CISCO7609-S Cisco Router Expansion Module - 9 Slots Ports, Rack-mountable

Highlights of Cisco CISCO7609-S Rack-Mountable 9-Slot Router

The Cisco CISCO7609-S is a high-capacity rack-mountable modular chassis router designed for carrier-grade, enterprise backbone, and large-scale service provider networks. With its 9-slot architecture, ultra-high throughput capability, and advanced redundancy features, this 7609-S platform delivers scalable and reliable performance for mission-critical networking environments.

General Information

• Manufacturer: Cisco
• Part Number: CISCO7609-S
• Product Type: Rack-Mountable Chassis Router
• Sub Type: 7609-S 9-Slot Modular Router Chassis

Technical Specifications

Chassis Design & Physical Structure

• Form Factor: 21U rack-mountable modular chassis
• Slot Capacity: 9 total expansion slots
• Dimensions: 36.75 x 17.2 x 20.7 inches
• Weight: Approx. 54.9 kg (chassis only)

Slot Architecture & Expansion Capability

• 9-slot flexible modular design for line cards and supervisors
• Supports multiple high-performance interface configurations
• Optimized for scalable network expansion
• Ideal for high-density routing environments

Performance & System Throughput

• Up to 720 Gbps total system throughput
• Forwarding capacity up to 400 million packets per second (Mpps)
• High-speed packet processing for backbone networks
• Optimized for large enterprise and carrier networks

Network Interface & Connectivity Options

Supported Interface Range

• 10 Mbps Ethernet legacy support
• Fast Ethernet and Gigabit Ethernet ports
• 10 Gigabit Ethernet high-speed interfaces
• OC-192 / STM-64 WAN connectivity support

Service Provider Flexibility

• Multi-service network integration support
• Compatible with diverse WAN technologies
• Scalable interface module architecture

Power System & Cooling Design

Power Supply Options

• Supports -208 to 240 VAC AC input
• Supports -48 to -60 VDC DC input
• Redundant power supply configuration available
• High-efficiency power distribution system

Cooling System

• Front-to-back airflow cooling design
• Vertically mounted line card airflow optimization
• Redundant high-speed fan tray modules
• Stable thermal performance under heavy load

High Availability & Reliability Features

Redundancy Architecture

• Redundant power supply support
• Backup supervisor engine capability
• Hot-swappable fan tray modules
• Designed for zero-downtime operations

Operational Stability

• Carrier-grade system reliability
• Continuous 24/7 mission-critical operation support
• Minimized service interruption risk

Advanced IP Services & Security

Networking Services

• Hardware-accelerated MPLS (VPN, LDP, RSVP-TE)
• Advanced IPv6 routing support
• Quality of Service (QoS) traffic shaping and policing
• High-performance routing optimization features

Security Features

• Integrated Access Control Lists (ACLs)
• VPN encryption support for secure communication
• Built-in firewall capabilities
• Enhanced network protection mechanisms
