HPE Proliant DL380 Server Xeon 20-core Gold 5218r / 2.1GHz 32 GB DDR4 SDRAM (P36135-B21)

Processor: Gold 5218r / 2.1GHz

The HPE Proliant DL380 Server Xeon 20-core is equipped with the powerful Gold 5218r processor, which operates at a speed of 2.1GHz. This processor is specifically designed to deliver exceptional performance for demanding workloads. Whether you are running resource-intensive applications, virtualization environments, or data analytics workloads, the Gold 5218r processor ensures smooth and efficient operations.

Main Information of P36135-B21

• Manufacturer: Hewlett Packard Enterprise
• Model Number: P36135-B21
• Server Type: 2-way Rack Mountable
• Rack Height: 2U
• Product Name: Proliant DL380 Gen10

Processor & Chipset

• Processor: 2nd Gen Intel Xeon Gold 5218R at 2.1 GHz
• Max Turbo Speed: 4.0 GHz
• Number of Cores: 20-core
• Installed CPUs: 1
• Max CPUs: 2
• CPU Upgradability: Yes
• Processor Features: Hyper-Threading, Intel Turbo Boost Technology 2
• CPU Socket: FCLGA3647
• Chipset: Intel C621

Cache Memory

• Installed L3 Cache: 27.5 MB
• Cache Per Processor: 27.5 MB

RAM Specifications

• Installed RAM: 32 GB
• Maximum RAM: 1.5 TB
• Memory Type: DDR4 SDRAM - Advanced ECC
• Effective Memory Speed: 2666 MHz
• Rated Memory Speed: 2933 MHz
• Form Factor: DIMM 288-pin
• Available Slots: 24 total, 23 empty
• Features: Registered, Dual Rank, HPE SmartMemory

Supported Memory Configurations

• Load-Reduced ECC: Up to 3 TB
• Registered ECC: Up to 1.5 TB
• Non-Volatile ECC: 192 GB
• HPE Persistent Memory - Optane DC Persistent: Up to 6 TB

Storage Options

No HDD included

Storage Controllers

• Type: 1 x SATA - PCIe 3.0 x4
• Controller Interface: SATA 6 Gb/s
• Controller Name: HPE Smart Array S100i SR Software RAID
• Channel Quantity: 14
• RAID Levels: 0, 1, 5, 10

Optical and Graphics Components

No Optical Drive included

Graphics Controller

• Video Memory: 16 MB
• Video Interfaces: VGA

Networking & Communication

• Ethernet Ports: 2 x 10 Gigabit Ethernet
• Ethernet Controller: Broadcom BCM57416
• Data Link Protocol: 10 Gigabit Ethernet
• Remote Management Controller: Integrated Lights-Out 5
• Features: Wake On LAN (WOL), PXE Support

Expansion & Connectivity

• Available Bays: 8 x Hot-Swap 2.5” SFF

Expansion Slots

• MicroSD Card Slot: 1 (internal)
• PCIe 3.0 x8: 1 (Full-length, Full-height)
• PCIe 3.0 x16: 1 (Full-length, Full-height)
• PCIe 3.0 x8: 1 (Half-length, Full-height)
• FlexibleLOM Slot: 1 (currently occupied)

Interfaces & Ports

• USB 3.0 Ports: 3 (1 front, 2 rear)
• VGA Port: 1
• LAN Ports: 2 x 10 Gigabit Ethernet
• HPE iLO Ports: 1 (standard), 1 (service port)

Miscellaneous Information

• Cable Management Arm
• 4 Standard Fans
• SFF Easy Install Rails

Compliance Standards

• WEee
• TLS v1.2
• ASHRAE Class A4
• ASHRAE Class A3
• WEee 2002/95/EC
• ACPI 6.1

Power Specifications

• Type: Hot-Plug Power Supply
• Redundancy: Optional
• Redundancy Scheme: 1+1 (with optional power supply)
• Installed Qty: 1
• Max Supported Qty: 2
• Voltage Required: AC 120/230 V (50/60 Hz)
• Power Output: 800 Watts

Software & Operating System

• HPE iLO Standard with Intelligent Provisioning
• HPE OneView Standard (Free Download)

Environmental Specifications

• Energy Star Certified: Yes
• Energy Star Version: 3.0

Environmental Parameters

• Minimum Operating Temperature: 50°F
• Maximum Operating Temperature: 95°F
• Humidity Range: 8 - 90% (Non-condensing)

Dimensions & Weight

• Width: 17.5 inches
• Depth: 28.8 inches
• Height: 3.4 inches
• Weight: 32.54 lbs

Increased Processing Power

The Gold 5218r processor features 20 cores, allowing it to handle multiple tasks simultaneously. This significantly increases the processing power of the server, enabling it to execute complex calculations and data processing tasks quickly. With more cores, the server can efficiently distribute the workload, ensuring optimal performance even under heavy usage.

