HPE Proliant DL380 Server Xeon 2.8GHz 8-Core Silver DDR4 SDRAM Smart Array 10GB P55245-B21

Processor

The HPE Proliant DL380 Server Xeon is equipped with a powerful 2.8GHz 8-Core processor, making it an exceptional choice for businesses and organizations that demand high performance and reliability. This feature sets the DL380 Server apart from its competitors and provides users with a multitude of benefits.

Product Overview of P55245-B21

• Manufacturer: Hewlett Packard Enterprise
• Part Number: P55245-B21
• Server Scalability: 2-way
• Rack Height: 2U
• Product Name: HPE ProLiant DL380 Gen10 Plus 4309Y 2.8GHz 8-Core 1P 32GB-R MR416i-P NC 8SFF 800W PS Server

Processor & Chipset

• CPU: 3rd Gen Intel Xeon Silver 4309Y
• Base Clock Speed: 2.8 GHz
• Max Turbo Speed: 3.6 GHz
• Cores: 8
• Installed CPUs: 1
• Max CPUs: 2
• CPU Upgradeability: Yes
• Chipset: Intel C621A

Cache Memory

• Installed L3 Cache Size: 12 MB
• Cache Per Processor: 12 MB

Memory Specifications

• Current Size: 32 GB
• Max Capacity: 2 TB
• Memory Technology: DDR4 SDRAM
• Effective Memory Speed: 2933 MHz
• Rated Memory Speed: 3200 MHz
• Form Factor: DIMM 288-pin
• Total Slots: 32
• Empty Slots: 31
• Configuration Features: 1 x 32 GB

Supported Memory Types

• Load-Reduced: Up to 8 TB
• Registered: Up to 2 TB
• Persistent Memory: Up to 8 TB (HPE Optane DC Persistent)

Storage Information

• Type: No HDD

Storage Controllers

• Controller Type: 1 x RAID
• Interface: SATA 6 Gb/s / SAS 12 Gb/s / PCIe 4.0 (NVMe)
• Controller Name: Broadcom MegaRAID MR416i-P
• Host Bus: PCIe 4.0 x8
• Buffer Size: 4 GB
• Supported Devices: Disk Array (RAID)
• Channel Quantity: 16
• Max Storage Devices: 240
• RAID Levels: 0, 1, 5, 6, 10, 50, 60
• Connections: 1 x PCIe 4.0 x8

Graphics & Network

• Video Memory: 16 MB
• Video Interfaces: VGA

Network & Communication

• Interface Type: Open Compute Project Mezzanine (OCP) 3.0
• Ethernet Ports: 2 x 10 Gigabit Ethernet
• Ethernet Controller: Broadcom BCM57412
• Data Link Protocol: 10 Gigabit Ethernet
• Remote Management Controller: Integrated Lights-Out 5

Expansion & Connectivity

• Hot-Swap Bays: 8 x 2.5 SFF

Slots

• PCIe Slots:
  • 1 x PCIe 4.0 x16 - Full-length, Full-height
  • 1 x PCIe 4.0 x16 - Half-length, Full-height (x8 Mode)
  • 1 x PCIe 4.0 x16 - Full-length, Full-height (x8 Mode)

Interfaces

• 1 x HPE iLO - RJ-45
• 3 x USB 3.0 (1 Front, 2 Rear)
• 1 x HPE iLO (Service Port)
• 2 x LAN (10 Gigabit Ethernet) - SFP+
• 1 x VGA

Miscellaneous

• CPU Standard Heatsink
• HPE Easy Install Rails with CMA
• 6 Maximum Performance Fans

Compliant Standards

• AES
• FIPS 140-2
• WEEE
• Triple DES
• TLS v1.2
• ASHRAE Class A4
• ASHRAE Class A3
• Redfish API
• UEFI
• ACPI 6.3
• SMBIOS 3.2

Power Specifications

• Type: Hot-plug
• Redundancy: Optional
• Redundancy Scheme: 1+1 (with optional power supply)
• Installed Quantity: 1
• Max Supported Quantity: 2
• Nominal Voltage: AC 120/230 V (50/60 Hz)
• Power Provided: 800 Watt
• 80 Plus Certification: 80 Plus Platinum

Dimensions & Weight

• Width: 17.54 in
• Depth: 28 in
• Height: 3.44 in
• Weight: 35.54 lbs

Enhanced Performance

With its 2.8GHz clock speed and 8 cores, the processor offers exceptional processing power. It can handle complex tasks, such as running multiple virtual machines simultaneously or handling resource-intensive applications, with ease. This leads to enhanced productivity and faster response times, ensuring that your business operations run smoothly.

