Cisco WS-C2960X-48FPS-L Catalyst 2960x-48fps-l Managed Switch

Ports

The Cisco Catalyst 2960x-48fps-l Managed Switch is equipped with an impressive 48 ports, making it an ideal choice for businesses and organizations that require a high-density network solution. With this many ports, users have the flexibility to connect numerous devices to their network infrastructure, ensuring smooth and uninterrupted data flow.

WS-C2960X-48FPS-L Overview

Device Specifications

• Type: Managed Switch with 48 Ports, Stackable
• Form Factor: Desktop and Rack-Mountable 1U
• Port Configuration: 48 x 10/100/1000 (PoE+), 4 x Gigabit SFP

Power and Performance

• Power Over Ethernet (PoE): PoE+
• Power Budget: 740 Watts
• Switching Capacity: 216 Gbps
• Forwarding Performance: 107.1 Mpps (64-byte Packet Size)

Capacity and Interfaces

• Virtual LANs (VLANs): Supports up to 1023
• Jumbo Frame Size: 9216 bytes
• Remote Management Protocols: SNMP v1/v2c/v3, RMON (1, 2, 3, 9), Telnet, HTTP, TFTP, SSH, CLI

Advanced Features

• Layer 2 Switching Capabilities
• DHCP Support
• Auto-Negotiation and ARP Support
• VLAN Support and Auto-Uplink (Auto MDI/MDI-X)
• IGMP Snooping and Intrusion Detection System (IDS)
• IPv6 and IPv4 Support
• Rapid Spanning Tree Protocol (RSTP) and Multiple Spanning Tree Protocol (MSTP)
• Dynamic Trunking Protocol (DTP) and Port Aggregation Protocol (PAgP)
• Trivial File Transfer Protocol (TFTP) and Access Control List (ACL) Support
• RADIUS and SSH Support
• Jumbo Frames Support and MLD Snooping
• Dynamic ARP Inspection (DAI) and CISCO EnergyWise Technology
• Unicast Reverse Path Forwarding (URPF) and Uni-Directional Link Detection (UDLD)
• Rapid Per-VLAN Spanning Tree Plus (PVRST+)
• Shaped Round Robin (SRR) and Link Aggregation Control Protocol (LACP)
• MAC Address Notification and Remote Switch Port Analyzer (RSPAN)
• NetFlow and Hot Standby Router Protocol (HSRP)
• Energy Efficient Ethernet and Multicast VLAN Registration (MVR)
• Class Of Service (CoS) and CISCO FlexStack Plus

Standards Compliance

• IEEE 802.3 Series: 802.3, 802.3u, 802.3z, 802.3ab, 802.3ae, 802.3at, 802.3az
• IEEE 802.1 Series: 802.1d, 802.1q, 802.1p, 802.1x, 802.1w, 802.1s, 802.1ae, 802.1ab (LLDP)
• IEEE 802.3ad (LACP)

Power Requirements

• Input Voltage: AC 120/230 V (50/60 Hz)
• Power Redundancy: Optional

Increased Connectivity

One of the primary benefits of having 48 ports on the Cisco Catalyst 2960x-48fps-l Managed Switch is the increased connectivity it provides. Whether you need to connect computers, printers, servers, or other network devices, this switch has you covered. The abundance of ports allows for easy expansion and growth of your network as your business or organization evolves.

Scalability

Scalability is crucial in today's fast-paced business environment. With the Cisco Catalyst 2960x-48fps-l Managed Switch's 48 ports, you can easily scale your network infrastructure to accommodate the growing demands of your organization. This switch provides the flexibility to add more devices without sacrificing performance or causing network congestion.

Efficiency

With 48 ports at your disposal, you can eliminate the need for additional switches or hubs in your network setup. This not only simplifies your network architecture but also reduces power consumption and cabling requirements. By consolidating your network devices into a single switch, you can achieve greater efficiency and cost savings.

Streamlined Management

Managing a large number of devices can be challenging and time-consuming. However, with the Cisco Catalyst 2960x-48fps-l Managed Switch's 48 ports, you can simplify the management process. The switch's intuitive management interface allows for easy configuration and monitoring of all connected devices. Additionally, features like VLAN support and Quality of Service (QoS) ensure optimal performance and prioritization of network traffic.

Flexibility

The 48 ports on the Cisco Catalyst 2960x-48fps-l Managed Switch offer users a high degree of flexibility. You can allocate ports for different purposes, such as connecting workstations, IP phones, access points, or even servers. This flexibility allows you to tailor your network setup to meet the specific needs of your organization, ensuring efficient and reliable connectivity.

Redundancy and High Availability

Having 48 ports on the Cisco Catalyst 2960x-48fps-l Managed Switch also enables redundancy and high availability in your network infrastructure. By connecting devices to multiple ports, you can create redundant paths, ensuring that if one port or link fails, traffic can seamlessly be rerouted through an alternative path. This redundancy minimizes downtime and enhances the overall reliability of your network.

