Cisco Catalyst WS-C2960X-48TD-L Managed Switch, 48 Ports

Ports

The Cisco WS-C2960X-48TD-L Managed Switch is equipped with an impressive 48 ports, making it an ideal choice for businesses and organizations with high network connectivity needs. Each of these ports provides fast and reliable Ethernet connectivity, allowing users to connect multiple devices to the network simultaneously.

Key Specifications of the WS-C2960X-48TD-L

• Manufacturer: Cisco
• Part Number: WS-C2960X-48TD-L
• Type: Managed Switch with 48 Ports
• Form Factor: Desktop and Rack-mountable 1U

Connectivity

• Interface: Gigabit Ethernet
• Ports: 48 x 10/100/1000 Ethernet + 2 x 10 Gigabit SFP+

Performance Metrics

• Switching Capacity: 216 Gbps
• Forwarding Performance: 130.9 Mpps (64-byte packet size)

Capacity & Management

• Virtual Interfaces (VLANs): Up to 1023
• Jumbo Frame Support: Up to 9216 bytes
• Management Protocols: SNMP (v1, v2c, v3), RMON (v1, v2), Telnet, HTTP, TFTP, SSH, CLI

Advanced Features

• Layer 2 Switching: Yes
• DHCP Support: Yes
• Auto-Negotiation: Yes
• ARP Support: Yes
• Trunking: Yes
• VLAN Support: Yes
• Auto-Uplink: Auto MDI/MDI-X
• IPv6 Support: Yes
• Rapid Spanning Tree Protocol (RSTP): Yes
• Multiple Spanning Tree Protocol (MSTP): Yes
• Dynamic Trunking Protocol (DTP): Yes
• Port Aggregation Protocol (PAgP): Yes
• Trivial File Transfer Protocol (TFTP): Yes
• Access Control List (ACL) Support: Yes
• RADIUS Support: Yes
• Jumbo Frames Support: Yes
• MLD Snooping: Yes
• Dynamic ARP Inspection (DAI): Yes
• Cisco EnergyWise Technology: Yes
• Unicast Reverse Path Forwarding (URPF): Yes
• Uni-Directional Link Detection (UDLD): Yes
• Rapid Per-VLAN Spanning Tree Plus (PVRST+): Yes
• IPv4 Support: Yes
• Shaped Round Robin (SRR): Yes
• Link Aggregation Control Protocol (LACP): Yes
• Remote Switch Port Analyzer (RSPAN): Yes
• NetFlow: Yes
• Hot Standby Router Protocol (HSRP): Yes
• Energy Efficient Ethernet: Yes

Compliance Standards

• IEEE 802.3: Standard Ethernet
• IEEE 802.3u: Fast Ethernet
• IEEE 802.3z: Gigabit Ethernet
• IEEE 802.1d: Spanning Tree Protocol
• IEEE 802.1q: VLAN Tagging
• IEEE 802.3ab: Gigabit Ethernet over copper
• IEEE 802.1p: Class of Service
• IEEE 802.3x: Flow Control
• IEEE 802.3ad (LACP): Link Aggregation
• IEEE 802.1w: Rapid Spanning Tree Protocol
• IEEE 802.1x: Port-Based Network Access Control
• IEEE 802.3ae: 10 Gigabit Ethernet
• IEEE 802.1ae: MACsec
• IEEE 802.3az: Energy Efficient Ethernet
• IEEE 802.1ax: Link Aggregation

Power Specifications

• Input Voltage: AC 120/230 V (50/60 Hz)
• Power Redundancy: Optional

Enhanced Network Flexibility

With 48 ports, this Cisco-managed switch offers enhanced network flexibility, enabling businesses to connect a multitude of devices to their network infrastructure. Whether it's computers, printers, IP phones, surveillance cameras, or any other network-enabled device, this switch ensures that you can connect them all. This flexibility is particularly crucial for growing organizations that need to accommodate an expanding number of devices in their network environment.

Improved Network Performance

The abundance of ports on the Cisco WS-C2960X-48TD-L Managed Switch translates into improved network performance. With more ports available, the switch can handle higher traffic volumes without experiencing congestion or slowdowns. This is especially vital in environments where data-intensive applications or multimedia content is frequently transmitted over the network. The switch's ability to handle heavy traffic ensures that your network operates smoothly even during peak usage periods. It minimizes latency and packet loss, ensuring that users can access resources and communicate seamlessly. This is particularly important for businesses that heavily rely on real-time applications, such as video conferencing or VoIP services.

Simplified Network Management

Managing a network with numerous devices can be challenging, especially when it comes to troubleshooting or making configuration changes. The Cisco WS-C2960X-48TD-L Managed Switch simplifies network management by providing a dedicated port for management purposes. This allows administrators to easily access the switch's management interface without interrupting the normal operation of other ports. Furthermore, this managed switch supports advanced features like VLANs (Virtual Local Area Networks) and QoS (Quality of Service), which can be configured on a per-port basis. VLANs enable network segmentation, enhancing security and improving performance by separating traffic into logical groups. QoS, on the other hand, prioritizes certain types of traffic, ensuring that critical applications receive the necessary bandwidth for optimal performance.

Scalability and Future-Proofing

Investing in a switch with 48 ports ensures scalability and future-proofing for your network infrastructure. Having ample ports available means that you won't need to invest in additional switches or hardware shortly as your organization grows. This not only saves you money but also simplifies network management by reducing the number of devices to monitor and maintain. Moreover, the Cisco WS-C2960X-48TD-L Managed Switch supports uplink modules, allowing you to connect it to other switches or network devices using high-speed fiber connections. This gives you the flexibility to expand your network beyond the limitations of traditional Ethernet connections, providing higher bandwidth and longer reach.

Cost-Effectiveness

While a switch with 48 ports may seem like overkill for some small businesses, it offers long-term cost-effectiveness. By investing in a switch with ample ports upfront, you eliminate the need for frequent hardware upgrades or additional purchases down the line. This ensures that your network can accommodate future growth without requiring significant investments in infrastructure. Additionally, the Cisco WS-C2960X-48TD-L Managed Switch is built with energy efficiency in mind. It incorporates advanced features like Cisco EnergyWise technology, which allows you to monitor and control power consumption across your network devices. By optimizing power usage, this switch helps reduce operational costs and contributes to a greener and more sustainable environment.

In conclusion, the 48 ports featured in the Cisco WS-C2960X-48TD-L Managed Switch offer enhanced network flexibility, improved performance, simplified management, scalability, and cost-effectiveness. Whether you are a small business looking to accommodate future growth or a large organization with demanding network requirements, this switch provides the necessary connectivity to meet your needs. Experience the benefits of a robust and reliable network infrastructure with the Cisco WS-C2960X-48TD-L Managed Switch.