Increased Efficiency

The 8-core design of the processor allows for efficient multitasking and improved workload distribution. Each core can independently execute tasks, enabling multiple processes to be executed simultaneously. This results in faster processing of requests and reduced waiting times for users, increasing overall system efficiency.

Optimized Resource Allocation

The 2.8GHz clock speed ensures that each core operates at high speeds, reducing the time taken to complete individual tasks. This allows for quicker data processing and reduces latency, ensuring that users can access data and applications swiftly. The improved resource allocation also enables better utilization of system resources, maximizing performance and minimizing bottlenecks.

Seamless Scalability

The DL380 Server's processor is designed to support future growth and expansion. With its 8-core capability, it can handle increased workloads as your business grows without compromising performance. This scalability ensures that your investment in the DL380 Server is future-proofed and can adapt to changing business needs.

Reliability and Stability

The 2.8GHz 8-Core processor is built to deliver exceptional reliability and stability. It undergoes rigorous testing and quality control processes to ensure that it can operate flawlessly under demanding conditions. This reliability is essential for businesses that rely on their servers for critical operations, minimizing the risk of system failures and downtime.

Memory

The HPE Proliant DL380 Server Xeon boasts Silver DDR4 SDRAM memory, offering significant benefits and importance for users. The memory module plays a crucial role in the overall performance and efficiency of the server, making it an essential feature to consider.

Improved Data Access Speed

The Silver DDR4 SDRAM memory provides faster data access speeds compared to previous generations of memory modules. This translates into quicker retrieval and processing of information, resulting in reduced latencies and improved system responsiveness. Users will experience faster application loading times and smoother multitasking capabilities, enhancing their overall productivity.

Enhanced Multitasking

The DL380 Server's Silver DDR4 SDRAM memory allows for efficient multitasking by providing ample capacity to handle multiple applications simultaneously. With larger memory capacity, users can seamlessly switch between resource-intensive tasks without experiencing performance degradation. This feature is particularly beneficial for businesses where employees need to work on multiple applications or virtual machines concurrently.

Scalability and Future-Proofing

The Silver DDR4 SDRAM memory offers scalability options, allowing users to expand their server's memory capacity as their needs evolve. This scalability ensures that the DL380 Server can accommodate growing workloads and application requirements without the need for a complete hardware upgrade. It also enables businesses to plan for future expansions and avoid potential bottlenecks in memory capacity.

Reliability and Error Correction

The Silver DDR4 SDRAM memory incorporates error correction capabilities that enhance system reliability. It can detect and correct single-bit errors, ensuring data integrity and reducing the risk of data corruption or system crashes. This feature is particularly crucial for businesses that handle sensitive information or operate in industries where data accuracy is paramount.

Energy Efficiency

The Silver DDR4 SDRAM memory module is designed to be energy-efficient, consuming less power compared to previous generations. This not only reduces operational costs but also contributes to a greener and more sustainable IT infrastructure. By choosing the DL380 Server with Silver DDR4 SDRAM memory, businesses can align their operations with environmentally conscious practices without compromising performance.

Storage

The HPE Proliant DL380 Server Xeon features the Smart Array storage technology, which offers numerous benefits and plays a vital role in data management and reliability.

High Data Availability

The Smart Array storage technology ensures high data availability by implementing RAID (Redundant Array of Independent Disks) configurations. By distributing data across multiple drives, it provides redundancy and safeguards against data loss in case of a disk failure. This feature is essential for businesses that rely on continuous access to critical data, preventing disruptions and minimizing downtime.

Optimized Performance

The Smart Array technology optimizes storage performance by intelligently managing data access and distribution. It utilizes advanced algorithms to determine the most efficient way to read and write data across multiple drives, minimizing latency and maximizing throughput. This results in faster data access speeds and improved application performance.

Scalability and Flexibility

The DL380 Server's Smart Array storage technology offers scalability options, allowing businesses to expand their storage capacity as their needs grow. Whether it's adding additional drives or upgrading to higher-capacity disks, the Smart Array technology ensures seamless integration and minimal disruption to operations. This flexibility enables businesses to adapt to changing storage demands without the need for a complete infrastructure overhaul.

Data Protection and Recovery

The Smart Array storage technology incorporates advanced data protection features such as data mirroring and striping. These features enhance data resilience and enable quick recovery in case of disk failures. By automatically duplicating data across multiple drives, it safeguards against data loss and minimizes the impact of hardware failures.

Storage Efficiency

The Smart Array storage technology optimizes storage utilization by enabling features like thin provisioning and data deduplication. Thin provisioning allows businesses to allocate storage capacity dynamically, ensuring efficient resource utilization and reducing wastage. Data deduplication eliminates redundant data, reducing storage requirements and improving overall efficiency. These features contribute to cost savings and ensure that businesses can make the most out of their storage infrastructure.

