HPE Proliant DL380 Gen10 32GB Server P40423-B21 XEON 6226R/2.9 GHz,DDR4

Processor

The HPE Proliant DL380 Gen10 Server is equipped with a powerful XEON 16Core 6226R processor running at 2.9 GHz. This processor is a standout feature of this server and plays a crucial role in delivering exceptional performance and efficiency to users.

General Specifications of P40423-B21

• Manufacturer: Hewlett Packard Enterprise
• Part Number: P40423-B21
• Server Scalability: 2-way
• Rack Height: 2U
• Product Name: Proliant DL380 Gen10 - Rack Mountable Server

Processor & Chipset

• Processor: 2nd Gen Intel Xeon Gold 6226R, 2.9 GHz
• Max Turbo Speed: 3.9 GHz
• Number of Cores: 16-core
• CPU Quantity: 1 (upgradable to 2)
• CPU Socket: FCLGA3647
• Chipset: Intel C621

Processor Features

• Hyper-threading Technology
• Intel Turbo Boost Technology 2

Cache Memory

• Installed Cache Size: 22 MB L3 Cache
• Cache per Processor: 22 MB

Memory

• Installed RAM Size: 32 GB
• Maximum Supported RAM: 1.5 TB

Memory Technology

• Type: DDR4 SDRAM - Advanced ECC
• Effective Memory Speed: 2933 MHz
• Form Factor: DIMM 288-pin

Configuration and Features

• Slots: 24 (total), 23 available
• Features: Registered, Dual Rank, HPE SmartMemory
• Configuration Example: 1 x 32 GB
• Supported RAM Types: Load-reduced ECC, Registered ECC, Non-volatile ECC, HPE Persistent Memory

Storage

• Type: No HDD

Storage Controllers

• Type: 1 x SATA - PCIe 3.0 x4
• Controller Interface: SATA 6 Gb/s
• Storage Controller Name: HPE Smart Array S100i SR Software RAID
• RAID Levels: 0, 1, 5, 10

Optical Storage and Card Reader

• Type: No Optical Drive

Card Reader

• Type: Card Reader
• Supported Flash Cards: MicroSD

Graphics & Networking

• Video Memory: 16 MB
• Video Interfaces: VGA

Networking

• Ethernet Ports: 2 x 10 Gigabit Ethernet
• Ethernet Controller: Broadcom BCM57414
• Data Link Protocol: 10 Gigabit Ethernet
• Remote Management: Integrated Lights-Out 5
• Features: Wake On LAN (WOL), PXE Support

Expansion & Connectivity

• Total: 8 (all free)
• Type: Hot-swap 2.5” SFF

Expansion Slots

• MicroSD Card Slot: 1 (internal)
• PCIe Slots:
  • 1 x PCIe 3.0 x8 - Full-length, Full-height
  • 1 x PCIe 3.0 x16 - Full-length, Full-height
  • 1 x PCIe 3.0 x8 - Half-length, Full-height
• FlexibleLOM: 1 (occupied)

Interfaces & Ports

• 3 x USB 3.0 (1 front, 2 rear)
• 1 x VGA
• 2 x LAN (10 Gigabit Ethernet)
• 1 x HPE iLO
• 1 x HPE iLO (Service Port)

Miscellaneous

• Cable Management Arm
• 4 Standard Fans
• SFF Easy Install Rails

Compliance Standards

• WEEE
• TLS V1.2
• ASHRAE Class A4
• ASHRAE Class A3
• WEEE 2002/95/EC
• ACPI 6.1

Power Specifications

• Power Supply: Hot-plug
• Redundancy: Optional (1+1 with optional power supply)
• Installed Quantity: 1
• Max Supported Quantity: 2
• Voltage Required: AC 120/230 V (50/60 Hz)
• Power Provided: 800 Watts
• 80 Plus Certification: 80 Plus Platinum

Operating System & Software

• No Operating System

Certified Operating Systems

• CentOS
• Microsoft Windows Server 2012 R2
• VMware vSphere 6.0 (ESXi)
• SUSE Linux Enterprise Server 11 SP4
• Microsoft Windows Server 2016
• Red Hat Enterprise Linux 7.3
• Red Hat Enterprise Linux 6.9
• VMware vSphere 6.5
• SUSE Linux Enterprise Server 12 SP2
• ClearOS

Environmental Standards

• Energy Star Certified: Yes
• Energy Star Version: 3.0

Environmental Parameters

• Min Operating Temperature: 50 °F
• Max Operating Temperature: 95 °F
• Humidity Range: 8 - 90% (non-condensing)

Dimensions & Weight

• Width: 17.5 in
• Depth: 26.7 in
• Height: 3.4 in
• Weight: 32.54 lbs

Enhanced Performance

The XEON 16Core 6226R processor is designed to deliver outstanding performance for demanding workloads and applications. With its high core count and clock speed, it can handle complex tasks and intensive workloads with ease. Whether you're running virtualization software, performing data analysis, or running resource-intensive applications, this processor ensures smooth and efficient operations.

