N55-D160L3 Cisco Layer 3 Daughter Card Expansion Module

Overview of the Expansion Module

The N55-D160L3 Cisco Layer 3 Daughter Card Expansion Module is a specialized networking hardware component engineered to extend the routing and switching capabilities of compatible Cisco Nexus systems. Designed for enterprise-grade data centers and high-performance networking environments, this Layer 3 daughter card enhances system intelligence, improves routing efficiency, and enables advanced traffic management features that are essential for modern cloud, virtualization, and high-density workloads.

Main Information

• Brand: Cisco
• Part Number: N55-D160L3
• Product Type: Expansion Module

Key Specifications

• Form Factor: Front-facing plug-in module.
• Forwarding Capacity: Up to 160 Gbps.
• Packet Throughput: 240 million packets per second.
• Network Ports: 2 x 1 Gigabit Ethernet RJ-45.
• Console Management: 1 x RJ-45 Serial Console.
• Auxiliary Management: 1 x RJ-45 AUX port.
• USB Interface: 1 x 4-pin Type A USB.
• Routing Tables (V1): Supports up to 8K host entries.
• Multicast Tables (V1): Supports up to 4K multicast routes.
• Hardware Services: Enterprise-grade VRRP, OSPF, and BGP.

Compatibility

• Primary Switch: Cisco Nexus 5548P.
• Secondary Switch: Cisco Nexus 5548UP.
• Module Trade-off: Replaces the default Layer 2 I/O module (N55-DL2).
• Slot Requirements: Does not consume rear expansion slots.
• Chassis Location: Installs inside the dedicated front slot.
• Port Sharing: Bandwidth is shared across all 48 ports.
• Software Requirement: Operates under Cisco NX-OS Enterprise Services.
• Incompatible Switches: Cannot fit Nexus 5596UP or 5596T chassis.
• Version 2 Differences: The upgraded N55-D160L3-V2 handles 16K host entries.
