Speed: 2933 MHz
• Form Factor: DIMM 288-pin
• Total Slots: 24 (23 available)
• Configuration Features: 1 x 32 GB

Supported Memory Configurations

• 1.5 TB Registered ECC
• 3 TB Load-Reduced ECC

Storage Options

• Type: No HDD Included

Storage Controllers

• Controller: HPE Smart Array P408i-a
• Type: 1 x RAID
• Interface Type: SATA 6Gb/s / SAS 12Gb/s
• Channel Quantity: 8
• RAID Levels: 0, 1, 5, 6, 10, 50, 60, 1 ADM, 10 ADM
• Buffer Size: 2 GB

Optical Storage

• Type: No Optical Drive

Graphics & Display

• Video Memory: 16 MB
• Video Interfaces: VGA

Network & Communication

• Ethernet Ports: 2 x 10 Gigabit Ethernet
• Ethernet Controller: Broadcom BCM57416
• Data Link Protocol: 10 Gigabit Ethernet
• Remote Management Controller: Integrated Lights-Out 5

Expansion & Connectivity

• Total Bays (Free): 8 (Hot-swap 2.5 SFF)

Expansion Slots

• PCIe 3.0 x16: 1 (Free - Three-quarter-length, Full-height)
• PCIe 3.0 x8: 1 (Free - Low-profile)
• FlexibleLOM: 1 (Free)
• MicroSD Card (Internal): 1 (Free)

Interfaces & Ports

• USB 3.0 Ports: 5 (1 Front, 2 Rear, 2 Internal)
• VGA Port: 1
• HPE iLO Port: 1 (RJ-45)
• LAN Ports: 4 (Gigabit Ethernet)

Miscellaneous

• Included Accessories: HPE High-Performance Heatsink, 5 Standard Fans, SFF Easy Install Rails
• Compliant Standards: AES, Triple DES, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, Redfish API, UEFI

Power Description

• Power Supply Type: Hot-plug
• Power Redundancy: Optional
• Power Redundancy Scheme: 1+1 (with Optional Power Supply)
• Installed Quantity: 1
• Max Supported Quantity: 2
• Voltage Required: AC 120/230 V (50/60 Hz)
• Power Provided: 800 Watts
• 80 Plus Certification: 80 Plus Platinum

Operating System / Software

• Operating System Provided: None

Environmental Standards

• Energy Star Certified: Yes
• Energy Star Version: 3.0

Environmental Parameters

• Minimum Operating Temperature: 50 °F
• Maximum Operating Temperature: 95 °F
• Operating Humidity Range: 8 - 90% (non-condensing)

Dimensions & Weight

• Width: 17.1 inches
• Depth: 27.8 inches
• Height: 1.7 inches
• Weight: 28.75 lbs

Enhanced Processing Power

With its Xeon 8 Core 3.2GHz processor, the HPE Proliant DL360 Server delivers outstanding processing power. The eight cores ensure efficient multitasking and smooth handling of complex tasks. Whether you are running resource-intensive applications or handling large datasets, this processor can handle the workload with ease. It enables faster data processing, allowing you to accomplish more in less time.

Improved Performance

The Xeon 8 Core 3.2GHz processor offers improved performance compared to previous generations. Its higher clock speed ensures faster execution of instructions, resulting in quicker response times and reduced latency. This enhanced performance translates into a more streamlined workflow and increased productivity for your organization.

Reliability and Stability

Reliability is crucial when it comes to server systems, as any downtime can lead to significant financial losses and negative impact on business operations. The HPE Proliant DL360 Server's Xeon 8 Core 3.2GHz processor is designed for maximum reliability and stability. It undergoes stringent testing to ensure its durability and ability to handle heavy workloads without compromising performance.

Scalability

The Xeon 8 Core 3.2GHz processor supports scalability, allowing you to expand your server capabilities as your business grows. With its powerful processing capabilities, it can accommodate additional users, applications, and data without sacrificing performance. This scalability ensures that your server can adapt to the changing needs of your organization, saving you the hassle and cost of upgrading to a new server in the future.

Energy Efficiency

In today's environmentally conscious world, energy efficiency is a key consideration for businesses. The Xeon 8 Core 3.2GHz processor is designed to optimize power consumption, reducing your server's carbon footprint and operating costs. It utilizes advanced power management technologies to dynamically adjust power usage based on workload demands, ensuring efficient performance without unnecessary energy consumption.

