Cisco WS-C3550-24PWR-SMI 24 Port Managed Ethernet Switch

Cisco WS-C3550-24PWR-SMI Ethernet Switch Overview

General Information

• Manufacturer: Cisco
• Model Number: WS-C3550-24PWR-SMI
• Product Line: Catalyst
• Series: 3550
• Product Type: Ethernet Switch
• Type: Networking Device

Technical Specifications

Port and Interface Details

• Total Ports: 24
• Fast Ethernet Ports: Yes
• Interfaces:
• 24 x RJ-45 10/100Base-TX LAN
• 1 x RJ-45 Console Management
• Form Factor: Rack-Mountable

Memory and Storage

• RAM: 64 MB
• Flash Memory: 16 MB

Key Features

• Full Duplex Capability
• Uplink Support
• Auto-Sensing Per Device
• IP Routing
• DHCP Support
• Auto-Negotiation
• VLAN Support
• Manageable
• Stackable

Performance Metrics

Connectivity Media

• Category 3 UTP 10Base-T
• Category 4 UTP 10Base-T
• Category 5 UTP 10/100Base-TX

Performance Specifications

• Switching Fabric: 8.8 Gbps
• Forwarding Bandwidth: 4.4 Gbps (Layer 2 and Layer 3)
• Forwarding Rate: 6.6 Mpps for 64-byte Packets

Expansion and Connectivity

Expansion Slots

• Number of Expansion Slots: 2
• Type of Expansion Slots: GBIC
• Modules: Not Included

Network and Communication Details

Address Table

• MAC Addresses: 8K

Power Specifications

Power Device

• Power Supply: Integrated
• Voltage Requirement: AC 120/230 V (50/60 Hz)
• Operational Power Consumption: 525 Watts

Ports

The Cisco WS-C3550-24PWR-SMI Managed Ethernet Switch is equipped with a remarkable 24 ports, making it an excellent choice for businesses that require extensive connectivity options. These ports are a crucial feature that provides users with numerous benefits and play a vital role in ensuring seamless network operations.

Enhanced Connectivity

With 24 ports at your disposal, this Cisco switch offers enhanced connectivity options for your network infrastructure. Whether you have a small office or a large enterprise, the abundance of ports allows you to connect multiple devices simultaneously without any hassle. This capability is particularly beneficial for businesses that require a high number of network connections, such as data centers, call centers, or educational institutions.

Flexible Network Expansion

The 24 ports on the Cisco WS-C3550-24PWR-SMI switch provide flexibility for future network expansion. As your business grows and your network requirements increase, having additional ports readily available ensures that you can easily accommodate new devices, servers, or workstations without the need to invest in additional networking equipment. This scalability helps you save costs and simplifies the process of expanding your network infrastructure.

Improved Network Performance

A larger number of ports translates into improved network performance. By distributing the network load across multiple ports, the switch effectively reduces congestion and minimizes data bottlenecks. This leads to faster data transfer speeds, lower latency, and increased overall network efficiency. With 24 ports at hand, you can ensure that each connected device receives optimal bandwidth and experiences seamless connectivity.

Power over Ethernet (PoE) Capability

The Cisco WS-C3550-24PWR-SMI Managed Ethernet Switch is not only equipped with 24 ports but also features Power over Ethernet (PoE) capability on all these ports. This means that each port is capable of supplying both data and power to compatible devices, eliminating the need for separate power cables or nearby power outlets. This feature is particularly advantageous for devices such as IP phones, wireless access points, or security cameras, as it simplifies installation and reduces cable clutter.

Cost and Space Savings

The inclusion of 24 ports in a single switch offers significant cost and space savings. Rather than investing in multiple switches or networking equipment, you can consolidate your network connections into a single device. This not only reduces the overall hardware costs but also saves valuable rack or office space. Additionally, the Power over Ethernet capability eliminates the need for additional power sources, further reducing costs associated with power infrastructure.

Easy Management and Troubleshooting

Managing a network with 24 ports can be a complex task, but the Cisco WS-C3550-24PWR-SMI Managed Ethernet Switch makes it easier with its comprehensive management features. The switch provides intuitive web-based management interfaces, allowing network administrators to efficiently configure and monitor the device. Additionally, troubleshooting becomes simplified as you can easily identify and isolate issues connected to specific ports, ensuring faster resolution and minimizing downtime.

High Reliability

In critical networking environments, having redundant connections becomes crucial to ensure high availability and reliability. The Cisco WS-C3550-24PWR-SMI switch supports link aggregation and redundant power supply options, providing an additional layer of resilience to your network infrastructure. With 24 ports available, you can establish multiple redundant connections to ensure continuous network operation, minimizing the risk of single points of failure.

In conclusion, the 24 ports featured in the Cisco WS-C3550-24PWR-SMI Managed Ethernet Switch offer enhanced connectivity options, flexibility for future expansion, improved network performance, PoE capability for simplified installation, cost and space savings, easy management and troubleshooting, as well as high reliability. This abundance of ports makes this switch an ideal choice for businesses that require extensive connectivity and seek a reliable and scalable networking solution.
