IE-4000-4T4P4G-E Cisco Industrial 4000 Series 12 Ports Managed Switch

Cisco IE-4000-4T4P4G-E Industrial Managed Switch Overview

The Cisco IE-4000-4T4P4G-E is a high-performance 12-port industrial managed switch designed for robust network connectivity in harsh environments. Combining reliability, flexibility, and advanced management features, it ensures uninterrupted operations for industrial networks.

Key Product Details

• Manufacturer: Cisco
• Part Number: IE-4000-4T4P4G-E
• Product Type: Managed Switch
• Port Configuration: 12 Ports (4 x 10/100, 4 x 10/100 PoE+, 4 x Combo Gigabit SFP)

Technical Specifications

Device Features

• Din Rail mountable enclosure
• Fast Ethernet and Gigabit combo ports
• Power over Ethernet (PoE+) support
• Virtual interfaces (VLANs): 1000
• IGMP groups support: 1000
• MAC address table capacity: 16k entries
• Static IPv4 routing

Management and Security

• Remote management via SNMPv1/2/3, RMON, Telnet, HTTP, SSH, CLI
• Authentication support: RADIUS, TACACS+
• DHCP snooping and relay, Dynamic ARP Inspection
• Port security and MAC address notification
• Spanning Tree Protocol (STP, RSTP, MSTP)

Advanced Features

• Quality of Service (QoS) and Class of Service (CoS)
• Multicast, broadcast, and unicast storm control
• NAT, BootP, trunking, VLAN support, IGMP snooping
• Resilient Ethernet Protocol (REP) and Flex Link
• Precision Time Protocol (PTP) and NTP synchronization
• Profinet V2, IP source guard, and smartport technology

Standards Compliance

• IEEE standards: 802.3, 802.3u, 802.3z, 802.1d, 802.1q, 802.3ab, 802.1p, 802.3af, 802.3at, 1588v2, 1613
• Electromagnetic and environmental: CISPR 22, EN55024, EN55022, IEC 60068 series
• Industrial certifications: UL 508, IEC 60529 IP30, EN 50121-3-2, ISO 9223
• RoHS, BSMI, VCCI, KN22, China RoHS compliant

Memory and Expansion

• RAM: 512 MB
• Flash memory: 128 MB
• Interfaces: Mini-USB Type B, console RJ-45, SFP and RJ-45 uplinks
• Expansion slot: 1 SD card (1 GB included)

Power Specifications

• Voltage: DC 9.6 – 60 V
• Current: 3.7 A
• Operational power consumption: 35 W

Reliability and Durability

• Mean Time Between Failures (MTBF): 562,300 hours
• Designed for extreme industrial conditions
• Supports long-term continuous operation

Cisco IE-4000-4T4P4G-E Industrial 4000 Series Managed Switch

The Cisco IE-4000-4T4P4G-E represents the pinnacle of industrial networking solutions, designed to provide resilient, high-performance connectivity in demanding environments. As part of the Cisco Industrial Ethernet 4000 Series, this switch is tailored for industries where reliability, security, and long-term availability are critical. Its 12 ports, combining both copper and fiber connectivity options, offer flexibility to integrate seamlessly into existing industrial networks while supporting future growth.

Robust Industrial Design for Harsh Environments

The Cisco IE-4000-4T4P4G-E is engineered for environments where traditional enterprise switches cannot operate efficiently. With a ruggedized form factor, it withstands extreme temperatures, high vibration, and electrical noise, making it suitable for manufacturing plants, oil and gas facilities, transportation systems, and utilities. Its hardened construction ensures uninterrupted network performance even under adverse environmental conditions, maintaining high availability for mission-critical operations.

Temperature and Vibration Resistance

This industrial switch supports a wide operating temperature range, allowing it to function effectively in environments from sub-zero to high-heat conditions. Additionally, it is designed to resist mechanical vibrations and shocks commonly found in industrial and transportation applications. This capability minimizes downtime, ensuring consistent network operation across facilities with demanding physical conditions.

Ingress Protection and Durability

The Cisco IE-4000-4T4P4G-E features an IP-rated enclosure to protect against dust, water, and other contaminants. This ensures that the internal electronics remain operational even in harsh conditions. The durability of the switch reduces the need for frequent maintenance, lowering total cost of ownership and enhancing operational efficiency.

Port Configuration and Network Flexibility

Equipped with a combination of 12 ports, the Cisco IE-4000-4T4P4G-E supports a mix of Gigabit Ethernet copper and fiber connectivity. This allows for flexible deployment scenarios, enabling seamless integration with legacy systems and modern high-speed networks. Its ability to handle both uplink and edge connections provides network architects with extensive design options for scalable industrial networks.

Gigabit Ethernet and Fiber Options

The switch includes 4 Gigabit SFP uplink ports alongside 8 copper RJ-45 ports, offering both high-speed connectivity and reliable data transmission over existing cabling infrastructure. The fiber ports extend network reach and support long-distance connections, critical for sprawling industrial facilities or outdoor applications such as transportation hubs and energy sites.

Power over Ethernet (PoE) Capabilities

PoE support allows the Cisco IE-4000-4T4P4G-E to power devices such as IP cameras, wireless access points, and industrial sensors directly from the switch, eliminating the need for separate power sources. This capability simplifies deployment, reduces cabling complexity, and ensures that connected devices receive uninterrupted power even during transient power conditions.

