Cisco CBS350-48T-4G L3 Managed Switch SFP Supported Modular 48 Ports

CBS350-48T-4G
Hover on image to enlarge

Brief Overview of CBS350-48T-4G

Cisco CBS350-48T-4G 48 Ports L3 Managed Switch SFP Supported Modular. Excellent Refurbished with 6-Month Replacement Warranty
QR Code of Cisco CBS350-48T-4G L3 Managed Switch SFP Supported Modular 48 Ports
$457.65
$325.00
You save: $132.65 (29%)
Ask a question
180 days
+
Quote
Additional 7% discount at checkout
SKU/MPNCBS350-48T-4GAvailability✅ In StockProcessing TimeUsually ships same day ManufacturerCisco Product/Item ConditionExcellent Refurbished ServerOrbit Replacement WarrantySix-Month (180 Days)
Our Advantages
  • Free Ground Shipping
  • — Min. 6-month Replacement Warranty
  • — Genuine/Authentic Products
  • — Easy Return and Exchange
  • — Different Payment Methods
  • — Best Price
  • — We Guarantee Price Matching
  • — Tax-Exempt Facilities
  • — 24/7 Live Chat, Phone Support
Payment Options
  • — Visa, MasterCard, Discover, and Amex
  • — JCB, Diners Club, UnionPay
  • — PayPal, ACH/Wire Transfer
  • — Apple Pay, Amazon Pay, Google Pay
  • — Buy Now, Pay Later - Affirm, Afterpay
  • — GOV/EDU/Institutions PO's Accepted
  • — Invoices
Delivery
  • — Deliver Anywhere
  • — Express Delivery in the USA and Worldwide
  • — Ship to -APO -FPO
  • For USA - Free Ground Shipping
  • — Worldwide - from $30

Same product also available in:

Description

Cisco CBS350-48T-4G 48-Port Managed Ethernet Switch Overview

General Information

  • Brand: Cisco
  • Model Number: CBS350-48T-4G
  • Product Line: Catalyst 350 Series
  • Type: Managed Ethernet Switch

Technical Specifications

Port and Performance Details

  • Total Ports: 48 Gigabit Ethernet ports
  • Port Configuration: 48 x 10/100/1000 Mbps + 4 x SFP
  • Switching Capacity: 104 Gbps
  • Forwarding Rate: 77.38 Mpps (for 64-byte packets)
  • Buffer Size: 3 MB
  • MAC Address Table: 16,000 entries
  • Jumbo Frame Support: Up to 2 KB
  • Max Stackable Units: 4

Capacity and Configuration

  • RPVST+ Instances: 126
  • MSTP Instances: 8
  • VLANs Supported: Up to 4,094
  • ACL Rules: 1,024

Routing and Management Features

Supported Routing Protocols

  • IGMPv2, IGMPv3
  • Static IPv4 and IPv6 Routing
  • Policy-Based Routing (PBR)
  • MLDv2, MLD
  • CIDR, MSTP, RSTP, STP

Management and Remote Protocols

  • SNMP (v1, v2c, v3)
  • RMON, Telnet, HTTP, HTTPS
  • TFTP, SSH, CLI, SCP
  • ICMP, DHCP, TACACS+, RADIUS
  • SSL Encryption

Advanced Features

  • Flow Control, BOOTP, ARP Support
  • VLAN and IPv6 Support
  • DoS Attack Prevention, QoS
  • Dynamic ARP Inspection (DAI), Broadcast Storm Control
  • Link Aggregation Group (LAG), STP Root Guard
  • Multicast Storm Control, Cable Testing
  • SmartPort Technology, Dual Image Support
  • Private VLAN Edge (PVE), LLDP-MED

Compliance and Standards

  • IEEE 802.3, 802.3u, 802.3z, 802.1D, 802.1Q, 802.3ab
  • 802.1p, 802.3x, 802.3ad (LACP), 802.1w, 802.1x
  • 802.3ae, 802.1s, 802.1ab (LLDP), 802.3an, 802.3az
  • UL 60950, CSA 22.2, FCC CFR47 Part 15 B Class A, USGv6

Hardware Specifications

Processor and Memory

  • Processor: ARM 800 MHz
  • RAM: 512 MB
  • Flash Memory: 256 MB

Indicators and Power

  • Status Indicators: Status, Link/Activity/Speed
  • Power Supply: Internal
  • Required Voltage: AC 120/230 V (50/60 Hz)
  • Power Consumption: 48.64 Watts

Environmental Parameters

  • Operating Temperature Range: 23 °F to 122 °F
  • Storage Temperature Range: -13 °F to 158 °F
  • Operating Humidity: 10 – 90% (non-condensing)
  • Storage Humidity: 10 – 90% (non-condensing)

Ports

The Cisco CBS350-48T-4G L3 Managed Switch is equipped with an impressive 48 ports, making it an ideal choice for businesses that require a high-density network infrastructure. These ports allow for seamless connectivity and efficient data transfer between devices, ensuring smooth and reliable communication within your network.

