HPE Proliant DL380 G10 2U Rack Server P24847-B21 Intel Xeon Gold 6234 3.3GHz 32GB RAM

Processor

The HPE Proliant DL380 G10 2U Rack Server is equipped with the powerful Intel Xeon Gold 6234 3.3GHz processor, providing exceptional performance and efficiency for a wide range of applications. This processor is a crucial component of the server, offering numerous benefits and playing a vital role in the overall performance and capabilities of the system.

Server Overview

• Type: Rack-Mountable Server
• Form Factor: 2U
• Built-In Devices: LED Panel
• Scalability: 2-Way
• Hot-Swap Bays: 8
• Localization: Global

Processor and Chipset Specifications

CPU Details

• Model: Intel Xeon Gold 6234
• Base Frequency: 3.3 GHz
• Turbo Boost: Up to 4 GHz
• Cores: 8
• Quantity: 1 (Expandable to 2)
• Socket Type: FCLGA3647
• Chipset: Intel C621
• Features: Hyper-Threading, Intel Turbo Boost Technology 2

Cache Memory

• Installed Size: 24.75 MB L3 Cache
• Cache per Processor: 24.75 MB

Memory Configuration

Installed and Supported RAM

• Installed Size: 32 GB
• Maximum Capacity: 1.5 TB
• Technology: DDR4 SDRAM with Advanced ECC
• Effective Memory Speed: 2933 MHz
• Form Factor: DIMM 288-Pin
• Available Slots: 24 (23 Empty)
• Configuration: 1 x 32 GB
• Supported Types: Load-Reduced ECC (3 TB), Registered ECC (1.5 TB), Non-Volatile ECC (192 GB), HPE Persistent Memory - Optane DC (6 TB)

Storage and Expansion

Hard Drive and Controller

• Hard Drive: None
• Storage Controller: 1 x SATA - PCIe 3.0 x4
• Controller Interface: SATA 6 Gb/s
• Storage Controller Name: HPE Smart Array S100i SR Software
• Channel Quantity: 14

Optical and Card Reader

• Optical Drive: None
• Card Reader: Yes
• Supported Flash Memory: MicroSD

Networking and Remote Management

• Ethernet Ports: 4 x Gigabit Ethernet
• Controller: HPE 331i
• Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
• Remote Management Protocols: SNMP 3, IPMI 2.0, SMASH CLP
• Remote Management Controller: Integrated Lights-Out 5
• Features: Wake On LAN (WOL), ACPI Support, PXE Support

Expansion and Connectivity

Bays and Slots

• Hot-Swap Bays: 8 (Total and Free) x 2.5 SFF
• Slots:
  • 1 x MicroSD Card (Internal)
  • 1 x PCIe 3.0 x8 - Full-Length, Full-Height
  • 1 x PCIe 3.0 x16 - Full-Length, Full-Height
  • 1 x PCIe 3.0 x8 - Half-Length, Full-Height
  • 1 x FlexibleLOM (Occupied)

Interfaces

• HPE iLO: Type A (Front) x 1
• USB 3.0 Ports: 5 (1 Front, 2 Rear, 2 Internal)
• HPE iLO RJ-45: 1 (Rear)
• Gigabit Ethernet RJ-45 Ports: 4 (Rear)
• VGA: 1 (Rear)

Power Specifications

• Power Supply: Hot-Plug
• Redundancy: Optional
• Redundancy Scheme: 1+1 (With Optional Power Supply)
• Installed Quantity: 1
• Maximum Supported Quantity: 2
• Nominal Voltage: AC 120/230 V (50/60 Hz)
• Power Provided: 800 Watts

Physical Dimensions

• Width: 17.5 inches
• Depth: 26.7 inches
• Height: 3.4 inches
• Weight: 32.85 lbs

Compliance Standards

• AES
• TLS v1.2
• ASHRAE Class A4
• ASHRAE Class A3
• WEEE 2002/95/EC
• ACPI 6.1

Exceptional Processing Power

The Intel Xeon Gold 6234 processor is designed to deliver exceptional processing power, making it ideal for demanding workloads and resource-intensive tasks. With its 24 cores and 48 threads, it can handle multiple tasks simultaneously, ensuring smooth and efficient operation even under heavy workloads. This level of processing power is especially beneficial for businesses that require high-performance computing, such as data analysis, virtualization, and database management.

