CD8069504198002 Intel Xeon Gold 6212U 2.4GHz 24-core Processor

Intel Xeon Gold 6212U Processor

The Intel Xeon Gold 6212U 2.4GHz 24-core processor is engineered to deliver exceptional performance and reliability for demanding enterprise workloads. As a part of Intel’s Cascade Lake family, this processor is designed to handle complex applications in data centers, cloud environments, and high-performance computing (HPC) settings. With its 24 cores, 48 threads, and 165W thermal design power (TDP), the Xeon Gold 6212U offers robust computing power and scalability, making it an ideal choice for businesses requiring top-tier performance and efficiency.

Intel Xeon Gold 6212U CD8069504198002 Processor

Overview

• Product Series: 2nd Generation Intel Xeon Scalable Processors
• Codename: Formerly known as Cascade Lake
• Target Market: Server and enterprise environments
• Processor Identifier: 6212U
• Status: Released
• Launch Period: Q2 2019
• Manufacturing Process: 14 nm technology

Performance Specifications

Core and Frequency Details

• Total Cores: 24 cores, ideal for high-performance parallel processing
• Total Threads: 48 threads, enhancing multitasking efficiency
• Base Clock Speed: 2.40 GHz, providing consistent and reliable performance
• Maximum Turbo Frequency: Up to 3.90 GHz, boosting performance during demanding tasks
• Cache Size: 35.75 MB of cache for faster data retrieval and improved system efficiency
• Thermal Design Power (TDP): 165 W, managing performance and power consumption effectively
• UPI Links: None for this model

Additional Specifications

• Embedded Options: Not available

Memory Specifications

Supported Memory Configurations

• Maximum Memory Capacity: Up to 1 TB, dependent on memory configuration
• Memory Types: DDR4-2933, ensuring high-speed data processing
• Maximum Memory Speed: 2933 MHz
• Memory Channels: 6 channels, optimizing data flow and system performance
• ECC Memory Support: Yes, for reliable error correction
• Intel Optane DC Persistent Memory: Supported for additional flexibility and performance

Expansion and Connectivity

Scalability and Interfaces

• Scalability: Designed for single-socket setups (1S)
• PCI Express Revision: 3.0, with support for up to 48 PCIe lanes for extensive connectivity

Package Details

• Supported Socket: FCLGA3647
• Case Temperature (TCASE): 90°C
• Package Dimensions: 76.0mm x 56.5mm

Advanced Technologies

Performance Enhancements

• Intel Deep Learning Boost: Yes, accelerating artificial intelligence and machine learning tasks
• Intel Speed Select Technology - Performance Profile: Not applicable
• Intel Speed Select Technology - Base Frequency: Not applicable
• Intel Resource Director Technology (RDT): Yes, for advanced resource and workload management
• Intel Speed Shift Technology: Yes, for more responsive frequency adjustments
• Intel Turbo Boost Technology 2.0: Yes, enhancing performance during peak load conditions
• Intel Turbo Boost Max Technology 3.0: Not supported
• Intel vPro Platform Compatibility: Yes, providing advanced manageability and security features
• Intel Hyper-Threading Technology: Yes, supporting improved parallel processing
• Intel Virtualization Technology (VT-x): Yes, enabling efficient virtualization capabilities
• Intel Virtualization Technology for Directed I/O (VT-d): Yes, enhancing input/output performance
• Intel VT-x with Extended Page Tables (EPT): Yes, improving virtual memory management
• Intel TSX-NI: Yes, for enhanced transactional processing
• Intel 64: Yes, supporting 64-bit computing architecture
• Instruction Set Extensions: Includes Intel SSE4.2, AVX, AVX2, and AVX-512
• Number of AVX-512 FMA Units: 2 units for optimized vector computations
• Enhanced Intel SpeedStep Technology: Yes, for efficient power scaling and management
• Intel Volume Management Device (VMD): Yes, supporting advanced storage management

Security and Reliability Features

Built-in Security Technologies

• Intel AES New Instructions: Yes, for accelerated encryption and data protection
• Intel Trusted Execution Technology: Yes, enhancing secure computing environments
• Execute Disable Bit: Yes, providing additional defense against malicious threats
• Intel Run Sure Technology: Yes, ensuring reliable and stable operation
• Mode-based Execute Control (MBE): Yes, offering improved security against certain types of attacks

Core Specifications of the Intel Xeon Gold 6212U

The Xeon Gold 6212U stands out with its impressive core specifications that cater to high-performance computing needs. The processor features 24 cores and 48 threads, a base clock speed of 2.4GHz, and a large 33MB cache. These attributes enable the processor to efficiently handle multi-threaded applications and large datasets, providing businesses with the power needed to manage complex tasks and workloads.