Advanced Managed Switch Features

The Cisco IE-4000-4T4P4G-E provides comprehensive managed switch capabilities, offering advanced Layer 2 and Layer 3 features that enhance network efficiency, security, and monitoring. Its management features are designed to provide full control over network traffic, allowing administrators to optimize performance and reduce downtime.

Layer 2 and Layer 3 Switching

With full Layer 2 switching and Layer 3 routing capabilities, this industrial switch enables the creation of complex network topologies, including VLAN segmentation, inter-VLAN routing, and dynamic routing protocols. This flexibility ensures that industrial networks can scale efficiently while maintaining high levels of performance and security.

Network Security and Access Control

Security is paramount in industrial networks, and the Cisco IE-4000-4T4P4G-E offers multiple features to safeguard data. These include port-based access control, MAC address filtering, and advanced encryption protocols. Additionally, the switch supports industrial security standards, ensuring protection against unauthorized access, data breaches, and cyber threats specific to industrial environments.

Quality of Service and Traffic Management

To support mission-critical applications, the switch includes robust Quality of Service (QoS) features. Administrators can prioritize time-sensitive traffic such as voice, video, and control signals, ensuring that critical processes maintain low latency and high reliability. Traffic shaping and rate-limiting capabilities further optimize network performance, preventing congestion and packet loss even in high-demand scenarios.

Integration with Industrial IoT and Automation Systems

The Cisco IE-4000-4T4P4G-E is optimized for Industrial Internet of Things (IIoT) and automation systems. Its capabilities allow for seamless integration with SCADA systems, programmable logic controllers (PLCs), sensors, and other connected devices. This integration enhances data visibility, enabling real-time monitoring and control across production lines, energy grids, and transportation networks.

Real-Time Data Monitoring and Analytics

By supporting industrial protocols such as Modbus, PROFINET, and EtherNet/IP, the switch enables real-time data exchange and monitoring. Administrators can collect actionable insights, detect anomalies, and implement predictive maintenance strategies to improve operational efficiency and reduce unplanned downtime.

Seamless Compatibility with Automation Standards

The switch is compatible with a wide range of industrial automation standards, allowing easy integration with existing systems. This interoperability ensures that facilities can adopt the Cisco IE-4000-4T4P4G-E without disrupting current workflows or requiring extensive modifications to network infrastructure.

Redundancy and Reliability for Mission-Critical Networks

Downtime in industrial environments can result in significant operational and financial losses. The Cisco IE-4000-4T4P4G-E addresses this concern through a suite of redundancy and reliability features that maintain continuous network operation even in the event of hardware or link failures.

High Availability and Network Redundancy

The switch supports multiple redundancy protocols, including Rapid Spanning Tree Protocol (RSTP) and Media Redundancy Protocol (MRP), ensuring rapid failover in the event of a network fault. This minimizes service interruptions and maintains continuous connectivity for industrial applications.

Resilient Power Options

With dual power supply support, the Cisco IE-4000-4T4P4G-E can operate with backup power in case of a primary power failure. This ensures uninterrupted operation of critical network devices and connected equipment, further enhancing the switch’s reliability in industrial scenarios.

Management, Monitoring, and Diagnostics

Effective management and monitoring are essential for industrial network operations, and the Cisco IE-4000-4T4P4G-E provides advanced tools for administrators to maintain optimal network performance. Its built-in diagnostics and monitoring capabilities reduce troubleshooting time and enable proactive maintenance strategies.

Web-Based and Command-Line Management

Administrators can configure and monitor the switch using both an intuitive web-based GUI and a comprehensive command-line interface (CLI). These management options provide flexibility for different operational needs and allow for detailed configuration of network parameters, security settings, and performance optimization.

Proactive Monitoring and Alerts

The switch includes features for real-time monitoring and alert generation. SNMP support and logging capabilities allow administrators to detect potential issues early, minimizing the impact on network operations and ensuring a high level of service continuity.

Diagnostic Tools for Troubleshooting

Integrated diagnostic tools provide deep insights into network performance and connected device health. Administrators can quickly identify faulty ports, detect network congestion, and perform loopback tests, enabling rapid resolution of network issues without disrupting operations.

Applications and Use Cases in Industrial Networking

The Cisco IE-4000-4T4P4G-E is widely used across various industries, including manufacturing, transportation, energy, and critical infrastructure. Its ability to operate reliably in harsh conditions while providing advanced networking capabilities makes it an ideal solution for a diverse range of industrial applications.

Manufacturing and Factory Automation

In factory environments, the switch connects production line equipment, robotics, sensors, and control systems. Its high reliability and low-latency communication ensure efficient automation processes, real-time monitoring, and seamless data exchange between devices, improving overall operational efficiency.

Transportation and Rail Systems

Transportation networks benefit from the Cisco IE-4000-4T4P4G-E’s rugged design and long-distance fiber connectivity. It supports reliable communication for signaling systems, passenger information systems, and surveillance networks, ensuring safety and efficiency across railways, subways, and highways.

Energy and Utilities

The switch provides resilient networking for critical energy and utility infrastructure, including power plants, substations, and renewable energy installations. Its ability to maintain high availability in electrically noisy and harsh outdoor environments ensures continuous monitoring and control of essential services.

Oil, Gas, and Chemical Industries

In hazardous environments such as oil refineries and chemical plants, the Cisco IE-4000-4T4P4G-E delivers reliable connectivity under extreme temperature, vibration, and exposure conditions. Its industrial-grade construction ensures that critical automation and monitoring systems remain operational without interruption.
