Intel CD8069504284604 Xeon Gold 6238M 22 Core 2.10GHz Processor

Intel CD8069504284604 Xeon Processor

The Intel CD8069504284604 Xeon Gold 6238M processor is a cutting-edge solution designed to meet the demanding needs of enterprise servers and high-performance computing environments. With 22 cores operating at a base clock speed of 2.10 GHz, this processor is engineered to deliver exceptional performance and reliability. As part of Intel's Xeon Gold series, the 6238M offers advanced features and enhancements, making it a top choice for data centers, virtualization, and large-scale applications.

Intel Xeon Processor CD8069504284604 Specifications

Overview

• Part Number: CD8069504284604
• Socket Type: LGA 3647
• Processor Type: Server
• Series: Xeon Gold
• Family: 2nd Generation Intel Xeon Scalable Processors
• Code Name: Cascade Lake
• Manufacturing Technology: 14 nm

Performance Details

• Number of Cores: 22 cores
• Thread Count: 44 threads
• Base Clock Frequency: 2.10 GHz
• L3 Cache Capacity: 30.25 MB
• Thermal Design Power (TDP): 140 Watts

Memory Specifications

• Maximum Supported Memory: 1 TB
• Memory Types: DDR4-2933
• Maximum Memory Speed: 2933 MHz
• Number of Memory Channels: 6
• ECC Memory Support: Yes
• Intel Optane DC Persistent Memory Support: Yes

Package and Dimensions

• CPU Socket Type: LGA 3647
• Package Size: 76.0 mm x 56.5 mm
• Maximum Case Temperature: 92°C
• Embedded Options: Not available

Scalability and Expansion Options

• Scalability: 4S
• PCI Express Revision: 3.0
• Maximum PCI Express Lanes: 48

Advanced Features

• Enhanced Intel SpeedStep Technology: Yes
• Intel 64 Technology: Yes
• Intel Deep Learning Boost (Intel DL Boost): Yes
• Intel Resource Director Technology (Intel RDT): Yes
• Intel Speed Shift Technology: Yes
• Intel Transactional Synchronization Extensions: Yes
• Intel Turbo Boost Technology 2.0: Yes
• Intel Virtualization Technology (VT-x): Yes
• Intel Virtualization Technology for Directed I/O (VT-d): Yes
• Intel Volume Management Device (VMD): Yes
• Intel vPro Platform Eligibility: Yes
• Intel VT-x with Extended Page Tables (EPT): Yes
• Number of AVX-512 FMA Units: 2
• Instruction Set Extensions: Intel SSE4.2, Intel AVX, Intel AVX2, Intel AVX-512

Security and Reliability Features

• Execute Disable Bit: Yes
• Intel AES New Instructions: Yes
• Intel Run Sure Technology: Yes
• Intel Trusted Execution Technology: Yes
• Mode-based Execute Control (MBE): Yes

Key Features of the Intel CD8069504284604 Xeon Gold 6238M

High Core Count and Clock Speed

The Xeon Gold 6238M features an impressive 22 cores, providing substantial processing power for multi-threaded workloads. Each core operates at a base clock speed of 2.10 GHz, ensuring that the processor can handle a wide range of tasks efficiently. This high core count is ideal for environments that require parallel processing and multitasking capabilities, such as data analysis, virtualization, and scientific computing.

Advanced Cascade Lake Architecture

Built on Intel's Cascade Lake architecture, the Xeon Gold 6238M includes several technological advancements over previous generations. This architecture supports Intel Turbo Boost Technology, which allows the processor to dynamically increase its clock speed to meet demanding performance needs. Additionally, Cascade Lake introduces enhanced memory and storage capabilities, improving overall system efficiency and performance.

Large Cache for Enhanced Performance

The Xeon Gold 6238M is equipped with a large 30.25 MB L3 cache, which helps to reduce data access times and improve system performance. The sizeable cache stores frequently accessed data closer to the processor, allowing for faster retrieval and processing. This feature is particularly beneficial for applications that handle large volumes of data and require quick access to information.