SFP Ports

In addition to its 48 Ethernet ports, the Cisco Catalyst 2960x-48fps-l Managed Switch also features 4 Small Form-Factor Pluggable (SFP) ports. These SFP ports provide users with enhanced flexibility for connecting devices over longer distances or using fiber optic cables.

Extended Reach

The SFP ports on the Cisco Catalyst 2960x-48fps-l Managed Switch allow for extended reach beyond the limitations of traditional Ethernet connections. By utilizing SFP modules, you can connect devices located at far distances or in different areas of your facility without compromising performance. This extended reach is particularly beneficial for organizations with large office spaces or multiple buildings.

Fiber Connectivity

Fiber optic cables offer several advantages over traditional copper cables, including higher bandwidth capabilities and better resistance to electromagnetic interference. With the SFP ports on the Cisco Catalyst 2960x-48fps-l Managed Switch, you can leverage these benefits by connecting devices using fiber optic cables. This is especially useful in environments where high-speed data transmission and reliability are crucial, such as data centers or multimedia production facilities.

Network Expansion

The 4 SFP ports on the Cisco Catalyst 2960x-48fps-l Managed Switch provide users with the ability to expand their network infrastructure. These ports can be used to connect additional switches, routers, or other network devices, allowing for seamless expansion and growth. By leveraging the versatility of SFP modules, you can easily integrate new devices into your existing network architecture.

Interoperability

SFP ports offer interoperability with a wide range of networking equipment. This means that you can connect devices from different manufacturers or utilize various SFP modules based on your specific requirements. The Cisco Catalyst 2960x-48fps-l Managed Switch's SFP ports ensure compatibility and flexibility, enabling you to create a robust and adaptable network environment.

Future-Proofing

Investing in a switch with SFP ports is a future-proofing strategy for your network infrastructure. As technology continues to evolve, the demand for higher bandwidth and faster data transmission will increase. By having SFP ports on your switch, you can easily upgrade your network to support these advancements without replacing the entire switch. This scalability ensures that your network remains capable of meeting future demands.

Mounting

The Cisco Catalyst 2960x-48fps-l Managed Switch is designed to be rack-mountable, offering users a convenient and space-saving solution for their network deployment.

Space Efficiency

Rack-mountable switches are a popular choice for organizations looking to maximize their available space. By mounting the Cisco Catalyst 2960x-48fps-l Managed Switch in a standard rack, you can free up valuable floor or desk space, allowing for a more organized and efficient working environment. This is particularly beneficial for data centers, server rooms, or any location where space is limited.

Easy Installation

The rack-mountable design of the Cisco Catalyst 2960x-48fps-l Managed Switch simplifies the installation process. It can be easily mounted in a standard 19-inch rack using the provided mounting brackets. This eliminates the need for additional hardware or complex installation procedures, saving both time and effort.

Improved Cable Management

Rack-mounting the Cisco Catalyst 2960x-48fps-l Managed Switch enables better cable management. With neatly organized cables running through the rack, you can minimize cable clutter and ensure proper airflow within your network infrastructure. This promotes better cooling and reduces the risk of overheating, ultimately enhancing the overall performance and reliability of your network.

Scalability and Flexibility

Rack-mountable switches offer scalability and flexibility when it comes to expanding your network. As your organization grows or your network needs change, you can easily add or replace switches within the rack without disrupting the entire setup. This modular approach allows for seamless integration of new devices and simplifies future maintenance or upgrades.

Centralized Management

Having all your network switches conveniently located in a rack promotes centralized management. You can easily access and monitor all switch ports from a single location, streamlining the configuration and troubleshooting processes. This centralized management improves efficiency, reduces downtime, and enables faster response to network issues.

Physical Security

Rack-mounting the Cisco Catalyst 2960x-48fps-l Managed Switch enhances physical security. By placing the switch in a locked rack or server cabinet, you can prevent unauthorized access or tampering with network equipment. This adds an extra layer of protection to your network infrastructure and helps safeguard sensitive data and resources.

In conclusion, the Cisco Catalyst 2960x-48fps-l Managed Switch's 48 ports, 4 SFP ports, and rack-mountable design offer numerous benefits and importance for users. The abundance of ports ensures increased connectivity, scalability, efficiency, and streamlined management. The SFP ports provide extended reach, fiber connectivity, network expansion, interoperability, and future-proofing capabilities. The rack-mountable design offers space efficiency, easy installation, improved cable management, scalability and flexibility, centralized management, and physical security. Whether you need a reliable network solution for a small office or a large enterprise, the Cisco Catalyst 2960x-48fps-l Managed Switch is a powerful and versatile choice that caters to your specific networking needs.