Increased Productivity

With the XEON 16Core 6226R processor, users experience enhanced productivity. The high core count allows for concurrent execution of multiple threads, enabling efficient multitasking. This means you can run multiple applications simultaneously without any noticeable slowdowns or performance bottlenecks. It's a great advantage for businesses that rely on running multiple applications simultaneously, ensuring that productivity remains high.

Improved Responsiveness

The 2.9 GHz clock speed of the XEON 16Core 6226R processor ensures quick response times, allowing for rapid data processing and reduced latency. Whether you're accessing large databases or performing complex calculations, this processor ensures that your tasks are completed swiftly, keeping your workflow smooth and uninterrupted.

Optimized Virtualization

Virtualization has become a fundamental technology for modern businesses. The XEON 16Core 6226R processor provides excellent support for virtualized environments. Its high core count enables efficient virtual machine (VM) deployment, allowing you to run multiple VMs simultaneously without compromising performance. This makes it an ideal choice for organizations that heavily rely on virtualization, such as cloud service providers or data centers.

Power Efficiency

In addition to its exceptional performance, the XEON 16Core 6226R processor is designed to be power-efficient. It incorporates advanced power management features that dynamically adjust power consumption based on workload demands. This not only helps reduce electricity costs but also lowers the overall carbon footprint of your data center or infrastructure.

RAM

Another notable feature of the HPE Proliant DL380 Gen10 Server is its 32GB DDR4 RAM. The amount and type of RAM in a server play a crucial role in determining its performance and ability to handle demanding tasks efficiently.

Enhanced System Performance

The 32GB DDR4 RAM provides a significant boost to the overall system performance. With ample memory capacity, the server can store and access a large amount of data quickly, resulting in faster application response times and reduced data retrieval latency. This is particularly important for memory-intensive applications, such as databases or virtualization environments, where quick access to data is essential for optimal performance.

Improved Multitasking

With 32GB of RAM, the server can handle multiple applications and processes simultaneously without experiencing memory constraints. This enables efficient multitasking, allowing users to run resource-intensive applications concurrently without any noticeable performance degradation. Whether you're running multiple virtual machines or performing data-intensive tasks, the ample RAM ensures smooth and efficient operations.

Scalability and Future-Proofing

The 32GB DDR4 RAM provides a solid foundation for scalability and future-proofing your server infrastructure. As your business grows and demands increase, you can easily expand the server's memory capacity by adding more RAM modules. This flexibility ensures that your server can adapt to changing requirements without incurring significant additional costs.

Reliability and Error Correction

DDR4 RAM also offers enhanced reliability and error correction capabilities. It incorporates advanced error correction code (ECC) technology, which detects and corrects memory errors on the fly. This ensures data integrity and reduces the risk of system crashes or data corruption. With 32GB DDR4 ECC RAM, you can rely on the server to handle critical workloads without worrying about memory-related issues.

Storage

The HPE Proliant DL380 Gen10 Server features 8 SFF (Small Form Factor) drive bays, making storage management efficient and flexible. The storage capabilities of a server are crucial for businesses that deal with large amounts of data and require high-performance storage solutions.

Ample Storage Capacity

The 8 SFF drive bays allow you to install multiple hard drives or solid-state drives (SSDs) in the server, providing ample storage capacity. This is particularly beneficial for businesses dealing with large data sets or running applications that require significant storage space, such as media streaming or data analytics. With this storage capacity, you can store and access your data efficiently, ensuring smooth operations and quick data retrieval.

Flexible Configuration Options

The 8 SFF drive bays offer flexible configuration options to optimize storage performance according to your specific needs. You can choose to configure the drives in various RAID (Redundant Array of Independent Disks) configurations, such as RAID 0, RAID 1, RAID 5, or RAID 10, depending on your performance and redundancy requirements. This flexibility allows you to tailor the storage configuration to meet your specific workload demands.

High-Speed Data Transfer

The 8 SFF drive bays support high-speed data transfer rates, enabling faster read and write operations. This is crucial for applications that require quick access to data or perform frequent data transfers, such as database servers or file servers. With the high-speed data transfer capabilities, you can ensure optimal performance and reduce data access latency, resulting in improved overall system responsiveness.

Hot-Swap Capability

The 8 SFF drive bays feature hot-swap capability, allowing you to replace or add drives without powering down the server. This eliminates the need for downtime during maintenance or drive replacement, ensuring uninterrupted operations and minimizing the impact on productivity. The hot-swap capability also simplifies storage management, as you can easily expand or upgrade your storage infrastructure as needed.

Data Redundancy and Protection

The RAID configurations supported by the 8 SFF drive bays provide data redundancy and protection against drive failures. Depending on the RAID configuration chosen, data can be mirrored across multiple drives or distributed with parity information to ensure that data remains accessible even if a drive fails. This helps safeguard critical data and prevents loss in case of hardware failures, providing peace of mind for businesses that rely on continuous data availability.

In summary, the HPE Proliant DL380 Gen10 Server's XEON 16Core 6226R processor, 32GB DDR4 RAM, and 8 SFF storage bays are key features that contribute to its exceptional performance, scalability, and reliability. Whether you're running resource-intensive applications, virtualization environments, or dealing with large amounts of data, this server is designed to meet your demanding needs while ensuring efficient operations and optimal productivity.
