Cisco WS-C3560CG-8TC-S Catalyst Switch 8 Ports Gigabit Ethernet
- — Free Ground Shipping
- — Min. 6-month Replacement Warranty
- — Genuine/Authentic Products
- — Easy Return and Exchange
- — Different Payment Methods
- — Best Price
- — We Guarantee Price Matching
- — Tax-Exempt Facilities
- — 24/7 Live Chat, Phone Support
- — Visa, MasterCard, Discover, and Amex
- — JCB, Diners Club, UnionPay
- — PayPal, ACH/Wire Transfer
- — Apple Pay, Amazon Pay, Google Pay
- — Buy Now, Pay Later - Affirm, Afterpay
- — GOV/EDU/Institutions PO's Accepted
- — Invoices
- — Deliver Anywhere
- — Express Delivery in the USA and Worldwide
- — Ship to -APO -FPO
- — For USA - Free Ground Shipping
- — Worldwide - from $30
Same product also available in:
SKU/MPN | Warranty | Price | Condition | You save |
---|---|---|---|---|
WS-C3560CG-8TC-S | Six-Month (180 Days) | $155.00 | Excellent Refurbished | You save: $571.30 (79%) |
WS-C3560CG-8TC-S | Six-Month (180 Days) | $690.00 | Factory-Sealed New Retail in Original Box (FSB) | You save: $25,304.39 (97%) |
Ports
The Cisco WS-C3560CG-8TC-S Switch is equipped with 8 ports, making it an ideal choice for small to medium-sized businesses that require a reliable and efficient networking solution. These ports provide connectivity options for various devices such as computers, printers, servers, and IP phones.
WS-C3560CG-8TC-S Overview
Device Specifications
Type and Form Factor
- Device Type: 8-Port Managed Switch
- Enclosure: Desktop Form Factor, 1U Height
Port Configuration
- Ports: 8 x 10/100/1000 Mbps Ethernet Ports
- Additional Ports: 2 x Shared SFP Slots
Performance Metrics
Throughput and Capacity
- Forwarding Performance: 13.2 Mpps (64-byte Packet Size)
- Switching Capacity: 10 Gbps
- Virtual Interfaces (VLANs): Up to 255
- Jumbo Frame Support: 9018 bytes
Networking Protocols and Management
Routing and Management Protocols
- Routing Protocols Supported: OSPF, RIP-1, RIP-2, BGP, OSPFv2, OSPF for IPv6
- Remote Management: SNMP v1, SNMP v2, RMON v1, RMON v2, RMON v3, RMON v9, Telnet, SNMP v3, SNMP v2c, HTTP, CLI
Authentication and Security
- Authentication Methods: Kerberos, Secure Shell (SSH), RADIUS, TACACS+
Advanced Features
Network Management and Security
- DHCP Support: Yes
- Auto-Negotiation: Supported
- BOOTP Support: Yes
- ARP Support: Yes
- VLAN Support: Yes
- Auto-Uplink: Auto MDI/MDI-X
- IGMP Snooping: Supported
- Syslog Support: Yes
- DiffServ Support: Yes
- Broadcast Storm Control: Enabled
- IPv6 Support: Yes
- Multicast Storm Control: Enabled
- Unicast Storm Control: Enabled
- Spanning Tree Protocol (STP) Support: Yes
- DHCP Snooping: Supported
- Dynamic Trunking Protocol (DTP) Support: Yes
- Port Aggregation Protocol (PAgP) Support: Yes
- Trivial File Transfer Protocol (TFTP) Support: Yes
- Access Control List (ACL) Support: Yes
- Quality of Service (QoS): Yes
- Dynamic ARP Inspection (DAI): Enabled
- STP Root Guard: Supported
- Uni-Directional Link Detection (UDLD): Supported
- Fanless Design: Yes
- DHCP Relay: Supported
- Remote Switch Port Analyzer (RSPAN): Yes
Compliance and Standards
- Standards Compliance: IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1d, IEEE 802.1q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ae, IEEE 802.1ab (LLDP), IEEE 802.3at
Memory and Expansion
Memory Specifications
- RAM: 128 MB
- Flash Memory: 64 MB
Expansion and Connectivity
- Interfaces: 10 x 10Base-T/100Base-TX/1000Base-T - RJ-45 - PoE
- USB Ports: 1 x 4-Pin USB Type A
- Console Ports: 1 x Mini-USB Type B - Management
- RS-232 Port: 1 x RJ-45 - Management
- SFP Slots: 2 x Mini-GBIC
Power Requirements
- Power Supply: Internal Power Supply
- Voltage Required: AC 120/230 V (50/60 Hz)
Increased Connectivity
Having 8 ports allows users to connect multiple devices to the network simultaneously. This eliminates the need for additional switches or hubs, simplifying the network infrastructure and reducing costs. With each port capable of handling different types of connections, users have the flexibility to connect both wired and wireless devices.
Enhanced Productivity
The availability of 8 ports ensures that employees can easily connect their devices to the network without any hassle. This promotes seamless collaboration and increases productivity as team members can quickly access shared resources and communicate effectively. Whether it's transferring large files or conducting video conferences, the ample number of ports ensures a smooth workflow.
Scalability
The 8 ports on the Cisco WS-C3560CG-8TC-S Switch provide room for growth. As your business expands and more devices are added to the network, this switch can accommodate the increased demand for connectivity. This scalability feature saves you from investing in additional networking equipment in the future, making it a cost-effective solution.
In summary, the 8 ports offered by the Cisco WS-C3560CG-8TC-S Switch deliver increased connectivity, enhanced productivity, and scalability for small to medium-sized businesses.
Speed
The Cisco WS-C3560CG-8TC-S Switch boasts Gigabit Ethernet speed, ensuring high-performance networking for demanding business environments. With Gigabit Ethernet, users can experience fast data transfer speeds and seamless connectivity.
Lightning-Fast Data Transfer
Gigabit Ethernet offers data transfer rates of up to 1000 Mbps, which is ten times faster than traditional Fast Ethernet. This high-speed connectivity enables quick file transfers, smooth multimedia streaming, and efficient data backup and recovery processes. Whether you are transferring large files or running bandwidth-intensive applications, Gigabit Ethernet ensures that your network operates at peak performance.
Improved Response Time
The speed provided by Gigabit Ethernet significantly reduces latency and improves response time. This is particularly beneficial for businesses that rely on real-time communication, such as video conferencing or VoIP calls. With Gigabit Ethernet, there are no delays or interruptions, ensuring a seamless and uninterrupted user experience.
Future-Proof Connectivity
Gigabit Ethernet is a future-proof technology that can handle the increasing demands of modern networks. As more bandwidth-intensive applications and devices emerge, Gigabit Ethernet ensures that your network can handle the traffic without bottlenecks or performance degradation. Investing in a switch with Gigabit Ethernet guarantees that your network infrastructure is ready for future advancements.
In conclusion, the Gigabit Ethernet feature of the Cisco WS-C3560CG-8TC-S Switch delivers lightning-fast data transfer, improved response time, and future-proof connectivity for businesses looking to optimize their network performance.
