HPE Proliant Ml30 Gen10 Xeon Quad-Core Server P44718-001

Processor

The HPE Proliant Ml30 Gen10 Server is powered by a robust 2.8 GHz Xeon Quad-Core processor, which delivers exceptional performance and reliability. With its advanced technology and powerful capabilities, this processor is designed to handle demanding workloads and ensure smooth operations for businesses of all sizes.

General Overview of P44718-001

• Company: Hewlett Packard Enterprise
• Part Number: P44718-001

Server Specifications

• Scalability: Single Processor
• Form Factor: Tower (4U)
• Model: HPE Proliant ML30 Gen10 Plus E-2314

Processor & Chipset

• Processor: Intel Xeon E-2314
• Base Clock Speed: 2.8 GHz
• Max Turbo Speed: 4.5 GHz
• Core Count: Quad-Core
• Number of CPUs: 1
• CPU Upgradability: Yes
• Main Processor Feature: Intel Turbo Boost Technology 2.0

Chipset Details

• Chipset Type: Intel C256

Cache Memory

• Installed Cache Size: 8 MB L3 Cache
• Cache per Processor: 8 MB

Memory

• Installed Memory: 16 GB
• Maximum Memory Capacity: 128 GB
• Memory Technology: DDR4 SDRAM with ECC
• Effective Memory Speed: 3200 MHz
• Rated Memory Speed: 3200 MHz
• Memory Form Factor: DIMM 288-pin
• Total Memory Slots: 4
• Available Slots: 3
• Configuration: 1 x 16 GB

Storage

• Drive Type: No HDD Installed

Storage Controllers

• RAID Controller: 1 x RAID
• Controller Interface: SATA 6 Gb/s
• Number of Channels: 6
• RAID Levels Supported: RAID 0, RAID 1, RAID 5, RAID 10

Graphics & Display

• Video Interfaces: VGA

Network & Connectivity

• Ethernet Ports: 2 x Gigabit Ethernet
• Network Controller: Broadcom BCM5720
• Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
• Remote Management: SNMP 3, IPMI 2.0, SMASH CLP
• Remote Management Controller: Integrated Lights-Out 5
• Additional Features: Wake On LAN (WOL), PXE Support

Expansion & Connectivity

• Internal Bays: 4 x 3.5” LFF (Free)
• PCIe Slots:
  • 1 x PCIe 4.0 x16 (Full-Length, Full-Height) - Free
  • 1 x PCIe 3.0 x16 (Full-Length, Full-Height, x4 Mode) - Free
  • 2 x PCIe 3.0 x8 (Half-Length, Full-Height, x4 Mode) - Free
  • 1 x M.2 Card (PCIe x2 and SATA Mode) - Free

Interfaces

• VGA: 1
• Gigabit Ethernet Ports: 2
• HPE iLO Port: 1
• USB Ports:
  • USB 3.0: 6 (1 Front, 4 Rear, 1 Internal)
  • USB 2.0: 1 (Front)

Miscellaneous

• HPE Standard Heatsink
• Non-hot Plug Non-redundant System Fan

Security and Compliance

• Theft/Intrusion Protection: Security Lock Slot (Cable Lock Sold Separately), Padlock Loop
• Security Slot Type: Kensington Security Slot
• Standards Compliance: EMC, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, UEFI, ACPI 6.3

Power Description

• Device Type: Power Supply
• Quantity Installed: 1
• Voltage Requirements: AC 100-120/200-240 V (50/60 Hz)
• Power Provided: 350 Watts
• 80 Plus Certification: 80 Plus Gold
• Efficiency: 92%

Dimensions & Weight

• Width: 6.9 inches
• Depth: 18.7 inches
• Height: 14.5 inches
• Weight: 22.27 lbs

Enhanced Performance

The 2.8 GHz Xeon Quad-Core processor offers a significant boost in performance compared to standard processors. It features four cores, each capable of handling multiple tasks simultaneously. This enables the server to efficiently process data, run applications, and handle complex calculations without experiencing performance bottlenecks.

Improved Multitasking

Multitasking is crucial for businesses that require their servers to handle multiple tasks simultaneously. The 2.8 GHz Xeon Quad-Core processor excels in multitasking scenarios, allowing users to run multiple applications or virtual machines without sacrificing performance. This capability enhances productivity and ensures that critical business operations remain uninterrupted.

Efficient Virtualization

Virtualization has become an integral part of modern server environments as it enables businesses to consolidate their hardware resources and run multiple virtual machines on a single physical server. The 2.8 GHz Xeon Quad-Core processor is specifically optimized for virtualization, providing excellent performance and efficient resource allocation. This ensures that businesses can make the most out of their server infrastructure while minimizing costs.

Reliable Workload Management

The 2.8 GHz Xeon Quad-Core processor is engineered to handle heavy workloads reliably. It efficiently manages the distribution of tasks across its four cores, ensuring that each core operates optimally without overloading the system. This results in consistent performance and prevents system crashes or slowdowns during peak usage periods.

Seamless Scalability

As businesses grow, their server requirements also increase. The 2.8 GHz Xeon Quad-Core processor offers seamless scalability, allowing businesses to upgrade their server's processing power without replacing the entire system. This flexibility enables businesses to adapt to changing needs and ensures that their server infrastructure can keep up with the demands of their expanding operations.

Part Number

The HPE Proliant Ml30 Gen10 Server features a unique part number, P44718-001, which plays a crucial role in identifying and procuring the correct server components or replacements. Understanding the benefits and importance of this feature is vital for users to ensure compatibility and streamline their procurement processes.

Easy Component Identification

The part number, P44718-001, serves as a unique identifier for the HPE Proliant Ml30 Gen10 Server and its associated components. It simplifies the process of identifying and ordering specific parts required for maintenance or upgrades. By referencing the part number, users can quickly locate the exact components they need, eliminating any confusion or compatibility issues.

Efficient Troubleshooting

In the event of a hardware failure or issue, having the correct part number is crucial for troubleshooting purposes. It allows users to accurately communicate the faulty component to technical support or procurement teams. This speeds up the resolution process as support personnel can quickly identify the problematic part and provide appropriate assistance or replacements.

Streamlined Procurement

Procuring server components can be a complex task, especially when dealing with various models and configurations. The part number, P44718-001, simplifies the procurement process by providing a standardized reference for the HPE Proliant Ml30 Gen10 Server. Users can easily communicate this part number to vendors or resellers, ensuring that they receive the correct components without any confusion or delays.

Compatibility Assurance

The part number acts as a guarantee of compatibility between different server components. It ensures that the procured components are specifically designed for the HPE Proliant Ml30 Gen10 Server, eliminating any compatibility issues that could arise from using generic or incompatible parts. This assurance enhances the server's reliability and reduces the risk of system failures or performance degradation.

Future Expansion and Upgrades

As businesses evolve, they may need to expand their server infrastructure or upgrade individual components. The part number, P44718-001, plays a vital role in facilitating future expansion and upgrades. It allows users to identify compatible components that seamlessly integrate with their existing HPE Proliant Ml30 Gen10 Server setup, ensuring a smooth and hassle-free upgrade process.

In conclusion, the 2.8 GHz Xeon Quad-Core processor and the part number P44718-001 are essential features of the HPE Proliant Ml30 Gen10 Server. The powerful processor enhances performance, multitasking capabilities, virtualization efficiency, workload management, and scalability. On the other hand, the unique part number simplifies component identification, troubleshooting, procurement, and ensures compatibility for future expansions or upgrades. Together, these features contribute to a reliable and efficient server solution for businesses seeking high-performance computing power.