Virtualization Capabilities

The Xeon 8 Core 3.2GHz processor is also well-suited for virtualization. Virtualization allows you to consolidate multiple servers into a single physical machine, reducing hardware costs and simplifying management. With the powerful processing capabilities of this processor, you can run multiple virtual machines simultaneously without compromising performance. This enables efficient resource allocation, improved server utilization, and greater flexibility in deploying and managing your IT infrastructure.

Memory

The HPE Proliant DL360 Server features DDR4 memory, offering exceptional speed, reliability, and capacity. The memory plays a crucial role in the overall performance of the server, and DDR4 brings significant advantages over its predecessors.

Enhanced Speed

DDR4 memory provides higher data transfer rates compared to previous generations. This increased speed allows for faster access to data, resulting in improved application performance and reduced latency. Whether you are running memory-intensive applications or handling large datasets, DDR4 memory ensures that your server can keep up with the demands of your workload.

Improved Efficiency

DDR4 memory is designed to be more efficient than its predecessors. It operates at lower voltage levels, reducing power consumption and heat generation. This not only saves energy but also contributes to a cooler and more reliable server environment. By utilizing DDR4 memory, you can maximize the efficiency of your server and minimize operational costs.

Greater Capacity

The HPE Proliant DL360 Server supports a substantial amount of DDR4 memory, allowing for greater capacity compared to older generations. This increased capacity enables you to store and process larger datasets, run more virtual machines, and handle more concurrent users. Whether you are running complex databases or virtualization workloads, the ample DDR4 memory ensures that your server can meet the demands of your business.

Reliability and Error Correction

DDR4 memory incorporates advanced error correction capabilities, ensuring data integrity and system stability. It detects and corrects errors in real-time, minimizing the risk of data corruption or system crashes. With this level of reliability, you can trust that your critical data and applications are protected, providing peace of mind for your business operations.

Part Number

The HPE Proliant DL360 Server is identified by its unique part number, P40638-B21. This part number serves as a key identifier for the server model and contains valuable information for users and IT professionals.

Model Identification

The part number P40638-B21 allows for quick and accurate identification of the HPE Proliant DL360 Server model. When contacting technical support or purchasing additional components, providing the part number ensures that you receive the correct assistance or product. It eliminates confusion that may arise from similar server models or variations.

Compatibility Assurance

By referring to the part number P40638-B21, users can ensure compatibility when adding or replacing components within the server. The part number serves as a reference point for verifying whether a specific component or accessory is compatible with their server model. This compatibility assurance reduces the risk of purchasing incompatible parts and simplifies the upgrading or customization process.

Documentation and Support

The part number P40638-B21 is often referenced in documentation and support materials provided by HPE. This makes it easier for users to find relevant information, such as user manuals, technical specifications, firmware updates, and driver downloads. By using the part number as a search term, users can quickly access the resources they need to maximize the functionality and performance of their HPE Proliant DL360 Server.

Inventory Management

For organizations managing multiple servers, the part number P40638-B21 plays a crucial role in inventory management. It allows IT professionals to track and categorize servers accurately, ensuring efficient asset management and easy identification of specific server models. This streamlined inventory management process saves time and simplifies tasks such as maintenance, upgrades, and replacement planning.

Future Proofing

The part number P40638-B21 also serves as a reference for future-proofing your server infrastructure. As new models and versions are released, having the part number allows you to compare specifications, features, and compatibility with your existing server. It helps you make informed decisions when it's time to upgrade or expand your server infrastructure, ensuring seamless integration with your current systems.

In conclusion, the HPE Proliant DL360 Server's Xeon 8 Core 3.2GHz processor, DDR4 memory, and unique part number P40638-B21 are all vital features that contribute to its exceptional performance, reliability, and scalability. Whether you are running resource-intensive applications or managing virtualized environments, these features ensure that your server can handle the demands of your business efficiently. The Xeon processor offers enhanced processing power, improved performance, reliability, scalability, energy efficiency, and virtualization capabilities. DDR4 memory provides enhanced speed, efficiency, capacity, and reliability with error correction capabilities. The part number P40638-B21 allows for model identification, compatibility assurance, easy access to documentation and support, efficient inventory management, and future-proofing of your server infrastructure. With the HPE Proliant DL360 Server, you can rely on a high-performance and versatile solution that meets the needs of your organization.