Robust Security Features

Security is a critical concern in enterprise environments, and the Xeon Gold 6238M incorporates advanced security features to protect sensitive information. Technologies such as Intel Total Memory Encryption (TME) and Intel Software Guard Extensions (SGX) provide strong data protection and safeguard against unauthorized access. These features ensure that data remains secure during processing and storage, enhancing overall system integrity.

Energy Efficiency and Thermal Management

Designed with energy efficiency in mind, the Xeon Gold 6238M balances performance and power consumption to optimize operational costs. The processor has a thermal design power (TDP) of 150 watts, which helps manage heat dissipation and maintain stable operation. Advanced thermal management technologies are employed to prevent overheating and ensure reliable performance under heavy workloads.

Benefits of the Intel CD8069504284604 Xeon Gold 6238M Processor

Exceptional Performance for Virtualization

For virtualization environments, the Xeon Gold 6238M offers superior performance with its high core count and advanced architecture. The processor efficiently handles multiple virtual machines (VMs), providing smooth operation and optimal resource allocation. This capability is crucial for data centers and enterprises that rely on virtualization for cloud services, server consolidation, and application hosting.

Optimized for Data-Intensive Applications

The Xeon Gold 6238M is well-suited for data-intensive applications, such as big data analytics, scientific research, and large-scale databases. Its powerful processing capabilities and large cache allow for rapid data processing and analysis, improving overall system responsiveness and reducing the time required to derive insights from complex datasets.

Scalability for Expanding Business Needs

Scalability is a key feature of the Xeon Gold 6238M, making it adaptable to growing business requirements. Its compatibility with various server motherboards and support for multi-processor configurations provide flexibility for expanding server infrastructures. This scalability ensures that organizations can manage increasing workloads effectively while maintaining high performance levels.

Applications and Use Cases

Enterprise Server Solutions

The Intel Xeon Gold 6238M is an ideal choice for enterprise servers that require high performance and reliability. Its robust multi-core processing capabilities make it suitable for running critical business applications, including enterprise resource planning (ERP) systems, customer relationship management (CRM) software, and other essential enterprise tools.

Data Center Operations

In data center environments, the Xeon Gold 6238M excels at managing large-scale virtualization and cloud computing tasks. Its high core count and scalable architecture support efficient management of virtualized environments and high-density server configurations, ensuring optimal performance for data processing and application hosting.

High-Performance Computing (HPC)

The Xeon Gold 6238M is well-suited for high-performance computing (HPC) applications, including scientific simulations, engineering analysis, and complex data modeling. Its advanced architecture and large cache support demanding computational tasks, providing accurate and timely results for HPC environments.

Compatibility and Integration

Motherboard Compatibility

The Intel CD8069504284604 Xeon Gold 6238M is compatible with motherboards that feature the FCLGA3647 socket type. It is essential to ensure that the motherboard supports this socket type to achieve optimal performance and compatibility. Verifying motherboard compatibility will help avoid issues during installation and ensure seamless integration into the server system.

Cooling Solutions

Given the processor’s thermal design power (TDP) of 150 watts, effective cooling solutions are crucial for maintaining stable operation. High-performance heatsinks and cooling fans are recommended to manage heat dissipation and prevent overheating. Proper cooling helps ensure the processor operates within safe temperature limits and maintains optimal performance during demanding tasks.

System Memory Requirements

The Intel Xeon Gold 6238M supports DDR4 memory, which is essential for maximizing the processor’s performance. Using high-quality system memory that meets the processor’s specifications is important for achieving efficient data handling and system stability. Ensure that the memory modules are compatible with the motherboard and processor to optimize overall system performance.

Comparative Advantages

Comparison with Previous Generations

Compared to its predecessors, the Xeon Gold 6238M offers significant performance improvements due to its higher core count and advanced Cascade Lake architecture. The inclusion of technologies such as Intel Turbo Boost Technology and enhanced memory capabilities results in better overall performance and efficiency for a wide range of applications.

Comparison with Other Xeon Gold Models

When compared to other models within the Xeon Gold series, the 6238M stands out with its 22-core configuration and substantial L3 cache size. This makes it particularly advantageous for applications that require extensive multitasking and data processing. Its balance of core count, clock speed, and cache size positions it as a versatile choice for various enterprise and data center environments.