Networking

The HPE Proliant DL380 Server Xeon comes equipped with 10GB networking capabilities, providing users with high-speed connectivity and numerous advantages in modern network environments.

Blazing-Fast Data Transfer

The 10GB networking feature enables lightning-fast data transfer rates, significantly exceeding the speeds offered by traditional 1GB connections. This high bandwidth is particularly beneficial for businesses that deal with large file transfers or run bandwidth-hungry applications. Users can experience reduced transfer times and improved network performance, enhancing their productivity.

Reduced Network Congestion

The increased bandwidth of 10GB networking helps reduce network congestion, especially in environments with heavy network traffic. With more available bandwidth, multiple users can simultaneously access resources without causing bottlenecks or slowdowns. This is particularly crucial for businesses that rely on real-time collaboration or handle bandwidth-intensive tasks such as video streaming or virtualization.

Future-Proofing

The 10GB networking feature offers future-proofing capabilities, ensuring that the DL380 Server can adapt to evolving network infrastructure requirements. As networks continue to upgrade to higher speeds, having a server with built-in 10GB connectivity allows businesses to seamlessly integrate into these environments without the need for additional hardware upgrades. This scalability and compatibility ensure that the DL380 Server remains relevant and capable for years to come.

Enhanced Virtualization Performance

Virtualization environments greatly benefit from the 10GB networking capability, as it provides the necessary bandwidth for efficient communication between virtual machines and the host server. By eliminating network bottlenecks, businesses can achieve better virtual machine performance, improved responsiveness, and an overall enhanced virtualization experience.

Improved Network Security

The 10GB networking feature enhances network security by enabling faster transmission and analysis of network traffic. With higher speeds, security appliances can process and inspect data packets more efficiently, reducing the risk of network breaches or attacks. This feature is particularly important for businesses that handle sensitive data or operate in industries with strict compliance requirements.

Part Number

The HPE Proliant DL380 Server Xeon is identified by the part number P55245-B21, which carries significant benefits and importance for users.

Identification and Compatibility

The part number P55245-B21 uniquely identifies the DL380 Server model, ensuring easy identification during procurement or maintenance activities. It allows businesses to accurately communicate the server model when seeking technical support or ordering spare parts. Additionally, the part number ensures compatibility with specific server configurations and components, eliminating any compatibility issues that may arise.

Efficient Inventory Management

The part number plays a vital role in efficient inventory management for businesses that utilize multiple DL380 Servers. By having a unique identifier for each server model, businesses can accurately track and manage their server assets. This simplifies inventory audits, asset tracking, and maintenance planning, leading to improved overall IT infrastructure management.

Documentation and Support

The part number P55245-B21 is used to reference technical documentation, user manuals, and support resources specific to the DL380 Server model. This ensures that users can access the correct information and resources tailored to their server configuration. Having accurate and specific documentation streamlines troubleshooting processes, reduces downtime, and facilitates efficient system administration.

Standardization and Interoperability

Using a standardized part number like P55245-B21 promotes interoperability and compatibility across various systems and components. It ensures that businesses can integrate the DL380 Server seamlessly into their existing infrastructure without encountering compatibility issues. This standardization simplifies IT operations, reduces complexity, and enables efficient resource allocation.

Pricing and Procurement

The part number facilitates accurate pricing and procurement processes for the DL380 Server. It allows businesses to request quotations or place orders with vendors confidently, ensuring that they receive the correct server model with the desired specifications. This streamlined procurement process saves time and eliminates any potential confusion or errors in the ordering process.

In conclusion, the HPE Proliant DL380 Server Xeon offers exceptional features across its Processor, Memory, Storage, Networking, and Part Number specifications. The 2.8GHz 8-Core processor provides enhanced performance, efficiency, scalability, and reliability. The Silver DDR4 SDRAM memory offers improved data access speed, multitasking capabilities, scalability, reliability, and energy efficiency. The Smart Array storage technology ensures high data availability, optimized performance, scalability, data protection, and storage efficiency. The 10GB networking feature provides blazing-fast data transfer, reduced network congestion, future-proofing capabilities, enhanced virtualization performance, and improved network security. The part number P55245-B21 enables easy identification, compatibility assurance, efficient inventory management, documentation support, standardization, interoperability, accurate pricing, and streamlined procurement processes. With these features and benefits combined, the HPE Proliant DL380 Server Xeon proves to be a powerful and reliable solution for businesses and organizations seeking top-notch performance and efficiency in their IT infrastructure.
