WS-C3650-48PS-L Cisco Catalyst 3650 48 Ports Ethernet Switch

Overview of Cisco WS-C3650-48PS-L

Discover the Cisco WS-C3650-48PS-L, a robust Ethernet switch from Cisco's renowned Catalyst 3650 series. This model is engineered to meet the demanding needs of modern network environments.

Product Specifications

General Details

• Manufacturer: Cisco
• Part Number / SKU: WS-C3650-48PS-L
• Product Line: Catalyst
• Series: 3650
• Type: Ethernet Switch

Network Ports

• Total Ports: 48 Gigabit Ethernet
• PoE+ Ports: 48 RJ-45
• Expansion Slots: 4 Gigabit Ethernet

Media & Performance

• Media Type: Twisted Pair
• Ethernet Technology: Gigabit Ethernet
• Network Technology: 10/100/1000Base-T
• MTBF: 383,760 hours

Expansion and Slots

• Total Expansion Slots: 4
• Slot Type: SFP

Features

Switching Capabilities

• Layer 2 Switching
• ARP Support
• Trunking
• VLAN Support
• IGMP Snooping
• RSTP/MSTP Support
• DHCP Snooping
• PAgP Support
• ACL Support
• QoS
• RADIUS Support
• MLD Snooping
• DAI
• UDLD
• PVRST+
• LACP
• RSPAN
• Energy Efficient Ethernet

Compliance and Standards

• CISPR 22 Class A
• GOST
• BSMI CNS 13438 Class A
• CISPR 24
• EN 61000-3-2
• NOM
• EN 61000-3-3
• EN55024
• EN55022 Class A
• ICES-003 Class A
• RoHS
• UL 60950-1 2nd Ed.
• KCC
• FCC Part 15 A
• ISO 7779
• CSA C22.2 No. 60950-1 2nd Ed.
• EN 60950-1 2nd Ed.
• IEC 60950-1 2nd Ed.
• VCCI Class A
• KN24
• KN22 Class A

Network and Communication

• Layer Supported: Layer 2

Management & Protocols

Manageability

• Manageable: Yes
• Routing Protocol: Static IP Routing

Remote Management

• SNMP v1, v2c, v3
• RMON 1/2/3/9
• Telnet
• SSH
• CLI

Memory and Power

Memory

• RAM: 4 GB
• Flash Memory: 2 GB

Power Supply

• Device: Internal Hot-Plug Power Supply
• Installed Quantity: 1 (installed) / 2 (max)
• Redundancy: Optional, 1+1 (with optional power supply)
• Power Provided: 640 Watts
• Voltage Required: AC 120/230 V (50/60 Hz)
• Input Voltage: 220 V AC

Compatibility

• IEEE 802.1D Spanning Tree Protocol
• IEEE 802.1p CoS Prioritization
• IEEE 802.1Q VLAN
• IEEE 802.1s
• IEEE 802.1w
• IEEE 802.1X
• IEEE 802.1X-Rev
• IEEE 802.11
• IEEE 802.1ab (LLDP)
• IEEE 802.3ad
• IEEE 802.3x Full Duplex (10BASE-T, 100BASE-TX, 1000BASE-T)
• IEEE 802.3 10BASE-T
• IEEE 802.3u 100BASE-TX
• IEEE 802.3ab 1000BASE-T
• IEEE 802.3z 1000BASE-X
• RMON I and II Standards
• SNMP v1, v2c, v3

Ports

The Cisco WS-C3650-48PS-L Ethernet Switch is equipped with an impressive 48 ports, making it an ideal choice for businesses and organizations that require a high number of network connections. These ports are essential for connecting various devices such as computers, servers, printers, IP phones, and other network equipment.

Increased Connectivity

With 48 ports available, this Cisco Ethernet switch provides ample connectivity options for expanding your network infrastructure. Whether you need to connect multiple devices in a small office or manage a large-scale enterprise network, the WS-C3650-48PS-L has you covered. It allows you to establish reliable and fast connections between different devices, ensuring seamless communication and data transfer.

Flexibility and Scalability

Having 48 ports gives you the flexibility to accommodate future expansion or reconfiguration of your network. As your business grows or your network requirements change, you can easily add new devices without worrying about running out of available ports. The WS-C3650-48PS-L offers scalability, allowing you to adapt to evolving technology needs and infrastructure changes with minimal disruption.

Streamlined Network Management

The abundance of ports on the Cisco WS-C3650-48PS-L simplifies network management tasks. With more ports available, you can organize your network more efficiently by assigning specific devices to dedicated ports. This enables easier troubleshooting and maintenance as you can quickly identify the source of any network issues. Additionally, having multiple ports reduces the need for additional equipment such as switches or hubs, streamlining your network infrastructure.

Enhanced Network Performance

The 48 ports on this Cisco Ethernet switch support high-speed data transfer rates, ensuring optimal network performance. Each port delivers fast and reliable connectivity, allowing users to access resources and share data without experiencing lag or bottlenecks. The WS-C3650-48PS-L is designed to handle heavy network traffic, making it suitable for demanding applications and environments where bandwidth-intensive tasks are common.

