SPA-DSP Cisco Digital Signal Processor

Product Overview of the Cisco Digital Signal Processor Module

The Cisco SPA-DSP Digital Signal Processor is a high-performance voice processing module engineered to enhance IP communications and unified networking environments. Designed for Cisco enterprise platforms, it delivers advanced digital signal processing with reliable voice transcoding, media optimization, and efficient real-time communication handling. Its compact plug-in design, enterprise-grade performance, and seamless integration make it an excellent solution for organizations requiring scalable and dependable voice services.

General Information

• Brand: Cisco
• Model Number: SPA-DSP
• Product Type: Digital Signal Processor (DSP) Module

Technical Specifications

• Single-width, half-height plug-in module
• Pre-installed with 1 GB RAM
• Dimensions: 6.8 × 7.3 × 0.8 inches.
• Lightweight construction with an approximate weight of 11.99 oz (0.75 lbs).

Processing Performance

• Optimized for voice transcoding, transrating, and DTMF interworking.
• Handles up to 600 concurrent voice sessions for enterprise communication.
• Supports data throughput of up to 2 Gbps for efficient media processing.
• Integrated hardware echo cancellation to improve voice clarity.
• Advanced noise reduction and distortion suppression for enhanced call quality.
• Generates and terminates Real-Time Transport Control Protocol (RTCP) traffic for reliable media management.

Compliance Standards

• Complies with CISPR 22 electromagnetic compatibility requirements.
• Certified to CSA C22.2 safety standards.
• Meets EN 60950-1 safety specifications.
• Conforms to EN 300 386 networking EMC requirements.
• Supports AS/NZS 60950 compliance standards.

Compatibility

• Compatible with Cisco ASR 1000 Series routers, including ASR 1001, ASR 1002, ASR 1004, ASR 1006, and ASR 1013.
• Designed to integrate seamlessly with Cisco IP phones, enterprise switches, and Session Border Controllers (SBCs).
