Cisco C8300-2N2S-6T Gigabit Ethernet 1GBPS 6 Ports Router

Overview of Cisco C8300-2N2S-6T 6 Ports Router

Manufacturer Details

• Brand: Cisco
• Part Number: C8300-2N2S-6T
• Product Type: 6 Ports Router
• Series: 8300

Core Features

• Enclosure: 2U Rack-Mountable
• Connectivity: Wired, Gigabit Ethernet
• Data Link Protocol: Gigabit Ethernet

Performance Metrics

• SD-WAN IPSec Throughput:
  • 1400 Bytes (Clear Text): Up to 1.9 Gbps
  • IMIX (Clear Text): 1.75 Gbps
• IPv4 Forwarding Throughput: 19.7 Gbps (1400-byte Packet Size)
• IPSec Throughput: Up to 1.9 Gbps (1400 Bytes, Clear Text)

Capacity Specifications

• SD-WAN Overlay Tunnels: 6000
• IPSec SVTI Tunnels: 4000
• ACL Entries: 4000
• IPv4 Routes: 1,600,000
• IPv6 Routes: 1,500,000
• Queues: 16,000
• NAT Sessions: 1,200,000
• Firewall Sessions: 512,000
• VRF Entries: 4000

Networking Protocols

• Network/Transport Protocols:
  • RSVP, NTP, IPSec, PPPoE, DHCP, DNS
  • L2TPv3, RTP, RTCP, IPv4, IPv6
• Routing Protocols:
  • OSPF, IS-IS, RIP-1, RIP-2, BGP, EIGRP
  • HSRP, DVMRP, VRRP, PIM-SM, Static IP Routing
  • IGMPv3, GRE, OSPFv3, PIM-SSM, Policy-Based Routing (PBR)
  • MPLS, Bidirectional Forwarding Detection (BFD)
  • RSVP, LISP

Management and Security

• Remote Management Protocols: SNMP, SSH, CLI, SCP, NETCONF, NTP, DHCP, RADIUS, OMP
• Encryption Methods:
  • DES, Triple DES, SHA, MD5, IKE, SSL, TLS
  • SHA-1, PKI, 128-bit AES, 256-bit AES, SHA-2
  • DTLS, RSA (1024-bit, 2048-bit, 748-bit), ECDSA (256-bit, 384-bit)
  • HMAC, ESP, 256-bit AES-GCM, 256-bit AES-CBC, 512-bit SHA
• Authentication Methods: Secure Shell (SSH), RADIUS

Advanced Features

• Firewall Protection
• NAT and PAT Support
• Syslog and QoS Support
• Class-Based Weighted Fair Queuing (CBWFQ)
• Weighted Random Early Detection (WRED)
• Access Control List (ACL) Support
• DHCP Server and Client
• Network-based Application Recognition (NBAR)
• Flexible NetFlow (FNF) and Application Visibility and Control (AVC)
• Point-to-Point Protocol (PPP) and High-Level Data Link Control (HDLC)

Compliance Standards

• IEEE 802.1Q, IEEE 802.3ah, IEEE 802.1ag
• EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3
• FCC CFR47 Part 15 B Class A, FDA, UL 60950-1
• CNS 13438 Class A, IEC 60950-1, EN 60950-1

Hardware Specifications

• Processor: Intel
• RAM: 8 GB (Installed) / 32 GB (Max)
• Flash Memory: 8 GB
• Hard Drive: 16 GB

VoIP and Expansion

• VoIP Protocols: SIP, SRTP
• Interfaces: 6 x 1000Base-T, 1 x USB
• Expansion Slots:
  • 2 x Service Module (SM) Slots
  • 2 x NIM Slots
  • 1 x Pluggable Interface Module (PIM) Slot
• Installed Modules: 0 (Installed) / 5 (Max)

Power Specifications

• Power Device: Internal Power Supply

Ports

The Cisco C8300-2N2S-6T Router is equipped with six ports, making it a versatile and powerful networking device. These ports offer a range of benefits and features that are essential for users in various industries and settings.