Cascade Lake Architecture: Enhancing Performance and Efficiency

Built on Intel’s Cascade Lake architecture, the Xeon Gold 6212U offers several advancements over its predecessors. Cascade Lake processors are designed to provide improved performance, better memory support, and enhanced security features. This architecture incorporates innovations that help maximize performance while maintaining energy efficiency and reliability, making the Xeon Gold 6212U a strong contender in enterprise computing environments.

Turbo Boost Technology: Dynamic Performance Enhancements

The Xeon Gold 6212U utilizes Intel Turbo Boost Technology to dynamically increase its clock speed beyond the base 2.4GHz during periods of high demand. This feature allows the processor to provide additional performance when needed, making it ideal for handling peak workloads and resource-intensive applications such as data analytics, simulations, and virtualized environments.

Hyper-Threading Technology for Enhanced Multi-Threading

With 24 cores and 48 threads, the Xeon Gold 6212U supports Intel’s Hyper-Threading Technology, which enables each core to handle two threads simultaneously. This technology improves parallel processing efficiency, allowing the processor to execute multiple tasks concurrently. It is particularly beneficial for applications that require high levels of concurrency, such as virtualization platforms and multi-user databases.

33MB Cache: Accelerating Data Access

The processor’s 33MB L3 cache plays a crucial role in speeding up data access and reducing latency. By storing frequently accessed data closer to the cores, the large cache size enhances the processor’s ability to handle data-intensive applications and operations, improving overall system performance and responsiveness.

Security Features for Enterprise Environments

Security is a critical consideration for enterprise environments, and the Intel Xeon Gold 6212U includes a range of advanced features designed to protect data and ensure system integrity. The processor offers Intel Software Guard Extensions (SGX) and Intel Trusted Execution Technology (TXT) to provide robust security measures for sensitive applications and data.

Protection Against Side-Channel Attacks

The Xeon Gold 6212U incorporates hardware-level mitigations against side-channel attacks such as Spectre and Meltdown. These mitigations help secure the processor’s operations from potential vulnerabilities without compromising performance, providing a secure computing environment for critical business applications.

Intel Secure Key and OS Guard: Safeguarding Data and Systems

Intel Secure Key enhances cryptographic operations by providing a hardware-based random number generator, which strengthens data encryption processes. Additionally, Intel OS Guard offers protection against privilege escalation attacks, ensuring that the operating system remains secure and operational without unauthorized interference.

Intel Boot Guard: Ensuring Secure Boot Processes

Intel Boot Guard helps protect the system during the boot process by ensuring that only trusted firmware is used. This protection prevents unauthorized software from compromising the system at its most vulnerable stage, maintaining overall security and integrity from the moment the system starts up.

Memory Support and Capabilities

The Intel Xeon Gold 6212U supports a wide range of memory configurations, including up to 1TB of DDR4 RAM across six memory channels. This extensive memory support allows for high bandwidth and low latency, making the processor well-suited for applications requiring large memory capacities and fast data access.

Support for Intel Optane DC Persistent Memory

Intel Optane DC Persistent Memory technology offers a new level of performance and capacity, providing a memory tier between traditional DRAM and storage. This technology enhances application performance by offering faster data access and persistent storage, making it particularly valuable for data-intensive applications and large-scale analytics.

DDR4 Memory with ECC: Ensuring Data Integrity

The Xeon Gold 6212U supports DDR4 memory with Error-Correcting Code (ECC), which automatically detects and corrects data corruption. ECC memory is crucial in enterprise environments where data accuracy and system reliability are essential. By preventing data errors, ECC memory ensures smooth operation and minimizes the risk of data loss.

Scalable Memory Solutions for Growing Needs

The Xeon Gold 6212U’s scalable memory support allows businesses to expand their memory capacity as their needs evolve. This scalability ensures that the processor can accommodate increasing data demands and growing workloads, providing a flexible solution that adapts to changing business requirements.