Improved Performance and Responsiveness

The 3.3GHz clock speed of the Intel Xeon Gold 6234 processor ensures fast and responsive performance. It allows for quick data processing, reducing latency and improving overall system responsiveness. This is particularly important for applications that require real-time data processing or fast response times, such as financial transactions or online gaming.

Enhanced Security Features

Security is a critical concern for any server environment. The Intel Xeon Gold 6234 processor incorporates advanced security features to protect against potential threats and ensure the integrity of your data. With features such as Intel Trusted Execution Technology (TXT) and Intel Secure Key, it helps safeguard sensitive information from unauthorized access and attacks.

Intel Trusted Execution Technology (TXT)

Intel Trusted Execution Technology (TXT) provides hardware-based security features that help protect your server from malicious software attacks. It establishes a secure execution environment where critical system resources are isolated from potential threats, ensuring the integrity of your server's operation.

Intel Secure Key

Intel Secure Key is a hardware-based random number generator that enhances the security of cryptographic operations. It generates truly random numbers, making it difficult for attackers to predict encryption keys or gain unauthorized access to sensitive data.

Energy Efficiency

Energy efficiency is a crucial consideration for modern server environments. The Intel Xeon Gold 6234 processor is designed with power-saving features that optimize energy consumption without sacrificing performance. This helps reduce operational costs and lowers the environmental impact of your server infrastructure.

Intel Speed Select Technology

Intel Speed Select Technology allows for dynamic power allocation, enabling the processor to optimize power usage based on workload demands. It ensures that the server operates at peak performance when needed while minimizing power consumption during periods of lower activity.

Advanced Vector Extensions (AVX-512)

The Intel Xeon Gold 6234 processor supports Advanced Vector Extensions (AVX-512), which enhances the performance of vectorized applications. AVX-512 enables higher parallelism and higher performance for compute-intensive tasks, while simultaneously reducing power consumption.

Improved Virtualization Performance

Virtualization has become a fundamental technology in modern server environments. The Intel Xeon Gold 6234 processor includes features specifically designed to enhance virtualization performance and efficiency.

Intel Virtualization Technology (VT-x)

Intel Virtualization Technology (VT-x) provides hardware-assisted virtualization capabilities, allowing for efficient and secure virtual machine operation. It enables better resource allocation, improved isolation, and enhanced performance for virtualized workloads.

Intel Virtualization Technology for Directed I/O (VT-d)

Intel Virtualization Technology for Directed I/O (VT-d) enhances the security and performance of virtualized I/O devices. It allows for direct assignment of I/O devices to virtual machines, reducing latency and improving overall system responsiveness.

Ram

The HPE Proliant DL380 G10 2U Rack Server is equipped with 32GB of RAM, providing ample memory capacity to handle various workloads efficiently. The RAM plays a crucial role in the server's performance, offering several benefits and ensuring smooth operation.

Improved System Responsiveness

With 32GB of RAM, the server can efficiently handle multiple applications and processes simultaneously. This increased memory capacity allows for faster data access and retrieval, resulting in improved system responsiveness. It ensures that the server can quickly respond to user requests and perform tasks without experiencing bottlenecks or slowdowns.

Enhanced Multi-Tasking Capability

The larger RAM capacity of 32GB enables the server to handle a greater number of concurrent tasks efficiently. It reduces the need for frequent data swapping between RAM and storage devices, minimizing latency and improving overall performance. This is particularly beneficial for businesses that rely on running multiple applications simultaneously or handling complex workloads.