Enhanced Performance with Turbo Boost Technology

One of the key features of the Gold 5218r processor is its Turbo Boost Technology. This technology dynamically increases the clock speed of the processor when there is a need for additional performance. It can automatically boost the clock speed up to 3.9GHz, providing a significant performance boost for tasks that require extra processing power.

Improved Energy Efficiency

The Gold 5218r processor is designed with energy efficiency in mind. It utilizes advanced power management features to optimize power consumption without compromising performance. By intelligently adjusting power levels based on workload demands, the processor helps reduce energy costs and ensures sustainable operations.

Reliable and Secure Operations

HPE Proliant DL380 Server Xeon 20-core equipped with the Gold 5218r processor offers robust security features to protect your data and operations. It includes built-in hardware-enhanced security capabilities, such as Intel® Trusted Execution Technology (TXT) and Intel® Software Guard Extensions (SGX), to safeguard your critical workloads from potential threats.

Memory: 32 GB DDR4 SDRAM

Efficient Data Access and Processing

The HPE Proliant DL380 Server Xeon 20-core is equipped with 32GB DDR4 SDRAM, providing a significant amount of memory for efficient data access and processing. The DDR4 technology offers improved speed and bandwidth compared to its predecessors, ensuring that your applications can quickly retrieve and manipulate data.

Optimized Performance for Multitasking

With 32GB of memory, the server can handle multiple tasks and applications simultaneously without experiencing significant performance degradation. This is especially beneficial for businesses that require multitasking capabilities, such as running multiple virtual machines or hosting various databases simultaneously.

Increased System Reliability

The ample amount of memory in the HPE Proliant DL380 Server Xeon 20-core enhances system reliability. It helps reduce the risk of memory-related errors and crashes, ensuring that your server operates smoothly and consistently. Additionally, the DDR4 technology includes error-correcting code (ECC) functionality, which detects and corrects memory errors in real-time, further enhancing system stability.

Future-Proofing Your Infrastructure

By equipping your server with 32GB of memory, you future-proof your infrastructure to some extent. As applications become more resource-intensive over time, having a sufficient amount of memory ensures that your server can handle the increasing demands without the need for immediate upgrades. This helps save costs in the long run and ensures that your server remains capable of supporting new and emerging technologies.

Part Number: P36135-B21

Easy Identification and Compatibility

The HPE Proliant DL380 Server Xeon 20-core features a specific part number, P36135-B21, which serves as a unique identifier for the product. This part number simplifies the process of identifying and ordering the correct server model, ensuring compatibility with your existing infrastructure and components.

Streamlined Maintenance and Support

Having a specific part number for the server makes it easier to request maintenance or support from the manufacturer or authorized service providers. When contacting customer support, you can simply provide the part number, allowing them to quickly access relevant information about your server's configuration and specifications. This streamlines the troubleshooting process and ensures that you receive accurate and efficient assistance.

Faster Replacement of Components

In case of component failures or upgrades, having a specific part number allows for faster replacement of faulty or outdated components. By referencing the part number, you can easily identify the required replacement parts and order them without delay. This helps minimize downtime and ensures that your server is up and running again as quickly as possible.

Standardization and Documentation

Part numbers play a crucial role in standardizing the identification and documentation of server models across different systems and organizations. They simplify inventory management, asset tracking, and documentation processes by providing a consistent and reliable reference point for server identification. This is particularly important for businesses with multiple servers or complex IT infrastructures.

Ensuring Genuine HPE Products

Part number, P36135-B21, identifies the HPE Proliant DL380 Server Xeon 20-core as an original HPE product. It serves as an assurance that you are purchasing a genuine and high-quality server from a trusted manufacturer. This is essential for businesses that prioritize reliability, performance, and long-term support for their IT infrastructure.