Power Efficiency and Thermal Management

The Intel Xeon Gold 6212U is designed with a 165W TDP, balancing high performance with energy efficiency. Advanced power management features help optimize power consumption, making the processor suitable for data centers and enterprise environments focused on reducing operational costs and environmental impact.

Intel Speed Select Technology for Performance Optimization

Intel Speed Select Technology (SST) enables dynamic allocation of processor resources based on workload requirements. SST allows for adaptive performance optimization, ensuring that critical applications receive the necessary resources while maintaining overall energy efficiency. This technology is particularly useful in data centers where workload demands can vary significantly.

Effective Thermal Management for Consistent Performance

The Xeon Gold 6212U includes advanced thermal management features to maintain optimal operating temperatures. These features help prevent overheating and ensure consistent performance, even under heavy workloads. Effective thermal management extends the lifespan of the processor and maintains system stability.

Energy Efficiency for Sustainable Operations

The processor’s energy-efficient design contributes to sustainable operations in data centers and enterprise environments. By reducing power consumption while delivering high performance, the Xeon Gold 6212U helps organizations achieve their sustainability goals and minimize their environmental footprint.

Scalability and Flexibility in Enterprise Deployments

The Intel Xeon Gold 6212U is designed to be highly scalable, making it suitable for a variety of enterprise applications. It supports multi-socket configurations, allowing businesses to deploy systems with additional processors for increased computational capacity. This scalability is essential for environments requiring extensive parallel processing and high performance.

Compatibility with Leading Server Platforms

The Xeon Gold 6212U is compatible with a wide range of server platforms from top manufacturers such as Dell, HP, and Lenovo. This broad compatibility ensures that businesses can integrate the processor into their existing infrastructure with minimal changes, leveraging their current technology investments while upgrading to a higher level of performance.

Multi-Socket Configurations for Enhanced Capacity

Support for multi-socket configurations allows businesses to expand their processing power by adding additional processors. This capability is particularly valuable for applications requiring high levels of parallel processing, such as scientific simulations, financial modeling, and artificial intelligence.

Flexible Deployment Options for Cloud and On-Premises Solutions

The Xeon Gold 6212U’s versatility makes it suitable for deployment in various environments, including traditional on-premises data centers and cloud-based or hybrid solutions. This flexibility ensures that businesses can adapt their IT strategies to meet evolving demands, whether they are scaling up their infrastructure or transitioning to new technologies.

Applications and Use Cases

The Intel Xeon Gold 6212U is designed to excel in a wide range of enterprise applications, offering the performance, reliability, and scalability required for today’s complex IT environments. From virtualization and cloud computing to high-performance computing and big data analytics, the Xeon Gold 6212U provides a powerful solution for diverse workloads.

Virtualization and Cloud Computing

The processor’s multi-core architecture and high thread count make it well-suited for virtualization and cloud computing environments. It enables efficient consolidation of multiple virtual machines on a single server, optimizing hardware utilization and reducing overall costs while maintaining high performance and reliability.

Big Data and Analytics

The Xeon Gold 6212U’s ability to handle large datasets and perform complex calculations quickly is ideal for big data and analytics applications. Its advanced memory support and high-speed processing capabilities enable efficient data processing, allowing businesses to gain insights faster and make informed decisions based on accurate data analysis.

High-Performance Computing (HPC)

In high-performance computing scenarios, the Xeon Gold 6212U delivers the computational power needed for demanding simulations, modeling, and scientific research. Its high core count and threading capabilities ensure that it can handle intensive calculations and parallel processing tasks with ease, contributing to faster results and improved research outcomes.

Artificial Intelligence and Machine Learning

The processor’s parallel processing power and support for advanced instruction sets, including Intel Deep Learning Boost, make it suitable for artificial intelligence and machine learning applications. It accelerates training and inference processes, helping organizations develop and deploy AI models more effectively and efficiently.

Cost-Effective and Future-Proof Solution

Offering a competitive balance of performance, security, and energy efficiency, the Intel Xeon Gold 6212U represents a cost-effective and future-proof solution for businesses. Its scalability and advanced features ensure that it can meet the demands of evolving IT environments, providing lasting value and reliability for years to come.