Increased Connectivity

With 48 ports, this switch offers a significant increase in connectivity options compared to switches with fewer ports. This allows you to connect a larger number of devices directly to the switch, eliminating the need for additional networking equipment such as hubs or cascading switches. The increased connectivity provided by the Cisco CBS350-48T-4G L3 Managed Switch simplifies network management and reduces complexity.

Scalability

The abundance of ports on the Cisco CBS350-48T-4G L3 Managed Switch provides scalability for growing businesses. As your organization expands, you can easily add more devices without worrying about running out of available ports. This scalability ensures that your network can accommodate future growth and adapt to changing business needs.

Improved Performance

Having multiple ports on the switch enhances network performance by reducing congestion and improving data transfer speeds. Each device connected to an individual port has dedicated bandwidth, allowing for efficient data transmission without bottlenecks. This results in faster response times, reduced latency, and improved overall network performance.

SFP Supported

The Cisco CBS350-48T-4G L3 Managed Switch supports one Small Form-Factor Pluggable (SFP) port, which provides additional flexibility for your network infrastructure. This feature allows you to connect the switch to other networking devices using fiber-optic cables or copper cables with SFP modules.

Flexibility in Network Design

By supporting SFP, the Cisco CBS350-48T-4G L3 Managed Switch enables you to design your network in a way that best suits your requirements. You can connect the switch to other switches, routers, or servers located at longer distances using fiber-optic cables. Additionally, the SFP port allows for the use of different types of SFP modules, including multi-mode or single-mode fiber modules, giving you the freedom to choose the most appropriate media for your network.

Extended Reach

The SFP port on the Cisco CBS350-48T-4G L3 Managed Switch extends the reach of your network by enabling connections over longer distances. This is particularly beneficial for businesses with multiple buildings or locations that need to be interconnected. Fiber-optic cables used with SFP modules can transmit data over much greater distances without experiencing signal degradation, ensuring reliable and high-speed communication across your network.

Improved Performance and Bandwidth

Utilizing the SFP port allows for higher bandwidth capabilities, which is essential for demanding applications or data-intensive tasks. Fiber-optic cables provide higher data transfer rates and are less susceptible to electromagnetic interference compared to traditional copper cables. This translates into improved network performance, reduced latency, and enhanced reliability.

Modular

The Cisco CBS350-48T-4G L3 Managed Switch features modularity, allowing you to customize and expand your network as needed. The modular design provides flexibility and adaptability, making it easier to manage and upgrade your network infrastructure.

Customizable Network Solutions

With its modular design, the Cisco CBS350-48T-4G L3 Managed Switch enables you to tailor your network solutions to meet specific requirements. You can add or remove modules as needed, ensuring that your network infrastructure aligns with your business needs. This customization empowers you to optimize your network for different applications, such as voice, video, or data transmission.

Ease of Upgrades

The modular nature of the Cisco CBS350-48T-4G L3 Managed Switch simplifies the process of upgrading your network. Instead of replacing the entire switch, you can simply upgrade individual modules to accommodate new technologies or higher performance requirements. This saves time and resources, reducing downtime and minimizing disruption to your network operations.

Future-Proofing

Investing in a modular switch like the Cisco CBS350-48T-4G L3 Managed Switch ensures future-proofing your network infrastructure. As technology evolves and new networking standards emerge, you can easily upgrade specific modules to support these advancements. This scalability and flexibility enable your network to stay up-to-date with the latest technologies, protecting your investment in the long term.

In conclusion, the Cisco CBS350-48T-4G L3 Managed Switch offers an impressive 48 ports, providing increased connectivity, scalability, and improved performance for your network. The SFP support further enhances flexibility, extends reach, and improves performance and bandwidth capabilities. The modular design adds customization options, simplifies upgrades, and future-proofs your network infrastructure. With these features, the Cisco CBS350-48T-4G L3 Managed Switch is a reliable and versatile solution for businesses of all sizes.