Flexible Network Connectivity

With six ports, the Cisco C8300-2N2S-6T Router provides flexible network connectivity options. Users can connect multiple devices simultaneously, such as computers, printers, servers, and other networking equipment. This allows for efficient data transfer and seamless communication between devices within the network.

Increased Bandwidth

The six ports on the Cisco C8300-2N2S-6T Router ensure increased bandwidth availability. This means that users can enjoy faster data transfer speeds and reduced latency. Whether you are streaming high-definition videos, transferring large files, or running bandwidth-intensive applications, the ample bandwidth provided by these ports ensures a smooth and uninterrupted experience.

Improved Network Performance

By distributing network traffic across multiple ports, the Cisco C8300-2N2S-6T Router enhances network performance. This feature prevents bottlenecks and congestion that can occur when multiple devices compete for limited network resources. As a result, users can enjoy optimized network performance, reduced downtime, and improved productivity.

Scalability and Future-Proofing

The presence of six ports on the Cisco C8300-2N2S-6T Router offers scalability and future-proofing capabilities. As your network requirements grow, you can easily connect additional devices without the need for external switches or routers. This scalability ensures that your network infrastructure can adapt to evolving business needs, saving you time and money in the long run.

Speed

The Cisco C8300-2N2S-6T Router boasts a blazing-fast speed of 1GBPS, which is a significant advantage for users requiring high-speed data transfer and reliable connectivity.

Fast Data Transfer

With a speed of 1GBPS, the Cisco C8300-2N2S-6T Router allows for lightning-fast data transfer. Whether you are sharing files, streaming media, or conducting video conferences, this router ensures that your data is transmitted swiftly and efficiently. This speed is ideal for businesses that rely on quick and reliable communication, enabling seamless collaboration and productivity.

Reduced Latency

The high-speed connection offered by the Cisco C8300-2N2S-6T Router results in reduced latency. Latency refers to the delay in data transmission between devices. With lower latency, users can experience real-time interactions with minimal delays. This is particularly important for online gaming, video conferencing, and other applications that require instant responsiveness.

Support for Bandwidth-Intensive Applications

The 1GBPS speed provided by the Cisco C8300-2N2S-6T Router ensures seamless support for bandwidth-intensive applications. Whether you are running cloud-based services, hosting virtual meetings, or utilizing resource-heavy software, this router can handle the demands of such applications without compromising performance. Users can enjoy uninterrupted access to critical resources and services.

Future-Proof Investment

The 1GBPS speed of the Cisco C8300-2N2S-6T Router ensures that it is a future-proof investment. As internet speeds continue to increase, this router can keep up with evolving technology demands. By investing in a high-speed router like the Cisco C8300-2N2S-6T, users can avoid the need for frequent upgrades and ensure their network infrastructure remains up to date.

Interface

The Cisco C8300-2N2S-6T Router features Gigabit Ethernet interfaces, providing users with a reliable and high-performance network connection.

Fast and Reliable Connectivity

Gigabit Ethernet interfaces offer fast and reliable connectivity, ensuring that data is transmitted efficiently and accurately. The Cisco C8300-2N2S-6T Router's Gigabit Ethernet interfaces support data transfer rates of up to 1000 Mbps, providing users with a stable and high-speed connection for their networking needs.

Seamless Integration

With Gigabit Ethernet interfaces, the Cisco C8300-2N2S-6T Router seamlessly integrates into existing network infrastructures. These interfaces are compatible with various networking devices, such as switches, modems, and other routers. Users can connect their devices effortlessly, allowing for easy expansion and integration of the router into their network environment.

Enhanced Network Performance

The Gigabit Ethernet interfaces on the Cisco C8300-2N2S-6T Router contribute to enhanced network performance. Users can experience reduced latency, improved data transfer speeds, and optimized overall network efficiency. This feature is crucial for businesses that rely on consistent and reliable network performance to ensure smooth operations and productivity.

Secure Data Transfer

Gigabit Ethernet interfaces offer secure data transfer capabilities. The Cisco C8300-2N2S-6T Router supports advanced security protocols that protect sensitive data from unauthorized access or interception. With secure data transfer, users can have peace of mind knowing that their information remains confidential and protected from potential threats.