Cost Savings

By providing 48 ports in a single device, the WS-C3650-48PS-L eliminates the need for purchasing multiple switches or other networking equipment. This consolidation not only reduces upfront costs but also lowers ongoing maintenance and operational expenses. Additionally, having a single switch simplifies cable management and reduces the complexity associated with managing multiple devices.

Power

One of the standout features of the Cisco WS-C3650-48PS-L Ethernet Switch is its Power over Ethernet (PoE) capability. This feature provides significant benefits for users, particularly in environments where power outlets may be limited or inaccessible.

Easy Deployment

With PoE support, the WS-C3650-48PS-L simplifies the deployment of network devices such as IP phones, wireless access points, and security cameras. These devices can be conveniently powered using Ethernet cables, eliminating the need for separate power adapters or electrical wiring. This streamlined installation process saves time and effort, making it ideal for businesses that require quick and efficient network setup.

Flexibility in Device Placement

The PoE feature allows you to position network devices wherever they are needed without being constrained by power outlet locations. This flexibility is particularly valuable in environments where installing additional power outlets may be impractical or costly. With the WS-C3650-48PS-L, you can deploy devices in optimal locations to maximize network coverage or surveillance capabilities without worrying about power availability.

Centralized Power Management

The Cisco WS-C3650-48PS-L enables centralized power management, allowing you to monitor and control the power consumption of connected devices. This feature provides valuable insights into power usage patterns and helps optimize energy efficiency. By efficiently managing power allocation, you can reduce energy waste, lower electricity costs, and contribute to a more sustainable and environmentally friendly network infrastructure.

Improved Reliability

Power over Ethernet enhances the reliability of network devices by providing uninterrupted power supply. In the event of a power outage, the WS-C3650-48PS-L can leverage alternative power sources such as uninterruptible power supplies (UPS) to keep critical network equipment operational. This ensures continuous connectivity and minimizes downtime, which is crucial for businesses that rely heavily on their network infrastructure.

Future-Proofing

As technology advances, the demand for PoE-enabled devices continues to grow. By investing in the Cisco WS-C3650-48PS-L with PoE support, you future-proof your network infrastructure. This allows you to seamlessly integrate emerging technologies and devices that require PoE, such as advanced wireless access points or Internet of Things (IoT) devices. The WS-C3650-48PS-L ensures that your network remains adaptable and ready for future expansion.

Series

The Cisco WS-C3650-48PS-L belongs to the Catalyst 3650 series, which is renowned for its advanced features and robust performance. This series offers numerous benefits and plays a crucial role in enhancing network efficiency and security.

Advanced Feature Set

The Catalyst 3650 series, including the WS-C3650-48PS-L model, incorporates a wide range of advanced features designed to optimize network performance. These features include dynamic routing protocols, advanced quality of service (QoS) capabilities, comprehensive security measures, and advanced traffic management. By leveraging these features, businesses can prioritize critical applications, enhance data transfer speeds, and ensure reliable connectivity across their networks.

Enhanced Network Security

With increasing cybersecurity threats, network security has become a top priority for organizations. The Catalyst 3650 series offers robust security features, including integrated TrustSec technology, secure group access control lists (SGACLs), and MACsec encryption. These features help protect sensitive data, prevent unauthorized access, and mitigate network vulnerabilities. The WS-C3650-48PS-L ensures that your network remains secure and protected against evolving security threats.

Efficient Network Management

The Catalyst 3650 series simplifies network management with its intuitive and user-friendly interface. It provides centralized management through Cisco's DNA Center, allowing administrators to easily configure, monitor, and troubleshoot network devices. This streamlined management approach saves time and resources, enabling IT teams to focus on critical tasks and improve overall network efficiency.

Highly Reliable Performance

The WS-C3650-48PS-L delivers exceptional performance and reliability. With its advanced hardware architecture and Cisco StackWise technology, this switch provides high availability and resiliency. StackWise technology allows multiple switches to be stacked together, forming a single logical unit with increased redundancy and improved performance. This ensures seamless failover capabilities and minimizes downtime in the event of a switch failure.

Future-Ready Network

Investing in the Catalyst 3650 series ensures that your network is prepared for future technological advancements. The WS-C3650-48PS-L supports Cisco's Digital Network Architecture (DNA), which enables businesses to adopt emerging technologies such as Software-Defined Networking (SDN), cloud-based services, and automation. By embracing the Catalyst 3650 series, you can future-proof your network infrastructure and stay ahead in the ever-changing landscape of networking technologies.

In conclusion, the Cisco WS-C3650-48PS-L Ethernet Switch offers an extensive range of features tailored to meet the needs of modern networks. With its 48 ports, Power over Ethernet capability, and belonging to the Catalyst 3650 series, this switch provides users with increased connectivity, flexibility, streamlined network management, enhanced performance, and advanced security measures. By choosing the WS-C3650-48PS-L, businesses can build a reliable and future-proof network infrastructure that supports their growing needs.