Optimized Virtualization Performance

Virtualization has become a standard practice in modern server environments, allowing for efficient resource utilization and better workload management. The 32GB RAM capacity of the HPE Proliant DL380 G10 server is well-suited for virtualized environments. It provides sufficient memory to support multiple virtual machines, ensuring optimal performance and minimizing potential performance degradation due to memory constraints.

Increased Virtual Machine Density

With 32GB of RAM, the server can accommodate a higher number of virtual machines without compromising performance. This allows businesses to maximize their server resources and consolidate their infrastructure, resulting in cost savings and improved operational efficiency.

Better Application Isolation

Having ample RAM capacity enables better isolation of applications running on separate virtual machines. Each virtual machine can be allocated sufficient memory resources, preventing performance degradation caused by resource contention. It ensures that applications running on different virtual machines do not interfere with each other, resulting in a stable and reliable server environment.

Improved Reliability and Availability

The HPE Proliant DL380 G10 server with 32GB of RAM offers improved reliability and availability, ensuring uninterrupted operation and minimizing the risk of system failures.

Error Checking and Correction (ECC)

The server's RAM is equipped with Error Checking and Correction (ECC) technology, which detects and corrects memory errors in real-time. ECC helps prevent data corruption and system crashes, enhancing the overall reliability of the server. It is particularly crucial for mission-critical applications that require continuous uptime and data integrity.

Hot-Pluggable Memory

The HPE Proliant DL380 G10 server supports hot-pluggable memory modules, allowing for easy memory expansion or replacement without interrupting system operation. This feature ensures that businesses can scale their memory capacity as needed, accommodating future growth and adapting to changing workload requirements without downtime or disruptions.

Sku

The HPE Proliant DL380 G10 2U Rack Server SKU is P24847-B21. The SKU plays a significant role in identifying and differentiating the specific server model, making it an essential feature for users to consider.

Accurate Identification

The SKU provides a unique identification code for the HPE Proliant DL380 G10 server model. It ensures accurate identification of the specific product variant, allowing users to distinguish it from other server models within the HPE Proliant DL380 series or different rack servers offered by HPE. This is particularly important when ordering or searching for specific hardware components or software compatibility.

Simplified Inventory Management

The SKU simplifies inventory management for businesses and IT departments. With a unique SKU assigned to each server model, it becomes easier to track and manage stock levels, ensuring that the right server models are available when needed. It streamlines the procurement process, minimizes the risk of ordering incorrect server models, and enables efficient resource planning.

Compatibility Verification

The SKU can be used to verify compatibility with specific hardware or software components. Manufacturers often provide compatibility lists or databases that reference the SKU, ensuring that users can identify compatible components or software versions. This helps prevent compatibility issues and ensures a seamless integration of the HPE Proliant DL380 G10 server into existing infrastructure.

Easier Support and Maintenance

The SKU simplifies support and maintenance of the HPE Proliant DL380 G10 server. When contacting technical support or looking for documentation or firmware updates, providing the SKU allows for quick identification of the specific server model and ensures that users receive accurate and relevant assistance. It saves time and effort for both IT professionals and support personnel, leading to faster issue resolution and improved overall user experience.

Product Differentiation

With various server models available in the market, the SKU provides a clear differentiation between different variants within the HPE Proliant DL380 G10 series. It allows users to compare specifications, features, and pricing of different models easily. By understanding the distinctive features associated with each SKU, users can make informed decisions based on their specific requirements, ensuring they choose the most suitable server model for their needs.

Choice of Configurations

The SKU may represent different configurations within the HPE Proliant DL380 G10 series. For example, there may be variations in terms of storage capacity, network connectivity options, or RAID controller capabilities. By considering the SKU, users can identify which specific configuration best aligns with their intended use case, ensuring they get the desired functionality and performance from the server.

Scalability and Future Expansion

The SKU can indicate the scalability options or upgrade possibilities for the HPE Proliant DL380 G10 server. Some SKUs may offer additional expansion slots, support for higher RAM capacities, or compatibility with specific expansion modules. By understanding the SKU associated with the server, users can plan for future expansion or upgrades, ensuring their investment is future-proof and can adapt to changing business needs.
