Cisco N6004EF-4FEX-10G 24 Ports L3 Managed Switch Chassis

Device Overview

Manufacturer Details

Manufacturer: Cisco Systems, Inc

Part Number: N6004EF-4FEX-10G

Device Characteristics

Type: Managed Switch

Ports: 24 x 40 Gigabit QSFP+

Included Components: 4 x Cisco Nexus 2232PP 10GE Fabric Extender, 64 x 10G SFP+ module (FET-10G)

Form Factor: Rack-mountable, 4U enclosure

Subtype: 40 Gigabit Ethernet

Performance Specifications

Forwarding Capacity

Performance: 7.68 Tbps

Virtual Interfaces and Tables

• VLANs: 4096
• ACL Entries: 4000
• Multicast Entries (IPv4): 8000
• IGMP Snooping Entries: 8000
• VRF Entries: 4000

MAC Address Table Size: 256,000 entries

Jumbo Frame Support: Up to 9216 bytes

Routing Protocols

• BGP-4, RIP-2, BGP
• EIGRP, IGMPv2, HSRP
• VRRP, OSPFv2, PIM-SM
• IGMPv3, EIGRP for IPv6, OSPFv3
• PIM-SSM, Bidirectional PIM, MSDP
• Static IPv4 and IPv6 Routing

Management and Security

• Remote Management: SNMP v1, v2, v3; RMON; Telnet; SSH-2; CLI
• Authentication: RADIUS, TACACS+

Standards Compliance

• IEEE 802.3, IEEE 802.1D, IEEE 802.1Q
• IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP)
• IEEE 802.1w, IEEE 802.3ae, IEEE 802.1s
• IEEE 802.1Qbb, IEEE 802.1Qaz

Expansion and Connectivity

Interface Options

• 24 x 40Gbit LAN QSFP+
• 1 x USB
• 1 x Management Port

Expansion Slots

Total Slots: 8

Available Slots: 6

Installed Modules

Currently Installed: 2

Maximum Capacity: 8

Power Requirements

Power Supply

Type: Internal, Hot-plug

Installed Quantity: 6

Maximum Capacity: 6

Redundancy and Specifications

Redundancy: Yes (N+N)

Power Provided: 1100 Watts

Required Voltage: AC 120/230 V (50/60 Hz)

Ports

The Cisco N6004 Layer 3 Managed Switch Chassis is equipped with an impressive 24 ports, making it an ideal choice for businesses and organizations that require a high level of connectivity. These ports offer numerous benefits and play a crucial role in ensuring seamless communication and data transfer within a network.

Enhanced Connectivity

With its 24 ports, the Cisco N6004 Layer 3 Managed Switch Chassis provides users with enhanced connectivity options. This allows businesses to connect multiple devices, such as servers, computers, and other networking equipment, to the switch without any constraints. The abundance of ports ensures that there is no shortage of connections, enabling efficient data flow across the network.

Scalability

The generous number of ports on the Cisco N6004 Layer 3 Managed Switch Chassis offers scalability, allowing businesses to expand their network infrastructure as their needs grow. This is particularly advantageous for organizations experiencing rapid growth or planning to accommodate future expansion. The switch can easily handle the increased demand for connections without compromising performance or efficiency.

Improved Network Performance

The 24 ports on this switch contribute significantly to improved network performance. Each port can be utilized to connect various devices, enabling simultaneous data transmission and minimizing bottlenecks. With more ports available, businesses can distribute network traffic evenly and avoid congestion issues. As a result, users experience faster data transfer speeds and reduced latency.

Interface

The Cisco N6004 Layer 3 Managed Switch Chassis boasts an impressive interface that supports 10G connectivity. This feature provides users with numerous benefits and plays a vital role in optimizing network performance.

High-Speed Data Transfer

The 10G interface on the Cisco N6004 Layer 3 Managed Switch Chassis facilitates high-speed data transfer between devices connected to the network. With 10 gigabit per second (Gbps) capabilities, this switch can handle large volumes of data without experiencing bottlenecks or delays. This is especially beneficial for businesses that rely on data-intensive applications or transfer large files frequently, as it ensures that data can be transferred swiftly and efficiently.

Future-Proofing

The 10G interface offers future-proofing capabilities for businesses. As technology continues to advance, the demand for high-speed connectivity will only increase. By investing in a switch with a 10G interface, businesses can ensure that their network infrastructure can keep up with emerging trends and technologies. It provides the necessary bandwidth to support new applications, devices, and services that may require higher data transfer speeds.

Reduced Network Congestion

The 10G interface on the Cisco N6004 Layer 3 Managed Switch Chassis helps alleviate network congestion. With its high data transfer speeds, it enables faster communication between devices, reducing the likelihood of traffic congestion within the network. This ensures a smooth and uninterrupted flow of data, enhancing overall network performance and user experience.

SKU

The Cisco N6004 Layer 3 Managed Switch Chassis comes with the SKU N6004EF-4FEX-10G, which offers unique benefits and importance for users.

Compatibility

The SKU N6004EF-4FEX-10G is designed to be compatible with various networking equipment and systems. This compatibility ensures seamless integration with existing infrastructure, minimizing the need for additional hardware investments or complex configuration processes. Users can easily incorporate the switch into their network without experiencing compatibility issues or disruptions.

Flexibility

The SKU N6004EF-4FEX-10G provides users with flexibility in terms of deployment options. Whether it is used in a small office, a data center, or a large enterprise network, this switch can adapt to different environments and network requirements. Its versatility allows businesses to customize their network setup based on their specific needs, ensuring optimal performance and efficiency.

Reliability

The SKU N6004EF-4FEX-10G is known for its reliability and robustness. Cisco, as a trusted networking brand, ensures that their products undergo rigorous testing and adhere to industry standards. This switch is built to withstand heavy workloads and demanding environments, providing users with a reliable networking solution. Its stability and durability contribute to the overall network uptime, minimizing downtime and maximizing productivity.

In conclusion, the Cisco N6004 Layer 3 Managed Switch Chassis offers a range of impressive features that cater to the needs of modern businesses. With its 24 ports, businesses can enjoy enhanced connectivity, scalability, and improved network performance. The 10G interface ensures high-speed data transfer, future-proofing capabilities, and reduced network congestion. Lastly, the SKU N6004EF-4FEX-10G provides compatibility, flexibility, and reliability. All these features combined make the Cisco N6004 Layer 3 Managed Switch Chassis a versatile and dependable networking solution for businesses of all sizes.
